Alto-Shaam 1200-UP Series User manual

1200-UP SERIES
LOW TEMPERATURE HOT HOLDING CABINETS
ITEM NO. _______________________
FACTORY INSTALLED OPTIONS
●Reach-in compartment is standard.
■■➥ Specify pass-through doors as a
special order.
●Right-hand door swing is standard.
■■ ➥ Specify left-hand door as a special order.
Pass-th ro ugh cab ine ts canno t hav e a ll d o o rs
h inge d o n the sa e sid e .
■■Window Door [55068R].
NOT EN ERGY STAR RATED.
●Side Rack Model.
■■As an alte rnative to unive rsal pan slides, this unit
can b e o rd ered as a “sid e rack ” o d el w hich is
equip p ed w ith tw o (2) sid e racks and thre e (3)
stainless steel w ire shelve s. It w ill acco o d ate
full and half size US ho tel and Euro p ean
gastro no r p ans o r sh e e t p ans o n the sid e rack s.
ADDITIONAL FEATURES
●Optional HACCP Documentation web-based
software provides the ability to monitor, store,
and print all relevant data.
●Optional HACCP with Kitchen Management
web-based software provides the ability to
program, control, monitor, and store all
relevant data.
● HA O HEAT…a controlled, uniform heat source that gently surrounds food
for better appearance, taste, and longer holding life.
●Holds hot food hot...meat, poultry, fish, potatoes, casseroles, vegetables, rolls, etc.
●Dual purpose — both a holding cabinet and dough proofer.
●Universal rack design accommodates standard full-size (gastronorm) pans or
full-size sheet pans.
●Can be converted with side racks to accommodate shelves for full size gastronorm
pans or full size sheet pans.
●Non-magnetic stainless steel interior resists corrosion.
●Casters provide easy mobility.
●Antimicrobial handle retards the growth of illness-causing pathogens.
ELECTRONIC CONTROL OPTION
■■Solid state electronic control option simplifies temperature setting and
has a clear, easy-to-read ED display and includes our patented
SureTemp™ heat recovery system. SureTemp™ reacts immediately to
compensate for any loss of heat whenever the door is opened.
■■Electronic control is also available with six independent multiple timers
for each compartment to facilitate “first-in, first-out” concept.
1234 56
1234 56
ANSI/NSF 4
Double compartment holding cabinet with 22 gauge stainless steel doors with magnetic catch. Each compartment has
one (1) ON/OFF power switch; one (1) adjustable temperature knob with a temperature range of 60° to 200°F (16° to
93°C); one (1) indicator light; and one (1) digital display. Each compartment is equipped with two (2) sets of chrome
plated universal side rails and four (4) sets of pan slides designed to accommodate standard full-size pans. Pan
supports are adjustable in sixteen (16) positions on 1-3/4" (44mm) centers. Cabinet includes one (1) set of 5" (127mm)
heavy duty casters, two rigid and two swivel with brake.
■■MODEL 1200-UP/STD: Double compartment holding cabinet with a .040" stucco aluminum exterior casing.
■■MODEL 1200-UP/HD: Double compartment holding cabinet with heavy duty 20 gauge stainless steel
exterior casing.
#39 - 01/09
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FA : 262.251.7067 800.329.8744 U.S.A. ONLY
www.alto-shaam.com
DUE TO ONGOING PRODUCT IMPROVEMENT, SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.PRINTED IN U.S.A.

DIMENSIONS: H x W x D
EXTERIOR: 73-5/8" x 24-13/16" x 31-11/16"
(1870mm x 629mm x 803mm)
PASS-THRO GH:73-5/8" x 24-13/16" x 32-3/16"
(1870mm x 629mm x 817mm)
INTERIOR EACH COMPARTMENT:
28-7/8" x 22-1/4" x 26-1/2"
(733mm x 565mm x 673mm)
INSTALLATION REQUIREMENTS
Appliance must be installed level. It must
not be installed in any area where it may be
affected by steam, grease, dripping water,
high temperatures, or any other severely
adverse conditions.
WEIGHT (EST.)
1200-UP/STD 1200-UP/HD
NET 276 lb (125kg) 301 lb (137kg)
SHIP 315 lb (142kg) 350 lb (159kg)
CARTON DIMENSIONS: (HXWXD)
82" X35" X35" (2083mm x 889mm x 889mm)
OPTIONS & ACCESSORIES
■■Bumper, Full Perimeter 44088
■■Casters, 3" (76mm) - 2 RIGID, 2 SWIVE W/ BRAKE 14227
■■Door ock with Key K-22567
HACCP Network Options (E ECTRONIC CONTRO ON Y)
REFER TO SPECIFICATION #9015 FOR APPLICABLE PART N MBERS
■■HACCP Documentation
■■HACCP with Kitchen Management
■■Handle Kit, Push/Pull (SET OF FOUR) 55662
■■egs, 6" (152mm) (SET OF FOUR) 5205
■■Pan Grid, chrome plated, wire PN-2115
➥PAN INSERT 18" x 26" (457mm x 660mm x 25mm)
■■Probe, Internal Temperature (E ECTRONIC CONTRO )AVAI AB E
■■Shelf, Stainless Steel SH-23738
■■Shelf, Chrome Plated SH-2733
■■Universal Pan Slides, Chrome Plated SR-24447
■■Universal Pan Slides, Stainless Steel SR-24762
■■Water Reservoir Pan 1775
■■Water Reservoir Pan Cover 1774
71-13/16" (1824mm)
Electrical
Connection
Reach-In
Shown with
optional bumper
*72-15/16" (1834mm) - with optional 3" (76mm) casters
*74-9/16" (1894mm) - with optional 6" (152mm) legs
24-13/16"
(629mm)
67-13/16" (1722mm)
73-5/8" (1870mm)*
with 5"(127mm) casters
31-11/16"
(803mm)
33" (837mm)
53-3/8" (1355mm)
28-1/4"
(716mm)
C
L
I
o
I
o
I
o
I
o
LOWERCAVITY UPPERCAVITY
32-3/16"
(817mm)
73-3/4" (1873mm)
Electrical
Connection
Pass-Through
Option
1200-UP SERIES
LOW TEMPERATURE HOT HOLDING CABINETS
P R O D U C T \ PA N C A PA C I T Y (PER COMPARTMENT)
192 lbs (87kg) MAXIMUM
VO UME MAXIMUM: 120 QUARTS (152 ITERS)
—WITH PAN SLIDES PROVIDED:—WITH ADDT'L PAN SLIDES:
F LL-SIZE PANS:GASTRONORM 1/ 1:
Eight (8) 20" x 12" x 2-1/2" 530mm x 325mm x 65mm up to 16 Pans
Eight (8) 20" x 12" x 4" 530mm x 325mm x 100mm up to 10 Pans
Eight (8) 20" x 12" x 6" 530mm x 325mm x 150mm
F LL-SIZE SHEET PANS:
Four (4) 18" x 26" x 1" up to 16 Pans
UNIVERSA PAN S IDES - 1-3/4" (44mm) CENTERS w ith ad d itio nal sh e lve s
—WITH OPTIONAL SIDE RACKS FOR SHELVES
F LL-SIZE PANS:GASTRONORM 1/ 1:
Sixteen (16) 20" x 12" x 2-1/2" 530mm x 325mm x 65mm
Ten (10) 20" x 12" x 4" 530mm x 325mm x 100mm
Eight (8) 20" x 12" x 6" 530mm x 325mm x 150mm
E L E C T R I C A L - 1 2 0 0 - U P
VOLTAGE PHASE CYCLE / HZ AMPS K W CORD & PL G
at 120 1 60 16.0 1.92 NEMA 5-20P,
20A-125V P UG
208-240 (AGENCY)1 60 9.6 2.0 NEMA 6-15P,
at 208 1 60 7.2 1.5 15A-250V P UG
at 240 1 60 9.6 2.0 (USA ONLY)
208-240 (AGENCY)1 60 16.7 4.0 NO CORD
at 208 1 60 14.4 3.0 NO P UG
at 240 1 60 16.7 4.0
at 230 1 50 8.0 1.85 CEE 7/7,
at 230 1 50 16.0 3.7 220-230V P UG
230 208 - 240 120
2000W
4000W
2000W
4000W
CLEARANCE REQUIREMENTS
BACK 3" (76mm)
TOP 2" (51mm)
EACH SIDE 1" (25mm)
