Amana AP076E User manual

PORTABLE AIR CONDITIONER
CLIMATISEUR PORTATIF
ACONDICIONADOR DE AIRE PORTATIL
Model#
Modèle#
Modelo# AP076E
ROOM AIR CONDITIONING AND DEHUMIDIFIER PRODUCTS

A Word From Amana
Product Registration
TABLE
RECEPTACLE AND FUSE TYPES
RATED VOLTS
AMPS
WALL OUTLET
FUSE SIZE
TIME DELAY FUSE
(or circuit braker)
125/60 250/60
15 20 15 20 30
15 20* 15 20* 30
Plug Plug
Plug
Thank You for buying a dependable, energy saving and easy to operate AMANA air
conditioner. This manual contains useful information for you to maintain, operate, install and
safely use your air conditioner. Your air conditioner cleans, cools and dehumidifies the air in
your room to provide you with the ultimate level of comfort.
Please read instructions carefully before using the product. Also, do not forget to fill out and
mail the Product Registration Card.
Record Your Model and Serial Number.
Attach the sales receipt to this guide and keep for future reference. Model and serial number
can be obtained from the serial label, which is on your air conditioner. For all your service calls
during the warranty period the following information will be needed:
Model Number:....................................................................................................................
Serial Number: ....................................................................................................................
Date of Purchase: ................................................................................................................
Dealer’s Name:....................................................................................................................
Dealer’s Address: ................................................................................................................
Dealer’s Phone Number: ......................................................................................................
(1)
English

SAFETY PRECAUTIONS
WARNING: Following these basic precautions will reduce the risk of fire, electrical
shock, injury or death when using your air conditioner.
1) Air conditioner must be connected to proper electrical outlet with the correct electrical
supply. (see table previous page)
2) Proper grounding must be ensured to reduce the risk of shock and fire. DO NOT CUT OR
REMOVE THE GROUNDING PRONG. If you do not have a three-prong electric receptacle out-
let in the wall, have a certified electrician install the proper receptacle. The wall receptacle
MUST be properly grounded.
3) Do not operate air conditioner if power cord is frayed or otherwise damaged. Also avoid using
it if there are cracks or abrasion damage along the length, plug connector or if the unit mal-
functions or is damaged in any manner. Contact an authorized service for examination, repairs
or adjustments.
4) DO NOT USE AN ADAPTER OR AN EXTENSION CORD.
5) Do not block airflow around the air conditioner. Also the exhaust hose should be free of any
obstructions.
6) Always unplug the air conditioner before servicing it or moving it.
7) Do not install or use the air conditioner in any area where the atmosphere contains
combustible gases or where the atmosphere is oily or sulphurous. Avoid any chemicals coming
in contact with your air conditioner.
8) Do not place any object on the top of the unit.
9) Never operate the air conditioner without the filters in place.
10) Do not use the air conditioners near a bathtub, shower or wash basin.
SAVE THESE INSTRUCTIONS
(2)
English

Table Of Contents
Page
(3)
English
Advantages of this Model
1. This model is easy to operate. The electronic control panel has a timer, thermostat, three
cooling speeds, three fan speeds and one speed dehumidification function (dry).
2. The unit has a unique design which evaporates the water. Therefore no condensation tank is
necessary, thus avoiding you to have to wake up in the middle of the night to empty the
bucket and turn on the unit.
3. Easy to install window kit is included, which consists of the exhaust hose, 2 hose adapters,
the window panel kit and window panel adapter.
4. Full directional casters are included to help the unit to be moved in almost any area.
5. The filter screen is designed for easy accessibility of the filter.
6. Portable air conditioners are easy to store when not in use.
A Word From Amana ..............................................................................................................1
Product Registration ..............................................................................................................1
Safety Precautions ..................................................................................................................2
Advantages..............................................................................................................................3
Parts and Features..................................................................................................................4
Assembly and Installation......................................................................................................5
Operation ............................................................................................................................6-7
Product Specification ..............................................................................................................8
Care and Cleaning..................................................................................................................8
Storage ....................................................................................................................................8
Trouble Shooting ....................................................................................................................9
Warranty Information ..........................................................................................................10

Parts and Features
(4)
English
1. Control Panel
2. Air Deflector (Left-Right)
3. Front Panel
4. Handle Hole
5. Castor
6. Screen Filter
7. Air Intake (Evaporator)
8. Air Outlet (Heat Exchange)
9. Air Intake (Condenser)
10. Power Supply Cord
11. Water Drain
Front
Rear

(5)
English
Assembly and Installation
1. Push the round Window Panel Adapter through the rear of the Plastic Panel.
Line up the holes and tighten the Adapter with 4 screws that are included in
the kit. (Tighten screws from the front).
2. Adjust the Plastic Panel to the width or height of your window and tighten
the 2 screws that are attached to the panel.
3. Install the Window Plastic Panel into the window. If necessary use duct tape
to better secure the panel.
4. Connect exhaust hose to the unit by inserting the narrower side of the Unit
Adapter that is attached to the hose into the exhaust. Turn Adapter clock-
wise until it locks. (See Illustration A)
5. Move the unit to the window, extend the hose and attach the other end of
the hose to the window. Align the tabs on the hose and window panel
adapters and fasten them together.
6. Plug into wall outlet to get ready for operation.
• NOTE: Use on Single Outlet Circuit Only.
USING WINDOW PANEL KIT
1. Plastic panel - 2 pieces
2. Window Panel adapter - 1 piece
3. Screws - 4 pieces
123
Exhaust Hose
Window Adapter Unit Adapter
A
B

(6)
English
Power Control
The power control turns the unit on and off.
Warning Light
Condensed water may accumulate in the unit. If
the internal tank becomes full, the Warring Light
will shine and the unit will not operate until the
unit has been drained.
Mode Control
The Mode Control has three settings:
Cool Dehumidify Fan
The settings are adjusted with Mode Control but-
ton. A light will indicate which setting is currently
being used.
Cool Mode
When cool mode is selected, the indicator light
will shine green. During the cooling mode the air
is cooled and hod air is exhausted to the outside
air through the exhaust tube. Adjust fan speed air
through the temperature to suit your desired com-
fort level.
Note: The air exchange hoses must vent outside
the room when using cool Mode.
Dehumidify Mode
When Dehumidify mode is selected, the indicator
light will shine orange. Air is dehumidified as it
passes through the unit, without being in full
cooling mode . The fan will operate in Medium
speed. Fan speed is not adjustable in Dehumidify
mode.
Fan Mode
When Fan mode is selected the indicator light will
shine yellow. Air is circulated throughout the
room with no cooling.
Note: unit does not need to de vented in Fan
mode.
Fan Speed Control
The Fan Speed Control has 3 settings:
High Medium Low
Timer Control
Auto turn off : With machine in fan mode,
press timer button to select number of hours you
would like the unit to run in air conditioning
mode until it automatically shuts off.
Auto turn on : With machine powered off ,
press timer button to select number of hours until
you would like the unit to automatically start
running in air conditioning mode
Timer / Timer set Controls
Used for adjusting the timer and thermostat. The
default display is room temperature. In cooling
mode, When " " or " " button is pressed, the set
temperature is displayed and may be adjusted.
After 15 seconds the display will revert back to
room temperature. Temperature is only
adjustable in Cool and Heat mode. The time is
adjustable between 1 and 12 hours.
Note: By pressing both Temp/Timer Set buttons
at the same time, the display will toggle
between Celsius and Fahrenheit.
Operation Control Panel

Operation
NOTE: Wait for 24 hours to turn on air conditioner if the unit has been tilted for any
reason. This is for the oils and the coolants to settle and level off.
1. After a normal shut down wait for 3 minutes before restarting the unit so as to complete the
compressor cycle.
2. Use an 115v /15 amp outlet for the air conditioner. Do not use any other electrical appliances
on this line or you may trip the fuse. Use a dedicated line for this air conditioner.
3. Do not place the air conditioner in direct sunlight or close to any heating appliances
(eg. baseboard heaters, stoves, etc).
4. Operate on a flat surface only.
5. Keep the unit free of any obstructions such as drapes, curtains, blinds, etc.
6. Keep unit at least 1 foot away from the wall.
7. Check and clean the filter once every week for highest efficiency.
NOTE: Do not use unit without filter.
8. If the unit is not being used for a long period of time, remove the plug from the water drain
pipe and drain out any condensed water.
When turning on the unit for the first time after plugging it into an electrical outlet, the unit will
start in a low fan cool mode. The temperature reading out on the LED will be the current room
temperature. When turning on the unit during regular usage, it will remember the last shut off set-
ting. If you want to operate the air conditioner as a dehumidifier, then adjust to dry mode.
Setting The Temperature
To set the temperature, press the + or the - key to raise or lower the temperature. The tempera-
ture can be raised or lowered in the cool or dry mode. The temperature cannot be adjusted in the
fan mode.
Fan Speeds
There are 3 adjustable speeds in the cool and fan mode: Low, Medium & High. In the dry or
dehumidification mode the fan will only operate at low speed.
On/Off Time Set
The air conditioner has a 1-12 hour on/off built-in timer. To delay the start time for 1-12 hours at
1 hour intervals, simply press the time/set key and then press the + or - key to adjust the start
time. Note that the unit has to be plugged in to an electrical outlet for the timer to operate.
To automatically shut-off the unit, press the time/set key while the unit is running and then press
the + or - key to adjust the shut-off time. The auto shut-off switch operates in all 3 modes: Cool,
Dry & Fan.
NOTE: The temperature can be set between 60˚F to 89˚F.
(7)
English

• Always unplug your air conditioner before cleaning.
• Air filter needs to be cleaned at least once a week for your unit to operate at opti-
mum efficiency. Slide out the filter from the back by pulling on the tab. The filter may
be washed or vacuumed. Remove the excess water from the filter by gently shaking
the filter. This will remove dust and particles trapped in the filter. After cleaning, rein-
stall the filter. DO NOT use your air conditioner without the air filter in place.
• To clean the cabinet, DO NOT use harsh chemicals, abrasives, ammonia, chlorine,
bleach, concentrated detergents, solvents or metal scouring pads. Some of these
chemicals may dissolve, damage and/or discolor your air conditioner.
• Always use a soft cloth dampened with water or a mild soap and water solution to
wipe the front of the cabinet. Wipe dry with a soft cloth.
• To store your air conditioner when not being used for a long period of time, drain
condensed water using the drain pipe. Remove exhaust hose, clean the filters, cover
with plastic bag and store away.
Care and Cleaning Guide
Storage
(8)
English
Product Specification
Voltage and Frequency 115V / 60Hz
Input Power 850 W
Cooling Capacity 7000 BTU
Moisture Removal (pints/day) 60
Coolant R22
Timer 12 Hours
Operating Temperature Range 64˚F - 100˚F
Unit Dimensions (WxDxH) (inches) 17 3/32 x 15 3/4 x 30 5/16
Net Weight lbs. approximate 66 lbs.
Exhaust Hose 5 Feet

(9)
English
If air conditioner does not operate:
• Check if unit is plugged in. The plug may have come loose.
• Check if the electrical wall receptacle is of proper voltage.
• Check if the circuit breaker needs to be reset or if the fuse needs to be replaced.
• Check if the unit is in “Off” mode.
• If the warning light is on, drain the water drain pipe by removing the plug.
Air conditioner working but room not cooling:
• Room may have appliances that produce heat. Use an exhaust fan to remove excess heat.
• Check exhaust hose for proper installation.
• Redirect the airflow. Remove any obstacles.
• All doors and windows need to be closed so that cool air does not escape the room.
• Air filter may be blocked or may need cleaning.
• Unit BTU may be too low for the required cooling area.
• On extremely hot & humid days, air conditioners may take a little longer to cool.
• Drain the water drain pipe by removing the plug.
• Unit may be in fan or dry mode. Put air conditioner in cool mode.
Trouble-Shooting
