Amantii BI-DEEP-XT Installation and maintenance instructions

Fix your Fireplace
BI-DEEP-XT

Content
•How to replace LED light
•How to replace flicker motor
•How to replace heating element
•How to replace the PCB board
•How to replace the signal receiver
•How to replace the top light

Replace LED light
Remove the trim
Step 1 Replace ember bed LED light

Step 2
Unscrew the screw in the middle and then to
get out the front panel.
Unscrew the
screw

Use the metal piece you just removed
from the fireplace to hock and pull out
the front glass panel.
Front glass
Step 3

Step 4
Unscrew one screw on both sides.
Zoomed view

Step 5
Use the metal piece just took off from STEP4 to hook and pull out the
side inner black glass panels.

Unscrew 2 screws on each side to take off the side
inner bars. After the side inner metal panels are
removed, the ember bed glass panel can be
removed as well.
Step 6

Step 7
After the ember bed glass panel is removed, now you can replace
the LED light for ember bed effect.(Replace flame light see STEP7)

Unscrew 3 screws and unplug
to take off the top mood light.
Step 8

Unscrew 5 screws to remove the top fending bar
for the flame effect glass panel
Step 9

Unscrew 4 screws to take off the flame effect
glass panel.
Step 10

Now you can replace flame
Effect LED light bars.
Step 11

Replace the flicker motor
Please follow Step 1 to 10 in replacing LED light.
Replace flicker motor for ember bed effect
Unscrew the screw to disconnect
the flicker rod from the motor
Step 1

Unscrew 2 screws and unplug to take off the motor.
Step 2

The flicker motor for flame effect is behind the visual glass panel.
Unscrew the screw and then disconnect
the flicker rod from the motor
Step 3
Replace flicker motor for flame effect

Unscrew 2 screws, unplug and now you can
replace flicker motor for flame effect.
Step 4

Replace the heating element
Please follow Step 1 to 10 in replacing LED light, you come to here
The heating element locates here

Step 1
Unscrew the screws to take off the holding metal bar for flame effect glass panel.

Step 2
Unscrew 10 screws to remove the heating set from the unit.
