Analytik Jena contrAA 600 User manual

contrAA 600
HR-CS Atomic Absorption Spectrometer
Operating manual

Service:
Analytik Jena AG
Kundendienst (Customer Service)
Konrad
-Zuse-Str. 1
07745 Jena
Germany
Phone:
Hotline: + 49 (0) 3641 / 77-7407
Fax: + 49 (0) 3641 / 77-7449
Email:
[e-mail]
General information about Analytik Jena AG
on the internet: http://www.analytik-jena.de
Copyrights and Trademarks
contrAA is a trademark of Analytik Jena AG registered in Germany.
Microsoft, Windows 7/8, MS Excel are registered trademarks of Microsoft Corp.
The identification with ® or TM is omitted in this manual.
Documentation number: 10-1610-002-23
Edition – January 2014
Implementation of the Technical Documentation:
Analytik Jena AG
This publication describes the state of this product at the time of publishing. It need not necessarily
agree with future versions of the product.
Modifications reserved!
© Copyright 2014 Analytik Jena AG

Table of contents
contrAA 600 Edition 01/2014 1
Table of contents
1Basic information ......................................4
1.1 Intended use..................................................4
1.2 User manual notes ........................................4
2Safety instructions ....................................6
2.1 General safety instructions............................6
2.2 Warning signs on the contrAA 600..............11
3Specification.............................................13
3.1 Technical data.............................................13
3.1.1 Data on contrAA 600...................................13
3.1.2 Control computer data.................................15
3.1.3 Graphite tube technique data......................15
3.1.4 Data for HydrEA technique accessories......16
3.2 Guidelines and standards............................17
4Installation conditions.............................18
4.1 Environmental conditions ............................18
4.2 Space requirement and weight....................19
4.3 Energy supply..............................................19
4.4 Gas supply ..................................................20
4.5 Exhaust unit.................................................21
4.6 Device layout and space requirement .........22
5Functions and setup of the contrAA 60024
5.1 Physical measuring principle HR-CS AAS...24
5.2 Xenon lamp.................................................26
5.3 Electrothermal atomizer...............................27
5.3.1 Graphite tube furnace..................................28
5.3.2 Gas flows in the graphite tube furnace........29
5.3.3 Graphite tube variations, furnace parts and
inserts..........................................................30
5.3.4 Radiation sensor..........................................31
5.3.5 Furnace camera ..........................................31
5.4 Accessories for the graphite tube technique32
5.4.1 Autosampler AS-GF ....................................32
5.4.2Solid sampler SSA 600 and SSA 6z............33
5.5 Supplementary accessories ........................34
5.5.1 Mercury/hydride systems for HydrEA
technique.....................................................34
5.5.2 Autosampler AS-F and AS-FD for HydrEA
technique.....................................................34
6Installation and start-up..........................36
6.1 Supply and control connections.................. 36
6.2 Setting up the contrAA 600......................... 37
6.3 Installation and start of the ASpect CS
program....................................................... 38
6.4 Graphite tube technique.............................. 39
6.4.1 Connections in the sample chamber for the
graphite tube technique............................... 39
6.4.2 Software presets for the graphite tube
technique .................................................... 40
6.4.3 Inserting the graphite tube into the graphite
tube furnace................................................ 41
6.4.4 Formatting the graphite tube....................... 43
6.4.5 Cleaning the graphite tube / cleanout.......... 43
6.5 Complete and install the AS-GF autosampler44
6.5.1 Installing the AS-GF.................................... 44
6.5.2 Adjusting the AS-GF ................................... 46
6.5.3 Populating the sample tray of the AS-GF.... 48
6.5.4 Uninstalling the autosampler AS-GF........... 48
6.6 Notes on installing the automatic solid
autosampler SSA 600................................. 49
6.7 Installations for HydrEA operation............... 50
6.8 Starting up the contrAA 600 with accessories52
7Care and maintenance.............................54
7.1 Maintenance overview ................................ 54
7.2 Base device ................................................ 55
7.2.1 Replacing the fuses..................................... 55
7.2.2 Reactivating the safety circuits of the cooling
water circuit................................................. 56
7.2.3 Cleaning the sample chamber .................... 57
7.3 Removing and installing the xenon lamp..... 57
7.4 Check the cooling water level ..................... 59
7.5 Maintaining the graphite tube furnace......... 60
7.5.1 Cleaning the furnace windows.................... 60
7.5.2 Cleaning the graphite surfaces ................... 61
7.5.3 Cleaning and changing the graphite tube.... 62
7.5.4 Replacing the electrodes and the furnace
jacket........................................................... 62
7.6 Autosampler AS-GF.................................... 67
7.6.1 Washing the dosing tube............................. 67
7.6.2 Servicing the dosing tube............................ 68
7.6.3 Replacing the metering syringe................... 71

Table of contents
2 Edition 01/2014 contrAA 600
7.7 Automatic samplers AS-F, AS-FD...............72
7.7.1 Washing the mixing cup of the AS-FD ........72
7.7.2 Replacing the canulas and guide on the
autosampler arm......................................... 72
7.7.3 Replacing the intake tube............................ 73
7.7.4 Replacing the tube set for diluent and
washing liquid..............................................73
7.7.5 Clean-up after cup overflow.........................73
8Transporting the contrAA 600 ................74
9Waste disposal.........................................75
10 Abbreviations / terms ..............................76
11 Index..........................................................78
12 EC Declaration of Conformity.................80
Index of figures
Fig. 1 Warning signs on the contrAA 600...........12
Fig. 2 Dimensions of the contrAA 600 - front view22
Fig. 3 Dimensions of the contrAA 600 - top view 23
Fig. 4 Installation layout of the contrAA 600.......23
Fig. 5 Schematic comparison of the physical
measuring principle of LS AAS and HR-CS
AAS.......................................................... 24
Fig. 6 Beam path in the contrAA 600 .................25
Fig. 7 Xenon lamp without housing.................... 26
Fig. 8 Electrothermal atomizer – graphite tube
furnace.....................................................27
Fig. 9 Graphite tube furnace...............................28
Fig. 10 Inner and outer gas flows in the graphite
tube furnace............................................. 29
Fig. 11 Graphite tube furnace...............................30
Fig. 12 Graphite tube variations........................... 30
Fig. 13 Furnace jacket, adapters and inserts .......31
Fig. 14 Autosampler AS-GF................................. 32
Fig. 15 Solid sampler............................................33
Fig. 16Autosampler AS-FD with separate Fluidik
module .....................................................35
Fig. 17 Mains switch and bar for supply and control
connections on the right side of the
contrAA 600 ............................................. 36
Fig. 18 Bar for supply and control connections ....37
Fig. 19 Rear view of the contrAA 600 with
connections for the supply of gas and
electricity as well as the fuse holders.......37
Fig. 20 Graphite tube atomizer in sample chamber39
Fig. 21 Connections at the graphite tube furnace.39
Fig. 22 Elements in the sample chamber for the
graphite tube technique............................40
Fig. 23"Main Settings" window for graphite tube
technique..................................................40
Fig. 24 "Furnace / control" window ......................41
Fig. 25 Graphite tube furnace opened with inserted
graphite tube.............................................42
Fig. 26 Installing the AS-GF..................................45
Fig. 27 Aligning the AS-GF with the furnace using
the set screw and adjusting screw 1.........46
Fig. 28 AS-GF adjustment....................................47
Fig. 29 Attaching holding pin and crossbar to the
AS-GF support in the sample chamber.....49
Fig. 30 Position of the eccentric roll at the SSA 60049
Fig. 31 HydrEA system HS 60 modular................50
Fig. 32 Rear of the autosampler AS-FD................51
Fig. 33 Dosing unit at the Fluidik module of the AS-
FD.............................................................52
Fig. 34 Safety circuit switch for hardware .............57
Fig. 35 Xenon lamp housing.................................59
Fig. 36 Xenon lamp, installed................................59
Fig. 37 Cooling water container under the graphite
tube furnace..............................................59
Fig. 38 Identical markings at the furnace windows
facing upward ...........................................61
Fig. 39 Furnace tools............................................62
Fig. 40 Window "Autosampler / Function tests" in
the ASpect CS software............................68
Fig. 41 Dosing tube at the AS-GF.........................69
Fig. 42 Dosing unit at AS-GF and AS-FD.............71

Table of contents
multi N/C 2100 Edition 01/2014 3
List of tables
Table 1 Measurements and weights of the
components of the contrAA 600 ...............19
Table 2 Gases in the graphite tube technique.......21
Table 3 Exhaust unit requirements........................21
Table 4 Use and sample volume of different graphite
tube variations..........................................30
Table 5 Furnace parts and inserts......................... 31
Table 6 Maintenance overview.............................. 55
Table 7 Fuses ....................................................... 56

Basic information
4 Edition 01/2014 contrAA 600
1 Basic information
1.1 Intended use
The atomic absorption spectrophotometer contrAA 600 is a PC-controlled instrument for the
sequential trace detection of metals and non-metals in liquid and dissolved samples. The
contrAA 600 is a High-Resolution Continuum Source atomic absorption spectrometer for
graphite tube technique and HydrEA technique. It is used for the sequential trace detection
of metals and non-metals in liquid and dissolved samples.
Combined with an autosampler the contrAA 600 can be used as a multi element automat in
routine analysis. First, the elements of interest are calibrated. For this purpose, the calibra-
tion standards and then also the samples are processed sequentially. This means that the
results of all elements to be determined are available after every sample measurement.
All device settings, such as spectrometer settings and furnace programs for electrothermal
atomization, are performed automatically in accordance with the method parameters and
may vary from element line to element line. The ASpect CS control software based on the
Windows operating system assumes the complete instrument control of the base instrument
and the accessories as well as data recording and evaluation. The determination of the
analytic background also occurs automatically and simultaneously on the analysis line. The
control software contains default settings for the methodical set-up of an analysis line. The
prefabricated line parameter settings for all measurable elements of the periodic chart (also
called cookbook) provide an introduction to the field of analytics and can provide a basis to
create one's own multi-element methods. The control software includes comprehensive
presentation and storage options for measured signals and parameters, GLP-suitable log-
ging as well as different options for keeping quality control charts.
1.2 User manual notes
The following symbols for warnings and system messages are used in this manual:
WARNING
Indicates a potentially hazardous situation.
If it is not prevented death or most serious injuries (incapacitation) can result.
CAUTION
Indicates a potentially hazardous situation.
If
it is not prevented light or minor injuries and material damage can result.
WARNING! HOT SURFACE
!
Touching the hot surface can cause burns.
DANGER OF ELECTRIC S
HOCK IF TOUCHED!

Basic information
contrAA 600 Edition 01/2014 5
WARNING! OPTICAL RAD
IATION!
NOTE
This symbol must be observed to
obtain correct measurement results.
The manual uses the following system:
The numbering of the chapters and figures is consecutive.
Each figure has its own caption.
Instructions for actions which occur in chronological order are numbered and com-
bined in action units.
Menu and option sequences in the software are divided by "/" and are printed in
bold, e.g. File / Open. Buttons are marked with square brackets, e.g. [OK].

Safety instructions
6 Edition 01/2014 contrAA 600
2 Safety instructions
For your own safety and to ensure error-free and safe operation of the contrAA 600, please
read this section carefully before using the appliance.
Comply with all safety instructions in the manual and pay careful attention to all messages
and notes which are displayed on the screen by the control software.
Also observe the safety instructions for system components by other manufacturers supplied
with this device (e.g. PC, printer, autosampler). It is particularly important to comply with the
safety instructions on the labels as well as the information on handling, storage and disposal
of the reagents.
2.1 General safety instructions
PROPER USE!
The contrAA 600 may only be used for atomic absorption spectrometry in the techniques
described in this manual.
LOCAL REGULATIONS!
Observe the local safety regulations that apply to the use of this device (e.g., work protection
regulations, accident prevention regulations, safety regulations).
References to potential dangers in the manual do not replace the work protection regulations
which must be observed.
PERSONNEL!
The contrAA 600 may only be operated by qualified personnel, who have received additional
training for this type of work. Familiarization with the contents of this manual and the acco
m-
panying manuals of accessories a
nd system components must be included in this training.
Any work on electrical equipment may only be carried out by qualified electricians.
WARNING! PROTECTION AGAINST EXPLOSION AND FIRE
The contrAA 600 may not be operated in an explosive environment.
No smoking is allowed in the operating room of the contrAA 600.
INSTALLATION AND INI
TIAL USE
The device may only be assembled, installed and repaired by the service engineers from
Analytik Jena AG or by technical personnel authorized by Analytik Jena A
G. Any unauthor-
ized interference may place the operator in danger or endanger the functional safety of the
instrument and limits warranty entitlements.

Safety instructions
contrAA 600 Edition 01/2014 7
INSTRUMENT SHUTDOWN
IN CASE OF DANGER!
In an emergenc
y, switch off the contrAA 600 using the power switch right side wall. Discon-
nect the mains plug from the mains socket.
Switch off the installed components using the mains switch of the connected socket strip.
Ensure that the socket strip is positioned in s
uch a way that it allows quick access.
Caution!
For the PC there is a risk of data loss and damage to the operating system!
ELECTRIC SHOCK!
The contrAA
600 is supplied with electrical voltage. Life-threatening electrical voltages occur
at various locations within the system!
The mains plug may only be connected to a proper CEE power socket to ensure that the
device meets protection class I (ground connector). The protective effect must not be inval
i-
dated by the use of
an extension line which does not have a protective conductor (→
Section
"
Energy supply" p.19).
The contrAA
600 must be switched off before carrying out any electrical work, the mains plug
must be pulled out. Safe disconnection from the mains can only be achieved by pulling out
the ma
ins plug. Power is still supplied to certain areas of the spectrometer, as well as the
output socket, after the device has been switched off at the main switch.
The removal of the rear panel of the device may only be carried out by the customer service
of
Analytik Jena AG and specially authorized technicians.
Only Analytik Jena service engineers or specially trained electrical staff may open any co
m-
ponents of the instrument, especially the xenon lamp housing.
CAUTION! SHORT CIRCU
IT CAUSED BY WEARING JEWELRY
There is a risk of a short circuit occurring between the two parts of the furnace, or between a
furnace part and the console. Short
-circuited jewelry heats up quickly and can cause burns.
No metallic jewelry (especially around the neck) may be worn during working on and with the
contrAA 600. Otherwise there is a risk of causing a short circuit of the electrically heated
graphite tube.
CAUTION! OPERATING S
UBSTANCES, DANGEROUS SUBSTANCES
The operator is responsible for the selection of substances used in the process as well as for
their safe handling. This is particularly important for radioactive, infectious, poisonous, corr
o-
sive, combustible, explosive and otherwise dangerous substances.
When handling dangerous substances local safety instruction
s and guidelines must be
observed.
Observe the notes on the labels!
Only use clearly marked containers and wear protective goggles and rubber gloves!
The contrAA
600 may only be operated under an active laboratory exhaust hood (ozone,
combustion gases give
n off by the sample, poisonous and combustible by-products from
sample preparation processes).
Biological samples have to be handled according to local guidelines regarding the handling
of infectious material.
Warning! Sodium borohydride
(NaBH4) is strongly corrosive, hygroscopic and, in solution,
extremely aggressive. Avoid dripping and spilling of reduction agent.

Safety instructions
8 Edition 01/2014 contrAA 600
The operator is responsible for ensuring that waste materials, e.g., sample residues, are
disposed of in an environmentally responsible manner
and according to local regulations.
List of dangerous organic solvents
Methyl isobutyl ketone (MIBK)
Highly volatile, malodorous
Toluene
Danger to health
Kerosene
Flammable, low vapor pressure
Methanol, ethanol, propanol
Flammable, partly dangerous to health
Tetrahydrofuran (THF)
Highly volatile, easily ignited, dissolves polyethylene and
polystyrene
This list is in so far incomplete that other solvents could also come into consideration for use
in the contrAA 600 in the HydrEA technique. In cases of uncer
tainty about an un-named
fluid, this may only be used when the manufacturer has confirmed that there is no danger to
safety.
CLEANING AND DECONTA
MINATION MEASURES
The operator is responsible for carrying out suitable decontamination should the device be
c
ontaminated externally or internally with dangerous substances.
Spots, drops or larger spillages should be removed and cleaned using an absorbent material
such as cotton wool, laboratory wiping cloths or cellulose. The affected areas are then to be
wiped w
ith an Incidin Plus solution.
For cleaning the interior of the contrAA
600, the operator is responsible for establishing
appropriate safety precautions
– particularly in terms of contaminated and infectious materi-
als.
Before another cleaning or decontamina
tion procedure is used as that prescribed by the
manufacturer, the user shall check with the manufacturer that the intended procedure will not
damage the device.
Safety signs attached to the contrAA
600 must not be wetted with methanol!
DANGER OF
EXPLOSION! XENON LAMP AND LAMP HOUSING
Inside the quartz flask of the xenon lamp, there is an overpressure of 2 Pa which may rise to
up to 7 MPa during operation!
The lamp housing may only be opened by the customer service of Analytik Jena AG and
speciall
y authorized technicians.
CAUTION! UV RADIATIO
N AND RISK OF DAZZLING
Protect your eyes!
Never look directly at radiation from the xenon lamp or at the heated graphite tube without
UV protection glasses.
The xenon lamp in particular emits an intense l
ight in the visible range and the UV range!
Never use a hand mirror to observe the drying process of liquid samples in the graphite tube
furnace in the beam path!

Safety instructions
contrAA 600 Edition 01/2014 9
CAUTION! OZONE FORMA
TION
The UV radiation of the xenon lamp and the graphite tube furnace at temperatures over 2000
°C lead to an interaction with the surrounding air to form toxic concentrations of ozone e
x-
ceeding the permissible limit.
The contrAA
600 may only be operated with an active exhaust unit.
CAUTION! OPERATING P
RESSURIZED GAS CYLINDERS AND GAS
PLANTS
Inert gas and additional gas are taken from pressurized gas cylinders or local gas plants.
For gas cylinder or gas plant operation, the safety instructions and guidelines which are valid
at the operating location must be strictly c
omplied with.
High pressure tubing and pressure reducers may only be used for the assigned gases.
The operator must carry out weekly safety checks for leaks on all gas supplies and connec
t-
ors and at the device itself. Possible pressure drops in closed, pre
ssurized systems and
piping must be determined. Leaks must be localized and repaired immediately.
After changing the gas cylinder, thoroughly ventilate the cylinder location.
CAUTION! HIGH TEMPER
ATURES
During graphite tube furnace operation high temper
atures occur.
Observe the required cooling times!
Do not touch the hot components during, or directly after, a measurement.
Undertake maintenance work and change components only after an adequate cooling per
i-
od: Graphite tube furnace, cell, lamps.
Keep all
combustible material away from the device.
VENTILATION
Ensure that the ventilation fittings for contrAA
600 and its auxiliary devices are in proper
working order. Covered vents or ventilation slits may cause the device to break down or may
cause damag
e to it.
MAINTENANCE
Service, maintenance and repair work on the contrAA
600 may only be carried out by service
engineers from Analytik Jena AG or by technicians authorized by the manufacturer. Exce
p-
tions to this are described in Section "
Care and maintenance" p. 54. If these requirements
are not complied with, there is a serious risk of misalignment or da
mage to the device.
PREVENTIVE MEASURES
OF THE GRAPHITE TUBE TECHNIQUE!
Use only the inert gas specified in the manual for the graphite tube technique.
Do not look into the graphite tube opening without wearing protective goggles. Sputtering
sample
substances and hot graphite particles may cause eye and face injuries.

Safety instructions
10 Edition 01/2014 contrAA 600
REPLACING GRAPHITE T
UBES, REPLACEMENT PARTS
Only use replacement parts from Analytik Jena AG.
The graphite tubes of the contrAA
600 are manufactured specifically and may only be or-
d
ered from Analytik Jena AG. Do not use any other graphite tubes. The contrAA
600 may be
damaged.
SENSITIVE ELECTRONIC
S
Always electrically connect and disconnect components to/from the contrAA
600 when they
are switched off. This also applies when elec
trically connecting components with one anoth-
er.

Safety instructions
contrAA 600 Edition 01/2014 11
2.2 Warning signs on the contrAA 600
Observe the warning signs on the device! The following warning signs are displayed on the
contrAA 600:

Safety instructions
12 Edition 01/2014 contrAA 600
1 Warning sign on the xenon lamp (UV light source/ Protection for eyes and skin is required.)
2 Warning sign in the sample chamber of the graphite tube furnace (Caution! Hot surface! / Caution! Emission
of UV radiation! / Danger of short circuit! Handling with jewelry not allowed!)
2 Warning sign next to mains switch (Read operating manual before switching on the device!)
3 Warning sign on the back of the contrAA 600 (Disconnect AC line before removing cover!)
4 Warning sign on the mains fuse cover (Warning! Disconnect AC line before removing cover. Changing mains
fuses only by authorized personnel.)
Fig. 1 Warning signs on the contrAA 600

Specification
contrAA 600 Edition 01/2014 13
3 Specification
3.1 Technical data
3.1.1 Data on contrAA 600
Optical system
Reflexion optics with protective coating and optical system with light-proof enclosure
Monochromator Echelle, grating, double monochromator with a focal length of F=380 mm and variable
intermediate gap; upstream monochromator with quartz prism. Wavelength selection via
reflected additional neon radiator
Wavelength range 185-900 nm
Spectral bandwidth 2 pm at 200 nm
Grating Echelle grating
Optical bench
photometer encapsulation Optics in modular design on compact cast base plate for stability and robustness Protection from moisture, exhaust and chemical environmental influences
Detector Two-dimensional FFT backside illuminated CCD with high quantum efficiency and
increased UV sensitivity
Lamp
Xenon short arc lamp with UV focal spot in hot spot mode; automatic hot spot tracking; simultaneous drift correction
Lamp current 9-16 A / 8 A stand-by operation
Mode DC, monitoring of burning duration and ignition impulses
Power supply Power supply unit integrated into the spectrometer
Display modes
Absorbance 0 to 3.99
Concentration Value range: 5 characters (0.001 to 99999), unit freely selectable
Energy 0 - 35000 effective counts
Signal evaluation
Time-resolved Average value, maximum value of absorption, spectral volume integral value of absorp-
tion
Spectrally resolved Spectra with a width of 20 to max. 200 pixels
Power supply
Supply voltage
Frequency 200 / 220 / 240 V ± 10 % factory adjustable 50/60 Hz
Mains fuse installation in the
building Safety fuse ≥ 35 A, slow blow
No automatic fuse devices!
Typical average power consump-
tion Base device: 2100 VA Base instrument with PC, monitor and autosampler AS 52 s: 2800 VA
Maximum current consumption 52 A for a period of 8 s or 85 A for 1 s
Output socket 200/220/240 V ±10 %, 50/60 Hz
For connection of accessories: PC, compressor, hydride system

Specification
14 Edition 01/2014 contrAA 600
Overvoltage category II according to DIN EN 61010-1
Degree of contamination 2 according to DIN EN 61010-1
Safety class I
Protection type IP 20
When connecting further components aside from PC and monitor to the output socket you are in danger of exceeding the
permissible limit value of 5 mA for the drain current.
Instrument fuses
Instrument fuse fittings (5×20 mm²) according to IEC 60127.
Fuse number Type Protected circuit
F3 T 6.3 A/H Power socket
F4 T 6.3 A/H Power socket
F5 T 6.3 A/H Spectrometer
F6 T 6.3 A/H Spectrometer
F7 T 3.15 A Xenon lamp
F8 T 3.15 A Xenon lamp
Furnace fuse
Type Protected circuit
TR5-T 100 mA Graphite tube furnace
Power supply fuse
The power supply fuses may only be changed by service engineers from Analytik Jena AG or by technical personnel author-
ized by Analytik Jena AG.
gL-G instrument fuse fittings (10
×
38 mm²) according to 60947-3.
Fuse number Type Protected circuit
F1 32 A/T Power supply
F2 32 A/T Power supply
Environmental conditions
according to DIN ISO 90022-2:2003 / 01
Corrosion protection The device is corrosion-proof for the samples used in the analysis.
Working temperature + 10 °C to + 40 °C
Humidity Max. 93 % at +40 °C
Storage temperature (drying agent) - 40 °C to 70 °C
Dimensions and weights
Mass 160 kg
Dimensions (W x H x D): 785 mm ×653 mm ×765 (974) mm
Transport of device Only possible using the corresponding carrying handles which must be securely
screwed into place

Specification
contrAA 600 Edition 01/2014 15
3.1.2 Control computer data
Computer
(minimum requirements) PC Pentium 1 GHz with 512 MByte RAM
40 GByte hard disk,
43 cm color monitor (17")
VGA graphic card
Resolution 800x600 pixels or higher,
CD ROM
Ports:
2 x USB interface (USB 1.1 or 2.0) for the contrAA 600
Mouse, printer
Printer Inkjet printer HP DeskJet
Laser printer HP Laser Jet
Operating system Windows 7 Professional
3.1.3 Graphite tube technique data
Graphite tube furnace
Type of sample Liquid
Solid
Tube type
IC tube (wall atomization)
IC tube with PIN platform
IC tube solid
All tube types are pyro-coated.
Volume max. 50 µL
Temperature setting Temperature can be set between room temperature and
3000 °C, in steps of 1 °C
Temperature-time programming
(furnace program) Up to 20 steps can be freely programmed within determined limits, 0 to 999 s/step, in intervals of 1 s
Temperature increase (ramp):
1 °C/s to 3000 °C/s linear and maximum non-linear ramps (Full Power FP / No
Power NP)
Control of inert gas and additional gas
Inserting injection and enrichment steps
Determining the starting point for autozero and integration
Cooling system Integrated cooling, sediment-free, ph balanced, 20 to 50 °C
Inert gas Argon 4.8 and superior
Permitted components:
Oxygen ≤3 ppm
Nitrogen ≤10 ppm
Hydrocarbons ≤0.5 ppm
Humidity ≤5 ppm
Consumption: Max. 2 L/min
(depending on temperature-time program)
Inlet pressure: 0.6 to 0.7 MPa
Safety circuits ensuring protection
against
Overheating of furnace heating transformer
Graphite tube breakage
Shortage of cooling water

Specification
16 Edition 01/2014 contrAA 600
Operation while graphite tube furnace is open
Operation with insufficient cooling water
Operation with insufficient inlet pressure of the inert gas
Cooling for xenon lamp and graphite tube furnace
Autosampler AS-GF
Autosampler for adding liquid samples, complete PC controlled
Sample tray
Sample cups
Special cups
108 positions
100 pieces, 1.5 mL
8 pieces, 5 mL
Pipetter volume 1 to 50 µL
Wash volume 0.5 mL, number of wash cycles can be selected
Program methods Standard
Modifier
Dilution
Addition
Automatic enrichment
Mass 7.2 kg
Cooling
Maintenance-free cooling system for the heat dissipation of Xe lamp and graphite furnace according to the water/air/heat
exchanger principle integrated into the spectrometer.
Accessories for direct solid analysis
SSA 600 Solid autosampler for automatic operation
SSA 6 Solid autosampler for manual operation
3.1.4 Data for HydrEA technique accessories
Mercury/hydride systems for HydrEA technique
HS 60; HS 55
See the instruction manual for mercury/hydride systems
Autosampler AS-F
Autosampler without dilution function, completely PC-controlled
Sample tray 139/ 15
Sample cups
Special cups
129 pieces, 15 mL
10 pieces, 50 mL
Sample tray 54/ 50
Sample cups 54 pieces, 50 mL
Power supply Via AAS basic instrument
Wash bottle 2 L
Mass 6.5 kg

Specification
contrAA 600 Edition 01/2014 17
Autosampler AS-FD
Autosampler with dilution function, completely PC-controlled
Sample tray 139/ 15
Sample cups
Special cups
129 pieces, 15 mL
10 pieces, 50 mL
Sample tray 54/ 50
Sample cups 54 pieces, 50 mL
Dosing unit in the Fluidik module 5 mL
Power supply Via AAS basic instrument
Wash bottle 2 L
Bottle for diluent 2 L
Mass (total)
Autosampler
Fluidik module
10.0 kg
6.5 kg
3.5 kg
3.2 Guidelines and standards
Safety class and safety type
The contrAA 600 belongs to safety class I.
The casing is safety type IP 20.
Device safety
The contrAA 600 conforms to the safety standards
DIN EN 61010-1 (VDE 0411T.1; IEC 61010-1)
DIN EN 61010-2-061 (IEC 61010-2-061)
EMC compatibility
The contrAA 600 has been tested for radio interference elimination and interference immuni-
ty and fulfills the requirements stipulated by
DIN EN 61326
Environmental compatibility
The contrAA 600 has been tested for environmental compatibility and fulfills the require-
ments stipulated by
DIN ISO 9022-3:2000
DIN ISO 9022-32-03-0
DIN ISO 9022-2:2003/01
EC directives
The contrAA 600 is built and tested according to standards that fulfill the requirements
stipulated by the EC directives 2006/95/EC and 2004/108/EC. Each device leaves the manu-
facturer in a pristine and technically safe state. To maintain this condition and to ensure safe
operation, the operator must strictly observe the safety and operating instructions contained
in this manual. For accessories which have also been supplied, and system components
from other manufacturers, their operating instructions should be referred to.

Installation conditions
18 Edition 01/2014 contrAA 600
4 Installation conditions
CAUTION! ONLY SERVIC
E ENGINEERS ARE ALLOWED TO INSTALL
THE DEVICE!
The device may only be assembled, installed and repaired by the service engineers from
Analytik Jena AG or by technical personnel authorized by Anal
ytik Jena AG. Any unauthor-
ized interference limits warranty entitlements.
When setting up assistance is needed for part of the time. The service engineer will test the
device and document the test in the test report of the contrAA 600.
The operator is responsible for everything (e.g., parts, guidelines) that is not included in the
original delivery, but is necessary for operation of the contrAA 600. Operation of the con-
trAA 600 demands certain local and system-specific requirements:
Suitable place for assembly
Space requirement
Environmental conditions
Supply with inert gas and additive gas
Exhaust unit
Mains connection
CAUTION! OBSERVE THE SAFETY INSTRUCTIONS!
Observe the safety instructions in chapter "
Safety instructions" p.6.
Observe work protection regulations. Warnings regarding potential danger do
not replace
valid work protection regulations!
Possible dangers when working with the contrAA 600 are:
Risk of burning from hot furnace parts
Danger from electric current
Danger from UV radiation
Danger of ozone or nitride oxide formation
Danger when handling pressure cylinders
Danger from toxic and chemically aggressive substances
4.1 Environmental conditions
Do not set up the contrAA 600 directly beside a door or a window. The work space of
the contrAA 600 should be free of draft, dust, corrosive vapor and also vibrations.
Do not set up the contrAA 600 close to any electromagnetic source.
Avoid direct sunlight and heater radiation on the contrAA 600. In extreme cases,
provide acclimatized conditions in the room.
