Anet A8 User manual

Anet A8 3D Printer
Installation Guide

A8 assembly parts list 1

A8 assembly parts list 2

A8 assembly parts list 3

A8 assembly parts list 4

A8 assembly parts list 5

A8 assembly parts list 6
Please check printer parts quantity when you receive it.

Name of each printer part

Assembly Step 1
Step 1
Please be aware the screw holes is in
red circles

Assembly Step 2
Step 2
Please be aware the screw
holes is in black circles

Assembly Step 3
Step 3

Assembly Step 4
Step 2
Step 3

Assembly Step 5

Assembly Step 6
Threaded rod 400mm

Assembly Step 7
Y Guide rod 380mm

Assembly Step 8
Attention：Leave vacancy between belt fixation
clamp and hot bed fixed plate for belt positioning.
jeweils 2 Klemmen übereinander, dass
der Riemen dazwischen kann
Later with belt
4

Assembly Step 9
Attention: Please diagonally tighten the screws when all are in there place
Before Assembly
After Assembly

Assembly Step 9
Attention: Belt is for X&Y axis transmitting. Cut the length
you need to each transmission shaft. The belt is 1.5m in total
and 10-20cm left after installation.

Assembly Step 10
Attention: Hot bed screws should be in the bottom, and
wing nuts will keep the height of hot bed level as well as
firming the hotbed.

Assembly Step 11 Attention: This hole is for Z axis guide rod positioning
M2* 12 Schraube 2
M3* 30 Schraube 2
8
