Antunes DC-27L User manual

P/N 1011438 Rev. A 12/16
Display Cabinet
owner’s manual
Model DC-27L
Manufacturing Numbers:
9500701
www.antunes.com

DC-27L DISPLAY CASE
2P/N 1011438 Rev. A 12/16
OWNER INFORMATION
Fill in the information below and have it handy when
calling Antunes Technical Service for assistance. The
serial number is on the specification plate located on
the rear of the unit.
Purchased From:
Date of Purchase:
Model No.:
Serial No.:
Mfg. No.:
Network ID Number:
Use only genuine Antunes replacement parts in this
unit. Use of replacement parts other than those sup-
plied by the manufacturer will void the warranty.
IMPORTANT! Keep these instructions for future reference. If the unit
changes ownership, be sure this manual accompanies the equipment.
Warranty Information
Please read the full text of the Limited Warranty in this
manual.
If the unit arrives damaged, contact the carrier imme-
diately and file a damage claim with them. Save all
packing materials when filing a claim. Freight damage
claims are the responsibility of the purchaser and are
not covered under warranty.
The warranty does NOT extend to:
• Damages caused in shipment or damage as result
of improper use.
• Installation of electrical service.
• Normal maintenance as outlined in this manual.
• Malfunction resulting from improper maintenance.
• Damage caused by abuse or careless handling.
• Damage from moisture into electrical components.
• Damage from tampering with, removal of, or
changing any preset control or safety device.
General
This manual provides the safety, installation, and
operating procedures for this unit. Please read this
manual prior to installing and operating the unit.
This unit is manufactured from the finest materials
available and assembled to Roundup’s strict quality
standards. This unit has been tested at the factory to
ensure dependable trouble-free operation.
Service/Technical Assistance
If you experience any problems with the installation or
operation of your unit, contact your Authorized Service
Agency.

DC-27L DISPLAY CASE
3
P/N 1011438 Rev. A 12/16
SPECIFICATIONS
CB
A
Dimensions
Model & Mfg. No. Height
(A)
Width
(B)
Depth
(C)
DC-27L
9500701
25”
(635 mm)
27”
(686 mm)
27”
(686 mm)
Model & Mfg. No. Volts Watts Amps Hertz Plug Description
DC-27L
9500701
24 24 1 50/60 Trans Wall
24 VDC, 1A
Level V
Power Cord and Plug Configuration

DC-27L DISPLAY CASE
4P/N 1011438 Rev. A 12/16
Location
When placing the toaster into service, pay attention to
the following guidelines:
• Do NOT block or cover any openings on the unit.
• Keep away from heated surfaces.
1. Place the display case in the required position.
2. Load product into the display case. Insert appro-
priate card into the display card holder.
3. Connect the power supply to the rear of the
Display Case and connect to the appropriate out-
let.
4. Turn the rocker switch on the rear of the unit on
to turn on the Display Cabinet lights.
5. Use the flip-down front panel (Figure 1) to store
and conceal product wrapping materials.
Unpacking
1. Open the large box. It contains:
• DC-27L Display Case
• Three shelves
• Power Supply
• Owner’s Manual
2. Remove the foam inserts from the box.
3. Carefully remove the display case from the large
box.
4. Perform the Daily Cleaning steps found in the
Maintenance section of this manual.
NOTE: If any parts are missing or damaged, con-
tact Antunes Customer Service IMMEDIATELY at
1-877-392-7856 (North America only), or
630-784-1000.
INSTALLATION
Figure 1. DC-27L Display Case (front)
Flip-down front panel
Power Supply
Power Switch
(Lights)
Figure 2. DC-27L Display Case (rear)

DC-27L DISPLAY CASE
5
P/N 1011438 Rev. A 12/16
Daily Cleaning
Follow these steps to clean the Display Case.
1. Turn the rocker switch on the rear of the
Display Case off. Unplug the power sup-
ply from the outlet and from the rear of the
Display Case.
2. Remove food product from the display case
and store properly.
3. Remove the shelves from the display case.
Remove the crumbs from the shelves with a
clean, sanitizer-soaked towel and dispose the
crumbs into the trash receptacle.
4. Take the shelves to the 3-compartment sink
to wash with hot water and an approved all
purpose cleanser. For heavier soils, pre-spray
with an approved heavy duty degreaser solu-
tion prior to washing.
5. Rinse the shelves with clean, hot water at the
3-compartment sink.
6. Sanitize the shelves with an approved
sanitizer solution for one minute at the 3-com-
partment sink and allow to air dry.
7. Using a clean, sanitizer-soaked towel; sweep
crumbs out of the display case and empty into
the trash receptacle.
8. Spray and wipe the interior and exterior walls
of the display case an approved all purpose
cleaning solution and a clean, sanitizer-
soaked towel. For heavy soils, scrub the dis-
play case walls with non-scratch pad that will
not damage the display case surfaces.
9. Rinse the interior and exterior walls of the
display case with a separate, clean sanitizer-
soaked towel.
10. Spray the interior and exterior walls of the dis-
play case with sanitizer solution and allow to
air dry.
11. Reinstall the shelves and load food product.
12. Reconnect the power supply to the rear of the
unit and to the appropriate outlet. Turn the
rocker switch on.
MAINTENANCE

DC-27L DISPLAY CASE
6P/N 1011438 Rev. A 12/16
REPLACEMENT PARTS
2 ? 11 12
8
10
7
6
3
22
23
516 113
4
14
15
17
2119
20
19
17
18
19
18
17
17
17
17
1 0507339 Base, Display Case 1
2 0022249 Back Panel Weldment 1
3 0022246 Front Panel Weldment 1
4 0013230 Control Panel Assembly 1
5 0507343 Light Column LH 1
6 0507344 Light Column RH 1
7 0013227 Light Channel Assem. 20” 2
8 0900349 Acrylic Cover Strip for LED 2
9 0900344 Acrylic Side Panel LH 1
10 9099345 Acrylic Side Panel RH 1
11 0900346 Acrylic Panel Top 1
12 0507393 Nose Trip Top Panel 1
Item Part No. Description Qty.
13 2180473 Guide Rail 6
14 4030432 Power Supply 24 VDC 1.0 A Level V 1
15 4060377 Cable Tie Mount with Adhesive 6
16 2100285 Rubber Head Screw Bumper 4
17 308P104 8-32 X .38 LG Truss Head S.S. 1
18 306P104 #6-32 X .25 LG Mach Screw S.S. 1
19 310P123 10-24 X .50 LG Truss Head S.S. 1
20 212P266 Spacer #10 Screw .125 LG 1
21 308P145 Nut, Hex Acorn #08-32 Low Crown 1
22 2100247 Knob 1
23 0900348 Shelf Acrylic 3
* Available in packages of 10 (ten)
Item Part No. Description Qty.

DC-27L DISPLAY CASE
7
P/N 1011438 Rev. A 12/16
NOTES

[phone]
[phone]
[phone] [phone]
[phone]
[phone]
Limited Warranty
This Display Case has a 90 day warranty from date of purchase. This warranty does not cover misuse/abuse, dam-
age due to dropping, or damage resulting from improper maintenance. The warranty for this Display Case does not
cover travel time or mileage. Contact the Technical Service Department at [phone], [phone] (toll free
in the U.S.), or T[email protected] for any warranty issues.
