Antunes IS-8000 User manual

®
Steam and Hold
Mfg. Number:
9100948
Owner’s Manual
Inni Steam
IS-8000
www.antunes.com CAUTION: Read all instructions before using the unit.
Original Instructions
P/N 1011582 Rev. F 07/21

®
P/N 1011582 Rev. F 07/21
2
Overview
This unit is intended to be used for
commercial applications, for example:
in kitchens of restaurants, canteens,
hospitals and in commercial enterprises
such as bakeries, butcheries, etc., But not
for continuous mass production of food.
Before Use
This manual contains safety, installation,
and operating procedures for the unit.
Read and understand it completely before
installing or operating the unit. Keep this
document for reference. If the unit changes
ownership, this manual must accompany it.
In Case of Damage

with the carrier immediately. Save

claim. Freight damage claims are the
responsibility of the purchaser and are not
covered under warranty.
Website
www.antunes.com
Service/Technical
Assistance
In Case of Damage
If any parts are missing or damaged,
problems with the installation or operation
of this product contact Antunes Customer
Service immediately at [phone]
(toll free).
Fill in the information in the next section
and have it ready when calling for assis-
-
cation sticker located on the system.
Equipment Information to Save
Purchased from:
Date of purchase:
Model number:
Serial number:
Manufacturing number:
Authorized Service Agency
Name:
Phone No:
Address:
Table of Contents
Overview 2
Before Use 2
In Case of Damage 2
Website 2
Service/Technical Assistance 2
In Case of Damage 2
Equipment Information to Save 2
Authorized Service Agency 2
Safety Information 3
Installation 3
Maintenance 3
Service 3
Specications 4
Electrical Ratings 4
Electrical Cord & Plugs 4
Dimensions 4
Unpacking 5
Installation 6
Water Supply Quality 6
Water Supply Plumbing 6
Supply Wiring 7
System Water Drainage 7
Operations 7
Initial Startup 7
Drawer Installation 7
System Power-up 8
Programmed Steaming 8
Steamer Settings 9
Editing Products 9
Edit Clock 9
Edit Wakeup 9
Service Menu 9
Diagnostics 9
Edit Options 9
Restore Defaults 9
Reset to Factory Defaults 10
Maintenance 10
Daily 10
Weekly 11
Error Messages 13
Troubleshooting 14
Wiring Diagram 15
Exploded Diagram #1 16
Exploded Diagram #2 17
Exploded Diagram #3 18
ExplodedDiagram#4 19
Photo Diagram 20
Replacement Parts 21
Parts List 21
Replacement Parts Continued 22
Notes 23

®
P/N 1011582 Rev. F 07/21 3
Safety Information
Installation
yRead and understand all instructions
before installing or using the unit.
yThe unit MUST be installed by

electricity and plumbing.
yInstall this unit to comply with the
basic plumbing code of the Building
󰀩
Inc. (BOCA) and the Food Service
Sanitation Manual of the Food
and Drug Administration (FDA).
yInstall and locate the equipment
only for its intended use as
described in this manual.
WARNING
ELECTRICAL SHOCK HAZARD.
Failure to follow the instructions in
this manual could result in serious
injury or death.
Do not modify the power supply cord


electrician.
Electrical ground is required on this
appliance.

are unsure if the appliance is properly
grounded.
Do NOT use an extension cord with this
product.
The unit should be grounded accord-
ing to local electrical codes to prevent
the possibility of electrical shock. It
requires a grounded receptacle with
separate electrical lines, protected by
fuses or circuit breaker of the proper
rating.
NEVER unplug the power cord while
the unit is running. Use the proper
shutdown procedure before unplugging
the power cord.
Operation
yThe unit is furnished with
a properly grounded cord
connector. Do not attempt to
defeat the grounded connector.
yDo not operate the unit if it has
been damaged or dropped, if it
has a damaged cord or plug, or
if it is not working properly.
yDo not block or cover any
openings on the equipment.
yDo not immerse the cord,
unit, or plug in water.
yKeep the cord away from
heated surfaces.
yDo not allow the cord to hang over
the edge of a table or counter.
yKeep the area around the unit
free and clear of all combustible
materials. Failure to do so may

yOpening steamer drawers
during operation releases
steam. Compartment and
contents may be hot.
Maintenance
yDo not use abrasive materials;
they can damage the unit’s

yDo not use corrosive chemicals
in this equipment.
yChlorides or phosphates in cleaning
agents (e.g., bleach, sanitizers,
degreasers, and detergents) can
permanently damage stainless
steel equipment. The damage is
usually in the form of discoloration,

pits, voids, holes, or cracks.
This damage is permanent and
is not covered by warranty.
yAlways use a soft, damp cloth for
cleaning. Rinse with clear water and
wipe dry. When required, always rub
in the direction of metal polish lines.
yRoutine cleaning should be
performed daily with soap and water.
y󰀨
using soap and water.
yDo not clean unit or components


yDo not clean the unit with a
water jet or steam cleaner.
yWhen using the citric acid
cleaning solution as prescribed
in this manual, follow the
recommended manufacturer’s
safety precautions. Use gloves and
eye protection when required.
Service
yInspection, testing, and
repair of electrical equipment
must be performed only by

yTo avoid possible personal injury
and/or damage to the unit, all
inspections, tests, and repair of
electrical equipment should be

ONLY. Contact Antunes Technical
Service for adjustment or repair.
y󰀨
cord, and allow unit to cool to room
temperature before performing
any service or maintenance.
yIf the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent, or

to avoid an electrical hazard.
yCleaning and user maintenance
shall not be made by children
without supervision.

®
P/N 1011582 Rev. F 07/21
4
Specications
Electrical Ratings
Electrical Cord & Plugs
Model &
Mfg. No. Description Conguration
9100948
9100949
NEMA 6-50P
250 VAC, 50 AMP
or 6 AWG Wires
Model &
Mfg. No. Volts Watts Amp Hertz
9100948
9100949 208 9000 41 50/60
Dimensions
Water Requirements
Water Quality (Treated Water):
Hardness (Calcium & Magnesium) 1 GPG Maximum
Total Alkalinity 600 PPM Maximum
Total Silica 150 PPM Maximum
Iron Content 0.1 PPM Maximum
pH 6.5-10.5
Total Dissolved Solids 2,500 PPM Maximum
Oxygen Content 0 PPM
Carbon Dioxide 0 PPM
Water Pressure Requirements
Minimum Water Pressure 40 psig
Maximum Water Pressure 60 psig
33.0026.40
26.70
IMPORTANT
Failure to follow these water quality conditions will void the warranty
and may cause the steamer to operate erratically or fail prematurely and
require a service call.

®
P/N 1011582 Rev. F 07/21 5
Unpacking
WARNING
This steamer must be installed by

with electricity and plumbing. Improper
installation can cause injury to personnel
and/or to the equipment. The steamer
must be installed in accordance with all
applicable codes.
CAUTION
The Steamer has an approximate
shipping weight of 260 pounds. For safe
handling OBTAIN EXTRA PERSONNEL
to properly and safely install the steamer.
WARNING

and the cart, table, or service rack MUST
have a rated service weight capacity of
360 pounds per steamer.
1. Remove steamer and all accessories
from the packaging.
2. Remove all packing materials and
protective coverings from the steamer.
3. Record the model number, serial
number, and installation date of your
steamer and keep this information
for future reference. Space for this is
provided on page 2.
NOTE: If any parts are missing or
damaged, contact Antunes
IMMEDIATELY at 1-800-253-2991
(toll free in the U.S. and Canada)
orat630-784-1000.
4. Wash all removable components
in soap and water. Wipe down all
exterior surfaces of the steamer with a
hot damp cloth.
NOTE: Do NOT use a dripping wet
cloth. Wring out before use.
5. Install components onto steamer as
shown in Figure 2.
Figure 1. Steamer
Figure 2. Steamer Components
Removable
Drawers
(8 Single)
Disposable
Steam Pans
(Not included)
Drip Tray

®
P/N 1011582 Rev. F 07/21
6
Installation
The steamer should be installed in a well-
ventilated room. The steamer must be
securely fastened to a table or moveable
cart that is capable of handling the weight
of one or multiple steamers. Each Steam
and Hold weighs approximately 200
pounds and the total weight capacity
requirements of the cart or table must be
considered prior to installation. 3X safety
factor recommended. I.e. 1 Steam and
Hold (200 lbs) x 3 S.F. = 600 lbs minimum
weight load capacity per work surface.
NOTE: Installer MUST verify the weight
restrictions of the table, cart, or
service rack prior to installation
of the steamer. All warranties
will be VOID if work surface is
unabletohandlethespecied
weight load.
The steamer must be installed on a level
surface. The Steam and Hold has built-in
water level controls requiring the surface
to be parallel to the horizon. The steamer
must be level front-to-back or pitched
slightly backwards for the cavities to drain
properly.
Install steamer with at least 6 inches
of clearance from the back wall. Side
clearances of at least 6 inches are
recommended. Antunes recommends
enough clearance for easy cleaning,



Water Supply Quality
The quality of the water supply to the boiler
is important for proper operation. Low
hardness water will keep the boiler cleaner
and reduce the need for frequent clean
cycles.
It is recommended that the water quality
conditions in this documents be met.
An Antunes Water Treatment System is
recommended to best attain these water
conditions. Consult Antunes Customer
Service for more information on and
Antunes product that is designed for the
Steam and Hold.
NOTE: Failure to follow these water
quality conditions will VOID the
warranty and may cause the
steamer to operate erratically or
fail prematurely and require a
service call.
Water Supply Plumbing
The Steam and Hold is equipped with
a standard 1/4 NPT female water
connection. Also included with the

2080134 (Male) & 2080118 (Female))
which can be readily adapted and/or

feed line that delivers water pressure at a
minimum of 40 psig and a maximum of 60

required.
NOTE: Minimum dynamic supply water
pressure (from a softener, RO
system, or tap water supply
line)tobe40psigminimum
and a maximum of 60 psig.
Contact Antunes Tech Service
on measuring the proper supply
water pressure.
Antunes Recommended Clearances from walls and other Equipment
Front of Steamer Rear of
Steamer
Left Side of
Steamer Right Side of Steamer
36” - 48” for full drawer
extension
6”- 8” for proper

6” for ease of
cleaning and
maintenance
6” for ease of cleaning
and maintenance
Agency Required Clearances from walls and other Equipment
36” 6” 0” 0”
Figure 3. Steamer Connections and Items (Rear of Steamer)
Treated
Water
Intake
Water
Pressure
Regulator
RO System
Connection
Drain
Rear Access
Panel with
IOT box
Intake Fan
System
Drain
Power
Cord
USB
Port

®
P/N 1011582 Rev. F 07/21 7
Supply Wiring
System Water Drainage
A 9 ft. roll of high temperature 3.4” I.D.


hose, will impede the performance and
functionality of the Steam and Hold.
1. Measure distance from steamer drain

room for a two (2) inch gap between

2. Cut the supplied drain tubing for drain
connection.
NOTE: A 2 inch air gap from the drain
hosetotheoordrainmustbe
maintained in order to provide
adequate/proper drainage
capabilities. Failure to comply
with a 2” air gap minimum will
result in a warranty failure and
nuisance performance issues.
NOTE: Depending on your installation,
local plumbing codes may
require the use of a wall
mounted drain box (P/N
0013900).
Operations
Initial Startup
1. Connect the water treatment system
to the treated water inlet according to
Figure 3 on page 6.
2. Plug the power cord into the
appropriate outlet. Turn on water.
3. The steamer performs a system
test and displays information on the
display.
4. The steamer then shows the splash
screen. Press the Power Button to
turn the steamer on.
5. The steamer displays the main screen

6. 
reaches temperature, the steamer
displays “System is Ready” on the
main screen.
Drawer Installation
Inside of the drawer cavity is a roller and
a rail cutout on either side. The cutout
is located right behind the roller. On the
bottom rear edge of each drawer is a
tab extension. The tab helps to keep the
drawer inside the cavity. See Figure 5.
Rail Cutout
To Install:
1. Hold the drawer at about a 30 degree
angle. Insert the drawer tabs through
the cutouts in the drawer rails so the
tabs are under the rails.
Tab
Extension
2. Rotate the drawer down and insert
pan.
3. Drawer should now easily close and
seal.
NOTE: Remove pans before removing
drawers.
Hose should
retain volume
through entire
length
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing.
Replace all parts and panels before
operating. Failure to do so can result in
electrical shock or death.
WARNING
An electrical ground is required to the
wall receptacle. Failure to provide a
proper ground can result in death or
serious injury. All applicable electrical
codes MUST be followed in accordance
with ANSI/NFPA 70 or latest edition. In
Canada, provide electrical service in
accordance with Canadian electrical
code, CSA C22.1 and local codes.
1. Remove the four side panel screws as
shown below.
2. Route power supply (not included)
through the strain relief as shown
below and secure with screw.
Grounding
Stud
Strain
Relief
3. Connect black and white wires to
contactor as shown. Connect Line
Voltage Input to Contactor L1 and L2.
Use torque screw driver set at 35in-lb.
Figure 5. Kinked Hose
Figure 4. Electrical Side Panel
Figure 6. Rail Cutout
L1
L2
Strain
relief
Grounding
Stud
4. Connect green ground wire to
grounding stud using provided nut.
Use torque nut driver set at 20 in-lbs.
5. Reassemble side electrical panel.

®
P/N 1011582 Rev. F 07/21
8
Programmed Steaming
1. When the Initial Warm-up is complete,
the operations screen appears on the
display.
2. Open the appropriate drawer and
load the product to be steamed onto
the steam trivet. Close the drawer
securely.
3. On the display, press the appropriate
button for the drawer being used.
NOTE: All drawers can be used for
holding at the same time.
Steamingwithveormore
drawers at the same time will
reduce heating performance and
pan contenst may not reach the
desired internal temperature.
4. Select the product from the pre-loaded
options.
Select Product (Page 1 of 4)
Chicken
Hot Dog
Pork
Corn
Back
Turkey
Tamale
Beef
Taquito
5. After selecting the product, select the
product size to steam.
Select Product Size
Back
Small Medium Large
6. There are two options for steaming:
Now or Later. If Now is selected the
unit will return to the main screen and
begin steaming.
Select Function
Back
Start Now Start Later
7. If Start Later is selected the unit will
return to the main screen. The newly
created timer will wait for further
instruction before starting. This is
indicated by the --:--.
System Is Ready
Settings Start All
Chicken
No Product
No Product
No ProductNo Product
No Product
No Product 0F
0F
0F
0F
77F
- - : - -
0F
0F
No Product
0F
8. Tap the button for the primed timer.
There are three options: Start the
timer, Delete the timer (trash), or
change the steaming options for the
drawer.
Select Function
Back
Start Trash Change
9. 󰀨
and timers:
yYellow - The drawer is STEAMING
yGreen - The drawer is HOLDING
yRed - The drawer is EXPIRED
System Is Ready
Settings Start All
Chicken
No Product
No Product
No ProductNo Product
Tamale
165F
0F
0F 0F
165F
0 0 : 2 7
Turkey 165F
0 3 : 5 9
-0 0 : 5 9
0F
0F
No Product
10. 
the drawer will switch to holding.
Product may be removed and used
during any time while the drawer is
holding.
Select Function
Back
Stop Trash
NOTE: A timer may be stopped or
trashed at any time while in use.
Simply tap the selected drawer
and choose your option.
First In First Out (FIFO)
The Steamer uses a feature called First In
First Out. FIFO helps make sure product

removed. If there is more than one drawer
running the same product and size, the
display and beeper will prompt the user
to pull product from the drawer that was
started earliest.
System Power-up
1. Upon application of power, the system
will display the following splash
screen.
2. After initializing the system will
display:
Press And Hold Power Button To Begin
Time 12:00 AM Wakeup Disabled
NOTE: The system will display Wakeup
Disabled when the automatic
Wakeup function is not enabled.
When the Wakeup function is
enabled, the screen will display
‘Wakeup X:XX’ where X is the
set time.
3. Press and Hold the Power Button on
the Control Panel to begin. The unit
will display “System is Not Ready”,

the heating process. Once the unit
reaches temperature the screen will
display:
System Is Ready
Settings Start All
No Product
No Product
No Product
No ProductNo Product
No Product
No Product 141F
0F
0F
0F
No Product
0F
0F
0F
0F

®
P/N 1011582 Rev. F 07/21 9
Steamer Settings
To access the Steamer Settings, press the
Settings button on the display. This opens
the Settings screen, shown below.
Settings Menu
Done
Set
Clock
Edit
Wakeup
Clean
Boiler
Service
Menu
The Settings Screen shows three buttons,
described below:
Button Description
Edit Product
Select to access the
Edit Screen for access
to editing products,
steaming times, and
product names.
Edit Clock Changes the date and
time.
Edit Wakeup
Changes the time in
which the Steamer turns
on.
Clean Boiler
This option works with
the Antunes RO system.
Please see your RO
manual for information
on how to use the clean
cycle.
Service
Displays information
necessary for servicing/
repairing the unit.
Editing Products
To Edit Products:
1. Press Settings to open the settings
menu.
2. Press Edit Products.
3. Select the product you wish to edit
from the available list
(see below).
Select Product (Page 1 of 4)
Chicken
Hot Dog
Pork
Corn
Back
Turkey
Tamale
Beef
Taquito
4. The following screen displays:
00:30 02:30
Small Medium
Portion4
Portion6Portion5
Chicken
Large 00:00
00:00
Steam
05:00
Steam
00:00
Steam
04:00 145F
Hold Temp
Select Field to Edit
Done
5. 
is changed will save automatically or
press Cancel to discard any changes.
Chicken
Edit Name
Return123Space123Cancel
q w e r t y u i o p
a s d f g h j k l
Shift z x c v b n m Del
NOTE: Cook time is displayed in
minutes : seconds
Hold time is displayed in
hours : minutes
Edit Clock
To change the time and date on the
Steamer:
1. Select Edit Clock in the Tools Screen.
2. The screen will display as shown
below:
Edit Clock
Exit Set
01 - 01 - 01
01
MM DD
HH MM
YY
Period
01 01
00 00 AM
00 : 00 : 00 AM
3. 
time and date. Press Set to save
changes. The clock will begin ticking.
Edit Clock
Exit Set
05 - 14 - 20
05
MM DD
HH MM
YY
Period
14 20
12 21 PM
12 : 22 : 25 PM
Edit Wakeup
To change the time when the Steamer
turns on and Disable or Enable Wakeup
Mode:
1. Select Edit Wakeup in the Tools
Screen.
2. The screen will display as shown:
Edit Wakeup
Cancel OK
HH MM Period
00 00 AM
Mode
Enabled
3. 
AM or PM, and Disable or Enable
Wakeup Mode.
Edit Wakeup
Cancel
OK
HH MM Period
06 00 AM
Mode
Enabled
4. Press OK to save.
Service Menu
To enter Service menu:
1. Press Settings to open the settings
menu.
2. Press Service.
Service Menu
Done
USB Import USB Export
Restore
Defaults
Diagnositics Edit Options
Diagnostics
Diagnostics displays the items that the unit
is constantly measuring. This cannot be
edited.
Edit Options
Edit Options allows ability to adjust various
system settings and set a Password.
264F 250F
Boiler SP Ready SP
20:00 00:10
Clean Time Rattle Time
FLOUD
Degrees Beeper
05:00 2
Drain Time Clean Count
3
Rinse Count
12345
Password
140F 30%
Idle SP Temp Check
Edit Options
Done
To set a Password, select Password. The
screen will be as shown below. The factory
default is ‘12345’.
12345
Enter Password
Done
1 2 3
4 5 6
7 8
0
9
Restore Defaults
Allows system to reset to default Options,
and Products to factory settings.
NOTE: Do NOT adjust set points
or clean cycle times unless
instructed to by Antunes
Technical Service.

®
P/N 1011582 Rev. F 07/21
10
Reset to Factory Defaults
IMPORTANT
Resetting the Steam and Hold to Factor
Defaults erases all edits, menu changes,
and customized functions back to
Factory Settings.
To reset settings to the factory defaults:
1. Press Settings on the display. This
opens the Settings screen, shown
below:
Settings Menu
Done
Set
Clock
Edit
Wakeup
Clean
Boiler
Service
Menu
2. Select Service to open the Service
Menu. Press Restore Defaults.
Service Menu
Done
USB Import USB Export
Restore
Defaults
Diagnositics Edit Options
3. Restore Defaults option opens.
Default Options and Default
Products is shown.
Restore Defaults
Done
Default
Options
Default
Products
4. Press either of the functions to restore
to the factory defaults. The following
screen appears:
Operation Completed
Done
5. Press Done to return to the Service
Menu.
Maintenance
Daily
The Steam and Hold requires a
minimal amount of maintenance. Daily
maintenance helps keep the steamer
running smoothly and free of any excess
buildup that comes from daily use and
wear. These steps should be completed
at the end of every day to ensure that the
󰀩
Open the drawers and remove the steam
pans and steam trivets (Figure 8).
1. Remove the drip trays (Figure 8).
Figure 7. Cavity Drain Screen
Figure 8. Steamer Drawer Components for Cleaning
2. Wash, rinse, and sanitize the drip
trays at the sink. Allow to air dry.
3. Remove all cavity drain screens and
rinse clean of any debris (Figure 6).
4. Clean the steam drawers and the
inner cavity with a clean towel
dampened with sanitizer. Allow to air
dry.
NOTE: Do not use a dripping wet towel.
Wring the towel out before
wiping the steamer.
5. Reinstall all parts (Figure 8).
Drip Tray
Removable Drawers
Disposable
Steam Pans
(Not included)
Clean Cycle
Door

®
P/N 1011582 Rev. F 07/21 11
Weekly
Clean Cycle Maintenance
The cleaning cycle can be accessed and
performed at any time during the day.
When low mineral content (low TDS) water
is used with the steamer, the clean cycle
should only be needed monthly. Higher
mineral content water may require more
frequent clean cycles.
NOTE: Failure to properly clean and
de-scale boiler will cause
signicantchangesinoperation
of steamer. Antunes is not
responsible for any damage or
complications due to negligent
maintenance of steamer.
1. Select Settings. The Settings Menu
screen opens.
Settings Menu
Done
Set
Clock
Edit
Wakeup
Clean
Boiler
Service
Menu
2. Select Clean Boiler to begin the
Clean Cycle.
Close Drawer(s) And
Add Descaler
OKCancel
3. Remove the Cycle Key and insert it
into the Cleaning Cartridge (Figure
9). Rotate cartridge counter-clockwise
and remove from steamer.
4. Remove top of Cleaning Cartridge by
󰀨
5. Pour 4oz of cleaning solution into the
plastic housing (Figure 10).
NOTE: Use two 2oz Delimer Packets in
Cleaning Cartridge per Clean
Cycle.
Figure 9. Clean Cycle
Rotate the door down and remove key
from pocket. Insert key into clean cycle
cartridge, counter clockwise, and remove
from steamer.
󰀨
the plastic housing.
Figure 10. Pour Delimer into Cleaning
Cartridge
6. Reattach top of Cleaning Cartridge.
7. Place Cleaning Cartridge back into
steamer.
8. Rotate the supplied key clockwise
to tighten cartridge. Steamer is now
ready to perform Clean Cycle.
9. Press OK to begin the cleaning cycle.
The following screen appears and
begins the cleaning cycle.
CLEANING
Clean Fill
Temp 119
Hi Probe DRY
Lo Probe DRY
Snap Switch COLD
Pressure Switch COLD
Time 00:04:54
Step 1 of 2
10. When the Cleaning Cycle is complete,
the following screen appears. Press
OK to return to the Tools Menu.
Cleaning Completed
Press OK
OK

®
P/N 1011582 Rev. F 07/21
12
Weekly Maintanence - Cleaning Cycle
Scaled Clean
WARNING
Failure to properly follow the cleaning instructions for the unit will
result in excess buildup of scale and lime as seen in the examples
below. Excess buildup of scale and lime may cause damage to the
unit and will void the warranty.

®
P/N 1011582 Rev. F 07/21 13
Error Messages
If the steamer displays any error messages, turn the steamer
o󰀨andrestartit.Iftheerrorpersists,contactAntunesTechnical
Serviceat1-877-392-7854(tollfree).
WARNING
Before replacing any parts, or opening any side or rear panel from the steamer,
disconnect the steamers from the electrical power supply.
CAUTION
Use of any replacement part other than those supplied by Antunes of their authorized
distributors can cause injury to the operator and damage to the equipment and will
void all warranties.
Error Description
FRAM Missing Control Board Failure
Zero Cross
TC0 Open Thermocouple Broken or Disconnected
TC1 Open
FlipFlop ON Power Switch Circuit Malfunction
FlipFlop OFF
Bootload Fail Software Update via USB Stick Failed
OPTION Write Failed
EEPROM FailureMENU Write Failed
PID Write Failer
24V Missing 24VDC Power Supply Failed
Display Missing Touch Screen Display Failed
Boiler Hot Boiler Failed to Cool Down
Boiler Not Empty Boiler Failed to Drain
Drain Timeout
Clean Drain Timeout Boiler Failed to Cool Down
Initial Fill Timeout Boiler Initial Water Fill Failed
Clean Fill Timeout Boiler Clean Cycle Water Fill Failed
 Boiler Normal Operation Water Fill Failed

®
P/N 1011582 Rev. F 07/21
14
Troubleshooting
YourAntunesSteamerisdesignedtooperatesmoothlyande󰀩cientlyifproperlymaintained.
However, the following is a list of checks or activities to make in the event of a problem:
Problem Possible Cause
Who
Services
Steamer
Corrective Action
Excessive steam
escaping from the
cavity
Cavity Drain Screen is
Plugged User Remove both drawers of steamer and clean Drain Screens.
Drain Hose is kinked or
2" air gap is blocked User Make sure the drain hose are not kinked and a 2” air gap is 
Excessive water is
pouring out of the cavity
Water Probes Scaled User Run one or more clean cycles. Check the water treatment
system.
Cavity Drain Screen is
Plugged User Remove both drawers of steamer and clean Drain Screens.
Drain Hose is kinked or
2" air gap is blocked User Make sure the drain hose are not kinked and a 2” air gap is 

clogged
Auth Service
Rep Only 
Steam Solenoid Valves
are clogged.
Auth Service
Rep Only
Check Steam Solenoids Valves for debris and continuity (N.C.)
for normal operation.
Steamer Does Not Heat
Steamer is unplugged
or circuit breaker is
tripped
User Make sure steamer is plugged in and circuit breaker has not
tripped.
Cavity Drawer(s) are
not fully inserted. User Make sure both cavity drawers are pushed in all the way.
Loose component
connections
Auth Service
Rep Only
Check operation of Pressure Switch, Control Board, Contactor,
and Cartridge Heaters for continuity and/or loose connections.
Steamer fails to reach
proper temperature
GUI Settings have
changed User
Adjust GUI Control Settings and set Boiler Temperature (BT)
to 268 deg F. See settings/ operation section in this manual
on page 17.
Voltage issue on
electrical components
Auth Service
Rep Only
Check for voltage or open circuit on control board, contactor,
heaters, pressure switch, or GUI control Panel.
Steamer is continually
draining and doesn’t
build pressure or
temperature
System buildup or
blockage. User
󰀨
to complete the entire clean cycle – See preventative
maintenance section of this manual on page 18.
Drain Valve
malfunction/failure.
Auth Service
Rep Only
Clean the drain valve seat or replace drain valve with the
steamer powered down. Once powered up, run a clean cycle
to ensure trouble free operation.
Steam is escaping from
the rear panel of the
steamer
Internal Component
Failure
Auth Service
Rep Only Shut down and unplug the unit. Call Authorized Service Rep.
Water is escaping from
rear of steamer during
initial operation
Water Inlet Hose has
connection problem User Check inlet water feed hose to steamer. Reconnect if needed and/or replace.
Water level probe
scaled up User Run a cleaning cycle.
System Error Displayed
on GUI
System Error - Refer
to Error Messages on
Next Page
User Turn steamer OFF and then back ON. If error persists, contact
Authorized Service Rep

®
P/N 1011582 Rev. F 07/21 15
Wiring Diagram
1 1
2 2
3 3
4 4
5 5
6 6
DD
CC BB
AA
L2
L1
GND
To Line Cord
#2 RED CAT5 #3 ORANGE CAT5
Water Fill Solenoid
Drain Solenoid
140 Degree Snap Switches
Wire Legend
* 22 GA PVC
o 20 GA PVC
▲ 18 GA PVC
■ 12 GA TEF
**
♥ 8 GA
♥
Clean Switch Interlock Clean Solenoid
#4 YELLOW CAT5
#5 BLUE CAT5
#6 PURPLE CAT5
#7 GRAY CAT5
#1 BLACK CAT5
**
**
**
**
J109
J24
J23
24VAC LLCO
FILL
#8 WHITE CAT5
24V DC FAN
+
-
J2 Fan
J101 - J108 Cat 5 wiring to Drawers
Boiler Thermocouple
J25
J6Touch Panel Display
Y1R1Y2R2
J7IOT PORT
J1See Power Switch wiring Diagram
Power Switch
Contactor
Chassis Ground
Pressure Switch
L2
L1
G
N.O.
COM COM
N.C.
GND
G
*
LLCO
*
H
GND
Heater
Heater
SSR2
Heater
Heater
SSR1
2_Pole_Branch_Circuit_Breaker
■
■
■
■ ■
■
♥ ♥
▲
▲
o
o
o
o
GND
G
▲ ▲
▲ ▲
Mean Well 24 Volt Power Supply
MSP-200-24
SSR1 -
SSR2 -
SSR1 +
SSR2 +
Water Level Board
SSR1 - SSR2 -
SSR1 +
SSR2 +
Wires go to the SSRs
SSR input wires
connected to J8
J8
on main board
*
*
*
*
* *
*
MOV Board
▲
▲
▲
Snubber
o
o
Buzzer Board
J11 Buzzer
Cavity BreakoutBoard Wiring This is Repeated for all 8 Drawers
13 24
Drawer Reed Switch
Drawer Thermister
Drawer Solenoid
CAT 5
Cable
Power Push
Button Board
J101-J108 Wiring
Touch Screen Display
* *
*
* **
J7 IOT Port Wiring
J7
IOT Module Main Board
▲
▲
* *
SSR
Pressure Switch
J26
Water Level Board Interface
Power In / Contacotor
1
8
J6
USB
J16
Connected to Panel USB Port (Not Shown)
2
3
1
4
13
4
2
24V Power IN
+-
*
* *
**
*
*
GND
GND
31
2
4
1 4
1 10
1
6
1 6
12
7
1
6
ORG
BLU
ORG
BLU RED RED BLK
WHT
BLK
WHT BLU
BLU
WHT
ORG
RED
BLK
RED
BLK
YEL ORG
BLK WHT
BLK
WHT
BLK
BLK
BLU
RED
RED BLK
*
*
*
*
BLK
BLU
ORG
RED
BLU BLU
RED
RED
RED BLK
BLK
BLU
BLU
BLU
GRN
GRN
GRN
▲▲
ORG
BLU
YEL
RED
RED BLK
ORG GRA
YEL
GRN
RED
ORG
YEL
BLK
BLU
PUR
GRN
GRN
YEL
PUR
LLCO Sensor Probe
Fill Probe

®
P/N 1011582 Rev. F 07/21
16
72
4
17
66
71
60
23
95
94 61
75
6
79
201
219
196
69
15
49
188
Item 15
119
125
111
121
224
226
222
166
223
228
224
225
227
Exploded Diagram #1
Mfg. No.
9100949
ONLY
135
137
62
185
48
32
33
28
28
23
18
136
Item 4

®
P/N 1011582 Rev. F 07/21 17
Exploded Diagram #2
124
57
182
189
191
5
190
56
206
186
7
116
171 77
16
31
77
46
174
208
58
30
186
174
199
157
105
129
128
106
92
104
Item 7
211
214
209
217
212
209
210
214
213
78
215
Item 208

®
P/N 1011582 Rev. F 07/21
18
Exploded Diagram #3
70
167
192
218
55
198
197
194
166
187
53
207
11
157
174
59
74
174

®
P/N 1011582 Rev. F 07/21 19
ExplodedDiagram#4
1
127
129
70
102
126
14
9
3
102
133
114
113
122
2
206
182
54
190
58
187 39
188
201
138
195
113
31
46 116
57
16
208
219

®
P/N 1011582 Rev. F 07/21
20
Figure 11. Interior Side Panel View
Figure 12. Rear Access Panel View
Heat sync
Pressure Release
Switch
Water Level Board
Power Supply Board
Circuit Breaker
Contactor
Cavity Breakout
Board
Drain Tubing
Photo Diagram
Main Control
Board
Display Board
Boiler
SSR Relay
Power Button
Board
Solenoid
System Drain
Power Cord
Treated Water
Intake
Regulator
Assembly
