Antunes DCH-100 User manual

P/N 1010772 Rev. H 05/18
DCH-100/200/300
DCH-120/220/320
owner’s manual
Toasters Heated
Manufacturing Numbers:
9500500, 9500510, 9500512, 9500520,
9500530, 9500531, 9500532, 9500533,
9500534, 9500535, 9500536, 9500537,
9500538, 9500540, 9500550, 9500551,
9500552, 9500553, 9500554, 9500556,
9500557, 9500559
www.antunes.com

2P/N 1010772 Rev. H 05/18
Overview
The Antunes Display Case attrac-
tively displays your food and main-
tains it at ready-to-eat temperature.
A convection fan (some models)
circulates heat throughout the entire
toaster while a digital temperature
control maintains a constant tem-
perature. Humidity water trays
(some models) extend food holding
times by reducing moisture loss.
Models DCH-100, DCH-200, and
DCH-300 are primarily for meats and
poultry products.
Models DCH-120, DCH-220, and
DCH-320 are primarily designed for
bread products.
Before Use
This manual contains safety, instal-
lation, and operating procedures for
the display cabinet. Read and under-
stand it completely before installing
or operating the toaster. Keep this
document for reference. If the heated
toaster changes ownership, this
manual must accompany it.
In Case of Damage
If the toaster arrives damaged, le
a claim with the carrier immediately.
Save all packing materials when ling
a claim. Freight damage claims are
the responsibility of the purchaser
and are not covered under warranty.
Website
www.antunes.com
Service/Technical
Assistance
In Case of Damage
If any parts are missing or damaged,
contact Antunes Customer Service
immediately at [phone] (toll
free).
If there are problems with the instal-
lation or operation of this product,
contact Antunes Technical Service
toll free at [phone].
Fill in the information in the next col-
umn and have it handy when calling
for assistance. The serial number is
on the specication plate located on
the system.
Content
Overview 2
Before Use 2
In Case of Damage 2
Website 2
Service/Technical Assistance 2
In Case of Damage 2
Equipment Information to Save 2
Safety Information 3
Installation 3
Operation 3
Maintenance 3
Service 3
Heated Toaster Glass Warnings 4
Speccations 5
Temperature Ranges 5
Dimensions 5
Capacities 5
Electrical Ratings 6
Electrical Cord
& Plug Congurations 6
Model Designation 6
Installation 7
Unpacking 7
Equipment Setup 7
Operations and Programming 8
Maintenance 9
Daily Cleaning 9
Parts Replacement 9
Halogen Bulb Replacement 9
Front Display Graphics/ 9
Bulb Replacement 9
Rear Door Replacement 10
Front Glass Replacement 10
Side Glass Replacement 10
Display Codes 11
Troubleshooting 12
Replacement Parts – DCH-100/120 13
Replacement Parts – DCH-200/220 15
Replacement Parts – DCH-300/320 18
Wiring Diagrams 20
Limited Warranty 22
Equipment Information to Save
Purchased from:
Date of purchase:
Model number:
Serial number:
Manufacturing number:
Authorized Service Agency
Name:
Phone No:
Address:

3
P/N 1010772 Rev. H 05/18
Safety Information
Installation
yRead and understand all
instructions before installing
or using the eated toasterr
yInstall and locate the equipment
only for its intended use as
described in this manual.
yAll electrical connections must
be in accordance with local
electrical codes and any other
applicable codes. The equipment
must be grounded according to
local electrical codes to prevent
electrical shocks. It requires a
grounded receptacle with separate
electrical lines, protected by fuses
or a properly-rated circuit breaker.
yElectrical ground is required
on this appliance. Consult a
qualied electrician if there is any
uncertainty about whether the
appliance is properly grounded.
yDo not modify the power supply
cord plug. If it does not t the
outlet, have a proper outlet
installed by a qualied electrician.
yDo not use an extension
cord with this appliance.
Operation
yThe heated toaster is furnished
with a properly grounded cord
connector. Do not attempt to
defeat the grounded connector.
yDo not operate the heated toaster
if it has been damaged or dropped,
if it has a damaged cord or plug,
or if it is not working properly.
yDo not block or cover any
openings on the equipment.
yDo not immerse the cord
or plug in water.
yKeep the cord away from
heated surfaces.
yDo not allow the cord to hang over
the edge of a table or counter.
Maintenance
yDo not use abrasive materials;
they can damage the heated
toaster’s stainless steel nish.
yDo not use corrosive chemicals
in this equipment.
yChlorides or phosphates in
cleaning agents (e.g., bleach,
sanitizers, degreasers, and
detergents) can permanently
damage stainless steel equipment.
The damage is usually in the form
of discoloration, dulling of the metal
surface nish, pits, voids, holes, or
cracks. This damage is permanent
and is not covered by warranty.
yUse only chemical cleaners
that are safe for cast aluminum.
Observe all precautions and
warnings on product labels.
yAlways use a soft, damp cloth
for cleaning. Rinse with clear
water and wipe dry. When
required, always rub in the
direction of metal polish lines.
yRoutine cleaning should be
performed daily with soap,
ammonia detergent, and water.
ySponge stains and hard water
spots with a 50% vinegar solution.
yRub o󰀨 nger marks and
smears using soap and water.
yDo not clean the heated
toaster with a water jet.
Service
yInspection, testing, and
repair of electrical equipment
must be performed only by
qualied service personnel.
yHave the heated toaster serviced
only by qualied personnel.
Contact Antunes Technical
Service for adjustment or repair.
yTurn the power o󰀨, unplug the
power cord, and allow unit
to cool to room temperature
before performing any
service or maintenance.
yIf the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent,
or a similarly qualied person in
order to avoid an electrical hazard.

4P/N 1010772 Rev. H 05/18
DO NOT scratch, chip, or nick the glass.
DO NOT place any metal objects in contact with the glass (merchandise holders, signs,
etc.).
DO NOT transfer coins over the unit.
DO NOT use the glass as a serving counter.
When cleaning, handling, or removing the glass, make sure that the
glass is cool (room temperature).
USE approved cleaners marketed for glass cleaning only.
USE a at surface covered with a soft cloth to place the glass on, if the glass is removed.
USE a clean, soft cloth when cleaning the glass. Do not use paper towels.
USE light pressure when wiping/cleaning the glass.
MAKE SURE that the top cover glass does not touch the edge of the side glass.
MAKE SURE to replace scratched, chipped, nicked, cracked, or broken glass.
Please follow the Safety Instructions below in order to reduce the chance of
damaged/broken glass:
Warning: Mishandling this product or failure to follow these instruc-
tions may result in shattering glass.
Heated Toaster Glass Warnings
(DCH Models)

5
P/N 1010772 Rev. H 05/18
Capacities
DCH-100/DCH-120
yOne 2-1/2” (63.5 mm) deep full size steam table pan.
yOne water tray (some models) at 4 quarts (3.8 liters).
yOne Crumb Tray (some models).
DCH-200/DCH-220
yTwo 2-1/2” (63.5 mm) deep full size steam table pans.
yTwo water trays (some models) at 4 quarts (3.8 liters) each.
yOne Crumb Tray (some models)
DCH-300/DCH-320
yThree 2-1/2” (63.5 mm) deep full size steam table pans.
yTwo water trays at 5 quarts (4.7 liters) each.
Temperature Ranges
DCH-100: 150°-165°F (66°-74°C)
DCH-120: 100°-165°F (38°-74°C)
DCH-200: 150°-165°F (66°-74°C)
DCH-220: 100°-165°F (38°-74°C)
DCH-300: 150°-165°F (66°-74°C)
DCH-320: 100°-165°F (38°-74°C)
Dimensions
A
B
C
Model A B C
DCH-100
DCH-120
15-1/8”
(384 mm)
30-1/4”
(768 mm)
22-13/32”
(569 mm)
DCH-200
DCH-220
30-1/4”
(768 mm)
30-1/4”
(768 mm)
22-13/32”
(569 mm)
DCH-300
DCH-320
42-1/16”
(1068 mm)
30-1/4”
(768 mm)
22-13/32”
(569 mm)
Speccations

6P/N 1010772 Rev. H 05/18
Electrical Ratings
Model Designation
TYPE OF POWER CORD
H = HARMONIZED
C = COMMERCIAL
TYPE OF PLUG
C = CEE 7/7 Schuko
F = NEMA 5-15P
T = NEMA 5-20P
B = BS-1365
DCH-100 XX
DCH-120
DCH-200
DCH-220
DCH-300
DCH-320
Model and
Mfg. #
Voltage Watts Amps Hertz
DCH-100CF
9500500
120 1550 12.9 50/60
DCH-120CF
9500510
120 1550 12.9 50/60
DCH-120CT
9500512
120 1550 12.9 50/60
DCH-200CT
9500520
120 1800 15.0 50/60
DCH-220CT
9500530
120 1760 14.6 50/60
DCH-220CT
9500531
120 1800 15.0 50/60
DCH-220CT
9500532
120 1800 15.0 50/60
DCH-220
9500533
International
Unit
200-240 2050 9.3 -
8.5
50/60
DCH-220
9500537
200-240 2050 9.3 -
8.5
50/60
DCH-220CT
9500534
120 1800 15.0 50/60
DCH-220
9500535
120 1760 14.6 50/60
DCH-220HC
9500536
220-240 2000 8.7 50/60
DCH-220CT
9500538
120 1800 15.0 50/60
DCH-300CT
9500540
120 1800 15.0 50/60
DCH-320CT
9500550
120 1800 15.0 50/60
DCH-320CT
9500551
120 1800 15.0 50/60
DCH-320CT
9500552
120 1800 15.0 50/50
DCH-320
9500553
International
Unit
200-240 2850 14.3 -
11.8
50/60
DCH-320CT
9500554
120 1800 15.0 50/60
DCH-320HC
9500556
220-240 2800 12.2 50/60
DCH-320CT
9500557
120 1800 15.0 50/60
DCH-320HB
9500559
Saudi Arabia
220-240 2800 12.2 50/60
ElectricalCord&PlugCongurations
Letter
Code*
Description Configuration
C
H
Commercial Cord
Harmonized Cord
(H)C*** CEE 7/7, 16 Amp.,
250 VAC (Assembly
Only).
(C)F** 5-15P, 15 Amp., 120
VAC., Non – Locking
(Assembly Only).
WHT BLK
GRN
(C)T** 5–20P, 20 Amp., 120
VAC., Non – Locking
(Assembly Only). WHT BLK
GRN
(H)B BS-1365 - Fused
Permaplug 16
Amp., 250 VAC
* Used in Model Designation
** Indicates that the plug comes with a Commercial Cord.
*** Indicates that the plug comes with a Harmonized Cord.
CAUTION
All electrical connections must be
in accordance with local electrical
codes and any other applicable
codes.

7
P/N 1010772 Rev. H 05/18
Figure 1. Display Components (DCH-100 Shown)
Installation
Unpacking
1. Remove unit and all packing
materials from shipping carton.
2. Open the large box. Remove all
packing materials and protec-
tive coverings from the unit and
parts.
NOTICE: If any parts are missing,
contact A.J Antunes & Co.
IMMEDIATELY at 1-877-392-
7854 in the U.S., or +1-630-
784-1000 outside the U.S..
3. Wash all components in soap
and water. Wipe all surfaces of
the unit with a hot damp cloth.
NOTICE: Do not use a dripping wet
cloth. Wring out before use.
4. Install components in unit.
Equipment Setup
When placing the unit into service,
pay attention to the following guide-
lines:
yMake sure power to the
unit is off and the unit is
at room temperature.
yDo not block or cover any
openings on the unit.
yDo not immerse cord
or plug in water.
yKeep cord away from
heated surfaces.
yDo not allow cord to hang
over edge of table or counter.
yPlace unit on a sturdy, level
table or work surface.
yEnsure that the line
voltage corresponds to the
stated voltage on the unit
specification label located at
the end of the power cord.
yTurn the Rocker Switch (power
On/Off) to OFF. Connect the
unit to the power supply.
Water Tray
(some models)
Heating Element Shield
THIS UNIT IS DESIGNED TO
OPERATE ON 120 VOLTS
ONLY. APPLICATION WITH ANY
OTHER VOLTAGE SUPPLY
COMPLETELY VOIDS ALL
WARRANTY. PLEASE CHECK
YOUR LINE VOLTAGE BEFORE
INSERTING THIS PLUG INTO THE
RECEPTACLE.
WARNING WARNING
120 VAC
ONLY
THIS APPLIANCE MUST BE
EARTHED (GROUNDED)
THIS APPLIANCE MUST BE
EARTHED (GROUNDED)
THIS UNIT IS DESIGNED TO
OPERATE ON 220-240 VOLTS
ONLY. APPLICATION WITH ANY
OTHER VOLTAGE SUPPLY
COMPLETELY VOIDS ALL
WARRANTY. PLEASE CHECK
YOUR LINE VOLTAGE BEFORE
INSERTING THIS PLUG INTO THE
RECEPTACLE.
WARNING WARNING
220-240
VAC ONLY
THIS APPLIANCE MUST BE
EARTHED (GROUNDED)
THIS APPLIANCE MUST BE
EARTHED (GROUNDED)
Crumb Tray
(some models)
Do NOT use with Water
Diffuser
(Only used with Water
Tray)
Heating
Element

8P/N 1010772 Rev. H 05/18
TEMP
UP
TEMP
DOWN
TEMP
SCALE
FC
O
O
WATTS
SERIALNO.
CAROLSTREAMIL60188
MFG.NO.
VOLTS
180KEHOEBOULEVARD
A.J.ANTUNES & CO.
HZ.
DESCRIPTION
FOODEQUIPMENTDIVISION
MODELNO.
CITYOFNEWYORK
ACCEPTEDFORUSE
MEA10-96-E
DCH-320CT
DISPCABINETHEATED
50/60
120~
9500550 XXXXXXXX
1800
DEPARTMENTOFBUILDINGS
Operations and
Programming
NOTICE: Models DCH-120/220/320
have an adjustable tempera-
ture range of 100-165° F (38-
74° C). Since the tempera-
ture can be set below 150°
F (65° C), which is below the
safe holding temperature for
some foods, only NON-MEAT
products should be held in
these units. Models DCH-
100/200/300 have an adjust-
able temperature range of
150-165° F (66-74° C).
For units ONLY equipped with Water
Tray(s) and di󰀨user(s) (Figure 3):
yIf a dry environment is desired,
DO NOT add water to the Water
Trays. If a humid environment is
desired, add water to the Water
Trays as shown in Figure 2. If
more humidity is desired, remove
the Di󰀨users from the Water Trays.
NOTICE: Fogging/Condensation
of the glass may occur if
the Water Trays contain too
much water and/or the Dif-
fusers are not present in the
water trays. Units equipped
with a Crumb Tray (Figure
1) are designed to operate
WITHOUT water.
Figure 2. Filling Water Tray
(DCH-100 shown)
TEMP
UP
TEMP
DOWN
TEMP
SCALE
FC
O
O
The Setpoint temperature is the
desired cabinet temperature setting.
When the Temp UP button is pressed
and held (and provided that the unit
is up to temperature), the actual cab-
inet temperature is displayed. When
the button is released, the Setpoint
temperature is displayed.
1. Turn the unit ON. The display
will ash “LO” to indicate that the
unit is heating up. After 20-30
minutes (when the unit is up to
temperature), the display will
show the setpoint temperature.
2. To adjust the setpoint tempera-
ture, press and hold the Temp Up
and Temp Down buttons until the
display begins to ash. Release
the buttons. Then, press the
Temp Up or Temp Down buttons
to raise or lower the setpoint
temperature. Release when
the display shows the desired
temperature.
3. To change the display from Fahr-
enheit to Celsius and back, press
and hold the Temp Scale button
(Figure 3) for 2-3 seconds and
release.
4. Open the rear door(s) and place
the serving table pan(s) into the
unit (Figure 4). Load the pan(s)
with the food product using tongs
or similar utensil. Close the
door(s).
TEMP
UP
TEMP
DOWN
TEMP
SCALE
FC
O
O
Rocker Switch
(Power On/Off)
Control Panel Key
Pad
NOTE: Back of unit
shown
Figure 3. Controls
Figure 4. Loading Food (DCH-100 Shown)

9
P/N 1010772 Rev. H 05/18
Maintenance
Be sure to follow all of the warnings
and precautions listed in the Import-
ant Safety Information section of
this manual.
WARNING
Turn the unit o󰀨, disconnect the
power source and allow the unit
to cool down before performing
any service or maintenance on
the unit.
CAUTION
Do not remove water pan or-
crumb tray while unit is hot or
burns or other personal injury
may result.
WARNING
All glass surfaces must be cool
before cleaning. Once cool, wipe
glass with a clean cloth. Do not
attempt to clean glass when hot
or with cold towel as shattering
glass may occur.
Daily Cleaning
The unit requires a minimum amount
of maintenance. To ensure proper
operation, clean the unit at the end of
each serving day.
1. Turn unit o󰀨, unplug the power
cord, and allow the unit to cool to
room temperature.
2. Once cooled, remove all compo-
nents.
3. Wash all components in soap
and water. Wipe all surfaces of
the unit with a damp cloth.
NOTICE: Do not use a dripping wet
cloth. Wring the cloth out
before use.
4. Install components in unit.
Parts Replacement
Halogen Bulb Replacement
CAUTION
Do not handle halogen bulbs with
bare hands. Use a tissue or clean
cloth to handle halogen bulbs
CAUTION
Use 1000 Watt (Max.) Quartz
tungsten halogen lamp (T4
Bulb/‘RSC’ Base) only. To reduce
the risk of electric shock when re-
placing bulbs, turn display switch
to OFF position.
1. Turn the unit o󰀨.
2. Unplug the power cord from the
electrical outlet and allow the
unit to cool to room temperature
before proceeding.
3. Gently, but rmly, press the lamp
socket sideways and remove the
bulb (Figure 5).
4. Install a new 100 watt bulb while
pressing the socket sideways.
Make sure bulb is fully seated
before releasing socket.
Figure 5. Halogen Bulb Replacement
Front Display Graphics/
Bulb Replacement
1. Turn the Rocker Switch (Power
On/Off) to OFF
2. Unplug the power cord from
the electrical outlet and allow
the unit to cool to room tem-
perature before proceeding.
3. Using a screwdriver or simi-
lar flat bladed tool, gently pry
one side of the display panel
assembly from the unit (Figure
6), then remove the panel.
4. Remove bulb by gently turning
it counterclockwise. Install a
new 10 watt 120 volt bulb.
5. Install new graphics by remov-
ing the white diffuser plate and
transparency holder. Replace
transparency and reinstall hold-
er and plate.
NOTICE: The Display Panel Assem-
bly is held in place by mag-
netic strips. To remove, care-
fully pry the assembly from
its place using a at-blade
screwdriver or similar tool.
Figure 6. Display Lamp Replace-
ment

10 P/N 1010772 Rev. H 05/18
Rear Door Replacement
DCH-100/120 Models
1. Turn the Rocker Switch (Power
On/O󰀨) to OFF.
2. Unplug the power cord from the
electrical outlet and allow the
unit to cool to room temperature
before proceeding.
3. Open the rear door and lift o󰀨
the Hinge Pins.
4. Place new door on Hinge Pins
and close the door.
DCH-200/220/300/320 Models
1. Turn the Rocker Switch OFF,
unplug the power cord from the
electrical outlet, and allow the
unit to cool to room temperature
before proceeding.
2. Firmly grasp the sides of one
glass door. Lift the door up and
out of the bottom track (Figure
7). Repeat for the other door.
3. Place new door in the inside
upper track. Push up rmly and
slide bottom of door into bottom
inside track. Install other door
into outside tracks the same
way.
CAUTION
Front glass panel replacement
should be performed by two
people to prevent damage to the
glass.
Front Glass Replacement
1. Turn the unit OFF, unplug the
power cord from the electrical
outlet, and allow the unit to cool
to room temperature before
proceeding.
2. Loosen the thumbscrew secur-
ing each Top Glass Retainer
Assembly. Slide the retainer up
and to the rear (Figure 8).
3. Tilt the Front Glass Panel
Assembly forward on the Hinge
Plate and remove the panel
from the unit.
4. To reinstall, be sure the Front
Glass Panel Assembly is
fully seated in the Hinge Plate.
Then, tilt the assembly fully to-
wards the rear and secure it to
the Top Glass Retainer Assem-
bly using the thumb screws.
TEMP
UP
TEMP
DOWN
TEMP
SCALE
FC
O
O
Figure 7. Rear Door(s) Removal/Installation
DCH-200/220/300/320 Models.
Figure 8. Glass Panel (s) Replacement
Top Glass
Retainer
Assy.
Front Glass
Panel
Top Cap
Assy.
Side Glass
Hinge
Plate Nylon
Stopper
Nylon
Stopper
Side Glass Replacement
1. Turn the unit OFF, unplug the
power cord from the electrical
outlet, and allow the unit to cool
to room temperature before
proceeding.
2. Remove the thumbscrews se-
curing each Top Glass Retainer
Assembly. Slide the retainer up
and to the rear.
3. Tilt the Front Glass Panel As-
sembly forward on the Hinge
Plate and remove the assembly
from the unit.
4. Remove each Top Cap Assem-
bly (Figure 8). Next, lift the Side
Glass Panel up and forward to
remove it from the glass clips.
5. To reinstall, position the Side
Glass Panel into glass clips.
Push fully rearward and position
the Nylon Stoppers according
to Figure 8. Reinstall the front
glass panel assembly.
6. Secure with the Top Cap Assem-
bly and Top Glass Retainer As-
sembly using the thumbscrews.

11
P/N 1010772 Rev. H 05/18
Display Codes
This section describes the different display codes and
their meanings.
“LO” flashes during the initial warm up period. The unit
continues to display this code until the unit reaches the
setpoint temperature. When the unit reaches the set-
point temperature, it displays the setpoint temperature.
TEMP
UP
TEMP
DOWN
TEMP
SCALE
F
C
O
O
This figure shows an example setpoint temperature of
150° F displayed on the console.
“HI” flashes if the actual cabinet temperature exceeds
the setpoint temperature or if the thermistor has short-
ed.
NOTE: The thermistor should be 100k ohm +/- 2% at
room temperature.
“OPEN” flashes if the thermistor is OPEN or discon-
nected. The unit will not call for heat.
NOTE: The thermistor should be 100k ohms +/- 2%
at room temperature.
“PO” In 120 VAC units, this code flashes if the sup-
ply voltage is below 100 VAC or above 135 VAC. In
220/240 VAC units, this code flashes if the supply volt-
age is below 190 VAC or above 265 VAC.
NOTE: If voltage is within normal ranges, then the
Control Board is faulty.
To reset a unit in this state, the supply voltage must be
within acceptable limits and the unit must be turned off
for a few seconds and then turned back on.

12 P/N 1010772 Rev. H 05/18
Troubleshooting
WARNING
To avoid possible personal injury and/or damage to the unit, inspection, test and repair of electrical equip-
ment should be performed by qualified service personnel. The unit should be unplugged when servicing.
Problem Possible Cause Corrective Action
No heat, no display, and the
power switch indicator light is
OFF.
Power cord is not plugged in. Plug the power cord into the appropriate outlet.
Circuit breaker is off or has been tripped. Reset circuit breaker, contact your maintenance person or
Authorized Service Agency if it trips again.
No power at receptacle. Contact your maintenance person or Authorized Service
Agency for service.
Inoperable power cord.
Inoperable power switch.
Loose, burnt, broken wiring in the circuit.
No heat, no display, and the
power switch indicator light is
ON.
Inoperable Transformer. Contact your maintenance person or Authorized Service
agency for service.
Inoperable Control Board.
Loose, burnt, broken wiring in circuit.
Display flashes “LO” and the
cabinet does not heat up.
Inoperable Solid State Relay. Contact your maintenance person or Authorized Service
Agency for service.
Inoperable Control Board.
Inoperable Heater(s).
Loose, burnt, broken wiring in circuit.
Display flashes “HI” and the cab-
inet does not heat up.
Inoperable Thermistor. Contact your maintenance person or Authorized Service
Agency for service.
Inoperable control Board.
Display flashes “HI” and the cab-
inet is very hot.
Solid State Relay contacts shorted closed. Contact your maintenance person or Authorized Service
Agency for service.
Inoperable Control Board.
Display flashes “OPEN” and the
cabinet does not heat up.
Thermistor is disconnected or open. Re-secure the Thermistor onto the Control Board. If this
problem persists, contact your maintenance person or
Authorized Service Agency for service.
Inoperable Control Board.
Display flashes “PO” and the
cabinet does not heat up.
For 120 volt units, the supply voltage is below
100 VAC or above 135 VAC.
Contact your maintenance person or Authorized Service
Agency for service.
For 220/240 volt units, the supply voltage is
below 190 VAC or above 265 VAC.
Inoperable Control Board.
Product dries out quickly. Setpoint temperature is set too high. Lower the Setpoint temperature.
Incorrect wattage halogen bulb(s) being used. Use only 100 watt halogen bulb(s).
Water Tray(s) do not contain water or contain
insufficient water (for units equipped with
Water Trays only).
Add water to the Water Trays(s) and/or remove the Water
Tray Diffuser(s).
Toaster glass is fogging up and/
or has condensation.
Water Tray(s) contain too much water and/or
the Water Tray Diffusers are not present (for
units equipped with Water Trays only).
Remove excess water from the Water Tray(s) and/or install
the Water Tray Diffuser(s).
Halogen Bulb(s) do not light up. Bulb(s) burnt out. Replace bulb(s)
Bulb(s) not seated properly into spring loaded
sockets.
Remove and reinstall bulb(s) so that the ends snap into the
socket(s).
Inoperable Resistor Assembly. Contact your maintenance person or Authorized Service
Agency for service.
Loose, burnt, or broken wiring in Circuit.
Inoperable Bulb Sockets(s).
Front Display Graphics does not
light up.
Bulb(s) burnt out. Replace Bulb(s).
Loose, burnt, or broken wiring in circuit. Contact your maintenance person or Authorized Service
Agency for service.

13
P/N 1010772 Rev. H 05/18
Replacement Parts – DCH-100/120
47 18
60
50
61
23
22
50
60
59
19
47
27
47
30
28
32
31
33
35
20
12
55 16
49
53 50
49 15
17
11
13
40
44
52
2
42
43
52
3
1
55
52
4
99
10
5
6
58
7
57
63
21
48
37
64
36
62
8
45
51
34
14
65
56
25
50
39
38
65
26
66
67

14 P/N 1010772 Rev. H 05/18
Replacement Parts List DCH-100/120
Item
No.
Part # Description Qty.
17000365 Front Glass Panel Assy 1
20021057 Inner Lamp Housing Weldment 1
30011107 Resistor Assy. 1
40503046 Housing, Lamp 1
50011102 Rear Door Assy. (Incl. #6, 7, 57, 58) 1
62110139 Hinge, Lift-O󰀨 2
72100145 Knob, Cover 1
80503294 Crumb Tray (Some Models) 1
90503038 Water Tray (Some Models) 1
10 0502172 Heat Shield 1
11 0021315 Control Panel Weldment 1
12
7000346 Temperature Control Display,
150°F-165°F (66°C-74°C) DCH-100 1
7000345 Temperature Control Display,
100°-165°F (38°-74°C), DCH-120 1
13 4010151 Rocker Switch, Power On/O󰀨 120 VAC 1
14 7000645 Side Glass Replacement Kit 1
15 0503948 Heat Sink Assy. 2
16 4010199 Transformer, 120V/12V 1
17 7000652 Relay, Solid State 1
18 7000136 Terminal Block, 3-Pole (Incl. #47 & 60) 1
19 4060341 Terminal Block, 8-Pole 1
20 0504070 Retainer, Glass (See Note) 2
21 0011718 Top Cap Assy., LH** (See Note) 1
0011717 Top Cap Assy., RH** (See Note) 1
22 0502866 Cover, Lamp Housing Bracket 1
23 0502865 Bracket, Lamp 1
25 0700463 Power Cord w/Plug, NEMA 5-15P 1
26 020K110 Gasket Kit, Bottom 1
27 0503990 Lamp, Bulkhead (Mfg# 9500512 Only) 1
0503275 Lamp, Bulkhead 1
28 4060360 Candelabra Lamp Holder 4
30 4060359 Lamp, 120V, 10 Watt 4
31 0900216 Di󰀨user Panel (White) 1
32 2070120 Nipple, 1/8 NPT x 3/8 1
33 0900215 Display Panel (Clear) 1
34
0021056 Display Frame Weldment 1
0021321 Display Frame Weldment
(Mfg# 9500512 Only) 1
35 0503033 Display Frame 1
36 0200202 Magnetic Strip 1
37 5040036 Base Hinge Assy. 1
38 4030305 Heating Element, 120V 1400 Watts 1
39 7000369 Thermistor Replacement Kit 1
40 0503037 Duct, Access Cover 1
42 4060252 Bulb, Quartz Halogen, 100 Watt 1
43 4060189 Bulb, Holder, Quartz 2
Item
No.
Part # Description Qty.
44 0800316 Guard, Lamp 1
45 0400251 Strain Relief w/ Locknut 1
47 306P101* Nut, Hex, #6-32, SS 1
48 306P105* Screw, #6-32 x 1/2, SS 1
49 306P130* Nut, Hex, KEPS, #6-32 1
50 308P103* Screw, #8-32 x 1/4 6
51 308P124* Screw, #8-32 x 1/2, One-Way 1
52 308P127* Screw, #8-32 x 5/16, SS 1
53 308P143* Nut, Hex, KEPS, #8-32 1
54 308P144* Screw, #8-32 x 1/4, #6 Head 2
55 308P159* Thumbscrew, #8-32 x 11/32 1
56 310P146* Nut, Hex, KEPS, #10-32 1
57 310P110* Screw, #10-32 x 1/2, SS 4
58 310P123* Screw, #10-24 x 1/2, SS 1
59 040P111* Snap Bushing 2
60 306P123* Screw, #6-32 x 7/8 2
61 308P151* Screw, #8-32 x 5/16” 1
62 0503044 Di󰀨user, Water Tray (Some Models) 1
63 400K123 Blower Kit 120V (Some Models)
Incudes #66 1
64 0501946 Blower Grill (Some Models) 1
65 2180179 Side Glass Nylon Stopper
(See Note) 2
66 7000174 Blower Cage Bearing/Grommet Kit 1
67 7000106 Display Rack (Optional)
*Only available in packages of 10.
** LH/RH is determined by viewing front of curved glass
panel.
NOTE 1: If the existing 2 Top Glass Retainers (item #20) ARE
NOT rubber coated, it is recommended that you replace them
along with the 2 Top Cap Assemblies (item #21) with Glass
Hardware Kit #7000368.
This kit consists of:
y2 rubber coated Glass Retainers (P/N 0504070)
y1 Top Cap Assembly (RH) (P/N 0011717)
y1 Top Cap Assembly (LH) (P/N 0011718)
y2 Nylon Slide Side Glass Stoppers (P/N 2180179)
y2 Thumbscrews (P/N 3080159)
yInstallation Instructions (P/N 1010828)
NOTICE
Use only genuine Antunes re-
placement parts in this display
cabinet. Use of parts other than
those supplied by the manufactur-
er will void the warranty.

15
P/N 1010772 Rev. H 05/18
Replacement Parts – DCH-200/220
47 18
60
50
61
23
22
50
60
59
19
47
27
47
30
28
32
31
33
35
20
12
55 16
49 53 50
49 15
17
11
13
40
44
52
2
42
43
52
3
1
55
52
4
99
10
5
6
58
7
57
63
21
48
37
64
36
62
8
45
51
34
14
65
56
25
50
39
53
64
46
45
53
48
54
25
26
20
58
21
24
50 18
68
12
16
56
52
15
17
11
13
35
42
43
55
41
66
10
65
9
58
55
50
6
4
55
40
44
23
7
19
52
67
31
32
33
34
30
29
68 62
14
5
22
59
1
39
38
70
37
36
69
27 71a
67
23
71b
66
65
9

16 P/N 1010772 Rev. H 05/18
Replacement Parts List DCH-200/220
Item
No.
Part # Description Qty.
DCH-200
120V
Qty.
DCH-220
120V
Qty.
DCH-220
230V
Qty.
DCH-220
Mfg. #
9500533
1 7000366 Front Glass Panel Assy. 1 1 1 1
2 0020675 Inner Lamp Housing Weldment 1 1 1 1
30010706 Resistor Assy., 120V 1 1 - -
0010644 Resistor Assy., 220V - - 1 1
4 0502895 Housing, Lamp - - 1 1
5 9020459 Display Rack (Optional) - - - -
67000443 Sliding Door Assy., Clear Glass 1 1 1 1
7000445 liding Door Assy., Mirrored, Glass (optional) 1 1 1 1
7 0501820 Support, Center Pan 1 1 1 1
9 0503293 Crumb Tray (some models) - - - -
10 0503283 Heat Shield 1 1 1 1
11 0021453 Control Panel Weldmen 1 1 1 1
12 7000346 Temperature Control Display, 150°F-165°F (66°C-74°C) DCH-200 1 - - -
7000345 Temperature Control Display, 100°F-165°F (38°-74°C), DCH-220 - 1 1 1
13 4010151 Rocker Switch, Power On/O󰀨 (120V) 1 1 - -
4010137 Rocker Switch, Power On/O󰀨 (250V) - - 1 1
14 7000645 Side Glass Replacement Kit 2 2 2 2
15 0020702 Heat Sink Assy 1 1 1 1
16 4010199 Transformer, 120V/12V 1 1 - -
4010187 Transformer, 240V12V - - 1 1
17 7000652 Relay, Colid State. 1 1 1 1
18 7000136 Terminal Block, 3 Pole (incl. #50 & 67) 1 1 1 1
219 4060341 Terminal Block, 8 Pole 2 2 2 2
20 0504070 Retainer, Glass (see Note 1) 2 2 2 2
21 0011718 Top Cap Assy., LH** (see Note 1) 1 1 1 1
0011717 Top Cap Assy., RH** (see Note 1) 1 1 1 1
22 2100183 Door Track, Upper 1 1 1 1
23 2100184 Door Track, Lower 1 1 1 1
24 0501946 Grill, Blower (some models) 1 1 - -
25
0700451 Power Cord w/Plug, NEMA 5-20P 120V 1 1 - -
0700453 Power Cord w/Plug, CEE 7/7 240V
0700556 Power Cord Assembly UK (9500537 Only) - - 1 1
26 020K107 Gasket Kit, Bottom 1 1 1 1
27 0503291 Lamp, Bulkhead (some models) 1 1 - -
0503771 Lamp, Bulkhead (some models) - 1 1 1
29 4060360 Candelabra Lamp Holder 6 6 6 6
30 4060359 Lamp, 120 v/10 Watt 6 6 6 6
31 0900151 Di󰀨user Panel (white) 1 1 1 1
32 0900173 Transparency Holder 1 1 1 1
33
0900150 Display Panel (black outline) Optional 1 1*** - -
0900180 Display Panel (clear) Optional - 1*** - -
0900244 Display Panel (blue outline) - 1 1 1
34 0501797 Display Frame 1 1 1 1
35 400K123 Blower Motor, 120 Volt (some models) Incl #69 1 1 - -
4000194 Blower Motor - - - 1
36 0200154 Magnetic Strip 2 2 2 2
37 5040027 Base Hinge Assy. 1 1 1 1
38 4030324 Heating Element, 120V, 1400 Watts 1 1 - -
4030325 Heating Element, 230V, 1650 Watts - - 1 1
39 7000369 Thermistor Kit 1 1 1 1
40 0501806 Duct, Access Cover 1 - - -
41 0502555 Heat Deector (some models) 1 - - -
42 4060252 Bulb, Quartz Halogen, 100 Watt 2 2 2 2
43 4060189 Bulb Holder, Quartz 4 4 4 4
44 0800224 Guard, Lamp 1 1 1 1

17
P/N 1010772 Rev. H 05/18
Replacement Parts List DCH-200/220 (continued)
Item
No.
Part # Description Qty.
DCH-200
120V
Qty.
DCH-220
120V
Qty.
DCH-220
230V
Qty.
DCH-220
Mfg. #
9500533
45 0502866 Cover, Lamp Housing Bracket 2 2 2 2
46 0502865 Bracket, Lamp Housing 2 2 2 2
48 0400251* Strain Relief w/ Locknut 1 - - -
0400354* 90° Strain Relief - 1 1 1
50 306P101* Nut, Hex, #6-32, SS 1 1 1 1
51 306P105* Screw, #6-32 x 1/2, SS 1 1 1 1
52 306P130* Nut, Hex, KEPS, #6-32 1 1 1 1
53 308P103* Screw, #8-32 x 1/4 6 6 6 6
54 308P124* Screw, #8-32 x 1/2, One-Way 1 1 1 1
55 308P127* Screw, #8-32 x 5/16, SS 1 1 1 1
56 308P143* Nut, Hex, KEPS, #8-32 1 1 1 1
57 308P144* Screw, #8-32 x 1/4 2 2 2 2
58 308P159* Thumbscrew, #8-32 x 11/32 1 1 1 1
59 310P146* Nut, Hex, KEPS, #10-32 1 1 1 1
60 310P110* Screw, #10-32 x 1/2, SS 4 4 4 4
61 310P123* Screw, #10-24 x 1/2, SS 1 1 1 1
62 040P111* Snap Bushing 2 2 2 2
63 308P105* Screw, #8-32 x 1/2, SS 2 2 2 2
64 308P151* Screw #8-32 x 5/16” 1 1 1 1
65 0503280 Di󰀨user, Water Tray (some models) - - - -
66 0503279 Water Tray (some models) - - - -
67 2180179 Side Glass Nylon Stopper 2 2 2 2
68 306P123* Screw, #6-32 x 7/8” 1 1 1 1
69 7000174 Blower Cage Bearing/Grommet Kit 1 1 1 1
70 213K103 Full Size Pan 2-1/2” deep - Non-perforated (optional) - - - -
71
002K853 Pan Adapter Insert (optional)
(accommodates two optional 4” deep full size pans) - - - -
0021348 Pan Adapter Insert - Sloped Version (Optional) - - - -
* Only available in packages of 10
** LH/RH is determined by viewing front of curved glass panel.
*** Mfg. No. 9500535 is shipped with the 0900180 Display Panel and does not include the 0900150 Display Panel.
NOTE 1: If the existing 2 Top Glass Retainers (item #20) ARE NOT rubber coated, it is recommended that you replace them
along with the 2 Top Cap Assemblies (item #21) with Glass Hardware Kit #7000368.
This kit consists of:
y2 rubber coated Glass Retainers (P/N 0504070)
y1 Top Cap Assembly (RH) (P/N 0011717)
y1 Top Cap Assembly (LH) (P/N 0011718)
y2 Nylon Slide Side Glass Stoppers (P/N 2180179)
y2 Thumbscrews (P/N 3080159)
yInstallation Instructions (P/N 1010828)
NOTICE
Use only genuine Antunes re-
placement parts in this display
cabinet. Use of parts other than
those supplied by the manufactur-
er will void the warranty.

18 P/N 1010772 Rev. H 05/18
53
64
46
45
53
48
54
25
26
20
58
21
24
5018
68
12
16
56
52
15
17
11
13
35
42
43
55
41
66
10
65
9
58
55
50
6
4
55
40
44
23
7
19
52
67
31
32
33
34
30
29
68 62
14
5
22
59
1
39
38
70
37
36
69
27 71
67
23
53
46
45
12
16 56
52
15
17
11
13
42
43
55
41
9
69
58
6
4
55
40
44
2
3
7
5
1
39
70
23 7
20
58
22
24
66
53
48
54
25
5018
65
34
31
32
33
29
30
50
37
66
36
35
52
19
35
52
71
71
14
21
34
55
67a
67b
10
65
62
38
8
Replacement Parts – DCH-300/320

19
P/N 1010772 Rev. H 05/18
Replacement Parts List – DCH-300/320
Item
No.
Part # Description Qty.
17000367 Front Glass Assy. 1
20020676 Inner Lamp Housing Weldment 1
0020675 Inner Lamp Housing Weldment
Mfg. No. 9500553 1
30010706 Resistor Assembly - 120V 1
0010644 Resistor Assembly - 230V 1
40502850 Housing, Lamp 2
0502895 Housing, Lamp Mfg. No. 9500553 1
59020469 Display Rack (optional) 1
67000444 Sliding Door Assembly 2
7000975 DCH Mirrored Doors Replacement Kit
(Mfg. No. 9500551 ONLY 2
70501869 Support, Center Pan 2
80504354 Crumb Tray Mfg No. 9500554 & 556
Only) 1
90501866 Water Tray (All Except for Mfg No.
9500554 & 556) 2
10 0502172 Shield, Heat 3
11 0021317 Control Panel Weldment 1
12 7000346 Temperature Control Display,
150°F-165°F (66°C-74°C) 1
7000345 Temperature Control Display,
100°-165°F (38°-74°C) 1
13 4010151 Switch, Rocker 25A-125V 1
4010137 Switch, Rocker 25A-250V 1
14 0900143 Glass, Side 2
15 0020702 Heat Sink Assy. 1
16 4010199 Transformer 120VAC/12VAC 1
4010187 Transformer 230VAC/12VAC 1
17 7000652 Relay, Solid State 1
18 7000136 Terminal Block-3 Pole (Incl. #50 & 65) 1
19 4060341 Terminal Block-8 Pole 2
20 0504070 Glass Retainer (see Note 1) 1
21 0011717 Top Cap Assembly** RH (see Note 1) 1
0011718 Top Cap Assembly** LH (see Note 1) 1
22 2100185 Upper Door Track 1
23 2100186 Lower Door Track 1
24 0501946 Grill, Blower 1
25
0700451 Power Cord w/Plug, NEMA 5-20P
120V 1
0700556 BS-1365 - Fused Permaplug16 Amp.,
250 VAC 1
0700453 Power Cord w/Plug, CEE 7/7 1
26 020K108* Gasket Kit, Bottom 1
27 0503976 Lamp, Bulkhead 1
29 4060360 Lampholder 8
30 4060359 Lamp, Night - 120V, 10 Watts 8
31 0900152 Display Panel (Black Outline) 1
0900181 Display Panel (Clear)
(Mfg. No. 9500556 and 9500557) 1
32 0900174 Transparency Holder 1
33 0900153 Di󰀨user Panel (White) 1
34 0501860 Frame, Display 1
35 400K123 Motor, Blower 120V Incl. #71
(Except Mfg. No. 9500554 & 556) 2
4000194 Blower Motor (Mfg. No. 9500553) 1
36 0200155 Magnetic Strip 2
37 5040028 Base Hinge Assy. 1
38 4030304 Heating Element, 120V, 500 Watts 3
4030239 Heating Element 230 Volts 825 Watts 3
39 7000369 Thermistor Kit 1
40 0501865 Duct Access Cover 1
Item
No.
Part # Description Qty.
41 0502556 Deector, Heat 1
42 4060252 Bulb-Quartz Halogen 100W 2
43 4060189 Bulbholder, Quartz 4
44 0800229 Guard, Lamp 1
0800224 Guard, Lamp Mfg. No. 9500553 1
45 0502866 Cover, Lamp Bracket 2
46 0502865 Bracket, Lamp Housing 2
48
040K251 Strain Relief Kit. (DCH - 300 Only) 1
0400354 °90° Strain Relief *(DCH-320 Only) 1
040K315 Strain Relief Kit (Mfg. # 9500553) 1
50 306P101* Nut, Hex, #6-32, SS 1
51 306P105* Screw, #6-32 x 1/2, SS 1
52 306P130* Nut, Hex, KEPS, #6-32 1
53 308P103* Screw, #8-32 x 1/4 6
54 308P124* Screw, #8-32 x 1/2 1
55 308P127* Screw, #8-32 x 5/16, SS 1
56 308P143* Nut, Hex, KEPS, #8-32 1
57 308P144* Screw, #8-32 x 1/4, #6 Head 2
58 308P159* Thumbscrew, #8-32 x 11/32 1
59 310P146* Nut, Hex, KEPS, #10-32 1
60 310P110* Screw, #10-32 x 1/2, SS 4
61 310P123* Screw, #10-24 x 1/2, SS 1
62 040P111* Snap Bushing 2
63 308P105* Screw, #8-32 x 1/2, SS 2
64 308P151* Screw, #8-32 x 5/16” 1
65 306P123* Screw, #6-32 x 7/8” 1
66 2180179 Side Glass Nylon Stopper 1
67 0021478 Pan Adapter Insert (Optional)
(Slope Version) 1
002K897 Pan Adapter Insert (Optional)
(Non-Slope Version) 1
69 0501966 Di󰀨user, Water Tray 2
70 213K103 Full size pan 2-1/2” Deep (Optional) 1
71 7000174 Blower Cage Bearing & Grommet Kit
(Except Mfg. No. 9500554 & 556) 1
* Only available in packages of 10
** LH/RH is determined by viewing front of curved glass
panel.
NOTE 1: If the existing 2 Top Glass Retainers (item #20)
ARE NOT rubber coated, it is recommended that you replace
them along with the 2 Top Cap Assemblies (item #21) with
Glass Hardware Kit #7000368.
This kit consists of:
y2 rubber coated Glass Retainers (P/N 0504070)
y1 Top Cap Assembly (RH) (P/N 0011717)
y1 Top Cap Assembly (LH) (P/N 0011718)
y2 Nylon Slide Side Glass Stoppers (P/N 2180179)
y2 Thumbscrews (P/N 3080159)
yInstallation Instructions (P/N 1010828)

20 P/N 1010772 Rev. H 05/18
Wiring Diagrams
#WHT
*WHT
#WHT
*WHT
*BLK
SWITCH
POWER
GRN-YEL
GRN
WHT/BLU BLK/BRN
THERMISTOR
HEATER
QUARTZ
LAMP
#BLK
#BLK
YEL
YEL
YEL
YEL
RED
BLK
WHT
BLK
TRANSFORMER
#WHT
*BLK
4
3
S.S.
RELAY
1
2
*BLK
TEMPERATURE
CONTROLLER
T5
T1
T2
T3
T4
T9
T7
T8
BLOWER
M
RESISTOR
#BLK
WHT
WHT
BLK
BLK
WHT
BLK
WHT
DISPLAY LAMPS
BLK
#BLK
*GRN
BLOCK #1
TERMINAL
GND
CORD
POWER
+-
*14 GA. TFE 200°
#18 GA. TFE 200°
TERMINAL
BLOCK #2
#WHT
*WHT
#WHT
*WHT
*BLK
SWITCH
POWER
GRN-YEL
GRN
WHT/BLU BLK/BRN
WHT
BLK
WHT
BLK
BLK WHT WHT
DISPLAY LAMPS
THERMISTOR
BLK
HEATER
QUARTZ
LAMP
#BLK
#BLK
YEL
YEL
YEL
YEL
RED
BLK
WHT
BLK
TRANSFORMER
#WHT
*BLK
4
3
S.S.
RELAY
1
2
*BLK
WHT
WHT
BLK
BLK
TEMPERATURE
CONTROLLER
T5
T1
T2
T3
T4
T9
T7
T8
#WHT
#BLK
BLOWER
M
RESISTOR
RESISTOR
#BLK
#BLK
(OPTIONAL)
BLOCKS
TERMINAL
*GRN
BLOCK #1
TERMINAL
GND
CORD
POWER
+-
*14 GA. TFE 200°
#18 GA. TFE 200°
BLOCKS
TERMINAL
1 2
5
4
#WHT *WHT
#WHT
*WHT
*BLK
SWITCH
POWER
GRN-YEL
GRN
WHT/BLU BLK/BRN
WHT
BLK
WHT
BLK
WHT BLK
DISPLAY LAMPS
THERMISTOR
HEATER
QUARTZ
LAMP
#BLK
#BLK
YEL
YEL
YEL
YEL
RED
BLK
WHT
BLK
TRANSFORMER
#WHT
*BLK
4
3
S.S.
RELAY
1
2
*BLK
WHT
WHT
BLK
BLK
TEMPERATURE
CONTROLLER
T5
T1
T2
T3
T4
T9
T7
T8
RESISTOR
RESISTOR
#BLK
WHT
BLK
BLK
BLK
LAMP
QUARTZ
WHT
BLOCKS
TERMINAL
*GRN
BLOCK #1
TERMINAL
GND
CORD
POWER
+-
*14 GA. TFE 200°
#18 GA. TFE 200°
BLOCKS
TERMINAL
#WHT
*WHT
#WHT
BLOCKS
TERMINAL
*WHT
*BLK
*GRN
SWITCH
POWER
BLOCK #1
TERMINAL
GND
GRN-YEL
GRN
WHT/BLU BLK/BRN
CORD
POWER
BLK
WHT
BLK
WHT
WHT BLK BLK
DISPLAY LAMPS
THERMISTOR
WHT
HEATER #1
QUARTZ
LAMP
#BLK
#BLK
YEL
YEL
YEL
YEL
RED
BLK
WHT
BLK
TRANSFORMER
#WHT
*BLK
4
3
S.S.
RELAY
1
2
*BLK
*14 GA. TFE 200°
#18 GA. TFE 200°
BLK
BLK
WHT
WHT
TEMPERATURE
CONTROLLER
T5
T1
T2
T3
T4
T9
T7
T8
#BLK
#WHT
BLOWER Optional
M
BLOCKS
TERMINAL
RESISTOR
RESISTOR
BLK
BLK
BLOWER Optional
M
BLK
BLK
WHT
HEATER #2 HEATER #3
*WHT *BLK
*BLK
*WHT
+-
DCH-100/120 (120 Volt Units) DCH-200/220 (120 Volt Units)
DCH-220 (220/240 Volt Units) DCH-300/320 (120 Volt Units)
