APS iBoard IB-R905 User manual

iBoard
®
Customer Support: [e-mail]
Rev. 20220301
1
iBoard® by APS PART#: IB-R905/R906
READ INSTRUCTIONS CAREFULLY BEFORE START ING
INSTALLATION. REMOVE CONTENTS FROM BOX AND
VERIFY ALL PARTS ARE PRESENT. ASSISTANCE IS
RECOMMENDED.
*ROCKER PANEL MOUNT
*NO DRILLING REQUIRED
Fastener Size Tightening Torque (ft-lbs) Required
6mm 6-7 √
8mm 16-18 √
10mm 31-32 X
12mm 56-58 X
14mm 92-94 X
Front
Driver Passenger
1#
1#
1#
1#
1#
1#
1#
1#

iBoard
®
Customer Support: [e-mail]
Rev. 20220301
2
Item QTY Description Item QTY Description
1# 8Mounting Brackets 4# 16 M8 Lock Washers
2# 16 M8X1.25-20mm Hex Bolts 5# 12 M8 Hex Nuts
3# 16 M8 Large Flat Washers
3 #
2 # 4 # 5 #
2#
1# 3#
Hardware Package B (For Step Bar Installation)
Item QTY Description Item QTY Description
1# 16 M6X1-20mm Square Head Bolts 3# 16 M6 Nylon Lock Nuts
2# 16 M6 Large Flat Washers

iBoard
®
Customer Support: [e-mail]
Rev. 20220301
3
STEP 1
Starting on the driver side front of the vehicle. Attach Driver
Front Mounting Bracket as shown, (Fig 1). Do not fully tighten
hardware at this time.
Note: (8) Mounting Brackets are universal.
STEP 2
Move to Driver side other 3 mounting locations. Repeat Step 1
to install the Mounting Brackets. Do not fully tighten hardware
at this time.
Front
(Fig 1) Driver Front Mounting Bracket Installation
Models without factory bolt:
(1) M8X1.25-20mm Hex Bolt
(1) M8 Lock Washer
(1) M8 Large Flat Washer
Models with factory bolt:
(1) M8 Large Flat Washer
(1) M8 Lock Washer
(1) M8 Hex Bolt
(1) M8X1.25-20mm Hex Bolt
(2) M8 Large Flat Washers
(1) M8 Lock Washer
(1) M8 Hex Bolt

iBoard
®
Customer Support: [e-mail]
Rev. 20220301
4
STEP 4
Level and adjust the Running Board and fully tighten all hard-
ware.
Important: Please follow the recommended Tightening Tor-
ques shown in the table on page 1. Don’t over tighten, or
the nuts/bolts will be damaged.
Attention
Do periodic inspections to the installation to make sure
that all hardware is secure and tight.
In order to protect your bars/boards, please use mild
soap/non-abrasive products for cleaning only.
STEP 5
Repeat Steps 1-4 for the other side Running Board installation.
The installation is completed.
(Fig 3) Running Board Installed Onto Mounting Bracket
(2) M6X1-20mm Square Head Bolts
(2) M6 Large Flat Washers
(2) M6 Nylon Lock Nuts
STEP 3
Once all (4) mounting brackets are installed. Select a Running
Board. Slip (4) M6X1-20mm Square Head Bolts into each bot-
tom channel, (Fig 2). Carefully position the Running Board onto
the (4) Mounting Brackets. Attach the Running Board to each
Mounting Bracket with (2) M6X1-20mm Square Head Bolts, (2)
M6 Large Flat Washers and (2) M6 Nylon Lock Nuts, (Fig 3).
Do not fully tighten at this time.
IMPORTANT: Do not slide the Running Board on the Brackets
or the bottom surface of the board will be damaged.
(Fig 2) Slip M6X1-20mm Square Head Bolts Into
The Bottom Channels
M6X1-20mm Square Head Bolts
