APS iBoard IB-192A-B User manual

iBoard®
Customer Support: [email protected]
Rev. 20210301
1
iBoard® by APS
PART#: IB-192A-B
PART LIST
*BODY FRAME MOUNT
*DRILLING IS REQUIRED/ CUTTING IS REQUIRED
Fastener Size Tightening Torque (ft-lbs)
6mm 6-7
8mm 16-18
10mm 31-32
12mm 56-58
14mm 92-94
Front
READ INSTRUCTIONS CAREFULLY BEFORE
START ING INSTALLATION. REMOVE CONTENTS
FROM BOX AND VERIFY ALL PARTS ARE PRE-
SENT. ASSISTANCE IS RECOMMENDED.
Driver Front Mounting
Bracket (DFM)
Driver Rear Mounting
Bracket (DRB)
Passenger Front Mounting
Bracket (PFM)
Passenger Rear Mounting
Bracket (PRB)
Driver Front Support
Bracket (DFS)
Passenger Front Support
Bracket (PFS)
Driver Front Bar
Bracket (DFB)
Passenger Front Bar
Bracket (PFB)

iBoard®
Customer Support: [email protected]
Rev. 20210301
2
M6X1-20mm
Square Head Bolt
X8
M6 Large Flat
Washer
X8
STEP 1
M6X1 Nylon
Lock Nut
X8
M8 Hex Nut
X2
M10X1.5-
35mm Hex Bolt
X6
M10 Lock Washer
X10
Start installation from the driver side front of the vehicle. Locate
the (3) factory holes (1 round and 2 oval holes).
In the bottom of the left front floor panel, (Fig 1). Insert (1)
M10X40 Bolt Plate into the smaller, (inner), oval hole and feed
the threaded end back out through the larger, (outer), oval hole,
(Fig 2). Next, insert (1) M10X40 Bolt Plate into the oval hole in
the bottom of the inner frame channel, (Fig 3).
M10X35 Bolt Plate
X2 M10 Hex Nut
X12
M8 Large Flat
Washer
X4
X18
M10 Large Flat
Washer
(Fig 1) Driver Side Front Mounting Location Pictured
(Fig 3) Insert (1) M10X40 Bolt Plate Into The Bottom Of The Inner
Frame Channel
M10X40 Bolt Plate
X4
M8X1.25-
35mm Hex Bolt
X2
M8 Lock Washer
X2
Front
Front
(Fig 2) Insert (1) M10X40 Bolt Plate Into The Inner Small Oval
Hole
Front
Driver Side Inner
Frame Channel
M10X40 Bolt Plate

iBoard®
Customer Support: [email protected]
Rev. 20210301
3
(Fig 4) Driver Front Mounting Bracket Assembly
STEP 2
Select the Driver Front Mounting Bracket (DFM) and the Driver
Front Bar Bracket (DFB). Bolt the Bar Bracket to the back of the
Mounting Bracket with the included (2) M10X1.5-35mm Hex
Bolts, (4) M10 Large Flat Washers, (2) M10 Lock Washers and
(2) M10 Hex Nuts, (Fig 4). Do not fully tighten hardware at this
time.
Then, attach the assembled driver side front Bracket to the (2)
M10X40 Bolt Plates with the included (2) M10 Large Flat Wash-
ers, (2) M10 Lock Washers and (2) M10 Hex Nuts, (Fig 5). Do
not fully tighten hardware at this time.
STEP 3
Front
Next, select the Driver Front Support Bracket (DFS), (Fig 6).
Attach the Support Bracket to the front side of the Driver Front
Bar Bracket with (1) M10X1.5-35mm Hex Bolt, (2) M10 Large
Flat Washers, (1) M10 Lock Washer and (1) M10 Hex Nut, (Fig
6). Do not fully tighten hardware at this time.
(Fig 6) Driver Front Support Bracket Assembly
(2) M10X1.5-35mm Hex Bolts
(4) M10 Large Flat Washers
(2) M10 Lock Washers
(2) M10 Hex Nuts
(Fig 5) Driver Front Mounting Bracket Installation
(2) M10X40 Bolt Plates
(2) M10 Large Flat Washers
(2) M10 Lock Washers
(2) M10 Hex Nuts
DFM
DFS
DFB
DFB
STEP 4
Move to driver side rear mounting location. Locate the large
oval slot in the floor panel. Insert (1) M10x35 Bolt Plate into the
slot, (Fig 7). NOTE: Rotate the Bolt Plate so that the plate is
across, not inline with the oval hole.
Attach the Driver Rear Mounting Bracket (DRB) to the M10x35
Bolt Plate with (1) M10 Lock Washer and (1) M10 Hex Nut, (Fig
8). NOTE: A deep socket is required to tighten the Hex Nut up
into the Bracket. Do not fully tighten hardware at this time.
(1) M10X1.5-35mm Hex Bolt
(2) M10 Large Flat Washers
(1) M10 Lock Washer
(1) M10 Hex Nut
DFM
Front
Front

iBoard®
Customer Support: [email protected]
Rev. 20210301
4
(Fig 8) Driver Rear Mounting Bracket Installation
(1) M10 Lock Washer
(1) M10 Hex Nut
(Fig 7) Insert (1) M10x35 Bolt Plate Into The Slot
Rear
M10X35 Bolt Plate
Rear
STEP 5
Select a Running Board. Slip (2) M6X1-20mm Square Head
Bolts into each bottom channel (Fig 9). Carefully position the
Running Board onto the (2) Mounting Brackets.
IMPORTANT: Do not slide the Running Board on the Brackets
or the bottom surface of the board will be damaged. Attach the
Running Board to each Mounting Bracket with (2) M6x1-20mm
Square Head Bolts, (2) M6 Large Flat Washers and (2) M6 X1
Nylon Lock Nuts (Fig 10). Do not fully tighten at this time.
(Fig 9) Slip M6X1-20mm Square Head Bolts Into The Bottom
Channels
STEP 6
With the Running board Bracket hardware loose, pull the Brack-
ets outward away from the vehicle for proper clearance.
STEP 7
Line up the Driver Front Support Bracket (DFS) with the back of the
pinch weld, (Fig 11). Push the Support Bracket up as high as possi-
ble to where the pinch weld meets the floor panel. Do not fully tight-
en hardware.
Check the Running Board for level. Once properly aligned and ad-
justed, tighten all hardware. IMPORTANT: If the Support Bracket is
too low and close to the edge of the pinch weld, loosen the Support
Bracket and front Bracket hardware. Push the Bracket and Support
Bracket up a little into position against the floor panel and away from
the edge of the pinch weld, (Fig 11). Level and adjust the Running
Board properly and tighten all hardware.
(Fig 10) Running Board Installed Onto the Mounting Bracket
(2) M6X1-20mm Square Head Bolts
(2) M6 Large Flat Washers
(2) M6X1 Nylon Lock Nuts

iBoard®
Customer Support: [email protected]
Rev. 20210301
5
STEP 10
Level and adjust the Running Board and fully tighten all hard-
ware.
STEP 11
Repeat Steps 1-10 for other side Running Board installation.
The installation is completed (Fig 13).
(Fig 13) Installation Completed
Attention
Do periodic inspections to the installation to make sure
that all hardware is secure and tight.
In order to protect your bars/boards, please use only
mild soap/non-abrasive products for cleaning.
STEP 8
Use the hole in the Support Bracket as a guide to mark the drill-
ing location on the back of the pinch weld, (Fig 11). Once you
have marked the location, temporarily remove the Sidebar, the
front Mounting Bracket and Support Bracket. Remove the plas-
tic clips securing the plastic rocker cover to the rocker panel.
Use a 5/16” drill bit and carefully drill the marked location.
NOTE: The plastic rocker panel cover may need to be trimmed
to clear the hex bolt for the Support Bracket. IMPORTANT: Any
cutting or drilling tool may break or shatter. Government regula-
tions require safety glasses & equipment at all times when cut-
ting or drilling.
Fig 11
Drill 5/16" Hole Through Marked Spot
On Pinch Weld. Do Not Drill Close To
The Edge Of The Pinch Weld
DFS
STEP 9
Re-install the driver side front Mounting Bracket and Support
Bracket. Attach the Support Bracket to the pinch weld with (1)
M8X1.25-35mm Hex Bolt, (2) M8 Large Flat Washers, (1) M8
Lock Washer and (1) M8 Hex Nut, (Fig 12). NOTE: Insert the
M8 Hex Bolt with (1) M8 Large Flat Washer through the pinch
weld first, then through the Bracket.
Cut the rocker panel cover as required and reinstall the cover
with the factory plastic clips. Reinstall the Running Board.
(Fig 12) Driver Front Support Bracket Installation
Front
(1) M8X1.25-35mm Hex Bolt
(2) M8 Large Flat Washers
(1) M8 Lock Washer
(1) M8 Hex Nut
Front
