Ares Gamma 370 Pro User manual

1














Wingspan:38.6in(980mm)
Length:30.6in(775mm)
WeightwithBattery: 16.0oz(455g)
Battery:1000mAh2S7.4VLiPo(includedwithRTF,requiredforRFR)
Charger:DC2S7.4VLiPoBalancingandACadapter(includedwith
RTF,requiredforRFR)
Transmitter:6‐channel2.4GHz(includedwithRTF,requiredforRFR)
On‐BoardElectronics:Receiver(installedinRTF,requiredforRFR),ESCand
2servos(installedinRTFandRFR)
S
p
ecifications
Instruction Manual

2

Specifications......................................................................................................................................1 

SafetyPrecautionsandWarnings.............................................................................................................3
FCCInformation........................................................................................................................................4
Gamma370RTF(Ready‐To‐Fly)Contents................................................................................................5
Gamma370RFR(Ready‐For‐Receiver)Contents.....................................................................................5
RequiredtoComplete...............................................................................................................................6
InstallingtheReceiver(ForRFRVersionOnly).........................................................................................6
BeforetheFirstFlightChecklist(RTFVersionOnly).................................................................................7
LiPoBatteryWarningsandUsageGuidelines..........................................................................................8
ChargingtheLiPoFlightBattery.............................................................................................................10
AssemblingtheWing..............................................................................................................................13
InstallingtheHorizontalandVerticalTails.............................................................................................15
InstallingtheLandingGear.....................................................................................................................16
TransmitterDetails.................................................................................................................................17
InstallingtheTransmitterBatteries........................................................................................................18
InstallingtheLiPoFlightBattery.............................................................................................................19
CenteringtheControlSurfaces..............................................................................................................20
InstallingthePropeller/PropSaver........................................................................................................23
AttachingtheWing.................................................................................................................................27
FlightControlsandTrimming.................................................................................................................29
SelectingaFlyingAreaandFlyingConditions........................................................................................32
ESC(ElectronicSpeedControl)Arming..................................................................................................33
FlightChecklist........................................................................................................................................34
Flying.......................................................................................................................................................35
TransmitterandReceiverBinding/Linking.............................................................................................38
OptionalBrushlessPowerSystem..........................................................................................................38
OptionalAileron(Aerobatic)WingSet...................................................................................................45
Repairs....................................................................................................................................................51
ReplacementPartsList...........................................................................................................................52
Warranty,SupportandService..............................................................................................................53
AMANationalModelAircraftSafetyCode.............................................................................................53


Table of Contents

3



TheAres™[air‐eez]Gamma370offersstabilityanddurabilityperfectforfirst‐timepilots
whilealsodeliveringthesmoothandcapableflightperformanceexperiencedsportflyerswill
enjoy.TheadvancedEPOfoamairframedesignisnotonlylightweight,durableandeasyto
repair,italsoarrivesfactory‐assembledandnearlyready‐to‐flyrightoutoftheboxsoyoucan
beflyingatalocalpark,schoolyardorflyingfieldinalmostnotimeatall.

Also,unlikeothersimilarclassmodelsthatrequiresignificantmodificationsandexpenseto
upgradetobrushlesspowersystemsoraileroncontrol,theGamma370isdesignedsoit’s
readyforboth.TheveryaffordableBrushlessPowerSystemUpgradeCombo(AZS1227)
includesabrushlessESCplusapowerful370brushlessmotorandmountthatinstalleasilyin
minutes.Andforfull4‐channelcontrolandaerobaticcapabilitytheoptionalaileron‐equipped
wingset(AZS1226)canbemountedinplaceofthestandardwingwithouttheneedforany
modifications.

TheGamma370isavailableinRTF(Ready‐To‐Fly)andRFR(Ready‐ForReceiver)versionsthat
includeafactory‐installed370‐motorequippedpowersystem,ESCand9‐gramsub‐micro
servos.TheRFRversionisreadyforyoutoinstallareceivercompatiblewithyourfavorite
transmitterwhiletheRTFversionincludeseverythingneededtoflyrightoutofthebox.From
AAbatteriesforthe6‐channel2.4GHztransmitteranda6‐channelreceivertothe1000mAh
2S7.4VLiPobattery,DCbalancingchargerandACadapterthere’snothingextratobuy!

AndalthoughtheGamma370isnearlyready‐to‐flyrightoutthebox,pleasetakethetimeto
readthroughthismanualforinformationaboutbatterysafetyandcharging,controlchecks
andmorebeforemakingyourfirstflight.Pleasealsovisitourwebsiteat
www.Ares‐RC.comforadditionalinformationincludingproductupdates,bulletins,videosand
more.




Failuretousethisproductintheintendedmannerasdescribedinthefollowinginstructions
canresultindamageand/orpersonalinjury.ARadioControlled(RC)airplane/helicopteris
notatoy!Ifmisuseditcancauseseriousbodilyharmanddamagetoproperty.

Keepitemsthatcouldbecomeentangledinthepropeller/rotorbladesawayfromthe
propeller/rotor,includinglooseclothing,tools,etc.Beespeciallysuretokeepyourhands,
faceandotherpartsofyourbodyawayfromthepropeller/rotorblades.

Introduction
Safet
y
Precautions and Warnin
g
s

4
Astheuserofthisproductyouaresolelyandwhollyresponsibleforoperatingitinamanner
thatdoesnotendangeryourselfandothersorresultindamagetotheproductorthe
propertyofothers.

Thismodeliscontrolledbyaradiosignalthatissubjecttopossibleinterferencefromavariety
ofsourcesoutsideyourcontrol.Thisinterferencecancausemomentarylossofcontrolsoitis
advisabletoalwayskeepasafedistancefromobjectsandpeopleinalldirectionsaroundyour
modelasthiswillhelptoavoidcollisionsand/orinjury.

•Neveroperateyourmodelifthevoltageofthebatteriesinthetransmitteristoolow.
•Alwaysoperateyourmodelinanopenareaawayfromobstacles,people,vehicles,
buildings,etc.
•Carefullyfollowthedirectionsandwarningsforthisandanyoptionalsupport
equipment(chargers,rechargeablebatteries,etc.).
•Keepallchemicals,smallpartsandallelectroniccomponentsoutofthereachof
children.
•Moisturecausesdamagetoelectroniccomponents.Avoidwaterexposuretoall
electroniccomponents,parts,etc.notspecificallydesignedandprotectedforusein
water.
•Neverlickorplaceanyportionofyourmodelinyourmouthasitcouldcauseserious
injuryorevendeath.




Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwo
conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemust
acceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.

Caution:Changesormodificationsnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser’sauthoritytooperatetheequipment.

Thisproductcontainsaradiotransmitterwithwirelesstechnologywhichhasbeentestedand
foundtobecompliantwiththeapplicableregulationsgoverningaradiotransmitterinthe
2.400GHzto2.4835GHzfrequencyrange.

Theassociatedregulatoryagenciesofthefollowingcountriesrecognizethenoted
certificationsforthisproductasauthorizedforsaleanduse:USA



FCC Information

5




ItemDescription

NotAvailableSeparately....Gamma370RTFAirframe
AZS1208AMD2...................6HPA6‐ChannelHPAirplaneTransmitter,Mode2
NotAvailableSeparately....AABatteries(8)
AZSB10002S20T.................1000mAh2‐Cell/2S7.4V20CLiPoBattery,TamiyaConnector
AZSC205C...........................205C2‐Cell/2S7.4VLiPo,0.5ADCBalancingCharger
AZSC1205PS.......................1205PS100‐120VACto12VDCAdapter,0.5‐AmpPowerSupply







ItemDescription

NotAvailableSeparately....Gamma370RFRAirframe

Gamma 370 RTF (Read
y
-To-Fl
y
) Contents
Gamma 370 RFR (Read
y
-For-Receiver) Contents

6




TheGamma370RTF(Ready‐To‐Fly)versionincludeseverythingneededtoflyrightoutofthe
box.There’snothingextratobuyorprovide!

TheGamma370RFR(Ready‐For‐Receiver)versionrequiresthefollowingitems:

3+channeltransmitter(withsuitablerangefora‘parkflyer’classmodel)

3+channelreceiver(compatiblewiththetransmitterthatwillbeused)

2‐Cell/2S7.4V800–1300mAhLiPobattery(15+Ccontinuousdischargeratecapable)

LiPobatterycharger(compatiblewiththebatterythatwillbeused)





Usetheincludedadhesive‐backed‘hook‐and‐loop’materialtoinstallthereceiver(not
includedwiththeRFRversion)compatiblewiththetransmitteryou’vechosentouse.Install
thereceiveronthesideofthefuselageoppositeoftheESC.Plugthe3‐wireleadfromtheESC
intothe‘throttle’channelandtheelevatorservoleadintothe‘elevator’channelonthe
receiver.

NOTE:It’simportanttoensurecorrectpolaritywhenpluggingtheleads/connectorsinto
thereceiver.Refertothemarkingsonthereceiver(orthemanualforthereceiver)to
identifywhichpinsaccepttheblackcolor(negative/ground),redcolor(positive)andwhite
color(signal)wireleads.Also,dependingonthemake/modelofreceiveritmaybe
necessarytoslightly‘bevel’theedgesoftheblackcolorconnectorssotheyfiteasilyinto
thecaseofthereceiver.WerecommendusingasmallfileorsandingblockandEXTREME
CAREtobeveltheappropriateedgesoftheconnectorsasneeded.

Wealsosuggestpluggingtherudderservoleadintothe‘aileron’channelonthereceiver.It’s
typicaltousethe‘aileron’controlstick/channeltocontroltherudderfor‘3‐channel’models
equippedwitharudderforprimary‘turning’control.Thishelpstoensureaneasiertransition
tocontrolling‘4‐channel’modelsequippedwithaileronslateron.

Re
q
uired to Com
p
lete
Installin
g
the Receiver (For RFR Version Onl
y
)

7





PLEASENOTE:ThischecklistisNOTintendedtoreplacethecontentincludedinthis
instructionmanual.Althoughitcanbeusedasaquickstartguide,westronglysuggest
readingthroughthismanualcompletelybeforeproceeding.

Removeandinspectallcontents
BeginchargingtheLiPoflightbattery(connectittotheDCbalancingcharger)
Assemble/installthewing,tailsandlandinggear
Installtheeight(8)AAbatteriesinthetransmitter
InstalltheLiPoflightbatteryintheairplane(afterit’sbeenfullycharged)
Testthecontrolstoconfirmproperoperation
Familiarizeyourselfwiththecontrols
Installthepropeller
Findasuitableareaforflying
Before the First Fli
g
ht Checklist (RTF Version Onl
y
)

8


IMPORTANTNOTE:LithiumPolymer(LiPo)batteriesaresignificantlymorevolatilethanthe
alkaline,NiCdandNiMHbatteriesalsousedinRCapplications.Allinstructionsand
warningsmustbefollowedexactlytopreventpropertydamageand/orpersonalinjuryas
mishandlingofLiPobatteriescanresultinfire.

Byhandling,chargingorusingtheincludedLiPobatteryyouassumeallrisksassociated
withLiPobatteries.Ifyoudonotagreewiththeseconditions,pleasereturnyourcomplete
productinnew,unusedconditiontotheplaceofpurchaseimmediately.

Andalthoughthe1000mAh2‐Cell/2S7.4V20CLiPoBattery(AZSB10002S20T)includedwith
theGamma370RTFversionisintendedtobechargedsafelyusingtheincluded205C2‐
Cell/2S7.4VLiPo,0.5ADCBalancingCharger(AZSC205C),youmustreadthefollowing
safetyinstructionsandwarningsbeforehandling,chargingorusingtheLiPobattery.

•YoumustchargetheLiPobatteryinasafeareaawayfromflammablematerials.
•NeverchargetheLiPobatteryunattendedatanytime.Whenchargingthebattery
youshouldalwaysremaininconstantobservationtomonitorthechargingprocess
andreactimmediatelytoanypotentialproblemsthatmayoccur.
•Afterflying/dischargingthebatteryyoumustallowittocooltoambient/room
temperaturebeforerecharging.Also,itisNOTnecessaryorrecommendedto
dischargethebattery‘completely’beforecharging(LiPobatterieshaveno‘memory’
andit’ssafetochargepartiallydischargedbatterieswhenusinganappropriate
chargerandsettings).
•Tochargethebatteryyoumustuseonlytheincluded205C2‐Cell/2S7.4VLiPo,0.5A
DCBalancingCharger(AZSC205C)orasuitablycompatibleLiPobatterycharger.
Failuretodosomayresultinafirecausingpropertydamageand/orpersonalinjury.
DONOTuseaNiCdorNiMHcharger.
•Ifatanytimeduringthechargeordischargeprocessthebatterybeginstoballoonor
swell,discontinuechargingordischargingimmediately.Quicklyandsafely
disconnectthebatterythenplaceitinasafe,openareaawayfromflammable
materialstoobserveitforatleast15minutes.Continuingtochargeordischargea
batterythathasbeguntoballoonorswellcanresultinafire.Abatterythathas
balloonedorswollenevenasmallamountmustberemovedfromservice
completely.
•Storethebatterypartiallycharged(approximately50%charged/3.85Vpercell),at
roomtemperature(approximately68–77°Fahrenheit[F])andinadryareaforbest
results.
LiPo Batter
y
Warnin
g
s and Usa
g
e Guidelines

9
•Whentransportingortemporarilystoringthebattery,thetemperaturerangeshould
befromapproximately40–100°F.Donotstorethebatteryormodelinahotgarage,
carordirectsunlightwheneverpossible.Ifstoredinahotgarageorcarthebattery
canbedamagedorevencatchfire.
•Donotover‐dischargetheLiPoflightbattery.DischargingtheLiPoflightbatterytoa
voltagethatistoolowcancausedamagetothebatteryresultinginreducedpower,
flightdurationorfailureofthebatteryentirely.

LiPocellsshouldnotbedischargedtobelow3.0Veachunderload.Inthecaseofthe
2‐Cell/2S7.4VLiPobatteryusedtopowertheGamma370youwillnotwanttoallow
thebatterytofallbelow6.0Vduringflight.

Theincluded20‐AmpBrushedMotorESC(AZS1210)featuresa‘soft’lowvoltage
cutoff(LVC)thatsmoothlyreducespowertothemotor(regardlessofthepower
levelyouhavesetwiththeleft‐hand/throttlestick)toletyouknowthevoltageof
thebatteryisclosetothe6.0Vminimum.However,evenbeforethisreductionin
power,ifyoufindthatmorethanthetypicalamountofthrottle/powerisrequired
tocruiseorclimbyoushouldlandthemodelanddisconnectthebatteryimmediately
topreventover‐discharge.

AndwhileitispossibletocontinueflyingthemodelafterthesoftLVCoccurs,thisis
NOTrecommended.Continueddischargingcanresultinreachingthe5.0V‘hard’LVC
whichmaycausepermanentdamagetotheLiPobatteryresultinginreducedpower
andflightdurationduringsubsequentfights(orfailureofthebatteryentirelywhich
isnotcoveredunderwarranty).

Also,itisnotrecommendedthatyouflytothesoftLVCeverytimeyoufly.Instead
youshouldbeawareofthepowerlevelofthebattery/airplanethroughoutthe
flight,andifatanytimetheairplanebeginstorequiremorethrottle/powerthan
typicaltomaintaincruiseorclimbyoushouldlandtheairplaneanddisconnectthe
LiPobatteryimmediately.ConstantlydischargingthebatterytothesoftLVCcanstill
causepermanentdamagetothebatterysoit’sbesttouseatimerorstop‐watchto
timethedurationofyourflightsandtostopflyingatareasonabletimebeforethe
softLVCisreached.

IMPORTANTNOTE:DONOTLEAVETHELIPOBATTERYCONNECTEDTOTHEESC
UNLESSYOUAREREADYTOFLY.IFTHEBATTERYISLEFTCONNECTEDTOTHEESC
WHENITISNOTINUSETHELIPOBATTERYWILLBEOVER‐DISCHARGEDBYTHE

10
SMALLAMOUNTOFCURRENTTHEESCCONSUMES.Itcansometimestakeafew
hoursorevenuptoafewdaystoover‐dischargethebatterythiswaybutdoingso
willlikelycausepermanentdamagetoorfailureofthebatteryentirely(whichisnot
coveredunderwarranty).




FortheGamma370RTFversionyoumustchargetheincluded1000mAh2‐Cell/2S7.4V20C
LiPoBattery(AZSB10002S20T)usingonlytheincluded205C2‐Cell/2S7.4VLiPo,0.5ADC
BalancingCharger(AZSC205C)orasuitablycompatibleLiPobatterycharger.Chargingthe
LiPobatteryusinganon‐LiPobatterycompatiblecharger(suchasaNiCdorNiMHbattery
charger),orevenadifferentLiPobatterychargerwiththeincorrectsettings,mayresultin
damagetothebatteryorevenfireresultinginpropertydamageand/orpersonalinjury.

PleasefollowthesestepstochargetheLiPoflightbatterywiththeincludedcharger:

Plugtheincluded1205PS100‐120VACto12VDCAdapter,0.5‐AmpPowerSupply
(AZSC1205PS)intoacompatible100‐120VACoutletthenconnectthepoweroutput
leadtothereceptacleonthesideofthe205Ccharger(NOTE:The1205PS
adapter/powersupplyispackedsafelyontheBOTTOMsideofthefoaminsertinside
thebox).Theadapter/powersupplyandchargerarepoweredonwhentheredcolor
LEDindicatorisglowing.



PLACETHE205CCHARGERONAFLAT,SMOOTHANDHEAT‐RESISTANTSURFACE.
It’simportantthatairisabletocirculatethroughthechargerduringthecharging
processinordertokeepitfromover‐heating.It’sespeciallyimportantthatthevent
openingsonthebottomandsidesofthechargerarenotblocked.DONOTplacethe
chargeroncarpetedorothersimilarsurfacesthatmayblocktheventopenings.
Also,DONOTplacethechargerindirectsunlightbefore,duringorafteruse.
Char
g
in
g
the LiPo Fli
g
ht Batter
y

11
Connectthewhite3‐pinconnectorfrombattery(alsotypicallyreferredtoasthe
‘balanceconnector’)tothematingconnectoronthecharger.YOUMUSTBECAREFUL
TOENSUREPROPERPOLARITYBEFOREMAKINGTHECONNECTION.Thisis
accomplishedbyensuringtheblackcolornegative/groundwireleadisorientedso
it’stowardtheright‐handsideofthechargerwhenlookingatthechargerfrom
above.Andwhilethewhiteconnectorsare‘keyed’tominimizetheriskofareverse
polarityconnection,ifyouforcethemitispossibletomakeconnectionwiththe
incorrectpolaritypotentiallycausingdamagetothebatteryand/orcharger.Whenthe
connectorsareproperlyalignedforcorrectpolarity,connectingthemshouldrequire
onlyamoderateamountofpressuretoachievethe‘click’thatindicatesasecure
connection.



Whenthebatteryisconnectedtothechargersecurelyandwiththeproperpolarity
boththeredcolorandgreencolorLEDindicatorswillglow.Thebatterywillbe
charginganytimethegreenLEDindicatorisglowing.

Itwilltakeapproximately1.5–2.5hourstofullychargeamostlyorfullydischarged
(notover‐discharged)battery(NOTE:Seethefollowinginformationinthissectionfor
moredetailsregardingoptional‘fast’chargingthatcanreducechargetimestoaslittle
as30‐45minutes).AndwhenthebatteryisfullychargedthegreenLEDindicatorwill
stopglowingentirely.WhenthegreenLEDindicatorisnolongerglowingyoucan
disconnectthebatteryfromthechargerasitisnowfullychargedandreadyforuse.

NOTE:TheLiPobatteryincludedwithyournewmodelwillarrivepartiallycharged.For
thisreasontheinitialchargemayonlytakeapproximately1hour.



12
IMPORTANTNOTE:DONOTSTORETHELIPOFLIGHTBATTERYFULLYCHARGED.
ForimprovedsafetyandlongevityoftheLiPobatteryit’sbesttostoreitonlypartially
chargedforanylengthoftime.StoringtheLiPobatteryatapproximately50%charged
(whichisapproximately3.85Vpercell)istypicallybest,howeveritwilltakesome
carefulmanagementofthechargetimeandtheuseofavoltmetertoachievethis
voltage.

Ifyouhavetheequipmentandskillstoachievethe50%chargelevelforstorageitis
recommended.Ifnot,simplybesuretonotstorethebatteryfullychargedwhenever
possible.Infact,aslongasthebatterywillbestoredatapproximatelyroom
temperatureandfornomorethanafewweeksbeforethenextuse,itmaybebestto
storethebatteryinthedischargedstateafterthelastflight(aslongasthebatterywas
notover‐dischargedonthelastflight).

Optional‘Fast’Charging

Theincluded1000mAh2‐Cell/2S7.4V20CLiPoBattery(AZSB10002S20T)canbe‘fast’
chargedatratesupto2C(2xtheCapacityofthebattery;2x1000mAh=2000mAh=
2.0A)whenusingapprovedandcompatibleLiPobatterychargers.Itwilltake
approximately30‐45minutestofullychargeamostlyorfullydischarged(notover‐
discharged)batterywhenchargingat2C.

For‘fast’chargingwerecommendusingtheRadient™PrimalorAscendchargers.Both
chargersarecapableofchargingtheincludedLiPobatteryatratesupto2C/2.0Aand
canalsobeusedtochargeotherhigherandlowercapacityLiPo,NiCdandNiMH
batteries.Bothchargersalsoincludeconnectorscompatiblewiththe‘Tamiya‐style’
andJST‐XH(balance)connectorsinstalledontheincludedLiPobatteryandcanbe
poweredfroma100–240VACoutlet.TheAscendchargercanalsobepoweredfroma
12–15VDCpowersource,suchasa12V‘car’battery,forquickandconvenient
chargingatthefieldorbeyond.YoucanfindtheRadientPrimalandAscendchargers
atHobbyTownUSA®storesandwww.HobbyTown.com.

13




Parts/ToolsRequired:
Leftandrightwingpanels
Plasticwingcover

Thintwo‐sidedtape(optional)
5–15minuteepoxy(optional)
Toassemblethewingstartbyslidingtheplywood‘joiner’thatextendsoutoftherightwing
panelintothecorrespondingslotintheleftwingpanel.Carefullyslidethepanelstogether
untiltheymeet.

OPTIONAL:Foramoresecurewingjointyoucanusethintwo‐sidedtapeor5–15minute
epoxybetweenthepanels.Thickcyanoacrylate(CA)gluemayalsobeusedkeepinginmind
thattheuseofglue/epoxywillresultinamore‘permanent’wingjoint.Also,it’simportantto
ensurethatthetopandbottomsidesofthewingpanelsarealignedproperly,especiallynear
theleading(front)andtrailing(rear)edges,whenjoiningthepanelswithtapeorglue/epoxy.

NOTE:Duetoslightvariationsintheproductionofrelatedpartsit’spossiblethattheleading
(front)andtrailing(rear)edgesofbothwingpanelswillnotalignexactlywhenthepanelsare
slidtogether.ThisOKandshouldhavenodiscernibleimpactontheflight
performance/characteristicsofthemodel.



Aftersliding/joiningthetwowingpanelstogetherlocatetheplastic‘wingcover’.Thiscover
helpsprotectthetopofthewingfromtherubberbandsusedtoattachittothefuselage
whilealsoprovidingadditionalsupportforthewingjoint.

Beforeremovingthebackingmaterialonthetapeusedtosecurethecovertothewingcheck
thefitofthecoveronthewing.Lineupthetrailing(rear)edgeofthecoverwiththetrailing
edgeofthewingwhilealso‘centering’thecoveroverthejointbetweenthewingpanels
Assemblin
g
the Win
g

14

Afterconfirmingthecoverfitscorrectlyremovethebackingmaterialtoexposethetape.
Then,verycarefullylineupthetrailingedgeofthecoverwiththetrailingedgeofthewing
andcenterthecoverbeforepressingitdownagainstthewingpanels.Startfromthetrailing
edgeofthewingandslowlypressthecoverdownwithlightpressuresoitfitsagainstthe
wingascloselyaspossibleuntilyoureachtheleading(front)edge.Applyonlylightpressure
soyoucanpossiblyremoveandreinstallthecoverifthefit/alignmentisnotcorrect.

Then,afterconfirmingthefitandalignmentaregood,applymorepressuretobettersecure
thecovertothewing.



NOTE:Insomecasesitmaynotbepossibleforalledgesofthecovertofitflushagainstthe
surfaceofthewing.Thisisnottypicallyaproblemastherubberbandsusedtoattachthe
wingtothefuselagewillhelpholdtheedgesofthecoverinplace.However,dependingon
thefitofsomepartsitmaybehelpfultoapplytransparent‘packing’tapeand/or
cyanoacrylate(CA)glue(werecommendMedium/Gap‐FillingorThickviscosity)tobetter
securetheedges.However,keepinmindthattheuseofgluewillresultinamore
‘permanent’installationofthewingcover.

Thewingisnowassembledandreadytoattachtothefuselageinalaterstep.










15



Parts/ToolsRequired:
Fuselage
Horizontalandverticaltails
Plastictailmount
2x8mm‘button’(small)headscrew;2pcs
2x8mm‘pan’(large)headscrew;1pc
Phillipsscrewdriver

Toinstallthehorizontalandverticaltailsstartbyaligningthe‘posts’extendingfromthe
bottomoftheverticaltailwiththesmallholeslocatedonthecenterlineofthehorizontaltail.
Carefullyslidethepoststhroughtheholeswithoutdamagingthefoamsothehorizontaland
verticaltailsare‘press‐fit’together.



Next,carefullyslidetheforwardsectionoftheverticaltailintothecorrespondingrecesson
thefuselagethenlowerthetailsectionintoplaceonthefuselagesothesmall‘tabs’onthe
bottomofthehorizontaltailalignandfitintothecorrespondingrecessesinthefuselage.
Nowtheentiretailsectionshouldbe‘press‐fit’tothefuselage.



Installin
g
the Horizontal and Vertical Tails

16
Beforeinstallingtheplastictailmountbesuretoalignandplacethetailwheel
bracket/mountintothecorrespondingrecessinthebottomofthefuselage.Then,carefully
slidethepostsextendingfromthetailmountintotheholesinthefuselage.Theposts
extendingfromthetailmountmustengagethepoststhatextendfromthebottomofthe
verticaltailwhilealso‘capturing’thetabsonthetailwheelbracket/mount.Takeyourtime
andcarefullyadjustthepositionofthetailsection,tailwheelbracket/mountandtailmount
untilbothpostsandthetailwheelbracket/mountengageproperly.



Whenengagedproperlythetailmountshouldfitalmostflushagainstthebottomofthe
fuselage.Nowyoucanslidethetwo2x8mm‘button’(small)headscrewsintotherecessed
openingsinthemountandtightenthemsecurely.Becarefulwhentighteningthesescrews
becausetighteningthemtoomuchcanstrip/breaktheplasticpostsand/ordamagethe
tails/fuselage.

Tocompletetheinstallationusetheremaining2x8mm‘pan’(large)headscrewtosecure
thetailwheelbracket/mountinplace.




Parts/ToolsRequired:
MainLandingGearAssembly
PlasticLandingGearCover
2x8mm‘button’(small)headscrew;2pcs
Phillipsscrewdriver

Themainlandinggearisinstalledintheslot/openinglocatedinthe‘LandingGear
Mount/BatteryHatch’onthebottomofthefuselage.Usemoderatepressureto‘squeeze’the
landinggearlegstogetherslightlythenslidethelandinggearintotheslot(youcanalso
removethelandinggearbydoingthesame).Besurethelandinggearisinstalledsoitangles
forwardwhenviewingtheairplanedirectlyfromtheside.
Installin
g
the Landin
g
Gear

17


Slidetheplasticlandinggearcoverintotheslot/overthelandinggearandcarefullyalignthe
smallpinsonthecoverwiththeholesinthemount.Pressthecoverintotoplacesoit’s
approximatelyflushwiththemount/hatchthenusetwo2x8mm‘button’(small)head
screwstosecurethecoverandlandinggearinplace.



TheGamma370RTFversionincludesa6HPA6‐ChannelHPAirplaneTransmitter
equippedwith2.4GHztechnology,trimlevers,servoreversingswitchesandoptional‐
use‘delta/elevon’mixing(theRFRversionrequiresa3+channeltransmitter/receiver).

IMPORTANTNOTE:Asistypicalofmost‘3‐channel’modelsthatareequippedwitha
rudderforprimary‘turning’control,the‘aileron’controlstick/channelisusedto
controltherudderontheGamma370.Thishelpstoensureaneasiertransitionto
controlling‘4‐channel’modelsequippedwithaileronslateron.
Transmitter Details

18
LowBatteryVoltage/PowerIndication
WhentheAAbatteryvoltage/powerdropstoalevelthat’stoolowforsafecontinued
operation,theredcolorLEDindicatorwillbeginflashing.DONOTusethetransmitter
orflywhentheredLEDindicatorisflashingandimmediatelyinstallnewAAbatteries
beforeusingthetransmitterorflying.

AntennaPosition/Orientation
TheRFoutputsignalstransmitbest/strongestfromtheshaftoftheantennaratherthan
fromthetip.Asaresultyoushouldneverpointthetipoftheantennadirectlyatthe
model.Also,thetransmitterantennacanberotatedupto180°andfoldedupto90°so
besuretoholdthetransmitterandpositiontheantennaasneededtoensurethebest
possiblesignaltransmission.

Control/ServoReversing
The6HPAtransmitterfeaturescontrol/servoreversingfunctionalityfortheaileron,
elevator,throttleandrudderchannels.Thecontrol/servodirectionsweresetcorrectly
atthefactoryfortheGamma370RTF,however,incasethecontrolsareoperatingin
thewrongdirection,oryouusetheelectronicsinothermodelslateron,simplychange
thepositionof‘ServoReverse’switchforthechannel(s)asneeded.

Delta/ElevonMixing
Locatedtotherightofthe‘ServoReverse’switchesisaswitchthat
activates/deactivatestheoptional‐use‘Delta/Elevon’mixing.Nosuchmixingisusedfor
theGamma370sopleasebesurethisswitchisintheOFF/lowerposition(failuretodo
sowillresultinimpropercontrolandtheinabilitytoflytheGamma370).However,if
usingthistransmitterwith‘flyingwing’,deltaorotherairplanesthat‘combine(mix)’the
elevatorandaileron(oftenknownas‘elevon’)controlsyoucanmovetheswitchtothe
ON/upperposition.




Installtheeight(8)includedAAbatteriesinthebackofthetransmitterbyfirstremovingthe
batterycompartmentcover/door.Ensureproperpolarityofthebatteriesbeforeinstalling
themasnotedbythemarkingsmoldedintothebatterycompartment,thenre‐installthe
compartmentcover/door.

CheckforproperoperationofthetransmitterbyswitchingthepowerswitchON(slideit
upward).The‘POWER’LEDindicatorshouldbegintoglowsolidgreen(indicatingthe
transmitterispoweredon)andthe‘RFOUTPUT’LEDindicatorshouldbegintoglowsolidred
shortlyafter(indicatingthetransmitterisoutputtinganRFsignal).Theseindicationsconfirm
thetransmitterispoweredonandfunctioningcorrectly.
Installin
g
the Transmitter Batteries

19



IMPORTANTNOTE:YoumustALWAYSturnthetransmitteronfirstANDhavetheleft‐
hand/throttlestickinthelowestpossiblepositionBEFOREconnecting/installingtheLiPo
flightbattery.Andbeforeproceedingwiththefollowingsteps,pleasebesurethe
transmitterispoweredonandtheleft‐hand/throttlestickisinthelowestpossibleposition.

AftertheLiPobatteryhasbeenfullychargedit’sreadytobeinstalledintheairplane.To
accessthebatterycompartmentonthebottomoftheairplane,rotatethetwolatchesuntil
they’reoutofthewayofthehatchcoverthenremovethecover.

TheLiPoflightbatterywillbesecuredinsidetheairplaneusing‘hook‐and‐loop’material.Use
theincludedadhesive‐backedhook‐and‐loopmaterialandapplytheappropriatesideinside
thebatterycompartmentand/oronthesideofthebatteryoppositeofthelabel.


Beforeinstallingthebatteryintheairplaneyou’llneedtoconnectittotheESC(Electronic
SpeedControl).YOUMUSTBECAREFULTOENSUREPROPERPOLARITYBEFORE
CONNECTINGTHEBATTERYTOTHEESC.Byorienting/aligningthewireleadsofthebattery
andESCsothey’re‘redtored’and‘blacktoblack’you’llbeabletomaketheconnection
withcorrectpolarity.

Also,althoughthe‘Tamiya‐style’connectorsare‘keyed’tominimizetheriskofareverse
polarityconnection,ifyouforcethemitmaybepossibletomakeconnectionwithincorrect
polaritypotentiallycausingdamagetotheESCand/orbattery.Whentheconnectorsare
properlyalignedforcorrectpolarity,connectingtheTamiya‐styleconnectorsshouldrequire
onlyaminimalamountofpressuretoachievethelight‘click’thatindicatessecure
connection.

Installin
g
the LiPo Fli
g
ht Batter
y

20
AftertheLiPobatteryisconnectedtotheESCyoucaninsertitintothebatterycompartment
thensecureitwiththehook‐and‐loopmaterial.Carefully‘tuck’thewireleadsandconnectors
insidethecompartmentensuringtheydonotdamagethebatteryorfoamairframewhile
alsoallowingthehatchcovertobeinstalledoverthecompartmentopening.Whenthehatch
coverisproperlyalignedandinstalledrotatethetwolatchesuntiltheysecurethecoverin
place.



ToremovetheLiPoflightbatteryfirstremovethehatchcoverandpullthewireleadsand
connectorsoutofthebatterycompartment.Then,carefullypullthebatteryoutofthe
compartmentbyseparatingthehook‐and‐loopmaterialmountedinsidethefuselageandon
thebattery.TodisconnectthebatteryfromtheESCgentlypressdownonthebackofthe
latchmoldedintothemaleconnectorfromtheESCsoitdisengagesthefemaleconnector
fromthebatteryandthenpulltheconnectorsapart.DONOTpoweroffthetransmitteruntil
theLiPoflightbatteryisremovedfromtheairplaneanddisconnectedfromtheESC.
REMEMBER:ThetransmitterisalwaysONFIRSTandalwaysOFFLAST!




WiththetransmitterturnedonandtheLiPoflightbatteryconnectedtotheESC(and
installedinthebatterycompartment)it’snowpossibletoconnectthepushrodstothe
rudderandelevatorcontrolsurfacesandto‘center’thesurfacesaccordingly.

First,besuretocentertheelevatorandrudder(aileron)trimlevers.Seethe
‘TransmitterDetails’and‘FlightControlsandTrimming’sectionsofthismanualformore
informationonthetrimleversandtheirfunctions.

Centerin
g
the Control Surfaces
