Argos 033 3560 Series User manual

Assembly Instructions - Please keep for future reference
2 Drawer Entertainment Centre
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev C - 30/11/2015
033 xx 3560
Width - 97.8cm
Dimensions
Depth - 38.8cm
Height - 40cm

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 4.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergants, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Left side (38.4x35.8cm) Right side (38.4x35.8cm)
Code - Code -
9153 9154
Bottom (90.7x32cm)
Backpanel (90.7x15.7cm)
Code - 7389
Left hand drawer front (44.8x15.7cm)
Code - 6845
Top (97.8x38.8cm)
Drawer bottom x 2 (42.6x29.8cm)
Code -
4472
7388 7383
Code -
Code -
Division (28.8x32cm)
Code - 9155
Left drawer side x 2 (30x10cm)
Code -
Drawer back x 2 (41.4x10cm)
Code -
Right drawer side x 2 (30x10cm)
Code -
622xx7002 624xx7005 623xx7002
Plinth x 1 (90.8x0.8cm)
Code - 6841
Shelf x 2 (44.6x31.9cm)
Code - 7384
Front
Grooved
edge
Front
Grooved
edge
Right hand drawer front (44.8x15.7cm)
Code - 6846
Trim x 2
(38.4cm long)
Code - 684xx6520

3
Components -Exploded View
9153
7389
Important - Thick lines indicate finished edges
7388
7384
9154
7384
7383
6841
6845
6846
4472
4472
9155
622xx7002
624xx7005
623xx7002
684xx6520
Trim
684xx6520
Trim
622xx7002
623xx7002
624xx7005

70 80 90 100 110 120
0 10 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components-Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more fittings
may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
4
Cross headed screwdriver
(small & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 14 - Code 760001103 Metal dowel x 18 - Code 760003004 Small cam x 4 - Code 760003005
Panel pin x 18 - Code 760001012
Panel pin guide x 1
Code 684004501
Runner x 4 - Code 760001040 9mm bolt x 4 - Code 690001078
Handle x 2
Code 644xx3511
A B C
D E F
H I
J L
45mm screw x 2 - Code 690001075
M
Metal shelf pin x 8
Code 760001137
N
Wooden dowel x 2
Code 770001006
18mm bolt x 4 - Code 700002021
G
8mm screw x 8
Code 700003510

Step 1
Assembly Instructions
5
Fittings you will need for this step:
A
B
B
B
B
B
(x6)
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Fittings you will need for this step:
A
(x8)
Note: Ensure cam
arrow points towards
the edge with hole.
A
Fittings you will need for this step:
A
(x4)
Fitting dowels to top
panel
Fitting cams to plinth
and bottom panel
Step 2
Step 3
Fitting cams and
dowels to left and
right hand end panels
Large
Large
7388
B
6841
Note: Ensure cam
arrow points towards
the edge with hole.
A
B
B
A
A
A
A A
A
A
7383
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
B
B
(x8)
A
A
A
A
B
B
B B B
B
B B
Front grooved edge
Front grooved edge
9153
9154

9154
9154
a:Align the drawer
runner with the
grooved edge of panel
, the 2nd hole from
the front will then line up
with a pre-drilled hole,
secure the runner to the
panel using screw .
6
2ND
Fittings you will need for this step:
(x1)
D
Attaching runners
H
b:Slide the drawer
runner forward to
secure screw .
The 2nd to last hole in the
runner will line up with
the pre-drilled holes in
the panel.
D
H
D
H
(x2)
H
D
Assembly Instructions
Step 4
a:
b:
9154
D
H
H
D
Front grooved edge
Note:
Please note
gap from the
front grooved edge.
Note:
Ensure these
holes are
positioned as shown.
D
H

7
Fittings you will need for this step:
(x1)
D
H
(x2)
Assembly Instructions
Step 5
a:Align the drawer
runner with the
grooved edge of panel
, the 2nd hole from
the front will then line up
with a pre-drilled hole,
secure the runner to the
panel using screw .
D
Attaching runners
H
b: Slide the drawer
runner forward to
secure the screw .
The hole in the runner
will line up with the
pre-drilled holes in the
panel.
D
H
a:
b:
9153
9153
2ND
H
D
H
Front grooved edge
Note:
Please note
gap from the
front grooved edge.
Note:
Ensure these
holes are
positioned as shown.
D
H
D
9153
H
D

8
Fittings you will need for this step:
(x1)
D
H
(x2)
Assembly Instructions
Step 6
b: Slide the drawer
runner forward to
secure 2 screws .
The 2nd to last hole in the
runner will line up with the
pre-drilled holes in the
panel.
D
H
a:
b:
9155
2ND
H
D
H
Front finished edge
Note:
Please note
gap from the
front finished edge.
Note:
Ensure these
holes are
positioned as shown.
D
H
D
9155
H
D
a:Align the drawer
runner with the
finished edge of panel
, the 2nd hole from
the front will then line up
with a pre-drilled hole,
secure the runner to the
panel using screws .
D
Attaching runners
to both sides of
division
H
9155
Step 7
Fitting cams and
wooden dowels to
division
Note: Ensure cam
arrow points towards
the edge with hole.
A
A
(x2)
Large
A
A
Fittings you will need for this step:
9155
Continued on next page.
Important:
We recommend you
do this on the packaging
the unit came in to
protect your floor.
N
(x2)
N
Use a hammer to
knock in wooden dowels
into inner holes.
N
N
N

9
Assembly Instructions
Fittings you will need for this step:
(x1)
D
H
Note:
Ensure these
holes are
positioned as shown.
D
d: Align the drawer
runner with the
finished edge of panel
, the 2nd hole from
the front will then line up
with a pre-drilled hole,
secure the runner to the
panel using screws .
H
e: Slide the drawer
runner forward to
secure screw .
The 2nd to last hole in the
runner will line up with the
pre-drilled holes in the
panel.
D
H
D
H
2ND
H
D
d:
e:
H
D
9155
Front finished edge
Step 7 - Continued
c: Turn panel
over to attach runner. c:
D
H
9155
9155
Note:
Please note
gap from the
front finished edge.
9155
9155 (x2)

a: Insert dowels into
drawer fronts
and .
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
10
Fittings you will need for this step:
(x4)
Drawer assembly
B
B
C
(x4)
Step 8
c: Insert wooden dowels
in drawer back
into holes in
left
right hand
drawer sides.
B
b: Insert small cams
into left
and right
drawer sides.
Note: Ensure cam arrow
points towards the edge
with hole.
C
C
B
B
Fittings you will need for this step:
Small
C
C
a:
b:
c:
Left hand side
Right hand side
Left hand side
Right hand side
Drawer Back
Continued on next page.
6845
6845
622xx7002 x2
624xx7005
623xx7002 x2
622xx7002
623xx7002
622xx7002
623xx7002
623xx7002
624xx7005
622xx7002
Assembly Instructions
B
B
6846
6846

G
G
J
6846
e:Insert cams already
inserted in left and right
drawer sides onto
dowels in drawer
fronts and .
11
Fittings you will need for this step:
(x4)
Drawer assembly
Continued...
C
J
G
(x2)
Assembly Instructions
Step 8- Continued
d: Slide drawer bottom
into grooves in
left,right drawer sides
and drawer back.
Ensure foil on the
drawer bottom is facing
upwards.
B
Turn cam 180 degrees
to lock
f: Secure handles to
drawer fronts
and using screws
.
C
G
G
J
J
G
d:
e:
f:
4472
4472
6845
6845
6845
6845
4472
6846
6846
6846
FOIL FACE FOIL FACE

Insert dowels in right
hand end panel
into cams in bottom
.
Then lock.
B
A
Turn cam 180 degrees
to lock
A
12
Attach right hand
panel to bottom panel
Assembly Instructions
Step 9
Attach division to
bottom panel
Step 10
9154
7383
Fittings you will need for this step:
(x2)
L
L
9154
Front grooved edge
9155
7383
7383
L
L
Locate wooden dowels
already inserted in
division into holes in
bottom panel .
Now locate screw
through holes in bottom
panel and screw
into holes in division
.
N
9155
7383
L
7383
9155

With help insert cams
in plinth onto
dowels in right hand
end . Now locate
dowels in left hand end
onto cams in
bottom and plinth
.
Then lock.
A
B
Turn cam 180 degrees
to lock
A
13
Attach plinth to right
hand end panel then
attach left hand
panel to bottom panel
and plinth
Assembly Instructions
Step 11
Attach top to ends
and division
Step 12
6841
9154
Front grooved edge
9154
7383
9155
9153
6841
9153
9154
B
9153
6841
7383
Locate dowels in
top 7 into cams
in left , right
hand end panels and
division .
Then lock.
B
Turn cam 180 degrees
to lock
A
7388
9153 9154
9155
Important:
2 people
required.
7388
A
Ensure plinth sits
flush.
Ensure plinth does
not overhang.

Push metal shelf pins
into panels ,
and .
M
14
Turn unit over so
grooved edges on
on end panels are to
the floor.
Locate metal shelf
pins to left and right
hand ends and
division
Assembly Instructions
Step 13
Locate shelves onto
metal pins
Step 14
9153 9154
9155
9154
9153
Important:
Please note you
will have turn
one of the
shelves round
for the groove to
match the
drillings.
9155
9153
9154
9155
(x8)
M
Fittings you will need for this step:
M
M
M
M
M
7384
7384
Locate shelves onto
metal shelf pins
already inserted into
panels ,
and .
M
7384
Small gap
Large gap
Front grooved edge
9153 9154
9155

15
Square unit up
Assembly Instructions
Step 15
Attach backpanel to
shelves and bottom
Step 16
DIAG 1
DIAG 2
DIAG 3
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
Measure to external corners
Ensure a tape measure
is used to square up
unit!
YY
YY
XX
XX
Important:
Fittings you will need for this step:
(x1)
E
F
(x18)
E
F
E
Align backpanel
so that there is an equal
gap from the edge of
bottom , and
shelves .
Then secure using panels
pins .
Use the panel pin guide
when locating the
panel pins . This will
hold the panel pins
vertical and ensure the
correct distance from the
edge.
E
F
E
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
7389
7389
7383
7383
7384
7389
7383

Assembly Instructions
Step 17
Lift unit up and
locate drawers
Step 18 Fittings you will need for this step:
(x4)
I
For this step we
recommend you follow
the helpful hints page
on page 17.
Fittings you will need for this step:
16
2nd HOLE
I
I
I
Warning:
2 people to lift.
Lift with care.
Locate the notch on
trim into
groove on left and
right ends.
Ensure the
trims are positioned
correctly.
To insert trims
use a hammer, place a
cardboard packing piece
between the hammer
and trims to
protect the
trims.
Attach trims
9153
9154
Warning:
2 people to lift.
Lift with care.
9153
9154
(x2)
Trims
Important:
The drawers
are left and right
handed so
please ensure
these are
located as
shown.
6846
6845
Your trims may have a
protective film on. Please
remove this after assembly
Turn unit over.

a: Pull sliding part of
drawer runners out
so they are fully
extended.
17
Locate drawers helpful
hints
Assembly Instructions
Step 18 - continued
I
H
b: Locate drawer onto
runners.
c: Locate screwdriver
into second threaded
hole in drawer runner .
H
d: Keeping screwdriver
in place push the drawer
closed.The screwdriver
will push against the end
panel and extend the
drawer runner .
H
e: Pull drawer out slowly
and line the hole in the
drawer side with the 2nd
threaded hole in the
runner . Now insert
screw through the
drawer side and
into threaded hole in
runner .
H
H
a: b:
c: d:
e: f:
l
f: Now insert screw
through the drawer side
and into threaded hole in
runner .
H
l
H
H
H
H
2nd hole
2nd hole

Congratulations! your unit is complete.
18
Note: Please turn over for
important information.

19
If you need help or have damaged or missing parts, call the Customer Helpline: 0170953412
Please have the following information: Unit Description, Product Code, Product Colour,
Place of Purchase, Catalogue Ref. No., Item Code, and have the assembly instructions close
to hand.
You can also e-mail your requests to us at: customer[email protected]
Simply contact us on CUSTOMER HELPLINE : 01709534123 Between 8am - 4.30pm
Monday to Thursday and 8am - 2.30p.m friday. Your statutory rights are not affected.
Alternatively Write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
Important Information
