Wow Lima Dining Table
Assembly Instructions - Please keep for future reference
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 01/04/13
Dimensions
Width - 90cm
Depth - 90cm
Height - 75.5cm
600/6503
600/6510

1
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Warnings
Care and maintenance
• Do not discard any of the
packaging until you have
checked that you have all the
parts and the pack of fittings.
• Assemble this product on a flat
surface.
• Assemble all parts loosely
before tightening any bolts.
• Discard all extra fittings and
keep fittings out of reach of
children.
• Unit weight: 11.6kgs.
• At least 2 people are required
to assemble this product.
• Retain Assembly Instructions
for future reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• This product should only be
used on firm, level ground.
• Make sure the legs remain in
contact with the ground.
• Do not stand on the product.
• Please clean the table surface
using either damp (not wet)
cloth and a mild domestic soap
solution or by using an
appropriate polish.
• Do not use any abrasive
materials when cleaning.
• From time to time check that
there are no loose bolts on this
unit.

2
Components - Parts
Components - Fittings
Please check you have all the parts listed below
Please check you have all the fittings listed below
Table top (90 x 90 x 2cm)
M6 x 70mm Bolt x 4
If you have damaged or missing components,
call the Customer Helpline: 08456 400800
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
1
Leg A x 2 (44 x 2.5 x 75cm)
holes lower
3Leg B x 2 (44 x 2.5 x 75cm) 4
A
M6 x 32mm Bolt x 8
B
Nut x 4
Allen key x 1 Spanner x 1
C
D E
Ruler - Use this ruler to help correctly identify the screws
0 15 30 45 60 75 905 20 35 50 65 80 9510 25 40 55 70 85 100 120 140105 125 145110 130 150115 135 155 160 165 170
holes higher
Middle brace (1.3 x 1.3 x 30.5cm)
2

Assembling legs B
Attach the legs B to
middle brace using
bolts and nuts .
Important:
Fasten bolts &
nuts using allen
key and
spanner but do
not fully tighten at
this stage.
A C
D
E
4
2
3
Assembly Instructions
Step 1
Step 2
Assembling legs A
Identify the correct legs
for assembly & with the
help of an assistant
attach the legs A to
middle brace using
bolts and nuts .
Important:
Fasten bolts &
nuts using allen
key and
spanner but do
not fully tighten at
this stage.
A C
D
E
3
2
A
C
4
4
2
A
C
A
C
44
2
A
A
A
CC
C
333
3
2
2

4
Assembly Instructions
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Step 3
Attaching rails
Place the table top
upside down on a flat
protected surface.
Position the legs &
on the table top as
shown and fix using bolts
.
Important:
After fully
tightening bolts ,
fully tighten all
bolts & nuts
assembled on
step 1.
Carefully turn the table
upright with the help of
an assistant.
Assembly is complete.
1
1
3 4
B
B
A C
33
3
4
4
1
1
BB
BB
B
B
B
B
B

Lima Dining Chair
Assembly Instructions - Please keep for future reference
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 13 /03/13
Dimensions
Width - 42cm
Depth - 42cm
Height - 85.5cm
600/6503
600/6510

1
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Warnings
Care and maintenance
• Do not discard any of the
packaging until you have
checked that you have all the
parts and the pack of fittings.
• Discard all extra fittings and
keep fittings out of reach of
children.
• At least 2 people are required
to assemble this product.
• Assemble this product on a flat
surface.
• Assemble all parts loosely
before tightening any bolts.
• Unit weight: 3.4kgs.
• Maximum safe weight of user:
110kgs.
• Retain Assembly Instructions
for future reference.
• Dispose of all packaging
carefully and responsibly.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• This product should only be
used on firm, level ground.
• Make sure the legs remain in
contact with the ground.
• Do not stand on the product.
• Please clean the table surface
using either damp (not wet)
cloth and a mild domestic soap
solution or by using an
appropriate polish.
• Do not use any abrasive
materials when cleaning.
• From time to time check that
there are no loose bolts on this
unit.

2
Components - Parts
Components - Fittings
Please check you have all the parts listed below
Please check you have all the fittings listed below
If you have damaged or missing components,
call the Customer Helpline: 08456 400800
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Backrest
(32.5 x 5 x 39.5cm)
3
Upper leg
(54.5 x 3 x 59cm)
1Lower leg
(54.5 x 3 x 59cm)
2
Seat
(38.5 x 38.5 x 4cm)
4
Ruler - Use this ruler to help correctly identify the screws
0 15 30 45 60 75 905 20 35 50 65 80 9510 25 40 55 70 85 100 120 140105 125 145110 130 150115 135 155 160 165 170
Allen key x 1
M6 x 15mm Bolt x 4
A B C
D
M6 x 35mm Bolt x 5 Washer x 2

Attaching seat
Place the seat face
down on a flat and raised
surface such as a table.
Position the chair frame
on the seat as shown
then fix through holes
using bolts & curved
washers then tighten
with allen key .
Important:
Carefully turn
over the chair.
Place it on a flat
even surface and
make adjustments
to ensure the legs
are even on the
floor.
Then fully tighten
bolts fixed on
step 1 using allen
key .
Assembly is complete.
3
Assembly Instructions
Step 1
A
A
A
A
A
A
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
B
B
CB
C
B
B
C
2
2
1
2
4
4
4
B
D
D
B
1
3
3
1
2
Attaching backrest
Position the upper leg
and lower leg in a
crossed position as
shown.
With the help of an
assistant holding the
legs, insert the legs
into holes on the
backrest as shown.
Then fix through holes
using bolts and tighten
with allen key .
Important:
Do not fully
tighten the bolts
at this stage.
A
A
D
1
2
3
Step 2
4
4
B
C
