Argos 481/3640 User manual

If you need help or have damaged or missing parts, c a l l t h e Customer Helpline: 03456 400 800
Important –Please read these instructions fully before starting assembly
Dimensions
Width - 128.1cm
Depth - 197.6cm
Height - 112,8cm
Issue 1 - 05/10/15
Chile - 4FT Bed
481/3640
496/9460
Assembly Instructions - Please keep for future reference

Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Note:If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
We do not
recommend the
use of power
drill/driversfor
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Parts of the assembly will be
easier with 2 people.
Dispose of all packaging
carefully and responsibly.
This product has been produced
from natural timber; you may
notice some variation in the grain
and colour of different component
parts which is normal for furniture
produced using natural wood and
is not the result of any
manufacturing fault.
The product has been treated
with a wax and oil finish to
prevent dirt ingress and preserve
moisture.
On unpacking the
furniture you may notice an
odour due to this treatment;
this will disappear once the
furniture is unpacked and
assembled after a period of time.
This process may leave some
staining on the packaging
material; please take care to
ensure this does not transfer
to clothing or carpeted surfaces
during assembly.
Care and maintenance
Use an appropriate furniture
polish for natural wood
furniture and a dry cloth to
clean the product.
Avoid placing the furniture in
direct sunlight as this will cause
the timber to prematurely age.
From time to time check
that there are no loose
screws on this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.

2
Headboard (112.8 x 128.1cm)
1
Footboard (61.8 x 128.1cm)
2
Side rail x 2 (190.0 x 14.0cm)
3
Central rail (189.3 x 6.5cm)
4
Middle support x 02 (
26.0 x 6.5cm)
6
Slats x 12 (122 x 7.0cm)
5
Components - Panels
Please check you have all the panels listed below

3
Components - Fittings
Please check you have all the fittings listed below
If you have damaged or missing components,
call the Customer Helpline: 03456 400 800
Note:
Ruler - Use this ruler to help correctly identify the screws
0510 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Tools required
Phillips screwdriver
(medium & large)
Eye protection
(when using a
hammer or glue)
Small
hammer
Ruler/tape
measure
2m
A
D
G
K
B
E
H
L
C
F
J
M
Wooden dowel x 4
N
Washer x 4
3.5 x 16mm Screw x 8 4.5 x 60mm Screw x 4
4 x 35mm Screw x 24 Headless bolt 1/4 x 75mm x 4 1/4 x 80mm Bolt x 4
Cod. 330103
Cab. 17
10 x 50mm
Half moon nut 1/4 x 4 Nut 1/4 x 4 Metal
bracket x 2
Allen key x 1
82mm Spacer x 2
Spanner
The quantities below are the correct amount to complete the assembly.
In some cases more fittings may be supplied than are required.

Assembly Instructions
4
Step1
Fixing metal brackets.
Fix metal brackets into
the pre drilled holes in
the headboard and
footboard using
screws .
Step2
1
2
2
Screw headless bols
into footboard .
B
E
E
E
BB
JJ
B
J
J
J
B
E
2
2
2
2
1

Assembly Instructions
Step3
Step4
6
6
C
C
4
2x
A
A
Assembling central rail
and inserting dowels.
central rail intoAttach
the pre drilled holes in
the middle supports
using screw .
Insert dowels into the
side rails .
4
6
C
3
A
3
5

6
Step6
Step5
Assembling side rails.
Important:
Two people are
required for an
easier assembly. 3
G
F
M
2
5
K
E
LL
H
G
F
M
With help, fit one side
Insert half moon nuts
as shown, then fix parts
using bolts
Repeat step 5 for the other Repeat step 5 for the other
side rail.
.
and allen key
to the headboard .
1
3
ab
Assembly Instructions
L
K
K
L
L
H
H
1
3
3
2
a: Insert washer into the
side rails. Fit the headless
bolts in the footboard
thought the washers.
b: Fix headless bolts
using nuts and spanner
.
Assembling of
Step and Step 6
will be easier with
people. It can also avoid
damages or brakes of any
part or component.

Assembly Instructions
7
Step8
Step7
B
4
B
B
B
4
Attach central rail to the
metal brackets in the
headboard and footboard
using screws .
N
D
D
DDD
DD
DDDD
DD
DD
DD DD
DDD
D
DD
N
5
Assembling slats
Please fix the first slat
at the end of the rail
and work towards the
middle of the bed using
the spacer as shown to
ensure correct spacing.
Fix slats in one side first,
then fix them in the other
side by pushing the rail
against the slats if
necessary.
Use screws for fixing.
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
