Argos Modular User manual

IMPORTANT - Retain these instructions for future reference
Issue 1 - 03/05/19
Spare Parts
www.argos-support.co.uk
[e-mail]
0370 112 1928
Customer Support
0345 640 2020
Modular

1
Product Details
581/3625
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough space
to layout the parts before
starting.
Care and maintenance
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
Only clean using a damp cloth
and mild detergent. Do not use
abrasive cleaners.
Use a dry cloth to clean the
product, furniture polish is
not recommended.
•From time to time check that there
are no loose screws, nuts or bolts.
If there are please re-tighten.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
Additional Guidance
●Assemble all parts and bolts loosely during assembly, only once the product is complete should you
fully tighten the bolts.
●Regularly check and ensure that all bolts and fittings are tightend properly.
This product has been
constructed to be used in the
domestic environment only and
not for commercial purposes.
Sainsbury's Argos is a trading name of both: Argos Limited, Registered office: 489-499 Avebury Boulevard, Milton Keynes, United
Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited, Registered
office: 33 Holborn, London, EC1N 2HT, registered number: 03261722 (England and Wales). Both companies are subsidiaries of J
Sainsbury's plc.
Safety and Care Advice
We do not
recommend the
use of power
drill/drivers for
inserting screws
as this could damage the unit.
Only use hand screwdrivers.
Parts of the assembly will be
easier with 2 people.
Dispose of all packaging
carefully and responsibly.
Assemble the item as close
room) as possible.
to its final position (in the same
Assemble on a soft level
surface to avoid damaging the
unit or your floor
· WARNING: To prevent
possible overbalancing this unit
must be secured to a wall using
the overbalance protector kit
supplied.
· A unit that is allowed to topple
can cause serious or fatal injury.
In addition to wall fixing the unit,
place heavy items on the lower
shelves, do not put any heavy
objects on top of the unit and
never allow children to climb or
hang on drawers, doors or
shelves.
Warning: Max loading weight
Small shelf - 5 kg
Hanging rail - 15kg

Bag 1
Fittings (Shown to scale)
2
Ruler/tape
measure
Tools required
25mm
Screw
A x 2
6x25mm
B x 2
9mm
Washer
C x 2
Phillips screwdriver
(small & medium)

Components
3
1Metal tube 43cm x 10 2Metal tube 71cm x 11 3 Metal tube 22.6cm x 10
7 Metal door35.5*61.5cm x 2 8 Metal door 35.5*64cm x 2 9
11 Hook x 2 Fabric shelf x 4
15 Wardrobe cover x 1
10 Corner joint x 20
14 Drawer x 2
13 Bottom x 2
4 Metal tube 100cm x 2 5 Metal tube 22.6cm x 2 6 Metal tube 100cm x 2
Fabric hook x2
(25 x 230mm)
12

4
1
2
3
1
2
10
10
2
12
10
1
10
section 1;2;3;4
Repeat steps1-3 so you have 4
complete identical shelf sections.

4
5
section 4
section 3
section 2
section 1
4
3
3
3
3
3
3
3
3
3
10
1
10
2
10
1
10
2
3
5
6
4
6
5

5
6
2
11
11
clothes rail
clothes rail
6

7
7
15

8section 5
section 6
7
8
8
7
9
section 5
section 5
5 6
8

10
11
section 6
5 6
section 6
15
9

12
13
13
14
13
section 7,8
10
Repeat step12 so you have 2 drawer.

14
Pt. No
Fabric hook
9
9
Top Fabric
wall
9
Bx2
Mark the fixing hole on
the wall and remove the
wardrobe. Drill a hole and
insert a wall plug .
B
!Warning:
Before drilling,
check the wall for
hidden pipes and
cables.
Note:
The correct type of fixing
must be used for your
wall,seek professional
advice if doubt.
AX 2 B X 2 C X 2
C A

A Guide to - Wall Mounting & Fixings
Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist ftting in this case. For light
loads, general purpose wall plugs can
be used.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
For use when ftting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with walls stuck with
plasterboard. The hammer fxing allows
it to be fxed to the wall rather than the
plasterboard. Always check the fxing
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
Safety: Always check the ftting
and location to ensure your safety
in and around the home.
Fitting: From time to time check
the ftting to ensure the wall plugs
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well ftted and are a tight ft in the
drilled hole.
If plastic wall plugs
are supplied with your
product:
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualifed
tradesperson if you are unsure.
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect fxings is the
responsibility of the installer.
