Argos Hallingford Gloss 790/7711 User manual

MADE IN
BRITAIN
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: [email protected]o.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0330 016 1114
For any other queries please contact the Customer Helpline on: 0345 640 2020
Important - Please read these instructions fully before starting assem-
Assembly Instructions - Important: Retain these instructions for
future reference
More help is available throughout this
booklet by scanning in the QR codes or
typing in the links
WARNING!
In order to prevent overturning, this product must be used
with the wall attachment device provided
Dimensions
Width - 37.5cm
Depth - 39.6cm
Height - 58cm
Hallingford Gloss - 3 Drawer Bedside
Issue 5 - 11/08/20
790/7711
760/8632
814/5091
806/8721

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• Regularly check all fastenings
to ensure that they are properly
tightened.
• Warning: This unit weighs
approximately 14kgs.
Please lift with care.
• Assembly to be carried out by
a competent adult only.
• Check you have all the
components and tools listed on
pages 1, 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• During assembly children
should be kept away from the
product due to possible risk of
injury.
• Installation shall only be
carried out exactly according to
the manufacturer’s instructions
- otherwise a safety risk can
occur if incorrectly installed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• WARNING: To prevent
possible overbalancing this unit
must be secured to a wall
using the overbalance
protector kit supplied.
• Dispose of all packaging
carefully and responsibly.
• Do not use this item if any
components are missing or
damaged.
Tools required
Rule
Scissors
Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Electric drill
(do not use for
fitting screws)
Bradawl
Flat-head
screwdriver
Spirit level

Components - Panels
Please check you have all the panels listed below
2
6 7
8
Left Side (DF-00010160)
(55.6 x 37.2cm)
Right Side (DF-00010161)
(55.6 x 37.2cm)
Top (DF-00010162)
(37.5 x 39.6cm)
1Drawer Front (DF-00010163)
(36 x 16.2cm) x 3
2Left Drawer Side (WRP-00000156)
(35 x 13cm) x 3
3Right Drawer Side (WRP-00000157)
(35 x 13cm) x 3
4Drawer Base (TDF-00022245)
(31.95 x 34.7cm) x 3
5Drawer Back (WRP-00000463)
(30.85 x 13cm) x 3
9Plinth (DF-00018114)
(34.1 x 6cm) x 2
10 Back (X535-366)
(53.5 x 36.6cm)

Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Components - Fittings
3
Main Fittings Bag
Individual Fittings Bags
Drawer Fittings Bag marked ‘drw kit’
A C
Knock-in Peg (F171GY) x 12
D E
19mm Screw (F461) x 6
B
Small locking cam
nut (F3) x 6
Metal dowel (F901) x 6
Wedgefix (F639) x 6
L
Drawer runner (F450) x 6
M
Handle (F306) x 3
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
F
9mm Screw (F74) x 6
J
Plastic Nail (F91) x 4
I
9mm Screw (F73) x 12
H
Wooden dowel (F22) x 8
K
Nail (F51) x 20
A
Metal dowel (F901) x 8
G
Large locking cam nut (F900) x 8
O
N
Overbalance protector kit (F474) x 1

1
Assembly Instructions
4
Step 1
x 3
x 3
x 3 x 3
Step 2
Prepare the 3 drawer
fronts
Screw 2 metal dowels
into each of the 3 drawer
fronts .
Note: Tighten the metal
dowels up fully against
the panels.
A
1
Prepare the 3 sets of
drawer sides
Insert a small locking
cam nut into the left
drawer sides and
right drawer sides .
Note: The arrow on the
locking cam nut must
point towards the hole in
the edge of the panel.
Step 3
B
2
3
Attach the drawer
sides to the drawer
fronts
Push the left drawer side
. and right drawer side
. onto the back of the
drawer front .
Turn the small locking
cam nuts on the left
drawer side and right
drawer side .
Note: Turn the locking
cam nuts clockwise
to secure panels - more
than 1/2 a turn.
2
3
1
B
2
3
B
A
B
B
BB
23
www.youtube.com/watch?v=InNBV_uuMmo
Drawer Assembly
AA
A
1
2
3
Use the Drawer Fittings Bag marked ‘drw kit’ for Steps 1 - 7

1
Assembly Instructions
5
Step 4
C
C
Fit the drawer bases
Slide the drawer base
down the grooves in the
drawer sides and
and down into the
groove in the drawer
front .
Step 5
Fit the drawer backs
Fit the drawer back
between the drawer
sides and .
Make sure that the
drawer base fits into
the groove in the drawer
back .
Hold the drawer back
in position and tap the
knock-in pegs
through the holes in the
drawer sides and .
4
2 3
1
5
2 3
4
5
5
C
Step 7
2 3
103
2
4
103
4
2
C
C
5
D
D
Step 6
Fit the handles
Attach a handle to
each drawer front
using screws .
M
D
1
E
Fit the wedgefixes
Turn the 3 drawer
assemblies over and
slide 2 wedgefixes
into the front and back
grooves, as shown, and
tighten up the screws.
E
Important: Make sure
that the drawer assembly
is square before fitting
the wedgefixes.
E
E
x 3
x 3
x 3
x 3
1
M
D

Finished
front edge
Finished
front edge H
H
Assembly Instructions
6
Step 8
Prepare the left side
a: Place 3 runners on
the left side as
shown. Slide back the
top of runner and use the
2nd hole from the front
to fit the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the left side .
c: Screw 2 metal
dowels into the left
side .
Insert 2 large locking
nuts into the left side
. .
Note: The arrow on the
locking nuts must point
towards the hole in the
edge of the panel.
Tap 2 wooden dowels
into the left side .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
6
I
I
G
6
H
6
6
L
L
A
6
a:
b:
c:
Finished
front edge
I
L
I
I
L
www.youtube.com/watch?v=yG4xJJeSg
Fitting Ball Bearing Runners
I
L
I
L
I
I
A
A
10mm
H
G
G
G
6
6
6
Finished
front edge

H
H
Assembly Instructions
7
Step 9
Prepare the right side
a: Place 3 runners on
the right side as
shown. Slide back the
top of runner and use the
2nd hole from the front
to fit the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the right side .
c: Screw 2 metal
dowels into the right
side .
Insert 2 large locking
nuts into the right
side .
Tap 2 wooden dowels
into the right side .
7
I
I
G
7
7
L
L
A
7
Finished
front edge
I
L
a:
b:
c:
I
L
I
L
I
L
I
I
I
A
A
G
G
H
7
7
7
7
H
Prepare the 2 plinths
Insert 2 large locking
nuts into each of the
2 plinths .
Tap 2 wooden dowels
into each of the 2 plinths
. . H
G
G
G
9
9
H
9
Step 10
x 2
Finished
front edge
Finished
front edge
Finished
front edge

N
Finished
front edge
Finished
front edge
Assembly Instructions
8
Step 11
Join the 2 plinths to
the right side
Push the 2 plinths
onto the right side .
Use a screwdriver to
tighten the 2 large
locking cam nuts
fitted to the plinths .
Note: Turn the large
locking cam nuts as
far as they will go - more
than 1/2 a turn.
A
G
G
9
7
9
G
Note: Support this
plinth until the left
side has been fitted
in the next step
Fit the left side
Push the left side
onto the 2 plinths .
Use a screwdriver to
tighten the 2 large
locking cam nuts
fitted to the plinths .
G
6
9
9
Step 12
6
9
9
9
9
7
Prepare the top
Screw 4 metal dowels
into the top .
Fit the bracket from the
overbalance protector kit
. to the shallow
mark-hole drilled into
the top using 1 of its
screws.
Note: Only fit 1 of the
screws, the other 1 will
be fitted later.
A
8
A
A
A
A
8
Step 13
Finished
front edge
N
N
8

Finished
front edge
Assembly Instructions
9
Step 14
Fit the top
Note: To make it easier
to fit the top, place
polystyrene blocks from
the packaging
underneath the side
panels to raise the
assembly.
Push the top onto
the assembly.
Use a screwdriver to
tighten the 4 large
locking cam nuts
fitted to the sides
and .
G
8
6
7
8
6
7
Fit the back
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the
outside edges of the
back .
Note: Nails should be
spaced about 150mm
apart.
10
K
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
10
www.youtube.com/watch?v=FeaI6541z7o
Squaring up a Chest and tting the Back Panel
yy
y
y
x
x
x
x
b:
K
Step 15
10
Polystyrene
block
Polystyrene
block

Assembly Instructions
10
Step 16
Fit the 4 plastic nails
Tap 2 plastic nails
into the bottom edge of
each of the sides and
. .
Carefully stand the
unit up for the next
step.
J
6
7
J
J
J
J
6
7
a:
b: N
Back
Top
N
Top
See the next page for a guide
to wall mounting and fixings
WARNING!
In order to prevent overturning
this product must be used with the
wall attachment device provided
Secure the unit to a
wall
a: Before fitting the unit
to a wall, use a spirit
level to check the top of
the unit is level,
front-to-back and
side-to-side in the 3
positions shown.
Use suitable packing
pieces (not supplied) to
make the unit level.
To prevent possible
overbalancing this unit
must be secured to a
suitable wall by fitting the
overbalance protector kit
. to a wall.
b: Push the unit up
against the wall and slide
the bracket against the
wall. Fit the 2nd screw
into the underside of the
top panel.
Mark the slot at the back
of the bracket for drilling
into the wall.
Wall fixings are not
supplied as they will need
to suit the wall type.
N
Step 17
Note: Take care when
drilling the wall that you
do not drill into any
pipes, wires etc.
If in doubt, consult an
expert.
N

Important note:
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
If plastic wall plugs
are supplied with your
product:
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect fixings is the
responsibility of the installer.
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualified
tradesperson if you are unsure.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well fitted and are a tight fit in the
drilled hole.
Types of walls You can use one of the following types of wall plug if your
walls are made of brick, breeze block, concrete, stone or wood.
Generally aerated blocks should not
be used to support heavy loads, use
a specialist fitting in this case. For light
loads, general purpose wall plugs can
be used.
For use with plasterboard partitions or
hollow wooden doors.
For use with walls stuck with
plasterboard. The hammer fixing allows
it to be fixed to the wall rather than the
plasterboard. Always check the fixing
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
For use when fitting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
No.1 “General Purpose” wall plug No.3 “Cavity Fixing” wall plug No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
A Guide to Wall Mounting & Fixings
Care &
Maintenance
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
11

Assembly Instructions
Assembly is complete
Please remove any blue protective film from panel
edges and clear protective film from panel surfaces
12
Step 18
Fit the drawers
Starting with the bottom
drawer, slide both the
runners forward and
locate the drawer
sides and
between them, lining up
the holes in the drawer
wrap with the 2nd
'threaded' holes in the
runners .
Working from the inside
of the drawer, insert 2
screws through the
drawer sides and out into
the 2nd threaded hole in
the runner.
Note: Do not overtighten
the screws .
If they catch on the
runner you may need to
loosen them slightly.
F
L
L
F
2 3
F
F
2
3
F
2nd threaded
hole
L

ALR3432
