Argos Mia Stars 4553326 User manual

Assembly Instructions - Please keep for future reference
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Argos Customer Helpline: 03456 400 800
Hearts 2463834
Stars 4553326
Hearts
Stars
Issue 3 - 23-09-2015
Mia Hearts / Stars 2 Door Wardrobe
Dimensions
Width
Depth
Height
:
:
:
350269
88.5 cm
52.3 cm
181.2 cm

!Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Care and maintenance
1
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not recommend the use
of power drill/drivers for
inserting screws, as this could
damage the unit. Only use hand
screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page
with these instructions for
future reference.

Components - Panels
Please check you have all the panels listed below
If you have damaged or missing components, call
the Argos Customer Helpline:
03456 400 800
2
350269-03
2
(172,5 cm x 47,3 cm)
Side, left
4x
1
(88,5 cm x 52,3 cm)
Top
3
(172,5 cm x 47,3 cm)
Side, right
4
(179,7 cm x 4,4 cm)
Post
8
(76,7 cm x 9,5 cm)
Front rail
7
(76,7 cm x 48,9 cm)
Bottom
5
(167,3 cm x 39,5 cm)
Back 2
x
6
(163 cm x 1,7 cm)
H-profile
10
(75,7 cm x 2,2 cm)
Hanging rail
9
(76,7 cm x 46,5 cm)
Shelf
11
(164,6 cm x 37,9 cm)
Door, left
12
(164,6 cm x 37,9 cm)
Door, right

Components - Fittings
Please check you have all the panels listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more ttings
may be supplied than are required.
3350269-04
12 ø7.8 x 40mm Wooden dowel x
Aa
Cb
ø5 x 8, cc34mm Bolt x 12
Ca
ø15 x 10.5mm Cam x
12
1.2 x 15mm Nail x
Di
50
Kb
ø5.8 x 8mm Screw x
4
17060 16040 90 15013070 120100 14011050 803020100
Ruler - Use this ruler to help correctly identify the screws
Tools required
Flatblade screwdriver
(Medium)
Hammer Phillips screwdriver
(Medium & large)
ø4 x 25mm Screw x
Jb
24
2
Vl
44 x 23 x 23mm Angle x
Ko
8
ø4,2 x 9,5mm Screw x
Magnet, adjustable x
Pc
4
35 x 12 x 1mm Magnet catch x
Pd
4
Mf
6
ø26mm Cup hinge x
Mc
6
0mm Crossplate x
Fl
2
Support for hanger rail - 15mm x
ø3 x 12mm Screw x
Bo
20
Wall strap and instruction x 1
Fh
Vn
Angle 23 x 23 x 24mm x 1
Shelf support x
Fr
4

Assembly Instructions
Fix the posts
4
onto the
sides
2
and
3
using
screws
Jb
into the holes
indicated.
The top of the posts
4
and
the sides
2
and
3
must be
ush.
Step 1.1
Assembly of the
wardrobe.
Step 1
4
350263-05
ø4 x 25mm Screw x
Jb
24
Jb
Jb
Jb
Jb
Jb
Jb
Jb
Jb
Jb
Jb
Jb
Jb
3
4
4
4
4
2
Jb
Jb
Jb
Jb
Jb
44
32
Jb
Jb
Jb
Jb
2
3
1
4
4
84
7
5
5
6
4
9
Jb
Jb
Jb
Jb

Assembly Instructions
Knock the dowels
Aa
into
the holes indicated
on the sides 2
and
3
.
Use
a small
hammer.
Screw
the bolts
Cb
into
the holes indicated on the
sides
2
and
3
.
Step 1.2
Fix the Crossplates
Mc
to the sides 2
and
3
using the pre-mounted
screws.
Note the details.
Position the Crossplates
Mc
exactly as shown.
Fix the supports for
hangerrails
Fl
onto the
sides 2 and
3
using
screws
Bo
.
Step 1.3
350269-06
5
Cb
ø5 x 8, cc34mm Bolt x 6
6 ø7.8 x 40mm Wooden dowel x
Aa
Aa
Aa
Aa
Aa
3
2
ø3 x 12mm Screw x
Bo
2
Fl
2
Support for hanger rail - 15mm x
Mc
6
0mm Crossplate x
Cb
Cb
Cb
Cb
Cb
Cb
Aa
Aa
Bo
Fl
Mc
Mc
Mc
Mc
Mc
Mc
Bo
Fl
2
3

Assembly Instructions
Knock the dowels
Aa
into
the holes indicated on
the bottom 7
using a
small hammer.
Press the magnets
Pc
into the holes indicated
on the bottom
7 .
Step 1.5
Fix the angles
Vl
using
screws
Ko
into the holes
indicated on the front
rail
6
.
Step 1.4
Place the sides 2and
3onto the bottom 7.
Push cams
Ca
into the
holes indicated on the
bottom 7. Arrows
pointing towards the
sides 2/3.
Turn the cams
Ca
to the
right to x the sides 2
and 3.
Step 1.6
6
350269-07
6 ø7.8 x 40mm Wooden dowel x
Aa
2
Vl
44 x 23 x 23mm Angle x
Ko
4
ø4,2 x 9,5mm Screw x
Ko
Ko
Magnet, adjustable x
Pc
2
Ko
Vl
8
8
7
Aa
Aa
Aa
Pc
Aa
Aa
Aa Pc
Vn
Angle 23 x 23 x 24mm x 1
ø3 x 12mm Screw x
Bo
1
2
7
Ca
Ca
Ca
Ca
Ca
Ca
3
Ca
ø15 x 10.5mm Cam x
6
Vn
Vl
Bo

Assembly Instructions
Place the top 1onto the
sides 2and 3.
Push cams
Ca
into the
holes indicated on the
sides 2and 3.
Arrows pointing towards
the top 1.
Turn the cams
Ca
to the
right to x the top 1.
Step 1.8
Place the front rail 8
as shown.
Fix the angles
Vl
to the
sides using screws
Ko
.
See detail.
Step 1.9
Screw the bolts
Cb
into
the holes indicated on the
top
1
.
Press the magnets
Pc
into the holes indicated
on the top
1 .
Step 1.7
350269-08
7
Ca
ø15 x 10.5mm Cam x
6
Ca
Ca
1
Cb
ø5 x 8, cc34mm Bolt x 6
Ca
2
3
Pc
Cb
Cb
Cb
Cb
Cb
Cb
1
Pc
Ca
8
Ko
Ko
Bo
7
3
2
Ko
4
ø4,2 x 9,5mm Screw x
Magnet, adjustable x
Pc
2

Assembly Instructions
Step 1.11
!
Important!
The wardrobe is
heavy. Lift with
care.
Its recommended that the
wardrobe is xed to the wall.
Use the ttings
Fh
. Follow
the instructions included
with the ttings.
Fix the shelf supports
Fr
to the
2and 3 using
screws
Kb
into the holes
indicated.
Lower the shelf
9
onto the
shelf supports
Fr
.
Step 1.10
Place the backs 5into
the rabbet on the top 1
into the H-prole 6and
onto the posts 4.
!
Important!
Make sure the
angle between the
top
1
and the posts
4
is
90° when the backs
5
is
attached.
Fix the backs
5
to the top
1, the posts 4and the
bottom 7
using
nails
Di
.
Use a small hammer.
350269-08
7
Ca
ø15 x 10.5mm Cam x
6
Ca
Ca
1
Cb
ø5 x 8, cc34mm Bolt x 6
Ca
2
3
Pc
Cb
Cb
Cb
Cb
Cb
Cb
1
Pc
Ca
8
Ko
Ko
Bo
7
3
2
Ko
4
ø4,2 x 9,5mm Screw x
Magnet, adjustable x
Pc
2
8
350269-09
1.2 x 15mm Nail x
Di
36
Distribute equally !
5
Di
4
4
1
5
6
Di
Di
Di
1
1
Kb
ø5.8 x 8mm Screw x
4
Shelf support x
Fr
4
Wall strap and instruction x 1
Fh
Kb Fr
Kb
Fr
Kb
Fr
9

Assembly Instructions
Place the cup hinges
Mf
into the holes indicated
on the doors
11 and 12 .
Fix the hinges using
screws
Bo
.
Fix the magnet catches
Pd
using screws
Bo
into
the holes indicated.
Step 2.1
Assembly of the doors.
Step 2
350269-10
9
12
Mf
Bo
Bo
Mf
6
ø26mm Cup hinge x
35 x 12 x 1mm Magnet catch x
Pd
4
ø3 x 12mm Screw x
Bo
16
Bo
Bo
Bo
11
12
10
11
Mf
Bo
Pd
Pd
Bo
Bo
Mf
Mf
Bo
Bo
Mf
Bo
Pd
Mf
Pd

Assembly Instructions
Step 2.2
Place the hanger rail 10
into the supports
Fl
.
Slide the cup hinges
Mf
onto the crossplates
Mc
.
Fix the hinges using the
premounted screw in the
crossplates.
See details below on how
to t the cup hinge
Mf
onto the cross plate
Mc
.
Adjust the magnets
Pc
.
350269-10
9
12
Mf
Bo
Bo
Mf
6
ø26mm Cup hinge x
35 x 12 x 1mm Magnet catch x
Pd
4
ø3 x 12mm Screw x
Bo
16
Bo
Bo
Bo
11
12
10
11
Mf
Bo
Pd
Pd
Bo
Bo
Mf
Mf
Bo
Bo
Mf
Bo
Pd
Mf
Pd
10
350269-11
!
!
Mc
Mf
Mf
Mc
Pc Pc
12
11
10
10

Assembly Instructions
Adjusting the doors
left/right.
a:
To adjust the door
towards the left hand
side - turn the adjusting
screw to the right.
b:
To adjust the door
towards the right hand
side - turn the adjusting
screw to the left.
Step 2.3
Adjusting the doors
forwards/backwards.
a:
Loosen the xing screw.
b:
Push the cup hinges /
the door forwards OR
backwards to adjust.
c:
Tighten the xing screws
of ALL the crossplates.
Adjusting the doors
up/down.
a:
Loosen the two pre-mounted
screws of each crossplate,
BUT ONLY as much as it
will allow the cross plate to
move up and down.
b:
Push the the door up OR
down to adjust.
c:
Tighten the pre-mounted
screws of ALL the
crossplates.
350269-12
11
a: b:
a: b: c:
a: b: c:
If you need help or have damaged or missing parts, call the Argos Customer Helpline: 03456 400 800
Home Retail Group - 489-499 Avebury Boulevard - Saxon Gate West - Central Milton Keynes MK9 2NW

350269-12
11
a: b:
a:b:c:
a:b:c:
If you need help or have damaged or missing parts, call the Argos Customer Helpline: 03456 400 800
Home Retail Group - 489-499 Avebury Boulevard - Saxon Gate West - Central Milton Keynes MK9 2NW
No.3 "Shield Anchor" Wall Plug
Heavy Loads
For use with heavier loads such as TV
& HiFi Speakers and Satellite Dishes etc.
No.4 "Cavity Fixing" Wall Plug
For use with plaster board partitions or
hollow wooden doors.
No.5 "Cavity Fixing - Heavy Duty"
Wall Plug
For use when fitting or supporting heavy
loads such as shelving, wall cabinets,
coat racks.
IMPORTANT:
When drilling into walls always check that there are no
hidden wires or pipes etc. Make sure that the screws and
wall plugs being used are suitable for supporting your unit.
Consult a qualified tradesperson if you are unsure.
HINTS:
1) General Rule Always use a larger screw and wall plug if you are not sure.
2) Ensure you use the recommended drill bit to match the wall plug and hole size.
3) Ensure you drill the hole horizontally, do not force the drill or enlarge the hole.
4) Take extra care when drilling high walls, ceilings and ceramic tiles. Ensure the plug is fitting below the ceramic
tile to avoid splitting or cracking.
5) Ensure wall plugs are well fitted and are a tight fit in the drilled hole.
Types Of Walls
You can use one of the following types
of wall plug if your walls are made of
brick, breeze block, concrete, stone,
wood or plaster board.
No.1 "Standard" Wall Plug
General Wall Materials
These come in various sizes and are made
from plastic or sometimes wood fiber.
No.2 "General Purpose" Wall Plug
Aerated / Breeze Block
Generally aerated blocks should not be
used to support heavy loads, use a
specialist fitting in this case.
For light loads, a General Purpose Plug
can be used.
No.6 "Hammer Fixing" Wall Plug
For use with walls stuck with plaster
board. The hammer fixing allows it to
be fixed to the wall rather than the plaster
board. Always check the fixing is secure
to the retaining wall.
CARE & MAINTENANCE
SAFETY
Always check the fitting and
location to ensure your safety in
and around the home.
FITTING
From time to time check the fitting
to ensure the wall plugs or screws
do not become loose.
Wall Mounting & Fixings
A Guide to
