Chicago Dining Set - Bench
Assembly Instructions - Please keep for future reference
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Issue 1 - 28/04/15
Dimensions
Length - 95cm
Width - 30cm
Height - 45cm
404/4952

Care and maintenance
Handy Hints
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• Do not stand on the bench.
• Do not use this bench as step
ladder.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the
bolts.
• Regularly check and ensure
that all bolts and fittings are
tightend properly.
• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product, this
could cause damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Unit weight: 7.8 kgs.
• Maximum safe weight of user:
110kgs.
1
Safety and Care Advice
Important - Please read these instructions fully before starting assembly

2
Components - Parts
Please check you have all the parts listed below
If you have damaged or missing components, call the
Customer Helpline: Argos = 0345 640 0800
Right leg x 2
(2.9 x 6.8 x 43cm)
5Left leg x 2
(2.9 x 6.8 x 43cm)
4
Seat
(7.5 x 30 x 95cm)
1Short stretcher x 2
(2 x 5.5 x 20.5cm)
2
Long stretcher
(2 x 5.5 x 81.5cm)
3
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
Flat washer x 8
B
Spring washer x 8
C
M6 x 70mm Bolt x 8
D
M4 x 38mm Screw x 6
E
Allen key x 1
Tools required
Crosshead screwdriver
L
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105

L
L
3
Attaching left legs and
short stretchers
a: Insert the short
stretchers into holes
on left legs as shown.
b: Then fix through
holes using screws .
Tighten screws using a
crosshead screwdriver.
Assembly Instructions
Step 1
Step 2
D
2
4
Attaching right legs
a: Insert the short
stretchers into holes
on right legs as
shown.
b: Then fix through
holes using screws .
Tighten screws using a
crosshead screwdriver.
D
5
2
D
D
D
D
D
D
a:
b:
a:
L
L
4
4
4
4
2
2
2
2
b:
2
2
2
2
5
55
5

4
Assembly Instructions
Step 3
Attaching long
stretcher
Attach the long stretcher
to the legs by
inserting the dowels on
the long stretcher into
holes on the short
stretcher .
3
L
Step 4
Attaching seat
Position the seat face
down on a flat protected
surface.
Position the leg frame on
the seat as shown then
fix the legs & to
seat using bolts ,
spring washers and
flat washers . Tighten
bolts using allen key .
A
B
C
E
1
Position holes up
R
L
2
5
4
2
3
3
2
2
5
4
R
L
A
A
B
B
CC
ABC
A
A
A
B
B
C
A
B
C
A
B
C
C
A
B
B
C
C
A
B
C1
1
4
4
4 5
5
5
5

R
5
D
D
D
R
L
Securing the long
stretcher
Fix through holes on the
long stretcher and
short stretchers using
screws . Tighten
screws using a
crosshead screwdriver.
Carefully turn over the
unit.
D
Assembly Instructions
Step 5
3
3
3
2
2
2
2
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Assembly is complete.
