Deco - 4 Shelf Display Cabinet
Dimensions
Width - 80cm
Depth - 9.5cm
Height - 60cm
Issue 23 - 26/09/2012
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01429 862616
or email us at [email protected]
Assembly Instructions - Please keep for future reference
MC0498
MC0497
MC0499
1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Care and maintenance
• Do not place very hot or cold
items on the glass surface(s)
unless adequately thick table
mats or coasters are used to
prevent such items from coming
into contact with the glass
• Do not sit or stand upon the
glass.
• Do no use the glass as a
chopping surface.
• Do no strike the glass with
hard or pointed items.
• When cleaning glass panels
use a damp cloth or leather
with washing up liquid or soft
soap if necessary: do not
use washing powders or any
other substances containing
abrasives since these
substances scratch glass.
Glass care and maintenance
Components - Panels
Please check you have all the panels listed below
2
Base (77 x 9.4cm)
2
Top (77 x 9.4cm)
1
Side x 2 (60 x 9.5cm)
3
If you have damaged or missing components,
call the Customer Helpline: 01429 862616
Left Door (57.3 x 39cm)
4Right Door (57.3 x 39cm)
5
Back Panel (folded) (59.5 x 39.8cm)
6Shelf x 4 (76.9 x 6.5cm)
7
glass glass
3
Please check you have all the fittings listed below
4cm Screw x 8
Ruler - Use this ruler to help correctly identify the screws
Tools required
A
Hanging Plate x 2
E
2cm Panel pins x 14
B
Shelf Support x 16
C
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Door Dampeners x 2
F
1.4cm Screw x 4
D
Screw Covers x 1 set
G
Components - Fittings If you have damaged or missing components,
call the Customer Helpline: 01429 862616
crosshead
screwdriver
Small
hammer
Ruler/tape
measure
Drill
Eye protection
(when using a
hammer or glue)
7mm Suitable drill bit
(for use with wall plug)
4
Assembly Instructions
Step 1
Attaching side
Position top 1and base
2as shown against
side panel 3.
Note: keep shelf support
holes in side 3at back of
unit and the door grooves of
base 2at the front.
Fix into place using
screws Abut don’t fully
tighten.
Inserting Glass Door
Warning:
Handle glass
doors with care
Slide left side glass door
4into the rear groove in
top 1and base 2.
Repeat for right side
glass door 5but slide
into the front groove in
top 1and base 2.
Inserting shelves
Slot all four shelves 7
into the frame resting
them on the base 2.
1
A
2
3
A
A
A
Step 2
4
Step 3
7
glass
Warning:
handle
glass
doors
with care
front edge
make sure
holes
are towards
the back of
the cabinet
Assembly Instructions
Step 4
Attaching left side
Position side 3against
base 2and top 1as
shown. Fix into place
using screws A. Push
top 1and bottom 2
panels together ensuring
runners are in tight
contact with glass, then
fully tighten 8 screws A.
Adjusting shelves
Insert shelf supports C
in pairs down the left
side panel 3. Repeat
another 3 times. Starting
with the top shelf, angle
each shelf 7in turn
so that they rest on the
inserted shelf supports.
Then add another two
shelf supports Cper
shelf into the right side
panel so that each shelf
rests level. Repeat 3
times.
Attaching back panel
Lay cabinet face down
on padded area and
ensure cabinet is fully
square at each corner.
Position back panel
6- again push Top 1
and Bottom 2together
ensuring runners are in
tight contact with glass
then insert panel pins B
into frame as shown.
Attach the metal hanging
plates Eto the top
corners of back panel 6
using screws D.
Step 5
5
3
A
A
A
A
C
C
B
6
B
BBB B B
B
B
BB B B
B
E
D
D
E
D
D
Step 6
NOTE:
Make
sure that
screws D
are fully
inserted
into side
panels 3
as these
are used
to sustain
the full
weight of
unit.
Assembly Instructions
Step 7
Inserting door stops
Insert door stop
dampeners Finto the
grooves in base 2.
Insert the left one in the
front groove and the right
one in the back groove
as shown.
Adding screw covers
Tighten all screws and
cover with screw cover
stickers G.
Fixing to wall
Measure the distance
between the fixing
holes in metal hanging
plates E. Transpose this
measurement to the wall
making sure the marks
are level.
Drill holes suitable for
your wall plugs. Tap wall
plugs into drilled holes.
Attach unit to wall using
suitable screws.
Note: make sure you use
wall plugs suitable for your
type of wall - see page 7.
Assembly is complete.
Step 9
6
If you need any help or have damaged or missing parts, call the Customer Helpline: 01429 862616
Techstyle Spares, Stadium North, Tofts Farm Industrial Estate, Brenda Road, Hartlepool, TS25 2DH
F
Step 8
G
G
G
G
G
G
G
G
F
7
No.3 "Shield Anchor" Wall Plug
Heavy Loads
For use with heavier loads such as TV
& HiFi Speakers and Satellite Dishes etc.
No.4 "Cavity Fixing" Wall Plug
For use with plaster board partitions or
hollow wooden doors.
No.5 "Cavity Fixing - Heavy Duty"
Wall Plug
For use when fitting or supporting heavy
loads such as shelving, wall cabinets,
coat racks.
IMPORTANT:
When drilling into walls always check that there are no
hidden wires or pipes etc. Make sure that the screws and
wall plugs being used are suitable for supporting your unit.
Consult a qualified tradesperson if you are unsure.
HINTS:
1) General Rule Always use a larger screw and wall plug if you are not sure.
2) Ensure you use the recommended drill bit to match the wall plug and hole size.
3) Ensure you drill the hole horizontally, do not force the drill or enlarge the hole.
4) Take extra care when drilling high walls, ceilings and ceramic tiles. Ensure the plug is fitting below the ceramic
tile to avoid splitting or cracking.
5) Ensure wall plugs are well fitted and are a tight fit in the drilled hole.
Types Of Walls
You can use one of the following types
of wall plug if your walls are made of
brick, breeze block, concrete, stone,
wood or plaster board.
No.1 "Standard" Wall Plug
General Wall Materials
These come in various sizes and are made
from plastic or sometimes wood fiber.
No.2 "General Purpose" Wall Plug
Aerated / Breeze Block
Generally aerated blocks should not be
used to support heavy loads, use a
specialist fitting in this case.
For light loads, a General Purpose Plug
can be used.
No.6 "Hammer Fixing" Wall Plug
For use with walls stuck with plaster
board. The hammer fixing allows it to
be fixed to the wall rather than the plaster
board. Always check the fixing is secure
to the retaining wall.
CARE & MAINTENANCE
SAFETY
Always check the fitting and
location to ensure your safety in
and around the home.
FITTING
From time to time check the fitting
to ensure the wall plugs or screws
do not become loose.
Wall Mounting & Fixings
A Guide to
