Argos Mix and Match 709/0439 User manual

MADE IN
BRITAIN
Dimensions
Width - 68.5cm
Depth - 49.5cm
Height - 167cm
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 3 - 11/12/12
Important - Please read these instructions fully before starting assembly
ALR2786
709/0439
709/2499
709/2509
Mix and Match - 2 Door Robe
Issue 2 - 25/07/12 - SC2810 6x5/8 Flange Head Screw replaced with SC2849 6x5/8 Flange Head Screw
Issue 3 - 11/12/12 - Replaced the old ‘Blue/Pink’ cat code with 2 new ‘Blue’ and ‘Pink’ cat codes.
Changed the text regarding the handles on the fittings page.

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 38kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
bracket supplied.
• Dispose of all packaging
carefully and responsibly.

Components - Panels
Please check you have all the panels listed below
2
1
80%
x 2
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Left Side (D0884A)
(1668 x 494mm)
Top (D0003A)
(670 x 492mm)
Base (D0004A)
(670 x 478mm)
2Right Side (D0885A)
(1668 x 494mm)
Plinth (D0005A)
(670 x 80mm)
Back (X805)
(1580 x 694mm)
Door (D0886A)
(1567 x 330mm) x 2
3
4
5
6 7
Hanging Rail (FHR660)
(660mm long)
8

Please check you have all the fittings listed below
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
see malibu fitment mk2 for large number of panels and fittings
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Tools required
Rule
Scissors
Spirit
level
Hammer Bradawl
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Step
ladder
Ruler - Use this ruler to help correctly identify the screws
Electric drill
(only use
when drilling
into walls)
Square
mm 10 20 30 40 50 60 70 80 90 100 mm 10 20 30 40 50 60 70 80 90 100
Silver Handle (F1091) x 2
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A
Wooden dowel (F22) x 6
B C
D E F
G H I
Nail (F51) x 30
Blue/Pink Handle (F215) x 2
J K
Rail holder
(F1014) x 2 Bracket (F327) x 1
25mm Screw (F50) x 4
13mm Screw (F63) x 14
40mm Screw (F910) x 10
Hinge (F522) x 6
Hinge plate (F523) x 6
Beech units are supplied
with Silver Handles
13mm Screw (F79) x 1
White units are supplied
with either Blue or Pink
Handles

Finished
front edge
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
J
J
J
B
G
Step 2
1
J
J
Prepare the left side
Fit 3 hinge plates onto
the left side , making
sure that the slot is
facing towards the
finished front edge.
Push a rail holder into
the left side . Make
sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
1
B
G
J
Prepare the right side
Fit 3 hinge plates onto
the right side , making
sure that the slot is
facing towards the
finished front edge.
Push a rail holder into
the right side . Make
sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
2
B
G
1
J
J
J2
J
Finished
front edge
2
B
G
1
2

Finished
front edge
Finished
front edge
Finished
front edge
D
D
D
D
A
Assembly Instructions
Step 3
Step 4
A
A
A
Prepare the top
Tap 2 wooden dowels
into the top as
shown.
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
A
3
Prepare the base
Tap 2 wooden dowels
into the base as
shown.
A
4
10mm
A
3
4
2
D
Fit the top and base
to the right side
Attach the right side
to the top and the
base and secure with
4 screws .
Step 5
3
2
4
plain
chipboard
surface
4
plain
chipboard
surface
3
Finished
front edge
Finished
front edge
5
Note: The top has been
finished on both surfaces.
The base only has one
finished surface.

D
Assembly Instructions
6
Step 6
A
A
Plain chipboard
surface
Fit the plinth
Push the plinth onto
the right side and
secure with screw .
Step 7
Fit the left side
Push the left side
onto the assembly
and secure with 5
screws .
Step 8
Prepare the base
Tap 2 wooden dowels
into the plinth as
shown.
A
55
5
2
5
2
D
D
D
D
D
D
1
1
D

Assembly Instructions
Step 9
Fit the back panel
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
coloured surface facing
down, onto the unit as
shown.
Nail around the
outside edges of the
back .
Note: Nails should
be spaced about 150mm
apart.
Stand the unit up for
the next step.
Warning: The
unit is heavy.
Lift with care.
H
7
7
y
y
x
x
b:
H
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
7
7

Assembly Instructions
8
Step 10
Step 11
Fit the hanging rail
Push the hanging rail
into the rail holders
fitted to the side panels
. and .
8
B
1 2
1
2
8
8
B
Prepare the doors
Push fit 3 hinges into
each of the doors .
Secure each hinge with
2 screws .
Note: Before securing
with the screws, make
sure that the hinges are
positioned at 90 degrees
with the edge of the
door.
G
K
6
90
K
K
G
G
K
G
G
K
G
G
x 2
6

Assembly Instructions
Step 12
Fit the doors and the
handles
2 people are needed
here
Note: The easiest way to
attach each door is
to fit the top hinge first,
then align and fit the
other hinges.
a: Push the hinge
onto the front part of the
hinge plate .
b: Keep the hinge
FLAT against the hinge
plate as you slide it
across as far as it will go.
Tighten screw A.
c: The hinge must be
flat against the hinge
plate prior to any
adjustment.
d: The hinge must
NOT be AT AN ANGLE
to the hinge plate
when assembled.
This would indicate that
the recess at the bottom
of screw B had not
located in the slot in the
hinge plate and the hinge
would not be secure.
Remove the hinge from
the hinge plate and then
re-assemble being
careful to follow
instructions a-c.
e: Attach a handle to
each door using
screws .
Note: Do not
overtighten screw .
K
K
K
J
J
J
K
J
I
E
E
6
6
E
I
I
E
6
6
a: b:
c: d:
J
K
J
J
B
J
K
K
K
A
K
J
B
e:
9

Assembly Instructions
10
Step 13
b:
c:
d:
a:
Adjust the doors if
needed
a: Before adjusting the
doors, use a spirit level
to check the base (or
top) of the unit is level,
front-to-back and
side-to-side in the 3
positions shown.
Use suitable packing
pieces (not supplied) to
make the unit level
BEFORE making any
adjustment to the hinges,
as shown.
b: Height adjustment.
Loosen screws A on
hinge plates and move
door up or down as
required.
Retighten screw A.
c: Forward and Back
adjustment.
Loosen screw B on hinge
plate and move door in
or out as required.
Retighten screw B.
d: Sideways
adjustment.
To move door ‘out’
loosen screw C.
To move door ‘in’ tighten
screw C.
A
A
B
C

Assembly Instructions
11
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
ALR2786
Step 14
Step 27
10
E
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
b:
10
yyy
x
x
E
Fit the drawers
Slide the wheels of the
runners fitted to the
drawers, over the wheels
of the runners fitted to
the side panels and
uprights, and push the
drawers into position.
Now repeat these
assembly instructions
for the other bedside
Assembly is complete
Side panel / upright
Drawer
10
Top of Unit
WALL WALL
Back of Unit
Fit the bracket
To prevent possible
overbalancing, we
recommend that this unit
is secured to a suitable
wall by use of the
bracket fitted to the
top of the unit.
Fixings are not supplied,
as they will need to suit
the wall type and the
length of screw will
depend on the distance
from the back of the unit
to the wall.
Fix the bracket
loosely onto the top of
the unit using screw
and mark the wall for the
wall fixing.
Swivel the bracket
away from the wall and
drill a hole in the wall
using a suitable drill bit
and fit your wall fixing.
Swivel the bracket
back and fix the bracket
to the wall, then tighten
Screw .
Note: Take care when
drilling the wall that you
do not drill into any
pipes, wires etc.
If in doubt, consult an
expert.
Warning: The
unit is heavy.
Lift with care.
Assembly is complete
C
C
F
C
C
F
C
F
C
C
