Argos 357/7097 User manual

MADE IN
BRITAIN
Dimensions
Width - 63cm
Depth - 39cm
Height - 75cm
Capella - 3+2 Drawer Chest
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 28/11/14
Important - Please read these instructions fully before starting assembly
357/7097
330/7559
339/2344
ALR3120
03/08/11 - Drawer assembly changed to Knock-in Pegs.
Drawer Sides and Drawer Back changed to take Knock-in Pegs.
Issue 4 - 16/05/12 - New Argos code added
Issue 5 - 27/03/14 - Increase drawer size.
Add 6 drawer wedges.
Add 4 Plastinails.
Remove old cat codes and add new ones
Issue 6 - 09/05/14 - Increased drawer wedges to 12.
Added‘x3’ to the Drawer Side, Drawer Back and Drawer Base on the components page.
Issue 7 - 21/05/14 - Changed wording at Steps 8B and 9B from“use the third hole from the back” to“use the corresponding hole”.
Step 12 diagram amended to show correct Dowel position.

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 24kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: If there is any
chance of this unit being pulled
over by children etc. it is
recommended that the unit is
secured to a wall using suitable
fixings (not supplied).
• Dispose of all packaging
carefully and responsibly.
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.

Components - Panels
Please check you have all the panels listed below
2
80%
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Large Drawer Front (D1010A)
(592 x 157mm) x 3
Back (X647-622A)
(647 x 622mm)
12
5
13
15
Large Drawer Base (T575-367)
(575 x 367mm) x 3
8 9
Small Drawer Back (W259 -124)
(259 x 124mm) x 2
Left Drawer Side (W370-124LH)
(370 x 124mm) x 5
Right Drawer Side (W370-124RH)
(370 x 124mm) x 5
12
6
Left Side (D1039A)
(744 x 390mm)
Small Left Drawer Front
(DF1852A) (294 x 157mm)
Right Side (D1040A)
(744 x 390mm)
Small Right Drawer Front
(DF1853A) (294 x 157mm)
7
3Top (DF1848A)
(596 x 369mm)
Rail (D1009A)
(596 x 103mm) x 2
4
14 Small Drawer Base (T270-367)
(270 x 367mm) x 2
11 Large Drawer Back (W564 -124)
(564 x 124mm) x 3
Divider (DF1851A)
(368 x 155mm)
10

Please check you have all the fittings listed below
Tools required
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A
Wooden dowel (F22) x 8
B
Metal dowel (F901) x 20
D E
Large locking
nut (F900) x 10
F
G H I
K
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Small locking
nut (F3) x 10
C
Nail (F51) x 16
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
J
Drawer runner (F1004) x 10
Handle (F930) x 5
25mm Screw (F50) x 10 9mm Screw (F74) x 10 9mm Screw (F73) x 20
L
Knock-in Peg (F171GY) x 20
Plastic Nail (F91) x 4
M
Wedgefix (F639) x 16
NStrap
Screw Washer x 2
Overbalance protector kit (F269) x 1

Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
x 3
Prepare the drawer
fronts
Screw 2 metal dowels
into the holes shown on
the back of each large
drawer front .
Note: Tighten the metal
dowels up fully against
the panels.
B
5
Prepare the drawer
sides
Insert a small locking
nut into the hole
shown on the left drawer
side and right drawer
side .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
B
E
8
9
Step 2
B
B
B
B
5
Step 3
x 3
x 3
x 3
B
E
Attach the drawer
sides to the drawer
fronts
Push the left drawer sides
. and right drawer sides
. onto the back of the
large drawer fronts .
Turn the small locking
nuts on the left
drawer side and right
drawer side .
Note: Turn the locking
nuts clockwise to
secure panels - more
than 1/2 a turn.
8
9
5
E
E
8
9
E
EE
89
9
8
5

Assembly Instructions
5
Step 4
Attach the handle
Attach a handle to
each large drawer front
using 2 screws .
K
G
Step 6
5
x 3
G
G
K
5
5
L
L
Fit the large drawer
base
Slide the large drawer
base down the
grooves in the drawer
sides and and
down into the groove in
the large drawer front .
.
Step 5
Fit the large drawer
back
Fit the large drawer back
. between the drawer
sides and .
Make sure that the
drawer base fits into
the groove in the drawer
back .
Hold the drawer back
in position and tap the
knock-in pegs
through the holes in the
drawer sides and .
13
8 9
5
11
8 9
13
11
11
L
x 3
x 3
x 3
L
L
8
13
13
9
8
8 9
11
M
Fit the wedgefixes
Turn the large drawer
assemblies over and
slide 4 wedgefixes
into the front and back
grooves, as shown, and
tighten up the screws.
M
M
MM
M
Step 7
9

Assembly Instructions
6
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 8
Prepare the drawer
sides
Insert a small locking
nut into the hole
shown on the left drawer
side and right drawer
side .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
E
8
9
Step 9
Step 10
E
x 2 x 2
EE
89
Step 1
x 2
B
B
B
E
Prepare the 2 small
drawer fronts
Screw 2 metal dowels
into the small left drawer
front and the small
right drawer front .
Note: Tighten the metal
dowels up fully against
the panels.
B
6
Attach the drawer
sides to the small
drawer fronts
Push the left drawer sides
. and right drawer sides
. onto the back of the
2 small drawer fronts
and .
Turn the small locking
nuts on the left
drawer side and right
drawer side .
Note: Turn the locking
nuts clockwise to
secure panels - more
than 1/2 a turn.
8
7
9
6
E
E
8
9
9
B
B
B
B
7
6 7
Note: The small right
drawer front has a shallow
identification mark.
8
67

Assembly Instructions
Step 11
L
L
Fit the small drawer
base
Slide the small drawer
base down the
grooves in the drawer
sides and and
down into the groove in
the small drawer fronts
. and .
Step 12
Fit the small drawer
back
Fit the small drawer back
. between the drawer
sides and .
Make sure that the small
drawer base fits into
the groove in the small
drawer back .
Hold the small drawer
back in position and
tap the knock-in pegs
through the holes in the
drawer sides and .
Step 13
14
8 9
6 7
12
8 9
14
12
12
L
Attach the handles
Attach a handle to
each small drawer front
. and using 2
screws .
Note: Do not
overtighten the screw.
K
G
6 7
x 2
x 2
x 2
L
L
9
8
67
14
14
9
8
8 9
12
H
89
x 2
7
Step 14
M
M
Fit the wedgefixes
Turn the drawer
assemblies over and
slide 2 wedgefixes
into the front and back
grooves, as shown, and
tighten up the screws.
M
M
G
G
K

Profiled
front edge
Profiled
front edge
Profiled
front edge
Assembly Instructions
8
Step 15
Profiled
front edge
I
J
I
J
Back edge
I
J
Prepare the left side
a: Place 4 runners on
the left side . Slide
back the top of the
runner and use the 1st
hole from the front to fit
the 1st screw .
b: Slide the runner back
the other way and use
the 3rd hole from the
back to fit the 2nd screw
.
c: Screw 4 metal
dowels into the left
side .
a:
b:
c:
1
I
B
1
I
J
I
J
I
J
I
J1
1
1
I
I
I
I
B
B
B
B

Assembly Instructions
9
Step 16
Prepare the right side
a: Place 4 runners on
the right side . Slide
back the top of the
runner and use the 1st
hole from the front to fit
the 1st screw .
b: Slide the runner back
the other way and use
the 3rd hole from the
back to fit the 2nd screw
. .
c: Screw 4 metal
dowels into the right
side .
Profiled
front edge
I
J
Back edge
I
J
I
J
2
I
B
2
a:
b:
c:
2
2
2
I
J
I
J
I
J
I
J
I
I
I
I
B
B
B
B
Profiled
front edge
Profiled
front edge
Profiled
front edge

A
A
Assembly Instructions
10
Prepare the top
Tap 4 wooden dowels
into the top as
shown.
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
Insert 4 large locking
nuts into the top .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Screw 2 metal dowels
into the top .
10mm
A
A
3
3
D
Step 18
B
3
D
D
D
D
A
A
Finished
front edge
3
B
Step 17
B
A
D
D
A
Prepare the rails
Tap 2 wooden dowels
into each of the rails .
Insert 2 large locking
nuts into each of the
rails .
A
4
D
4
4x 2

Assembly Instructions
11
Step 19
Finished
front edge
Finished
front edge
Prepare the divider
a: Place a runner on
the divider as shown.
Slide back the top of
runner and use the 1st
hole from the front to fit
the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the divider .
Insert 2 large locking
nuts into the divider
. .
Turn the divider over
c: Place a runner on
the divider as shown.
Slide back the top of
runner and use the 1st
hole from the front to fit
the 1st screw .
d: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the divider .
10
I
I
E
10
10
J
J
10
I
I
10
J
J
a: b:
c: d:
I
E
E
Note: Due to the manufacturing process, the 2 holes for
the large locking nut can be on either surface of the divider.
Finished
front edge
I
Finished
front edge
10 10
10 10
Turn the divider over
Finished
front edge
I
J
I
J
Finished
front edge
I
J
I
J
D
B
Join the divider and
top
Push the top onto
the divider as
shown.
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the divider .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
3
D
D
10
3
Finished
front edge
Finished
front edge
10
Step 20
10

Assembly Instructions
12
Step 21
D
B
Join the right side and
top
Push the top onto
the right side as
shown.
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the top .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
Step 22
3
2
D
D
3
Profiled
front
edge
2
3
Finished
front edge
Note: Support this
rail until the left
side has been fitted
in the next step.
Fit the rails
Push the rails onto
the right side as
shown.
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the rails .
4
2
D
4
2
3
Finished
front edge
4
4

Assembly Instructions
13
Step 23
Fit the left side
Push the left side
onto the assembly.
Use a screwdriver to
tighten the 4 large
locking nuts fitted to
the top and the rails
.
D
1
3
4
y
y
x
b:
C
Fit the back
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the
outside edges of the
back .
Note: Nails should
be spaced about 150mm
apart.
15
C
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
15
Step 24
Warning: The
unit is heavy.
Lift with care.
Fit the 4 plastic nails
Tap 2 plastic nails
into the bottom edge of
each of the sides and
. .
F
1
2
Stand the unit up
for the next step.
3
4
4
1
x
F
F
F
F
2
1
15

Assembly Instructions
14
Step 25
Fit the drawers
Starting with the bottom
drawer, slide both the
runners forward and
locate the drawer
sides and
between them, lining up
the holes in the drawer
wrap with the 2nd
'threaded' holes in the
runners .
Working from the inside
of the drawer, insert 2
screws through the
drawer sides and out into
the 2nd threaded hole in
the runner.
Note: Do not overtighten
the screws .
If they catch on the
runner you may need to
loosen them slightly.
Assembly is complete
H
J
J
H
2nd threaded
hole
J
H
8 9
Warning: The
unit is heavy.
Lift with care.
H
6
H
J
H
8
9

Assembly Instructions
15
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 25
Strap
Strap
Washer
Washer
Screw
(not supplied)
Screw
Wall fixing
(not supplied)
Wall
Wall
Fit one end of the strap to the wall
Fit the other end of the strap to a
suitable position on the unit
Fit the overbalance
protector
To prevent possible
overbalancing we
recommend that this unit
is secured to a suitable
wall by fitting of the
overbalance protector kit
. to the unit or an
alternative fixing method
of your choice.
Wall fixings are not
supplied as they will
need to suit the wall
type.
N
N
N
Warning: Take care
when drilling the wall that
you do not drill into any
pipes, wires etc. If in
doubt, consult an expert
ALR3120
