Argos 900/2566 User manual

Black Wide CD DVD Multimedia Unit
Dimensions
Width - 63.3cm
Depth - 20cm
Height - 113.1cm
Issue 1 - 9/07/08
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
900/2566
Assembly Instructions - Please keep for future reference

1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Note: If required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all ttings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its nal position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your oor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
Skin contact: Remove
contamination by washing with
soap and water. This procedure
should also be followed prior to
eating and drinking.
Eye contact: Rinse immediately
with clean water for 15 minutes
and seek medical advice.
If swallowed: Seek medical
advice immediately.
Glue safety - Take care when using glue, please follow the advice below

Please check you have all the panels listed below
2
Top
1
(13.2 x 60.6cm)
Base
2
(20 x 63.3cm)
Left side panels
3
(13.1 x 110.8cm)
Right side panels
4
(13.1 x 110.8cm)
Centre Section (Left)
5
(13.1 x 110.8cm)
Centre Section (Right)
6
(13.1 x 110.8cm)
Back board x 2
8
(21.6 x 111.3cm)
Components - Panels If you have damaged or missing components,
call the Customer Helpline: 08456 400800
Centre Back Board
9
(13.35 x 111.5cm)
Adjustable Shelves x 12
7
(10.6 x 20.85cm)

3
Please check you have all the ttings listed below
38mm Screw x 8
A
Dowel x 8
B
Glue x 1
C
Note: The quantities below are the correct amount to complete the assembly. In some cases more ttings
may be supplied than are required.
Components - Fittings
Stability brackets x 8
D
14mm Screw x 8
E
Shelf support x 48
F
Wall Strap x 2 10mm Screw x 2
G
Tools required
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Small
hammer
Ruler/tape
measure
Drill
Eye protection
(when using a
hammer or glue)
7mm Suitable drill bit
(for use with wall plug)
01 02 03 04 05 06 07 08 09 0 100 110 120 130 140 150
01 23 45 6
Ruler - Use this ruler to help correctly identify the screws
100 20 30 40 50 60 70 80 90 100
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Plug x 2 32mm Screw x 2

4
Assembly Instructions
Step 1
3
C
Top assembly
Using a drop of glue
attach eight dowels to
the underside of the top
.
Attach the sides &
and centre sections &
to the top ensuring
that they are the right
way up (as per the diagram)
and the grooves cut into
the panels for the back
boards are all to the rear
of the unit.
B
4
1
3
5
6
4
B
C
B
56
1
1
Step 2
8
Attaching back panel
Slide the back boards
& down the grooves
in the sides & centre
sections taking care to
ensure that the cut-out
in the top of part for
the wall xing strap is
adjoining the top when
in place.
8
8
9
1
1
89

5
Assembly Instructions
Step 3
Step 4
A
E
D
A
2
2
Bottom assembly
Attach the base using
eight screws .
Before tightening ensure
the back boards locate
correctly in the groove
cut into the base.
2
A
Using the screws attach
the Stability brackets in
the approximate positions
shown in the diagram to
ensure the assembled
unit is stable and rigid.
E
D

6
Assembly Instructions
Step 5
Setting CD or DVD
Compartments
For CD: CD is partitioned
into 7 compartments.
For DVD: DVD is partitioned
into 4 compartments.
Carefully turn the unit the
correct way up.
Insert the shelf supports
pins at the appropriate
level for the media you
wish to store and then
insert the shelves .
7
F
F
7
7
7
7
7
7
7
7
7
7
7
7
141.5
147.5
147.5
147.5
147.5
147.5
152
301.5
243.5
312
211.5
Step 6
For CD For DVD

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
7
Assembly Instructions
Step 7
Finishing the unit
NOTE: It would be useful
to ask someone to help
you at this stage.
It is strongly
recommended that the
unit is attached to the
wall using Wall Strap .
Drill a hole in the wall at
an appropriate position
and insert a suitable Wall
plug .
To secure the unit, x
wall Strap to the wall
using a suitable Screw .
Assembly is complete.
G
G
Warning:
Before drilling,
check wall for
hidden pipes
and cables.
Note: Wall plugs supplied are
for solid walls only.
The correct type of xing must
be used for your wall, seek
professional advice if in doubt.

8

Wide DVD and CD Multimedia Storage Unit
Dimensions
Width - 63.3cm
Depth - 20cm
Height - 113.2cm
Issue 1 - 3/07/13
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
900/2566Assembly Instructions - Please keep for future reference

1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Note: If required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its fnal position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws ,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance

Please check you have all the panels listed below
2
Top(13.2x60.6cm)
1
If you have damaged or missing components,
Components - Panels
call the Customer Helpline: 08456 400800
Base (20x63.3cm)
2
Left side panel
3
(13.1x110.8cm)
Right side panel
4
Left center panel
5
Right center panel
6
Adjustable shelf x 10
7
(10.6x20.8cm)
Fixed shelf x 2
8
(10.6x20.8cm)
Back board x 2
9(21.4x111.4cm)
Centre Back board
10 (13.6x111.4cm)
(13.1x110.8cm)
(13.1x110.8cm)
(13.1x110.8cm)
UP
UP

3
Please check you have all the fttings listed below
38mm Screw x 16
AB
Cam bolt x 8 Cam lock x 8
C
I
Note: The quantities below are the correct amount to complete the assembly. In some cases more fttings
may be supplied than are required.
Components - Fittings
Stability bracket x 8
D
15mm Screw x 8
E
H
Shelf support x 40
F
Wall strap x 2
25mm Screw x 2
G
Tools required
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Small
hammer
Ruler/tape
measure
Drill
Eye protection
(when using a
hammer or glue)
7mm Suitable drill bit
(for use with wall plug)
01 02 03 04 05 06 07 08 09 0 100 110 120 130 140 150
01 23 45 6
Ruler - Use this ruler to help correctly identify the screws
Wall plug x 2
12mm Screw x 2
JK
Cap x 8
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170

4
Assembly Instructions
Step 1
Fitting Cam bolt
Step 2
3
3
5
4
5
5
3
4
8
8
6
6
E
F
F
E
Screw the Cam bolts
into the panel &
.
4
6
Fitting Cam lock
lnsert the Cam lock
into Fixed shelf .
Turn the Cam lock
clockwise until tightened.
Be careful not to over
tighten as this can break
the Lock.
FF
8
J
F
UP
UP
J
E
J
F
NOTE: Ensure center
panel & are in the
right way up
(as per diagram ).
56

5
Assembly Instructions
Step 3
Step 4
Step 5
9
1
1
9
10
G
G
I
I
K
K
A
Attach the Top using
Screws .
Before tightening ensure
the grooves of the panels
for the back boards are all
in the rear of the unit.
A
Fitting Top
Fitting Back
Use 12mm Screw to fix
Wall strap onto the unit.
Slide the Back boards
& into the grooves of
the side & center panels.
Ensure that the cut-out in
the top of part for the
wall fixing strap is
adjoining theTop
in place.
Use Cap to cover the
screw.
1
9
9
10
1
1
UP
UP
UP

Assembly Instructions
Step 6
Step 7
Fitting Base
Attach the Base using
Screw .
Before tightening ensure
the back boards locate
correctly in the groove
cut of the base.
2
A
A
Attached the Stability
bracket using Screw
positions shown in the
diagram to ensure the
assembled unit is stable
and rigid. C
B
6
2
J
B
J
C
UP
in the approximate

7
Assembly Instructions
Step 8
Step 9
Fitting Shelf support
Insert Shelf support
at the appropriate level
7
7
7
7
7
7
7
7
7
7
DD
Carefully insert the Shelf
Fitting Shelf
onto the unit.
for the media you wish to
store.
7

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
8
Assembly Instructions
Step 10
Fixing to wall
NOTE: It would be useful
to ask someone to help
you at this stage.
It is strongly
recommended that the
unit is attached to the
wall using Wall strap .
Drill a hole in the wall at
an appropriate position
and insert Wall plug .
To secure the unit, fix
Wall strap to the wall
using Screw .
Assembly is complete.
I
I
I
J
J
H
Warning:
Before drilling,
check wall for
hidden pipes
and cables.
wall
Note: Wall plug supplied are
for solid walls only.
The correct type of fxing must
be used for your wall, seek
professional advice if in doubt.
J
H

9
A Guide to - Wall Mounting & Fixings
Revision 2 - ‘12/09/03
Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist ftting in this case. For light
loads, general purpose wall plugs can
be used.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
For use when ftting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with walls stuck with
plasterboard. The hammer fxing allows
it to be fxed to the wall rather than the
plasterboard. Always check the fxing
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
Safety: Always check the ftting
and location to ensure your safety
in and around the home.
Fitting: From time to time check
the ftting to ensure the wall plugs
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well ftted and are a tight ft in the
drilled hole.
If plastic wall plugs
are supplied with your
product:
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualifed
tradesperson if you are unsure.
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect fxings is the
responsibility of the installer.
