Argos Cube Coffee Table User manual

Simple Assembly Instructions - Please keep for future reference
IMPORTANT
1. Read these instructions carefully and
familiarise yourself with the procedure
before assembling the unit.
2. Check that you have all the component
parts following the list on the back
cover and familiarise yourself with
each part before proceeding.
3. Take all the fittings out of the plastic bag
and separate them into their groups.
4. Ensure you have enough space to lay out
all the parts before assembly.
Cube Coffee Table
Components
5. To avoid scratching it is recommended
that you assemble the unit on a soft
level surface.
Fittings
3-07
A
B
D
E
C
B26 x Dowel
1 x Table Top
1 x Bottom Panel
2 x Side Panel
2 x Base Side Panel
2 x Base Panel
D4 x Locking Nut
C4 x Locking Pin
1 x Glue
E
A4 x Screw

Assembly Instructions Assembly Instructions
Stage 2 – Fitting the Side PanelsStage 1 – Fitting the Base
CAUTION: Always check
the assembly method is correct
before applying Glue.
2. Place a small amount of Glue E
into the dowel holes and onto
the joints' surfaces. Fix the Base
Panels C onto the Base Side
Panels E.
See fig. 2.
NOTE: It would be useful to ask
someone to help you at this
stage.
3. Place a small amount of Glue E
into the dowel holes and onto
the joints' surfaces. Use Dowels
Bto fix the Bottom Panel B onto
the unit.
See fig. 3.
CAUTION: Always check
the assembly method is correct
before applying Glue.
NOTE: It would be useful to ask
someone to help you at this
stage.
2. Place a small amount of Glue E
into the dowel holes and onto
the joints' surfaces. Fix the Side
Panels D onto the unit.
See fig. 5.
NOTE: Ensure the screw holes on
the Side Panels are facing
inwards.
3. Use Screws Ato fix the Side
Panels B onto the unit.
See fig. 6.
1. Place a small amount of Glue E
into the dowel holes. Insert
Dowels B into the Base Side
Panels E.
See fig. 1.
1. Place a small amount of Glue E
into the dowel holes. Insert Dowels
Binto the Side Panels D.
See fig. 4.
NOTE: Ensure the top fixing holes
are aligned and face upwards
on the side panels before
assembly.
fig. 3
BE
B
fig. 2
C
E
E
E
fig. 6
AA
fig. 4
fig. 1
E
B
B
E
D
B
B
E
E
D
fig. 5

Assembly Instructions Assembly Instructions
Stage 4 – Finishing the UnitStage 3 – Fitting the Table Top
2. Carefully place the unit in the
desired location.
See fig. 10.
fig. 10
Care and Maintenance
Safety
To avoid any risk of suffocation to animals or children dispose of the plastic
bags immediately.
Fitting
From time to time please ensure there are no loose screws on the product.
Cleaning
As with all surfaces clean with a damp cloth and mild detergent, do not use bleach
or abrasive products.
NOTE: It would be useful to ask
someone to help you at this
stage.
NOTE: It would be useful to ask
someone to help you at this
stage.
CAUTION: Always check
the assembly method is correct
before applying Glue.
1. Screw in Locking Pins C into the
Table Top A.
See fig. 7.
2. Place a small amount of Glue E
into the dowel holes and onto the
joints' surfaces. Carefully locate
the Table Top A onto the unit.
See fig. 8.
1. Use Locking Nuts Dto fix the
Table Top A onto the unit.
See fig. 9.
NOTE: Before use make sure the
unit is secure. Allow Glue to
dry for 24 hours or be
completely dry before use.
fig. 7 A
C
C
fig. 8
A
E
fig. 9
D
