Argos Curve 377/3530 User manual

Curve - Toy Box White
377/3530
Assembly Instructions
- Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800
Important – Please read these instructions fully before starting assembly
Dimensions
Width - 80,6cm
Depth - 47,3cm
Height - 53,3cm
Issue 1 - 01/03/13

Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Note: if required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1
. Check you have all the
components and tools listed on
pages 2 and 3.
. Remove all fittings from the
plastic bags and separate them
into their groups.
. Keep children and animals
away from the work area, small
parts could choke if swallowed.
. Make sure you have enough
space to layout the parts before
starting.
. Do not stand or put weight on
the product, this could cause
damage.
. Assemble the item as close
to its final position (in the same
room) as possible.
. Assemble on a soft level
surface to avoid damaging the
unit or your floor.
. We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
. Parts of the assembly will be
easier with 2 people.
. Dispose of all packaging
carefully and responsibly.
This product contain
Natural timber; you may
notice some variation in the grain
and colour of different component
parts which is normal for furniture
produced using natural wood and
is not the result of any
manufacturing fault.
.
Care and maintenance
.
. Avoid placing the furniture in
direct sunlight as this will cause
the timber to prematurely age.
Use an appropriate furniture
polish for natural wood
furniture and a dry cloth to
clean the product.
. From time to time check
that there are no loose
screws on this unit.
. This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.

Components - Panels
Please check you have all the panels listed below
2
01 Top panel (80,6 x 47,6cm)
02
03
07
08
05
06
04
Base panel (72 x 43,4cm)
Back panel (72 x 44cm)
Foot X2 (49 x 4cm)
Foot X2 (49 x 4cm)
Left side panel (44 x 43,4cm)
Right side panel (44 x 43,4cm)
Front panel (72 x 44cm)

3
2m
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
0510 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Tools required
Phillips screwdriver
(medium & large)
Eye protection
(when using a
hammer or glue)
Small
hammer
Ruler/tape
measure
A
H
D
B
F
G
J
E
C
8,0 x 30mm Wooden dowel
8,0 x 20mm Wooden dowel
3,5 x 30mm Screw X 24
X 12
X 8
D
Foot pad X 4
If you have damaged or missing components,
call the Customer Helpline: 08456 400 800
3,5 x 14mm Screw X 16
4,5 x 30mm Screw X 8
Hinge X 2
I
Locking system X 1 Soft closing hinge X 3
3,0 x 14mm Screw X 12

Assembly InstructionsAssembly InstructionsAssembly Instructions
Step 2
Step 1
Assembly Instructions
4
A
A
A
H
H
H
H
H
H
H
H
H
H
A
A
A
A
C
CC
C
C
C
A
A
A
A
A
A
A
03
05
06
06
05
08
05
08
08
07
07
07
05
02
04
Correct position
Insert wooden dowels
into the indicated parts
as shown.
Insert wooden dowels
into the left side panel
and right side panel
as shown.
Fix left side panel to
foot and foot using
screws .
Parts and are labelled.
CORRECT POSITION!

Assembly Instructions
Step 3
Step 4
5
C
C
C
C
C
07
06
08
Correct position
C
08
08
07
07
06
Fix right side panel to
foot and foot using
screws .
Parts and are labelled.
02
05
B
B
B
B
02
05
B
Fit base panel to left side
panel . Then, fix it using
screws .

Assembly Instructions
Step 5
6
Step 6
Fix right side panel to the
assembled part using 9
screws .
06
06
B
B
B
03
04
B
B
B
B
B
PAINTED EDGE!
Correct position
03
04 B
Fix back panel and front
panel using screws .
Attention!
Make sure panels
are positioned as
shown.

Assembly Instructions
Step 7
7
Step 8
E
E
E
E
E
E
Fix hinges to the top
panel using screws .
F
F
F
F
E
01
01
B
B
B
B
B
B
J
J
J
J
B
X4
J
03
J
With help, turn cabinet
upside down.
Fix base panel to the front
and back panels using
screws as shown.
With the help of a hammer,
fix foot pads as shown.
B
03

Assembly Instructions
Step 9
8
Assemble is complete!
Step 10
F
F
F
E
E
E
E
E
E
E
E
E
E
E
E
D
D
D
DD
D
D
G
G
G
G
D
D
D
I
G
D
01
Fix top panel to the pre-
drilled holes and through
the hinges on the
assembled cabinet using
screws .
E
01
a)
b)
c)
X3
Two people are required
for an easier assembly.
a) Fix locking system to
the pre-drilled holes on top
panel using screws .
b) Fix locking system to
the pre-drilled holes on side
panel using screws .
Make sure locking system
is positioned as in the
picture.
c) Fix soft closing hinges
to the pre-drilled holes on
top panel and back panel
using screws .
Make sure hinges are
positioned as in the picture. D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
I
I
I
I
