Argos Sparkle 427/5484 User manual

MADE IN
BRITAIN
Dimensions
Sparkle - 3 Door Mirrored Robe
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 1 - 08/06/15
Important - Please read these instructions fully before starting assembly
ALR3195
427/5484
428/4767
395/5640
Width - 105.1cm
Depth - 51.6cm
Height - 182.3cm

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 68kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 1, 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
overbalance protector kit
supplied or, an alternative fixing
method of your choice.
• Dispose of all packaging
carefully and responsibly.
Rule
Tools required
Rule
ScissorsSquare
Spirit
level
Hammer Bradawl
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Step
ladder
Electric drill
(only use
when drilling
into walls)

Components - Panels
Please check you have all the panels listed below
2
12 3
80%
x 3
If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
8
Shelf (DF3848)
(33.3 x 45cm) x 3
Left Side (DF3837)
(180.8 x 49.4cm)
Large Rail (DF3840)
(66.9 x 8cm)
Right Side (DF3838)
(180.8 x 49.4cm)
9
Small Rail (DF4400)
(33.3 x 8cm)
Divider (DF3847)
(171.25 x 49.2cm)
Plain Door (DF3842)
(172.4 x 34.5cm) x 2
Mirror Door (DF3842M)
(172.4 x 34.5cm)
Mirror - SG31
172 x 34.1cm
Safety Back SAR
Large Back (X1739-688)
(173.9 x 68.8cm)
Small Back (X1739-352)
(173.9 x 35.2cm)
6
7Plinth (DF3845)
(101.7 x 8cm)
Top (DF3844)
(105.1 x 51.6cm)
4
5Base (DF3846)
(101.7 x 49.3cm)
11 12 13 14
Hanging Rail (FHR663)
(66.3cm long)
10

Please check you have all the fittings listed below
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A B
D E F
IG H
O
C
P Q
Large locking
nut (F900) x 16
Metal dowel (F901) x 14 Wooden dowel (F22) x 16
R
L
Rail Holder
(F891) x 2
13mm Screw (F63) x 28
Hinge plate
(F523) x 12
Strap Screw Washer x 2
Overbalance protector kit (F269) x 1
Nail (F51) x 40 Plastic Nail (F91) x 4
Hinge (F522) x 12
25mm Screw (F50) x 6
Handle (F569) x 2
40mm Screw (F910) x 2
J
Large wooden dowel (F40) x 1
K
Double metal dowel (F566) x 1
Shelf stud (F110) x 12
N
Back holder (F276) x 5
*These can also be round
M
Nail screw (F277) x 5

Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
Step 1
80%
x 3
90%
x 1
Finished
front edge
Finished
front edge
C
C
Prepare the left side
a: Screw 4 metal
dowels into the left
side .
Note: Tighten the metal
dowels up fully against
the panels.
Insert 2 large locking
nuts into the
left side .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Tap 2 wooden dowels
into the left side .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
b: To fit the rail holder
screw through the top
hole with screw and
into the mark hole drilled
in the left side . Make
sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
Fit 4 hinge plates onto
the left side , making
sure that the slot is
facing towards the
finished front edge.
A
1
1
C
1
A
F
L
F
L
F
F
L
10mm
C
A
AA
B
B
B
P
P
P
P
P
B
L
F
1
F
P
1
1
1
b:
a: A

Assembly Instructions
5
Step 2C
A
A
A
A
C
B
B
P
P
P
P
P
Finished
front edge
Finished
front edge
Prepare the right side
a: Screw 4 metal
dowels into the right
side .
Insert 2 large locking
nuts into the right
side .
Tap 2 wooden dowels
into the right side .
b: Fit 4 hinge plates
onto the right side ,
making sure that the slot
is facing towards the
finished front edge.
A
2
2
C
2
B
P
2
2
2
b:
a:
C
C
Prepare the base
Insert 4 large locking
nuts into the base .
Tap 4 wooden dowels
into the base .
5
C
5
B
Step 3
Finished
front edge
B
B
B
B
C
C
5

Finished
front edge
Finished
front edge
Assembly Instructions
Step 4
A
B
Fit the base to the
right side
Push the base onto
the right side .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the base .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
5
2
B
B
5
2
5
C
C
B
B
P
P
P
P
F
F
L
Finished
front edge
C
C
P
Prepare the divider
Insert 2 large locking
nuts into the
divider .
Tap 4 wooden dowels
into the divider .
To fit the rail holder
screw through the top
hole with screw and
into the mark hole drilled
in the divider . Make
sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
Fit 4 hinge plates onto
the divider , making
sure that the slot is
facing towards the
finished front edge.
3
C
3
B
L
F
3
F
P
3
3
Step 5
6

Assembly Instructions
Step 6
Step 7
5
Step 8
Note: Support this rail
until the left side has been
fitted in the next step.
C
Prepare the small rail
Insert 2 large locking
nuts into the small rail
. .
Tap a wooden dowel
into the small rail .
8
C
8
B
B
B
Finished
front edge
8
2
Finished
front edge
8
Fit the small rail
Push the small rail
onto the right side .
Use a screwdriver to
tighten the large locking
nut fitted to the small
rail .
2
8
B
8
Note: Support the small
rail until the divider has
been fitted in the next
B
A
D
D
K
K
J
B
J
Fit the divider
a: Push the divider
onto the base and
attach it using 2 screws
. .
b: Tap a double metal
dowel through the
divider and into the
small rail until it
‘’bottoms out’’.
Tap a large wooden
dowel through the
divider and into the
small rail until it
‘’bottoms out’’.
c: Use a screwdriver to
tighten the large locking
nut fitted to the small
rail .
5
3
D
K
3
8
J
3
8
B
8
b:
c:
a:
3
8
7

Finished
front edge
Assembly Instructions
Step 9
8
C
Prepare the plinth
Insert 2 large locking
nuts into the plinth .
Tap 2 wooden dowels
into the plinth .
7
C
7
B
B
B
C
7
Step 10
Fit the plinth
Push the plinth onto
the right side .
Use a screwdriver to
tighten the large locking
nut fitted to the plinth
. .
Step 11
2
7
B
7
2
7
Prepare the large rail
Insert 2 large locking
nuts into the large rail
. .
Tap a wooden dowel
into the large rail .
9
C
9
B
B
C
B
9

Assembly Instructions
Step 12
Note: Support this rail
until the left side has been
fitted in the next step.
9
Fit the large rail
Push the large rail
onto the divider .
Use a screwdriver to
tighten the large locking
nut fitted to the large
rail .
3
9
B
9Note: Support the large rail
until the left side has been
fitted in the next step.
7
9
3
Step 13
Fit the left side
Push the left side
onto the assembly.
Use a screwdriver to
tighten the 4 large
locking nuts fitted to
the base , the plinth
. and the large rail .
1
B
5
795
1
Prepare the top
Screw 6 metal dowels
into the top .
A
4
A
A
A
A
A
A
Finished
front edge
Step 14
4
Finished
front edge
9

Assembly Instructions
Step 15
10
Step 11
Fit the top
Note: To make it easier
to fit the top, place
polystyrene blocks from
the packaging
underneath the side and
divider panels to raise
the assembly.
Push the top onto
the assembly.
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the left side , the right
side and the divider
. .
4
B
1
2
3
Polystyrene
block
Polystyrene
block
4
1
2
3
Step 16
Fit the 4 plastic nails
Tap 2 plastic nails
into the bottom edge of
each of the sides and
. .
H
1
2
H
HH
H
2
1
Finished
front edge

yy
yy
xx
Assembly Instructions
Step 17
11
Fit the 2 back panels
a: Square up the unit by
making sure that
measurement x:x equals
y:y.
Place the small back
and large back ,
coloured surface facing
down, onto the unit as
shown.
Make sure that the 2
backs are pushed up
tight against each other
and that they meet in the
centre of the divider’s
back edge.
b: Nail around the
outside edges of the 2
backs.
Note: Do not nail where
the 2 backs meet.
c: Push the nail screws
. through the back
holders and tap them
down between the small
back and large back
. and into the back
edge of the divider .
Keep tapping the nail
screws in until the
back holders dig into
the small and large back.
Stand the unit up for
the next step.
13
14
G
M
N
13
14
3
M
N
Warning: The
unit is heavy.
Lift with care.
Note: If ever you need to take
the backs off to dismantle the
unit, the nail screws can be
taken out using a screwdriver.
M
N
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
Note: These can
also be round
NM +
c:
M
N
13
14
N
b:
G
13
14
xx

Assembly Instructions
Step 18
12
Ix 4
Ix 4
Ix 4
Fit the shelf studs
For each of the 3
shelves , insert 4 shelf
studs .
6
I
Step 19
Fit the shelves
Lower the 3 shelves
down onto the shelf
studs .
I
6
6
6
6

Assembly Instructions
Step 20
13
Fit the hanging rail
Push the hanging rail
into the rail holders
fitted to the side panels.
10
L
10
10
L
Step 21
Prepare the 3 doors
Push fit 4 hinges into
each of the 2 plain
doors and the mirror
door .
Secure each hinge with
2 screws .
Note: Before securing
with the screws, make
sure that the hinges are
positioned at 90 degrees
with the edge of the
door.
F
Q
12
11
90
Q
x 2
Q
F
F
Q
F
F
Q
F
F
Q
F
F
11
x 1
Q
F
F
Q
F
F
Q
F
F
Q
F
F
12
Warning:
Glass! Handle
with care

Assembly Instructions
Step 22
14
Fit doors and handles
Note: The easiest way to
attach each door and
. is to fit the top hinge
first, then align and fit the
other hinges.
a: Push the hinge
onto the front part of the
hinge plate .
The recess at the bottom
of screw B goes into the
slot in the hinge plate.
b: Keep the hinge
FLAT against the hinge
plate as you slide it
across as far as it will go.
Tighten screw A.
c: The hinge must be
flat against the hinge
plate prior to any
adjustment.
d: The hinge must
NOT be AT AN ANGLE
to the hinge plate
when assembled.
This would indicate that
the recess at the bottom
of screw B had not
located in the slot in the
hinge plate and the hinge
would not be secure.
Remove the hinge from
the hinge plate and then
re-assemble being
careful to follow
instructions a-c.
e: Attach a handle to
the 2 plain doors
using 3 screws .
Important: DO NOT attempt to
attached a handle to the mirror door.
Q
Q
Q
P
P
P
Q
P
O
E
11
12
11
a: b:
c: d:
P
Q
P
P
B
P
Q
Q
Q
A
Q
P
B
e:
E
E
E
O
11
12
11
O
Warning:
Glass! Handle
with care

Assembly Instructions
Step 23
15
b:
c:
d:
a:
Adjust the doors if
needed
a: Before adjusting the
doors, use a spirit level
to check the base (or
top) of the unit is level,
front-to-back and
side-to-side in the 3
positions shown.
Use suitable packing
pieces (not supplied) to
make the unit level
BEFORE making any
adjustment to the hinges,
as shown.
b: Height adjustment.
Loosen screws A on
hinge plates and move
door up or down as
required.
Retighten screw A.
c: Forward and Back
adjustment.
Loosen screw B on hinge
plate and move door in
or out as required.
Retighten screw B.
d: Sideways
adjustment.
To move door ‘out’
loosen screw C.
To move door ‘in’ tighten
screw C.
A
A
B
C

Assembly Instructions
Step 24
16
Fit the overbalance
protector
To prevent possible
overbalancing we
recommend that this unit
is secured to a suitable
wall by fitting of the
overbalance protector kit
. to the unit, or an
alternative fixing method
of your choice.
Wall fixings are not
supplied as they will
need to suit the wall
type.
Note: Take care when
drilling the wall that you
do not drill into any
pipes, wires etc.
If in doubt, consult an
expert.
R
R
WALL
Wall fixing
(not supplied)
Screw
(not supplied)
Washer
Strap
R
Strap
Washer
Screw
TOP OF UNIT
R

Assembly Instructions
17
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 25
Assembly is complete
IMPORTANT INFORMATION ABOUT THIS PRODUCT
This product complies with the requirements of BS 7449:1991 and has been manufactured by
DECORATIVE PANELS FURNITURE LTD, TEESSIDE INDUSTRIAL ESTATE,
THORNABY-ON-TEES, CLEVELAND, TS17 9LT .
The product code for this unit and the item code(s) for the glass components are listed in the Assembly
Instructions along with a description of the type of glass used. All clear/tinted glass complies with the
requirements of BS 6206 Class A. All mirrors comply with the requirements of BS 6206 Class C. If the
glass component contained in this unit is chipped or broken consult the furniture manufacturer, retailer,
or agent with regard to obtaining a manufacturing specification and shape for replacement glass
quoting the unit description and batch number or date of manufacture.
Do not place very hot or very cold items against or in close proximity to glass surface(s) unless
adequately thick insulating material is used to prevent such items coming in contact with the glass.
Do not strike the glass with hard or pointed items.
Do not sit or stand upon horizontal glass surfaces.
When cleaning glass panels use a damp cloth or leather with washing up liquid or soft soap if
necessary - do not use washing powders or any other substance containing abrasives since these
substances scratch glass.
If stated in the instruction leaflet, it is essential that this unit is fixed to a wall.
KEEP THESE INSTRUCTIONS FOR FUTURE USE

ALR3195
