Argos White Tongue & Groove 2 Drawer Unit User manual

Assembly Instructions - Please keep for future reference
White Tongue & Groove 2 Drawer Unit
Dimensions
Width - 34cm
Depth - 28cm
Height - 56cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Glue safety - Take care when using glue, please follow the advice below
Safety and care advice
Important - Please read these instructions fully before starting assembly
Care and maintenance
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them into
their groups.
• Keep children and animals away
from the work area, small parts
could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight
on the panels, this could cause
damage.
• Assemble the unit as close to its
final position (in the same
room) as possible.
• Assemble on a soft level surface
to avoid damaging the unit or your
floor.
• Note: Only apply the glue once
you are sure of the assembly.
• The wall plugs supplied are
suitable for solid walls only. It is
important that the correct type of
fixing is used for your wall, seek
professional advice if in doubt.
• Parts of the assembly will be
easier with 2 people.
• If using power tools, please
follow the safety instructions
supplied with the tools.
• We do not
recommend the use
of power drill/ drivers
for inserting screws,
as this could damage
the unit. Only use hand
screwdrivers.
• Warning: Before drilling, check
the wall for hidden pipes and
cables.
• Dispose of all packaging carefully
and responsibly.
• Warning: The unit weighs
approximately 5 kgs.
Please lift with care.
Skin contact: Remove
contamination by washing with
soap and water. This procedure
should also be followed prior to
eating and drinking.
Eye contact: Rinse immediately
with clean water for 15 minutes
and seek medical advice.
If swallowed: Seek medical advice
immediately. If possible show
product information or label to the
medical advisor.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on this
unit.
• This product should not be
discarded with household waste.
Take to your local authority waste
disposal centre.
Note: if required the next page
can be cut out and used as a
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1

Table Top (34x28cm)
2
Side x 2 (54.5x26cm)
1
Support x 2 (26x27.5cm)
3
Front (7x27.5cm)
4
Drawer Front x 2 (22x27.5cm)
5
Drawer Back x 2 (22x25.5cm)
6Drawer Side x 4
(22x24.5cm)
7
Drawer Bottom x 2 (26x23.5cm)
8
Components - Panels
Please check you have all the panels listed below
2

Locking Pin x 4
Phillips screwdriver
(medium & large)
Locking Nut x 4 25mm Screw x 10
Flatblade screwdriver
(medium)
Ruler/tape
measure
Dowel x 8 17mm Screw x 24 22mm Screw x 2
Handle x 2
Small
hammer
Eye protection
(when using a
hammer or glue)
ABC
Components - Fittings
Please check you have all the fittings listed below
Tools required
Ruler - Use this ruler to help correctly identify the screws
If you have damaged or missing components,
call the Customer Helpline: 08456 400800
DE F
G
3
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
05 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170

NOTE: It would be useful to ask
someone to help you at this stage.
a: Insert Dowels D into Side
Panels 1 .
Assembly Instructions
Step 1
Assembling the Side Panels
b: Use Screws C to fix the
Supports 3 on the Side Panel
1 .
4
a:
b:
1
3
1
D
C
D
D
D
D
1D
D
D
D
1
C
C
3
3
1

Assembly Instructions
Step 1
c: Use Screws C to fix the other
Side Panel 1 onto the unit.
d: Use Screws C to fix the Front
Panel 4 onto the unit.
5
c:
d:
1
4
C
C
1
C
C
4
C
C

2
NOTE: It would be useful to ask
someone to help you at this stage.
Assembly Instructions
Step 2
Fitting the Table Top
a: Screw Locking Pins B into
Table Top 2 .
b: Carefully place the Table Top
2 onto the unit. Insert Locking
Nuts Binto the Side Panels 1 .
Tighten the Locking Nuts Bto
secure the Table Top 2 to the
unit.
B
B
A
6
a:
b:
2
2
2
1
A
B
B
A
2
A
A
A
BB
BB

Assembly Instructions
Step 3
Assembling the Drawers
NOTE: It would be useful to ask
someone to help you at this stage.
a: Use Screws F to fix the Drawer
Sides 7 onto Drawer Back 6 .
b: Carefully slide the Drawer
Bottom 8 into the unit.
c: Use Screws E to fix the
Drawer Front 5 onto the drawer.
E
E
E
E
7
a:
b:
c:
7 6
8
5
E
E
8
5
E
E
E
6
7
7
E

Repeat Step 3 to assemble the
second drawer.
Assembly Instructions
Step 3
d: Use Screw F to fix the Handle
G onto the drawer.
e: Carefully slide the drawer into
the unit.
8
d:
e:
F
G
F
G

If you need help or have damaged or missing parts, call the
Customer Helpline: 08456 400800
NOTE: Before use make sure the
unit is secure.
Assembly Instructions
Step 4
a: With help, place the unit in
the intended position.
Finishing the Unit
The assembly is now complete.
NOTE: It would be useful to ask
someone to help you at this stage.
9
a:

White Tongue & Groove 2 Drawer Unit
832/9408
Issue 5 - 8/20/12
34cm
28cm
56.3cm

Components - Panels
Please check you have all the panels listed below
12
57
Left side Panel Top Panel 4Front Panel
Drawer Front x 2
6Drawer Back x 2 8Drawer Bottom x 2 9Right side Panel
Drawer Side x 4
2
If you have damaged or missing components,
call the Customer Helpline:08456 400800
Components - Fittings
Please check you have all the fittings listed below
Note:The quantities below are the correct amount to complete the assembly .In some cases more
fittings may be supplied than are required.
AB
D
C
EF
40mm Screw x 8
30mm Screw x 26 Knob x 2
Locking Nut x 4Locking Pin x 4
Tools required
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Phillips screwdriver
(medium & large)
Ruler - Use this ruler to help correctly identify the screws
Wooden Dowel x 12
3Support x 2

Assembly Instructions
Assembling side panels
Assembling top panel
NOTE:It would be useful to ask
someone to help you at this stage.
Insert wooden dowels into left
side panel and fix front panel
on the left side panel.
Tighten the locking nuts to
secure the unit.
a:
b:
B
3
Step 1
Screw locking pins into top panel
.
Carefully place the top panel
onto the unit.Insert locking nuts
into left side panel and right side
panel .
A
D
2
9
2
1
9
1
4
A
B
B
A
A
C
C
C
C
C
C
C
C
C
D
D
D
D
D
D
D
D
D
B
B
B
B
B
A
A
1
1
1
2
2
3
3
3
3
4
9
9
a: Insert wooden dowels into left
side panel and use 40mm
screws to fix the supports on
the left side panel .
b: Repeat same step to attach right
side panel to the unit.
C
D
1
3
Step 2

Step 3
Assembly Instructions
Assembling the Drawers
Finishing the unit
NOTE:It would be useful to ask
someone to help you at this stage.
NOTE:It would be useful to ask
someone to help you at this stage.
4
a:Use 30mm screw to fix knob
onto drawer front .
Use 30mm screws to fix drawer
front and drawer back onto
one of the drawer sides .
b:Carefully slide the drawer bottom
into the grooves of drawer front
and drawer back .
Use 30mm screws to fix the
other drawer side onto the unit.
Carefully slide the two drawers into
the unit.
With help,place the unit in the
intended position.
Repeat same step to assemble the
second drawer.
The assembly is now complete
NOTE: Please make sure the unit
is secure before use.
NOTE:If you have damaged or missing components,
call the Customer Helpline:08456 400800
Argos LTD,489-499 Avebury Boulevard,
Central Milton Keynes, MK9 2NW
a:
b:
E
F
F
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
6
6
5
5
5
5
7
7
8
6
5
7
7
8
Step 4
