Aritech CS350 User manual

14 1791 999 1
This manual contains installation details for
the CS350 control panels.
It provides the basic programming and instal-
lation information required by technicians and
engineers.
CS350
Installation Instructions
Downloaded from: http://www.guardianalarms.net

14 1791 9992

14 1791 999 3
CONTENTS
FEATURES .................................................................................................................................... 3
KEYPAD INSTALLATION ........................................................................................................... 4-5
WIRING SPECIFICATIONS ...........................................................................................................5
POWERING UP PANEL ................................................................................................................. 6
HOW TO PROGRAMME ................................................................................................................7
PROGRAMMING MAP ................................................................................................................... 8
PROGRAMMING FUNCTIONS ................................................................................................... 11
PERIDIAX FEATURE ................................................................................................................... 1
PROGRAMMING TEXT ............................................................................................................... 20
RETURNING TO FACTORY DEFAULT ...................................................................................... 21
QUICK CODES ............................................................................................................................ 21
ZONE WIRING OPTIONS ............................................................................................................ 22
WIRING OF SIRENS .................................................................................................................... 23
WIRING OF OUTPUTS
RELAYS ........................................................................................................................... 24
DIGITAL COMMUNICATORS ......................................................................................... 24
FIRE DETECTORS ......................................................................................................... 24
LIST WITH SHORT CODES ........................................................................................................ 25
DEFAULT CHART ........................................................................................................................ 26
PROBLEM SOLVING ................................................................................................................... 27
TECHNICAL SPECIFICATION .................................................................................................... 2
MAIN PANEL WIRING DIAGRAM ............................................................................................... 30
FEATURES
The CS350 is a microcomputer based alarm control panel operating from remote keypads, and has
the following features:
lFacility for up to 4 CD3008 remote keypads... one CD3008 is supplied with the panel.
l6 freely programmable dual zones.
lAuxiliary tamper input.
lSupervised bell tamper input.
lDigital communicator fault input... reprogrammable to include remote engineer reset.
lNew perimeter system capability which provides local alarms for perimeter zone activations.
This can reduce false alarms considerably. Exremely useful with inertia shock sensors.
l4 freely programmable open collector outputs.
l2 freely programmable high current outputs (eg. to control sirens).
lLCD with freely programmable zone names... up to 12 characters.
lBattery input monitored.
lFour user codes.
See rogramming Functions on page 14 for zone (Input) and page 15 for output types.
Features

14 1791 9994
Keypad Installation
✓
1234
ON SD
D
C
B
A
MIN MAX
CABLE ENTRY
FROM TOP
CABLE ENTRY
FROM BACK
CABLE ENTRY
FROM BOTTOM
MOUNTING HOLE
MOUNTING HOLE
MOUNTING HOLE
DIPSWITCHES
FOR KEYPAD ID
SPARE SCREW
TO FIX COVER
ONTO BASE
ADJUSTMENT
DISPLAY-CONTRAST
CD3008
PUSH CLAMP
GENTLY TO
REMOVE PCB
CD3008
LIFT
REMOVE SCREW
IF FITTED
PUSH
PUSH IN CLIP WITH
SCREW DRIVER AND
LIFT UP LID
1
2
3
Figure 1.
Figure 2.

14 1791 999 5
Keypad Installation
Wiring Specifications
Connect the additional keypads either using a STAR or MULTIDROP configuration.
MULTIDROP the keypads are 'daisy chained' together, each keypad being connected in parallel
to the one before it.
STAR each keypad is wired back separately to the control panel terminals.
Any combination of the above wiring methods is allowed with the restriction that the total cable length
on each of the wiring loops (either multidrop or star) is restricted to 100m.
The following diagram shows how 4 RKPs may be connected using both methods.
✓
1234
ON SD
MIN MAX
D
C
B
A
15
14
13
12
SW1
CD3008
Control panel
Terminal 5
1234
ON
ON
OFF
OFF
1234
Keypad 1
(all off) Keypad 2
12341234
Keypad 3 Keypad 4
Figure 3. Figure 4.
Figure 5.

14 1791 9996
Connection of the control panel and the remote keypad in the following sequence allows the engineer
to establish that the control panel is working correctly.
Connection sequence:
1. Before installing the remote keypad (RKP) at it's designated position, it may be connected at
the control panel, to enable the engineer to commission the system.
2. Check that the ID for the RKP is set correctly... one keypad has to have ID1 (refer to Diagram
2).
3. Connect the RKP to the panel as shown in Diagram 3.
4. Replace the cover of the RKP and ensure that the tamper switch in the panel is closed.
5. Apply mains power to the panel. The system will power up in armed state (Factory Programme
Setting). If any zones are open at power up, t e audibles will activate. The panel
defaults to the language select prompt when switched on for the first time [ UK/IRL Press é
1]. Enter [é] and [1] to select English language. Note that this also happens after returning to
factory default. See page 21 for more details.
6. Enter the Default User Security Code [1][1][2][2] at the keypad to disarm the system. The keypad
display shows DISARMING and the audibles, if sounding, will stop. Display then shows
any zones which are open and caused it to alarm. If [0] key is pressed at this stage, the display
will show FINISHED? . Enter ACCEPT [ü] to finish with operator menu.
7. The display shows Time/Date and the system is now disarmed.
8. Enter [1][2][7][8] (Default Engineer Code) to enter Engineer Mode and to change programme
parameters. See the rogramming Map and rogramming Functions for operational details.
How to programme is detailed on page 7.
. Each time the system is powered down the panel memorizes it's current state, i.e. whether
armed, disarmed, partguard, etc. and will restore to that state when powered-up again.
Powering Up Panel

14 1791 999 7
All programmed features can be changed. The structure and position of the programming options
are illustrated in the Programming Map on the next page. Features and options are grouped together
and allocated to 6 main menu blocks:
1 MAINTENANCE 4 ZONES
2 TIMERS 5 OUTPUTS/REMOTES
3 USERS 6 MISCELLANEOUS
Once in Engineer Mode, the blocks can be accessed by 'stepping' through the menu blocks and
accepting the option shown in the display. The keys used for programme selections are defined as
follows:
[ê] stepping forward to next block or programming option
[é] returning to previous block or programming option
[ü] enter programming block - enter programming option - confirm changes - accept option
[X] quit programming block - quit programming option - reject changes
After have installed the additional keypads - mind the correct dipswitch ID setting - go to the Engineer
Programming Mode and proceed as follows:
1. Use the [ê] key till OUTPUTS/REMOTES is displayed then enter [ü] .
2. Use the [ê] key till INSTALL REMOTE is displayed then enter [ü] .
3. The display shows the keypads connected, eg. REMOTE k k ✱ ✱ . Confirm [ü] these changes
when they are correct. If not correct, verify the wiring to the keypad and dipswitch ID settings.
The keypad must be powerless when changing dipswitch settings.
4. The display now shows INSTALL REMOTE . Quit programming blocks [X] till GOODBYE is
displayed. Now accept [ü] to leave the Engineer Programming Mode.
HOW TO P OG AMME
Adding Additional Keypads
P OG AMMING EXAMPLE

14 1791 9998
CS350 P OG AMMIMG MAP V1.0
1 1 Engineer Log Display Log
Clear Log
Maintenance Menu
2 Output Test nn Low
or
nn High
MAINTENANCE 3 how Open Zones All Closed
or
nn Zone
4 Walk Test Walk Test nn
5 LED Test Testing LEDs
Main Menu
2 1 Entry Time nn
2 Exit Time nn
3 plit Time OFF/ON
4 Bell Times Bell Cutout nn
Bel Delay nn
All Bells Cut ON/OFF
TIMER Dig Cutout ON/OFF
Perim.Bell Cutout nn
Timers Menu
5 Time hh:mm Time hh:mm
6 Date dd/mm/yy Date dd/mm/yy
7 ummertime Forward Date
Backward Date
ummertime ON/OFF
Main Menu Timers Menu
3 1 Change Codes xx Code In Use
xx Code Unused
New Code
Verify
Error
2 Code Privilege 01 Fs Us . . . . . . OK U ER ATTRIBUTE
02 . . . . . . . . . . . OK
03 . . . . . . . . . . . OK Mn=Manager
04 . . . . . . . . . . . OK In=Inhibit
U ER Leave this Ps=Part et
Us=Unset
3 Engineer Code New Code Fs=Full et
Verify
Error
4 Duress Code New Code
Verify
Error
5 Code Count nn
6
êê Open Zones ON/OFF
Main Menu

14 1791 999 9
4 1 Zone Type 01 Alarm ZONE TYPE
0x . . . . . . . . . . . .
06 . . . . . . . . . . . . Unused
Leave this Tamper
PA
2 Zone Attributes 01 In Key
0x . . . . . . . . . . . . Fire
06 . . . . . . . . . . . . Exit/Entry
Leave this Alarm
Keypad Lock
Key Inf=Infinite Entry
Exit Trm=Exit Terminator
ZONE 3 hock Zones nn Gross. x Pls y ZONE ATTRIBUTE
nn Wrong Type
Ls=Local Alarm hock
4 Zone Name La=Local Alarm Contact
In=Inhibit
5 Loop Type : Alarm 24=24 hours
Loop Type : Dual Pg=Partguard
o= oak Test
Ac=Access
Ch=Chime
KEY ZONE ATTRIBUTE
Fs=Full et
Ps=Part et
Us=Unset
Pu=Pulsed
Main Menu Qs=Quick et
5 1 Output Type 01 Disarm/Arm OUTPUT TYPE
0x . . . . . . . . . . . .
06 . . . . . . . . . . . . Disarm/Arm
Alarm
P.A.
Fire
Tamper
OUTPUT / 2 Install Remote Remote kk** Latch
REMOTE Fire Detect Reset
k=CD3008 Buzzer
Int.Bell
Ext.Bell
Partguard
ystem Clear
Trouble
Main Menu Perim.Alarm
Unused
Clear
CS350 Programming Map

14 1791 99910
CS350 Programming Map
6 1 Arm/Disarm Menu User Walk ON/OFF No Forced Arming
Forced Arm Opts Keep Inhibits
Rearm Options Clear when closed
ArmedDisplay ON/OFF Clear after exit
Exit Fault Buzzer/Bell
Final Door ON/OFF
Miscellaneous Menu Always rearm
Never rearm
Rearm 1 to 8 Times
2 P.A. Menu P.A. ilent/Bells
PA, LF ilent/Bells
éê PA ON/OFF
Miscellaneous Menu
3 Partgd/Chime Timed Partgd ON/OFF
Access>EE/Access
Partgd Digi ON/OFF
Latched Chime ON/OFF
Int.Bell Chime ON/OFF
Miscellaneous Menu
4 Eng. Reset Menu Reset Code/FTC or Code Only
P.A. Reset ON/OFF
Tamper Reset ON/OFF
MI CELLANEOU Alarm Reset ON/OFF
Clear Engineer Reset
Miscellaneous Menu
5 Warnings PF Buzzer ON/OFF
LF Buzzer ON/OFF
Miscellaneous Menu
6 Factory Prog Menu Engineer Lock ON/OFF
Miscellaneous Menu
7 Change Language English
Nederlands
Francais
Italiano
8 ysClear Inputs ystem Clear Mains ON/OFF
ystem Clear Battery ON/OFF
ystem Clear Fuse ON/OFF
ystem Clear Accs+EE ON/OFF
Main Menu Miscellaneous Menu
GOODBYE
