Arjo Sara 3000 User manual

INSTRUCTIONS FOR USE
Sara 3000/Flex/Lite/Stedy
Active Slings
04.SF.00-INT1_7 • 2023-07
Including Sara Flex wipeable standing sling
EN · ZH · DE · FR · IT · NL
⢪欽霹僈⛼ · Bedienungsanleitung · Mode d’emploi · Istruzioni per l’uso · Gebruiksaanwijzing

2
WARNING
To avoid injury, always read this Instructions for Use and accompanied
documents before using the product. Mandatory to read the Instructions for Use.
Design Policy and Copyright
® and ™ are trademarks belonging to the Arjo group of companies.
© Arjo 2023.
As our policy is one of continuous improvement, we reserve the right to modify designs without prior notice.
The content of this publication may not be copied either whole or in part without the consent of Arjo.
Foreword
Thank you for purchasingArjo equipment. Please read this Instructions For Use (IFU) thoroughly.
Arjo will not be held responsible for any accidents, incidents or lack of performance that occur
DVDUHVXOWRIDQ\XQDXWKRUL]HGPRGL¿FDWLRQWRLWVSURGXFWV
Customer Support
If you require further information, please contact your local Arjo representative. The contact
information is located at the end of this IFU.
'H¿QLWLRQVLQWKLV,)8
WARNING Means: Safety warning. Failure to understand and obey this warning may result
in injury to you or to others.
CAUTION Means: Failure to follow these instructions may cause damage to all or parts of
the system or equipment.
NOTE Means: This is important information for the correct use of this system or equipment.
Contents
Foreword ............................................................2
Customer Support .................................................. 2
'H¿QLWLRQVLQWKLV,)8 ............................................. 2
,QWHQGHG8VH ......................................................3
Patient/Resident Assessment ................................ 3
Expected Service Life ............................................ 3
Safety Instructions..............................................4
Safety Practices ..................................................... 4
Serious Incident ..................................................... 4
Parts Designation ...............................................5
Preparations .......................................................6
%HIRUH)LUVW8VHVWHSV ...................................... 6
%HIRUH(YHU\8VHVWHSV .................................... 6
After every use ....................................................... 6
Select Sling Size.................................................7
Measure ................................................................. 7
Sling Selection....................................................
Transfer/Transport.................................................. 
Allowed Combinations........................................9
6DIH:RUNLQJ/RDG6:/...................................... 9
Clip Attachment & Detachment........................... 9
$WWDFKWKH&OLSVVWHSV ....................................... 9
'HWDFKWKH&OLSVVWHSV...................................... 9
Applying the Sling.............................................10
,Q&KDLU:KHHOFKDLUVWHSV............................. 10
Removing the Sling .......................................... 11
,Q&KDLU:KHHOFKDLUVWHSV............................. 11
Cleaning and Disinfection.................................12
Disposable Sling - Do NOT wash......................... 12
Wipeable Sling - Disinfecting Agents ................... 12
Machine Washable Slings - Cleaning Instructions
VWHSV ............................................................... 13
Machine Washable Slings - Cleaning Agents....... 13
Care and Preventive Maintenance ...................13
%HIRUHDQG$IWHU(YHU\8VH.................................. 13
When Soiled, Stained and Between Patients....... 13
Storage................................................................. 13
Service and Maintenance..................................... 13
Troubleshooting................................................14
7HFKQLFDO6SHFL¿FDWLRQV ...................................15
Parts and Accessories......................................15
Label on the Sling.............................................16
,ඖඛගකඝඋගඑ඗ඖඛ)඗ක8ඛඍ
EN

3
Intended Use
The Active sling is a product intended for assisted
transfer and rehabilitation of patients/residents with
limited ability to move.
The Sara Flex wipeable standing sling is intended to
be used together with a lifting device to provide body
support during raising to a standing position and short
transfers of adult patients/residents. It is intended to be
cleaned by means of wiping.
The Active disposable sling has been designed to
support hospital or care facility patients/residents
while using a patient/resident transfer lifter, under the
VXSHUYLVLRQRIWUDLQHGQXUVLQJVWDႇ
The Active Sling, Sara Flex wipeable standing sling
and Active disposable sling should be used together
with Arjo lift devices in accordance with the Allowed
FRPELQDWLRQVVSHFL¿HGLQWKLV,QVWUXFWLRQVIRUXVH,)8
The Active sling, Sara Flex wipeable standing sling
and Active disposable sling shall only be used by
appropriately trained caregivers with adequate
knowledge of the care environment, and in accordance
with the instructions outlined in this Instructions for use.
The Active disposable sling is to be used for a limited
period only, and, by nature of its design, must be treated
DVDGLVSRVDEOHDQGSDWLHQWUHVLGHQWVSHFL¿FSURGXFW
The Active disposable sling must not be used to support
a patient/resident while bathing or showering. The
Active disposable sling cannot be washed.
The Active sling and Sara Flex wipeable standing sling
is intended to be used in hospital environments, nursing
homes, other healthcare facilities and home care.
The Active disposable sling is intended to be used
in hospital environments, nursing homes and other
healthcare facilities.
The Active sling, Sara Flex wipeable standing sling
and Active disposable sling should only be used for the
SXUSRVHVSHFL¿HGLQWKLV,QVWUXFWLRQVIRUXVH$Q\RWKHU
use is prohibited.
Patient/Resident Assessment
We recommend that facilities establish regular
assessment routines. For Active Sling and Active
disposable slings caregivers should assess each
patient/resident according to the following criteria prior
to use:
• The patient/resident sits in wheelchair
• Is able to partially bear weight on at least one leg
• Has some trunk stability
• Dependent on caregiver in most situations
• Physically demanding for caregiver
• Stimulation of remaining abilities is very important
Prior to the transfer with the Sara Flex wipeable
standing sling caregivers should assess each patient/
resident according to the following criteria:
• Size
• Mobility level
• Medical conditions
• Ability to understand and respond to instructions
The Sara Flex wipeable standing sling is intended for
patients/residents:
• Who are able to bear weight on at least one leg and
have some trunk stability.
• :KRVHZHLJKWLVQRPRUHWKDQNJ,EV
• has a length in the range of 140 cm and 200 cm
´DQG´
6DIH:RUNLQJ/RDG6:/IRU$FWLYHVOLQJ
• MAA3070M, MAA3071M, MAA3061M, MAA3060M:
NJOEV
• TSS.500-504, TSS.500-503S-1C, TSS.501-502SV,
766NJOEV
• 0)$6DUDGLVSRVDEOHNJOEV
The right type and size of slings should be used after
proper assessment of each patient/resident’s size,
condition and the type of lifting situation.
If the patient/resident does not meet these criteria an
alternative equipment/system shall be used.
Expected Service Life
The expected service time of Active sling, Sara Flex
wipeable standing sling and Active disposable sling are
the maximum period of useful life.
The expected life of the sling is dependent on the actual
use conditions. Therefore, before use, always make
sure that the sling does not show any signs of fraying,
tearing or other damage and that there is no damage
LHFUDFNLQJEHQGLQJEUHDNLQJ,IDQ\VXFKGDPDJHLV
observed, do not use the sling. If you have any doubts
about sling safety, as a precaution and to ensure safety,
do not use the sling.
The expected service life of Active sling and Sara Flex
wipeable standing sling:
Service time: 2 years
Shelf time: 5 years
The expected service life of Active disposable sling:
6HUYLFHWLPHZHHNVEDVHGRQWUDQVIHUVSHUGD\
Shelf time: 5 years
EN

4
Safety Instructions
WARNING
To avoid injury, make sure that the patient
is not left unattended at any time.
WARNING
To avoid falling, make sure that the user
weight is lower than the safe working load
for all products or accessories being used.
WARNING
To avoid injury, always assess the patient
prior to use.
WARNING
To avoid injury, never wash a disposable
sling. A disposable sling is only intended
for “single patient use”.
WARNING
To avoid injury, never let the patient smoke
when using the sling. The sling can catch
¿UH
WARNING
To avoid injury, only store the equipment
for a short period of time. If stored longer
than stated in the IFU, it can cause
weakness and breakage in the material.
WARNING
To avoid injury, keep the equipment away
from sun/UV-light. Exposure to sun/UV-
light can weaken the material.
Safety Practices
At any time, if the patient becomes agitated, stop
transferring/transporting and safely lower the
patient.
Serious Incident
If a serious incident occurs in relation to this
PHGLFDOGHYLFHDႇHFWLQJWKHXVHURUWKHSDWLHQW
then the user or patient should report the serious
incident to the medical device manufacturer or
WKHGLVWULEXWRU,QWKH(XURSHDQ8QLRQWKHXVHU
should also report the serious incident to the
Competent Authority in the member state where
they are located.
EN

5
Parts Designation
1. 6OLQJODEHOSULQWORFDWHGRQWKHRXWVLGH
2. Waist part
3. Inner attachment clip
4. Outer attachment clip
5. Attachment strap
6. 6XSSRUWEHOWEXFNOH
7. Buckle
 /HJÀDS
9. /HJVWUDSORRS
10.Waist belt
11. 6XSSRUWEHOWKRRNDQGORRSDWWDFKPHQW
12.'LVSRVDEOHVOLQJLGHQWL¿FDWLRQODEHOORFDWHG
RQWKHRXWVLGH
Example of slings. Not all models are represented.
1
2
6
7
3
5
7
11
12 9

1
10 1
4
XXXX-XX-XX
MADEINPOLAND
ArjoWipeableStandingClip Sling
ArjoHuntleighAB
HansMichelsensgatan10
21120Malmö,Sweden
www.arjo.com TSS.502W
XXXXXXXXX
(01)05056097369938 (11)YYMMDD(21)123456789
440lb
200kg
1
Outside
EN

6
Preparations
Before First Use (6 steps)
WARNING
To avoid injury, always make sure to
inspect the equipment prior to use. If any
part is missing or damaged – Do NOT use
the sling.
1. Check all parts of the sling, see section “Parts
Designation” on page 5. If any part is
missing or damaged – Do NOT use the sling.
2. Read this IFU thoroughly.
3. Check that the sling is clean.
4. Choose a designated area where the IFU
should be kept and easily accessible at all
times.
5. Make sure to have a rescue plan ready in
case of a patient emergency.
6. For questions, contact your local Arjo
representative for support.
NOTE
To keep track of the service life of the
wipeable sling, document the serial number
DQGWKHGDWHLWZDV¿UVWXVHG
NOTE
Arjo recommends the name of the patient is
written on the sling care label to avoid cross
contamination between patients.
Before Every Use (8 steps)
1. Patient assessment must always determine
the methods used in everyday care, see
“Intended Use” on page 3.
WARNING
To avoid the patient from falling, make sure
to select the correct sling size according
to the IFU.
2. Check the allowed combinations against the
sling and lift, see “Allowed Combinations” on
page 9.
WARNING
To avoid injury, always make sure to
inspect the equipment prior to use. If any
part is missing or damaged - Do NOT use
the sling.
3. Check all parts of the sling, see “Parts
Designation” on page 5. If any part is
missing or damaged - Do NOT use the sling.
4. Check for:
• fraying
• loose stitching/delamination
• cracks
• tears
• fabric holes
• soiled fabric
• damaged clips/loops/buckles
• unreadable or damaged label/print
WARNING
To prevent cross-contamination, always
follow the disinfection instructions
in this IFU.
5. Check that the sling is clean. If the sling is
not clean see “Cleaning and Disinfection” on
page 12.
6. Always check the washing symbol on the
disposable sling’s label. If the disposable sling
has been washed, throw the disposable sling
away. See “Disposable Sling - Do NOT wash”
on page 12.
7. If this symbol appears, do NOT use
the disposable sling. The label
indicates that the disposable sling has
been washed.
 Before using the sling, read the lift IFU for
transfer, transport and bathing.
After every use
For disposable slings
When the patient leaves the hospital, throw away
WKHSDWLHQWVSHFL¿FGLVSRVDEOHVOLQJ
For Sara Flex wipeable standing sling
1. Clean and disinfect the sling according to the
LQVWUXFWLRQVLQWKLV,)8
2. Check all parts of the sling, see “Parts
Designation” on page 5. If any part is
missing or damaged, dispose the sling.
EN

7
Select Sling Size
Measure
The patient’s physical disabilities, weight
distribution and general physique needs to be
taken into consideration when selecting a sling.
For Active Slings and Active Disposable
Slings (3 steps)
The sling size depends on the patient’s body
shape, what kind of lift is being used, and on the
attachment of the sling. For best result try out
the sling on the patient.
Each sling size has its own colour, which is found
on the binding of the sling. (See Fig. 1).
1. Place the sling around the patient’s waist.
2. Close the support belt and make sure
it overlaps with enough margin at
DSSUR[LPDWHO\FPLQFKHV
3. Make sure the sling attachments reach
the lift. If the attachment doesn’t reach,
change to another sling size.
S M L XL XXL
Fig. 1
For Sara Flex wipeable standing sling
(2 steps)
The patient’s physical disabilities, weight
distribution and general physique need to be
taken into consideration when selecting a sling.
1. Measure the patient’s waist in seated
position.
2. Select a sling size that is closest to that
measurement (See table below). In case of
doubt choose the smaller one. Each sling size
has its own colour which is found on the print
on the outside of the sling.
To double-check your size selection, align the
ÀDSIROGZLWKSDWLHQW¶VVLGH(See Fig. 2). If the
VOLQJLVWRRVPDOOWKLVÀDSIROGZLOOEHWRRIDUEDFN
(See Fig. 3),IWKHVOLQJLVWRRODUJHWKHÀDSIROG
will be further in the front (See Fig. 4).
Article number Product
description
Waist size in cm (in)
SMLXL
TSS.50XW Sara Flex wipeable
standing sling
FP
´´
76-104 cm
´´
FP
ò´´
FP
ò´´
Flap
fold
Patient’s
side
Patient’s
side
Flap
fold
Flap
fold
Patient’s
side
Fig. 2 Fig. 3 Fig. 4
EN


Sling Selection
Transfer/Transport
Sling Type Article number Safe Working
Load Product Description Size
Disposable MFA3000 NJOEV Sara Flex disposable
standing sling One size
Wipeable TSS.500-503W NJOEV Sara Flex wipeable
standing sling S, M, L, XL
Machine
Washable
TSS.500-503S-1C NJOEV
Sara Flex standing sling
– separate belt with one
buckle
S, M, L, XL
TSS.500-504 NJOEV Sara Flex standing sling S, M, L, XL, XXL
TSS.501-502SV NJOEV Sling split hook and loop
attachment M, L
TTS.501A-503A NJOEV Sara Flex standing sling M, L, XL
TSS.511 NJOEV Sara Flex seated transfer
sling One size
MAA3060M NJOEV Transfer sling, roll One size
MAA3061M NJOEV 7UDQVIHUVOLQJÀDW One size
MAA3070M NJOEV Standing sling, roll One size
MAA3071M NJOEV Sara clip standing sling
±ÀDW One size
$UWLFOHQXPEHUVZLWK³$VX௻[´HJ0/$$KDVD%$$%X\$PHULFDQ$FWFRPSOLDQWFRXQWU\RI
origin.
EN

9
Allowed Combinations
WARNING
To avoid injury, always follow the allowed combinations listed in this IFU. No other
combinations are allowed.
Safe Working Load (SWL)
WARNING
Always follow the lowest SWL in the complete system (lift or sling).
• Only use the earlier listed slings with the6DUD)OH[/LWH6WHG\ standing and raising aid.
• The SWL of the 6DUD6DUD)OH[LVNJOEVWKH6:/RIWKH6DUD/LWHis 175 kg
OEVDQGWKH6:/RIWKH6DUD6WHG\LVNJOEV
• Always follow the lowest SWL in the complete system. E.g. the 6DUD lift has a SWL of 200 kg
OEVDQGWKH0$$KDVD6:/RINJOEV7KLVPHDQVWKDWWKH0$$GLVSRVDEOH
sling has the lowest SWL. The patient is not allowed to weigh more than the lowest SWL.
Standing/
Raising Aid
Sara 3000,
Sara Flex Sara Lite Sara Stedy
SWL NJOEV NJOEV NJOEV
Active Sling SWL Size Size Size
MFA3000 NJOEV One size One size One size
TSS.500-503W NJOEV S, M, L, XL – S, M, L, XL
TSS.500-503S-1C NJOEV S, M, L, XL S, M, L, XL S, M, L, XL
TSS.500-504 NJOEV S, M, L, XL, XXL S, M, L, XL, XXL S, M, L, XL, XXL
TSS.501-502SV NJOEV M,L M,L M,L
TSS.501-503A NJOEV M, L, XL M, L, XL M, L, XL
TSS.511 NJOEV One size – –
MAA3060M NJOEV One size – –
MAA3061M NJOEV One size – –
MAA3070M NJOEV One size One size One size
MAA3071M NJOEV One size One size One size
Clip Attachment & Detachment
Attach the Clips (6 steps)
1. Select the inner or outer attachment clips.
2. Place the clip on the spreader bar lug.
(See Fig. 5)
3. Pull the strap down.
4. Make sure the lug is locked at the top end
of the clip. (See Fig. 6)
5. Make sure the strap is not squeezed
in between the clip and the spreader bar.
6. Make sure the straps are not twisted.
Detach the Clips (3 steps)
Make sure that the weight of the patient is taken
up by the receiving surface before removing
the clip.
1. Pull the strap up. (See Fig. 7)
2. Make sure the lug is unlocked
at the bottom of the clip.
3. Remove the clip.
Fig. 5 Fig. 6 Fig. 7
EN

10
Applying the Sling
In Chair/Wheelchair (17 steps)
For transfer/transport see the 6DUD)OH[
/LWH6WHG\OLIW,)8
1. Place the lift nearby.
2. Apply the brakes on the wheelchair.
3. In case of using 6DUD6WHG\ lift, make sure
you:
• Fold up the seat pads and let the patient
step up onto the 6DUD6WHG\.
• Fold down the seat pads and let the
patient sit down.
4. Place the sling around the patient’s lower
back. If needed, slightly lean the patient
forward. (See Fig. 8 – Stedy) or
(See Fig. 9 – Lite/3000/Flex)
5. For machine washable slings and disposable
slings: Position the bottom of the sling,
DOLJQHGKRUL]RQWDOO\DERXW¿YHFHQWLPHWUHV
WZRLQFKHVDERYHWKHSDWLHQW¶VZDLVWOLQH
For wipeable sling: Position the wipeable sling
centred around the patient’s waistline and
make sure the soft lilac surface is in contact
ZLWKWKHSDWLHQWODEHORQWKHRXWVLGH
6. Make sure that:
• patient’s arms are outside the sling,
• support belt is positioned loosely
around the patient’s body and
• support belt is not twisted or
trapped behind the patient’s back.
7. In case of using 6DUD6DUD)OH[ lift,
PDNHVXUH\RXSODFHWKHOHJÀDSVDURXQGWKH
legs and these are not twisted. (See Fig. 10)
 Fasten the support belt securely by pressing
the buckles or hook and loop attachments
together. The support belt should be tight but
comfortable for the patient.
WARNING
To avoid injury to the patient, pay close
attention when lowering or adjusting
the spreader bar.
9. Position the 6DUD6DUD/LWH6DUD)OH[
lift in front of the patient. Open up the lift legs,
if needed. See appropriate lift IFU.
10.Place the patient’s feet on the lift foot support.
In case of using6DUD6DUD/LWH6DUD
Flex lifts, make sure the patient’s legs are in
contact with the knee support.
11.Apply the brakes on the lift.
12.Attach the sling to the lift. See “Clip
Attachment & Detachment” on page 9 and
(See Fig. 11)
If the attachment strap is too loose, choose
the inner attachment clip. If the attachment
strap is too tight, choose the outer attachment
clip.
13. Transfer sling only$WWDFKWKHOHJÀDSV
loops to the central lug on the 6DUD,
Sara FlexOLIW6HHDSSURSULDWHOLIW,)8
(See Fig. 12)
WARNING
To avoid the patient from falling, make sure
that the sling attachments are attached
securely before and during the lifting
process.
14.Make sure that all clips/loops are attached
securely and the patient is comfortable
in the sling. (See Fig. 6)
15.If an adjustment is needed, lower the patient
and make sure that the weight of the patient
is taken up by the receiving surface before
removing the clip/loop.
16.Encourage the patient to assist during the
raising exercise by holding on to the support
grips with both hands.
17.Continue raising until the patient is in a
comfortable standing position. Make sure
the patient leans back against the sling at all
times. See corresponding lift IFU.
Fig. 8 –
Stedy
Fig. 9 –
Lite/3000/Flex
Fig. 10 Fig. 11 Fig. 12
Sara Flex
Sara 3000
Label on the
outside
Label on the
outside
EN

11
A
Fig. 13 Fig. 14 Fig. 15
Removing the Sling
In Chair/Wheelchair (11 steps)
1. Apply the brakes on the wheelchair.
2. Position the patient with the his/her back
against the chair/wheelchair. Open up the
legs of the lift, if needed. (See Fig. 13)
WARNING
To avoid injury to the patient, pay close
attention when lowering or adjusting the
spreader bar.
3. Lower the patient into the chair/wheelchair.
6HHFRUUHVSRQGLQJOLIW,)8
4. Make sure that the patient’s lower back is
positioned all the way in against the chair/
ZKHHOFKDLUADQGWKDWWKHZHLJKWRIWKH
patient is taken up by the receiving surface
before removing the clips/loops. (See Fig. 14)
5. Apply the brakes on the lift.
6. Detach the sling clips/loops from the lift.
(See Fig. 7)
7. Transfer Sling only:
• Detach the leg straps from the lift.
• Open and pull them out
from under the patient’s legs.
• Tuck the leg straps backwards
along the patient’s side.
 Remove the patient’s feet from the foot
support.
9. Move the lift away from the patient.
10.Open the sling support belt.
11.Lean the patient forward and remove the sling
from behind the patient. (See Fig. 15)
EN

12
Cleaning and Disinfection
WARNING
To prevent cross-contamination, always
follow the disinfection instructions
in this IFU.
WARNING
To avoid material damage and injury, clean
and disinfect according to this IFU:
• No other chemicals are allowed.
• Never clean with chlorine (except for the
wipeable sling).
• Chlorine will deteriorate the surface of
the material (except for the wipeable
sling).
WARNING
To avoid injury, always remove the sling
before disinfecting the lift.
WARNING
To avoid injury, never wash a disposable
sling. A disposable sling is only intended
for “single patient use”.
All 6DUD)OH[/LWH6WHG\ slings, except the
disposable sling, should be cleaned when they
are soiled or stained and between patients.
Disposable Sling - Do NOT wash
The disposable sing is for single patient use.
Do NOT clean, wash, disinfect, wipe or sterilize
the disposable sling. If the disposable sling has
been subjected to any such treatment, it shall be
discarded.
The disposable sling is marked with the “Do NOT
ZDVK´V\PERO(See Fig. 16)
If the disposable sling is washed, the “Do NOT
XVHOLIW´V\PEROZLOODSSHDU(See Fig. 17)
Fig. 16 Fig. 17
Wipeable Sling - Cleaning and
Disinfection Instructions (6 steps)
1. Detach the sling from the lift.
2. If needed, rinse to remove any deposits or
visible dirt from the sling.
3. Wipe all parts of the sling with one of the
disinfecting agents listed under “Wipeable
6OLQJ'LVLQIHFWLQJ$JHQWV´
4. Allow contact time according to the
disinfecting agent manufacturer’s instructions
for use.
5. If stated in the disinfecting agent
manufacturer’s instructions for use, rinse to
remove chemical residue.
6. Air dry at room temperature.
Do NOT
• machine wash
• use gas sterilization
• use any mechanical pressure
• tumble dry
• use autoclave
• dry clean
• steam
• iron
Wipeable Sling - Disinfecting Agents
The sling can be disinfected using:
• Ethanol based solution, up to 70%
• Isopropanol based solution, up to 70%
• Hydrogen peroxide based solution, up to 1.5%
• Quaternary ammonium based solution,
up to 0.1%
• %OHDFKVRGLXPK\SRFKORULWHEDVHGVROXWLRQ
up to 10000 ppm
NOTE
Wipable sling may show some signs of
discoloration and become slightly slightly
sticky after repeated contact with bleach
(sodium hypochlorite) at 10000 ppm.
EN

13
Care and Preventive Maintenance
WARNING
To avoid injury to both patient and
caregiver, never modify the equipment or
use incompatible parts.
Before and After Every Use
Visually check all exposed parts
The caregiver shall inspect the sling before and
after every use. The complete sling should be
checked for all deviations listed below. If any of
these deviations are visible, replace the sling
immediately.
• Fraying
• Loose stitching/delamination
• Cracks
• Tears
• Holes
• Discolouration or stains from bleaching
• Sling soiled or stained
• 8QUHDGDEOHRUGDPDJHGODEHOSULQW
• For disposable slings: Make sure the “Do
127ZDVK´V\PERORQWKHKHDGVXSSRUW
is intact. If damaged or missing and the
XQGHUO\LQJUHG³'R127XVHOLIW´V\PERO
appears, replace the sling immediately. See
³/DEHORQWKH6OLQJ´RQSDJH
When Soiled, Stained and Between
Patients
Clean/Disinfect, All slings except the
Disposable Sling
The caregiver should make sure that the
sling is cleaned according to “Cleaning and
Disinfection” on page 12, when it is soiled or
stained and between patients.
Disposable Sling
Washing or disinfection is not allowed. Do not
wipe, sterilize or soil the disposable sling. If
the disposable sling has been subjected to any
treatment, it shall be discarded.
Storage
When not in use, the slings should be stored
away from direct sunlight where they are
not subject to unnecessary strain, stress or
pressure, or to excessive heat or humidity. The
slings should be kept away from sharp edges,
corrosives or other things that could cause
damage on the sling.
Service and Maintenance
,WLVUHFRPPHQGHGWKDWTXDOL¿HGSHUVRQQHO
inspect the condition of the sling twice a year
HYHU\PRQWKDFFRUGLQJWR,62
Machine Washable Slings - Cleaning
Instructions (3 steps)
1. Detach the sling from the lift.
2. Close all buckles and hook and loop attach-
ments on the slings and belts prior to washing.
3. 0DFKLQHZDVKWKHVOLQJDW&),Q
RUGHUWRREWDLQVXႈFLHQWOHYHORIGLVLQIHFWLRQ
please wash according to local hygiene
legislation. If allowed according to the
product label, tumble dry in low temperature,
PD[&)
Do NOT
• wash with other items that have
rough surfaces or sharp objects
• use any mechanical pressure, pressing
or rolling during the washing and drying
process
• use bleach
• use gas sterilization
• use autoclave
• dry clean
• steam
• iron
Machine Washable Slings - Cleaning
Agents
)RUDOOZDVKDEOHVOLQJV127WKHGLVSRVDEOH
VOLQJRUWKHZLSHDEOHVOLQJXVHFRPPRQ
commercial detergent without optical brightener.
No other chemicals are allowed e.g. chlorine,
softener, iodine based disinfectants, bromine
and ozone.
EN

14
Troubleshooting
Problem Action
The patient is not positioned correctly in the
sling.
• Make sure the clips/loops are attached at the
right length.
• Make sure the straps are not twisted.
• Make sure the patient is positioned on the
inside of the sling. The outside has a label or
print for reference.
• Make sure the patient is centered in the sling.
The patient feels discomfort in the leg area when
seated in the sling.
• Make sure that there are no creases on the leg
ÀDSVRIWKHVOLQJ
• 0DNHVXUHWKHOHJÀDSVDUHDWWDFKHGDWWKH
right length.
,WLVGLႈFXOWWRDSSO\WKHFOLSV
• Make sure the clip is not caught between
the lug on the lift and the clip attachment.
• Select the other attachment clip position
LQQHURURXWHU
,WLVGLႈFXOWWRXVHWKHVOLQJLQFRPELQDWLRQZLWK
the lift.
8VHWKHVOLQJRQO\LQDFFRUGDQFHZLWKWKH
combinations described in section “Allowed
Combinations” on page 9.
The position of the patient in the sling should be
more reclined or seated.
8VHWKHFOLSVORRSVOLIWFRUGVWRDGMXVW
the patient’s position.
The patient wishes to have more support for the
back.
8VHWKHLQQHUFOLSVORRSVIRUDWWDFKPHQWRU
tighten the lift cords to adjust the patient’s
position.
The patient feels discomfort in the waist area. Adjust the support belt, tighten or loosen.
The sling is sliding up under the patient’s arms. Tighten the support belt for a more comfortable
¿W
The patient feels discomfort while using the sling.
• Make sure the patient is holding on to the
handles on the lift.
• Adjust the support belt for a more
FRPIRUWDEOH¿W
The disposable sling is soiled, stained or wet. Throw the disposable sling away and replace it
with a new one.
7KH³'R127ZDVK´ODEHOLVGDPDJHGRUPLVVLQJ
DQGWKHXQGHUO\LQJUHGODEHO³'R127XVHOLIW´
appears.
Throw the disposable sling away and replace it
with a new one.
The patient cannot reach fully standing position. Select another sling size or another attachment
FOLSSRVLWLRQLQQHURURXWHU
EN

15
7HFKQLFDO6SHFL¿FDWLRQV
General
6DIHZRUNLQJORDG6:/
= Maximum total load See “Allowed Combinations” on page 9
Service life
- Recommended period of use
Disposable sling: 2 weeks, based on 4 transfers/day*
All other slings: 2 years*
* Refer to “Expected service life” on page 3.
Shelf life
- Maximum storage period of new
unpacked product
5 years
Model and Type See “Sling Selection” on page 8
Operating, Transport and Storage Environment
Temperature &WR&)WR)2SHUDWLQJDQG6WRUDJH
&WR&)WR)7UDQVSRUW
Humidity 0D[±DW&)2SHUDWLQJDQG6WRUDJH
0D[±DW&)7UDQVSRUW
End of Life Disposal
Box The box consists of cardboard,
recyclable to local legislations.
Package The bag consists of soft plastic,
recyclable to local legislations.
Sling
6OLQJVLQFOXGLQJVWLႇHQHUVVWDELOL]HUVSDGGLQJPDWHULDO
any other textiles or polymers or plastic materials etc.
should be sorted as combustible waste.
Parts and Accessories
Sling Part Description Article number
TSS.500S-1C Belt TSB.100-C
TSS.501S-1C Belt TSB.100-C
TSS.502S-1C Belt TSB.100-C
TSS.503S-1C Belt TSB.200-C
TSS.501SV Belt TSB.100-V
TSS.502SV Belt TSB.100-V
MAA3070M Belt and Belt retainer KKX21440
MAA3071M Belt and Belt retainer KKX21440.0
MAA3071M Fleece ..;
EN

16
Label on the Sling
Care and Washing Symbols
0DFKLQHZDVK&)
No bleaching allowed
No tumble drying allowed
Tumble drying
Does not apply to disposable sling or
wipeable sling
No Ironing allowed
Do NOT wash
Only applies to the disposable sling
and wipeable sling
No dry cleaning allowed
Wipe clean
Only applies to the wipeable sling
&HUWL¿FDWHV0DUNLQJV
CE marking indicating conformity with
European Community harmonised
legislation
Indicates the product is a Medical
'HYLFHDFFRUGLQJWR(80HGLFDO'HYLFH
Regulation 2017/745
8QLTXHGHYLFHLGHQWL¿HU
Disposable Sling Symbols
³'R127ZDVK´V\PERO/RFDWHG
on the outside of the sling.
³'R127XVHOLIW´V\PERO7KH
disposable sling has been washed.
Located on the outside of the sling.
Symbol for Clip
8VHDFOLSVSUHDGHUEDU
Article Number
REF
XXXXXX-X Article number with -X refers to the sling size.
REF
XXXXXXX
If the article number is stated
without the size letter at the end,
it means the sling is a One Size.
Fibre Content
PES Polyester
PE Polyethylene
38 Polyurethane
PA Polyamide
738 Thermoplastic Polyurethane
Misc. Symbols
6DIH:RUNLQJ/RDG6:/
Patient’s name symbol
Single patient multiple use
Record symbol
Read the IFU before use
REF Article number
SN Serial number
Manufacturing date and year
Manufacturer name and address
Size of the sling illustrated by
colour and letter.
S for small, M for medium, L for
large, and XL for extra large.
Only applies to the wipeable sling.
UK Symbol explanation
7KLVVHFWLRQLVRQO\DSSOLFDEOHWR8QLWHG.LQJGRP8.PDUNHWZKHQ8.PDUNLQJLVDSSOLHGWR
the Arjo medical device labelling.
8.PDUNLQJLQGLFDWLQJFRQIRUPLW\ZLWK8.0HGLFDO'HYLFHV
5HJXODWLRQV6,1RDVDPHQGHG
UK Responsible Person & UK Importer:
Arjo (UK) Ltd, ArjoHuntleigh House, Houghton Regis. LU5 5XF
,VWKHDSSRLQWHG8.5HVSRQVLEOH3HUVRQDVGH¿QHGLQ8.0HGLFDO'HYLFHV5HJXODWLRQV
6,1RDVDPHQGHG
)RU1RUWKHUQ,UHODQG1,&(PDUNLQJZLOOVWLOODSSO\XQWLOIXUWKHUDPHQGPHQWWRDSSOLFDEOHUHJXODWLRQV
EN

17
险デ
⚹鼙⯝「ⵌ⠟㹲㖈⢪欽❡ㅷ⵸䗳곢ꢓ靀劥⢪欽霹僈⛼⟄⿺❡ㅷꥥ꣡涸俒咓կ霼⸉䗳ꢓ靀
劥⢪欽霹僈⛼կ
霃雦佟瘻ㄤ晜勉
® ㄤ™ 㾩✵ Arjo Ⱆ぀꧋㔙涸㉁叻կ
© Arjo 2022կ
䧮⟌涸㸺傋僽♶倗鵳遤佖鵳㔔姼䧮⟌⥂殆刿佖霃雦涸勉ⵄ䛓♶〥遤鸑濼կ
劢絑 Arjo ず䠑♶䖤Ⰼ鿈䧴鿈ⴔ㢕ⵖ劥ⴀ晜暟⚥涸ⰻ㺂կ
⵸鎊
䠭靧䝠餝✈ Arjo 霃㢊կ霼鸑靀劥 ⢪欽霹僈⛼ (IFU)կ
Arjo 㼆⟣⡦㔔劢絑䱇勉佖⸓❡ㅷ罜㼋荝涸䠑㢪ծ✲佦䧴䚍腊⚜㣟㖲♶䪬䬐⟣⡦餓⟣կ
㹐䨪佅䭯
㥵卓꨽銳刿㢴⥌䜂霼翫禹䝠䔲㖑涸 Arjo ➿邍կ翫禹⥌䜂㖈劥 ⢪欽霹僈⛼ ,)8涸剒た♧곜⴩ⴀկ
劥⢪欽霹僈⛼ (IFU) ⚥涸㹁⛐
险デ 邍爙㸝Ⰼ䚍险デկ㥵♶椚鍒䎇⚂♶黽㸛霪险デ〳腊⠔㼆䝠䧴➭➃鸣䧭➃魧⠟㹲կ
岤䠑✲고 邍爙㥵♶黽㸛鵯❈霹僈〳腊㼋荝侮⚡禹絡䧴霃㢊䧴Ⱖ⚥鿈ⴔ鿈⟝涸䰀㗁կ
岤䠑 邍爙鵯❈僽姻烁⢪欽劥禹絡䧴霃㢊涸ꅾ銳⥌䜂կ
湡䔶
⵸鎊 ................................................................17
㹐䨪佅䭯.............................................................17
劥⢪欽霹僈⛼,)8⚥涸㹁⛐ .............................17
傁㹁欽鸀 .........................................................
䝖罏/鄄撑䫡➃霉⠮ .............................................
곫雦⢪欽㼑ㄐ...................................................... 
㸝Ⰼ霹僈 .........................................................19
㸝Ⰼ錞玐.............................................................19
⚚ꅾ✲⟝.............................................................19
鿈⟝ぜ獦 .........................................................20
⢪欽ⲥ㢊 .........................................................21
ⴲ妃⢪欽⵸6 姿...............................................21
嫦妃⢪欽⵸姿...............................................21
嫦妃⢪欽た .........................................................21
鷥䭊じ⯶錞呔..................................................22
䲃倶 ....................................................................22
鷥䭊じ⯶ .........................................................23
鲮鵘/鵘鳕............................................................23
⯈雽絆ざ .........................................................24
㸝Ⰼ䪬ꅾ6:/.................................................. 24
鵶䱹♸䬒ꤑ⽓䩾 ..............................................24
鵶䱹⽓䩾6 姿...................................................24
䬒ꤑ⽓䩾3 姿...................................................24
䎾欽じ⯶ .........................................................25
㖈䏠喱/鲰喱⚥17 姿........................................25
䬒ꤑじ⯶ .........................................................26
㖈䏠喱/鲰喱⚥11 姿......................................... 26
幡峇ㄤ嶊嫫......................................................27
♧妃䚍じ⯶ - 霼⺡幡峤........................................ 27
〳亭䭎じ⯶ - 幡峇♸嶊嫫霹僈6 姿................... 27
〳亭䭎じ⯶ - 嶊嫫⵫ ...........................................27
〳劼峤じ⯶ - 幡峇霹僈3 姿.............................
〳劼峤じ⯶ - 幡峇⵫ ...........................................
⥂Ⱞ♸꣈䫡䚍絶䫡........................................... 
嫦妃⢪欽⵸た...................................................... 
䒚腮䧴属寓⟄⿺䝖罏⛓ꢂ✽欽傞.........................
餞㶸 ....................................................................
⥂Ⱞㄤ絶䫡 .........................................................
佦ꥻ䱗ꤑ .........................................................29
䪮助錞呔 .........................................................30
鿈⟝ㄤ꣡⟝......................................................30
じ⯶♳涸叻晥..................................................31
⢪欽霹僈⛼
ZH


傁㹁欽鸀
⚺⸓䒭じ⯶僽♧妴鷓欽✵鳇⸔獴⸓腊⸂剣ꣳ涸䝖罏鄄撑
䫡➃鵳遤鲮鵘ㄤ䐀㢕涸❡ㅷկ
4BSB'MFY〳亭䭎畀用じ⯶銳♸䲿⼮霃㢊ꂁざ⢪欽⟄⤑㖈
䧭䎃䝖罏鄄撑䫡➃饰魧荛畀用㪧⸷鵂玐⚥⟄⿺瀊兽鲮獴
鵂玐⚥䲿⣘魧⡤佅丒կ鸑鵂亭䭎倰䒭鵳遤幡峇կ
♧妃䚍⚺⸓䒭じ⯶欽✵㖈絑㛆雲涸䫡椚➃プ港漛♴⢪欽
䝖罏鄄撑䫡➃鲮鵘獴⡙劼傞⚹⼕ꤎ䧴䫡椚劼匬涸䝖罏鄄
撑䫡➃䲿⣘佅丒կ
䎾䭽撑劥⢪欽霹僈⛼*'6⚥䭷㹁涸⯈雽絆ざ㼜⚺⸓䒭
じ⯶ծ4BSB'MFY〳亭䭎畀用じ⯶⟄⿺♧妃䚍⚺⸓䒭じ⯶ꂁ
ざ"SKP⼮꣭獴⡙霃㢊⢪欽կ
⚺⸓䒭じ⯶ծ4BSB'MFY〳亭䭎畀用じ⯶⿺♧妃䚍⚺⸓䒭じ
⯶➑⣘㼆䫡椚梠㞯剣⯎ⴔ✫鍒䎇黽㸛劥⢪欽霹僈⛼⚥霹
僈涸雲絅剣稇涸䫡椚➃プ⢪欽կ
♧妃䚍⚺⸓䒭じ⯶➑㖈剣ꣳ傞ꢂ媯ⰻ⢪欽歋✵Ⱖ霃雦暵
䚍䗳곢䔲⡲♧妃䚍ㄤ䝖罏鄄撑䫡➃⚁欽❡ㅷ勻㢅椚կ
♶䖤⢪欽♧妃䚍⚺⸓䒭じ⯶㖈䝖罏鄄撑䫡➃峤嵮傞䲿⣘
佅丒կ♧妃䚍⚺⸓䒭じ⯶♶〳幡峤կ
⚺⸓䒭じ⯶ㄤ4BSB'MFY〳亭䭎畀用じ⯶鷓ざ㖈⼕ꤎ梠㞯
ծ䫡椚⚥䗱ծⰦ➭⨴䐀䫡椚劼匬ㄤ㹻䏭䫡椚⚥⢪欽կ
♧妃䚍⚺⸓䒭じ⯶鷓ざ㖈⼕ꤎ梠㞯ծ䫡椚⚥䗱ㄤⰦ➭⨴䐀
䫡椚劼匬⚥⢪欽կ
⚺⸓䒭じ⯶ծ4BSB'MFY〳亭䭎畀用じ⯶⿺♧妃䚍⚺⸓䒭
じ⯶〫腊欽✵劥⢪欽霹僈⛼⚥䭷㹁涸欽鸀կ犜姺欽✵Ⱖ
➭湡涸կ
䝖罏/鄄撑䫡➃霉⠮
䧮⟌䒊雳⢪欽劼匬䒊用傈䌢霉⠮玐䎸կ⚺⸓䒭じ⯶ㄤ♧
妃䚍⚺⸓䒭じ⯶䫡椚➃プ䎾㖈⢪欽劥鄳縨⵸呏䰘⟄♴叻
ⲥ霉⠮嫦ぜ䝖罏/鄄撑䫡➃
• 䝖罏/鄄撑䫡➃㗂㖈鲰喱ⰻ
• 荛㼱♧勵艙腊㢿䪬「鿈ⴔ⡤ꅾ
• Ⱘ剣♧㹁涸魱䎁珘㹁䚍
• 㖈㣐鿈ⴔ䞔ⲃ♴⣜饆䫡椚➃プ
• 魧⡤꨽銳⣜饆䫡椚➃プ
• ⵞ慨ⶥ⡮腊⸂ꬋ䌢ꅾ銳
獴⡙⛓⵸Sara Flex 〳亭䭎畀用じ⯶䫡椚➃プ䎾呏䰘⟄
♴叻ⲥ霉⠮嫦ぜ䝖罏/鄄撑䫡➃
• ⡤㘗
• 崞⸓腊⸂紩ⵆ
• ⼕毫朐ⲃ
• 椚鍒銳宠涸腊⸂ㄤㆇ䎾腊⸂
4BSB'MFY〳亭䭎畀用じ⯶鷓欽✵⟄♴䝖罏鄄撑䫡➃
• 荛㼱♧〫艙腊㢿䪬鲿魧⡤ꅾꆀ䎇⚂Ⱘ剣♧㹁涸魱䎁
珘㹁䚍կ
• ⡤ꅾ♶馄鵂NJOEVկ
• 魧넞㖈 140 cm ㄤFP⛓ꢂկ
⚺⸓䒭じ⯶涸㸝Ⰼ䪬ꅾ6:/
• MAA3070MծMAA3071MծMAA3061MծMAA3060M
NJOEV
• TSS.500-504ծTSS.500-503S-1CծTSS.501-502SVծ
TSS.511NJOEV
˙ .'"4BSB♧妃䚍じ⯶LHMCT
姻烁霉⠮嫦ぜ䝖罏/鄄撑䫡➃涸⡤㘗ծ朐ⲃㄤ獴⡙梠㞯碫㘗
た䎾⢪欽碫㘗ㄤ錞呔鷓ざ涸じ⯶կ
㥵卓䝖罏/鄄撑䫡➃♶忘駈鵯❈勵⟝䎾⢪欽Ⱖ➭霃㢊/禹
絡❡ㅷկ
곫雦⢪欽㼑ㄐ
⚺⸓䒭じ⯶ծSara Flex 〳亭䭎畀用じ⯶⿺♧妃䚍⚺⸓䒭
じ⯶涸곫雦⢪欽㼑ㄐ⚹剒Ɤ剣佪⢪欽劍կ
じ⯶涸곫雦⢪欽㼑ㄐ》Ɀ✵㹊꣢⢪欽勵⟝կ㔔姼⢪欽⵸
霼㨤絊烁⥂じ⯶尵剣⟣⡦熋䰀ծ丘鄬䧴Ⱖ➭䰀㗁鶺韌⚂
♶㶸㖈⟣⡦䰀㗁⽰灶鄬ծ䓮刼ծ䫔倗կ㥵卓溏ⵌ⟣⡦姼碫
䰀㗁䞔ⲃ霼⺡⢪欽じ⯶կ㥵卓㼆✵じ⯶㸝Ⰼ剣⟣⡦毟꡼
⡲⚹곫꣈䲃倶䎇⚹✫烁⥂㸝Ⰼ霼⺡⢪欽じ⯶կ
⚺⸓䒭じ⯶ㄤ Sara Flex 〳亭䭎畀用じ⯶涸곫雦⢪欽㼑ㄐ
⢪欽傞ꢂ2 䎃
⥂餘劍5 䎃
♧妃䚍⚺⸓䒭じ⯶涸곫雦⢪欽㼑ㄐ
⢪欽傞ꢂ2 ワ㛇✵ 4 妃鲮鵘/傈
⥂餘劍5 䎃
ZH

19
㸝Ⰼ霹僈
险デ
⚹鼙⯝➃魧⠟㹲䎾㨤絊剣⚁➃溏䫡䝖罏կ
险デ
⚹鼙⯝䶫⦝䝖罏⡤ꅾ♶䖤馄ⴀ䨾欽❡ㅷ⿺꣡⟝
涸㸝Ⰼ䪬ꅾ薴㔵կ
险デ
⚹鼙⯝➃魧⠟㹲䎾㖈⢪欽⵸㨤絊㼆䝖罏朐ⲃ鵳
遤霉⠮կ
险デ
⚹鼙⯝➃魧⠟㹲ⴗ⺡幡峤♧妃䚍じ⯶կ♧妃䚍
じ⯶➑ꣳ♧ぜ䝖罏⢪欽կ
险デ
⚹鼙⯝➃魧⠟㹲ⴗ⺡㖈⢪欽じ⯶傞雮䝖罏エ
掆կじ⯶⠔㼋荝抠拇կ
险デ
⚹鼙⯝➃魧⠟㹲➑䎾瀊劍㶸⪰霃㢊կ㥵卓㶸⪰
傞ꢂ馄鵂
⢪欽霹僈⛼ (IFU) ⚥錞㹁涸傞ꢂⴭ⠔
㼋荝勞俱倗鄬ㄤ䔂䏞」䓳կ
险デ
⚹鼙⯝➃魧⠟㹲霼鼙⯝꣉⯕/稘㢪⯕撑㼘ⵌ霃
㢊կ凐ꪪ✵꣉⯕/稘㢪⯕⠔꣭⡛勞俱䔂䏞կ
㸝Ⰼ錞玐
䔲䝖罏」䖤掓鬑♶㸝傞ꥥ傞⨢姺鲮鵘/鵘鷐䎇㸝Ⰼ
㖑佞⡛䝖罏կ
⚚ꅾ✲⟝
㥵卓〄欰♸霪⼕毫㐼唒湱Ⱒ䎇䕧ㆇ欽䨪䧴䝖罏涸
⚚ꅾ✲⟝ⴭ欽䨪䧴䝖罏䎾㼜霪⚚ꅾ✲⟝䫣デ絛⼕
毫㐼唒ⵖ鸣㉁䧴ⴔꝈ㉁կ㖈妍湅欽䨪鵮䎾ぢⰦ䨾
㖈䧭プ㕂涸⚺盗䔲㽷䫣デ霪⚚ꅾ✲⟝կ
ZH

20
鿈⟝ぜ獦
1. じ⯶叻晥/⽪ⵘ暟⡙✵㢪鿈
2. 舸鿈
3. ⰻ鵶䱹⽓䩾
4. 㢪鵶䱹⽓䩾
5. 鵶䱹じ䌄
6. 佅丒䌄䌄䩾
7. 䌄䩾
 䫡鴝
9. 艙䌄鵶䱹梠
10.舸䌄
11. 佅丒䌄鵶䱹꛰梠
12.♧妃䚍じ⯶叻霋晥⡙✵㢪鿈
じ⯶爙⢾կ劢爙ⴀ䨾剣㘗〿կ
1
2
6
7
3
5
7
11
12 9

1
10 1
4
XXXX-XX-XX
MADEINPOLAND
ArjoWipeableStandingClip Sling
ArjoHuntleighAB
HansMichelsensgatan10
21120Malmö,Sweden
www.arjo.com TSS.502W
XXXXXXXXX
(01)05056097369938 (11)YYMMDD(21)123456789
440lb
200kg
1
㢪⣩
ZH
