Arjo Malibu User manual

Soak a cloth in
disinfectant. Wipe all
other contact areas such
as the outside of the
bathtub, hand control
and the transfer chassis
with the cloth.
For bathtubs with Air Spa system
Disinfection cycle will turn off automatically.
For bathtubs without Air Spa system
Press the Disinfection button to end the
disinfection process.
Remove visual residue
Turn off all
functions.
Make sure the
transfer chair is
inside the
bathtub.
Put on protective gloves
and eye wear.
For bathtubs with Air Spa system:
The automatic disinfection will start. Approximate time
for the automatic disinfection is 3 to 4 minutes.
10 seconds after the start, the disinfection spray handle
is activated for 2 minutes before it shuts off.
Scrub all internal
bathtub surfaces,
lifting arm, transfer
chair, the loose parts
and the accessories
thoroughly.
Spray into the surface overflow outlet.
Lift out the disinfection spray
handle.
2
5
9
3 4
1
6 7
16 17
14
Spray disinfectant into the bathtub until
the flow meter (A) shows correct mixing
value according to the Instructions for
use. Adjust if needed (B).
Adjust water temperature to 20°C.
Spray disinfectant in the drain. Scrub the
drain with a brush. Close the drain.
8
10 11 12
13
Wet a new cloth with water and
remove the disinfectant. Occasionally
rinse the cloth in running water.
Press the
disinfection
button for
5 seconds.
Open the drain. Detach and place all
accessories at the bottom of the bathtub.
QUICK REFERENCE GUIDE - CLEANING AND DISINFECTION
Malibu/Sovereign
Continue with the steps on the next page
Disinfect with disinfection unit
Clean
Put the disinfection spray
handle back.
15
Open the drain.
Rinse all parts with plenty of water
having a temperature of 25 °C.
80
70
60
50
40
30
20
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö, Sweden
www.arjo.com
A
B
With water, shower
and rinse the bathtub,
lifting arm, transfer
chair and all sides of
the loose parts and
accessories.
Spray disinfectant on
all internal bathtub
surfaces, lifting arm,
transfer chair and on
all sides of the
loose parts and
accessories.
08.AZ6.00_1EN • 10/2020 • Page 1/3

21
Spray disinfectant in the drain.
Close the drain.
24 27
26
31
28
Leave to air dry.
Attach armrests and
seat. Make sure the
seat is attached.
Attach the neck pillow,
safety belt and rest of
the accessories.
30
Allow appropriate
contact time
according to the
instructions of the
disinfectant.
Put the disinfection spray
handle back.
Disinfect
Soak a cloth in disinfectant.
Wipe all other contact
areas such as the outside
of the bathtub, hand control
and the transfer chassis
with the cloth.
23
2
1
22
Wet a new cloth with
water and remove
disinfectant.
Occasionally rinse the
cloth in running water.
Open the drain.
Rinse all parts
with water having
a temperature of
25 °C.
Disinfect with disinfection unit (continued)
Spray disinfectant on
all internal bathtub
surfaces, lifting arm,
transfer chair and on
all sides of the loose
parts and accessories.
29
Place the
shower handle
in the holder.
For bathtubs with Air Spa system
Disinfection cycle will turn off
automatically.
For bathtubs without Air Spa system
Press the Disinfection button to end the
disinfection process.
25
For bathtubs with Air Spa system:
The automatic disinfection will start. Approximate time for
the automatic disinfection is 3 to 4 minutes.
10 seconds after the start, the disinfection spray handle is
activated for 2 minutes before it shuts off.
19 20
Press the
disinfection
button for
5 seconds.
Lift out the disinfection spray
handle.
18
08.AZ6.00_1EN • 10/2020 • Page 2/3

Remove visual residue
Turn off all
functions.
Make sure the
transfer chair is
inside the
bathtub.
Put on protective gloves
and eye wear.
2
5
9 10 11
34
1
6 7 8
Open the drain. Detach and place all
accessories at the bottom of the bathtub.
Clean
Spray disinfectant in the
drain. Scrub the drain with
a brush. Close the drain.
Spray into the surface
overflow outlet.
Scrub all internal
bathtub surfaces,
lifting arm, transfer
chair, the loose parts
and the accessories
thoroughly.
Open the drain.
Rinse all parts with
plenty of water
having a temperature
of 25 °C.
Soak a cloth in
disinfectant. Wipe all
other contact areas such
as the outside of the
bathtub, hand control
and the transfer chassis
with the cloth.
Wet a new cloth
with water and
remove the
disinfectant.
Occasionally rinse
the cloth in
running water.
Spray disinfectant
in the drain. Close
the drain.
Disinfect
16
1312 14
17
15
21
18
Leave to air dry.
Attach armrests and
seat. Make sure the
seat is attached.
Attach the neck pillow,
safety belt and rest of
the accessories.
20
Allow appropriate
contact time
according to the
instructions of the
disinfectant.
2
1
Open the drain.
Rinse all parts with water having
a temperature of 25 °C.
19
Place the shower handle in the
holder.
Soak a cloth in
disinfectant. Wipe all
other contact areas such
as the outside of the
bathtub, hand control
and the transfer chassis
with the cloth.
Disinfect with spray bottle
Spray into the surface
overflow outlet.
Wet a clean cloth
with water and
remove the
disinfectant.
Occasionally rinse
the cloth in
running water.
With water, shower
and rinse the bathtub,
lifting arm, transfer
chair and all sides of
the loose parts and
accessories.
Spray disinfectant on
all internal bathtub
surfaces, lifting arm,
transfer chair and on
all sides of the loose
parts and accessories.
Spray disinfectant on
all internal bathtub
surfaces, lifting arm,
transfer chair and on
all sides of the loose
parts and accessories.
08.AZ6.00_1EN • 10/2020 • Page 3/3
