ARRI SkyPanel S30 User manual

SkyPanel®
C and RP Versions
S30 / S60 / S120 / S360
L5.0019845
05 / 2018
U S E R M A N U A L

© 2018 Arnold & Richter Cine Technik GmbH & Co. Betriebs KG.
All rights reserved. Information subject to change without notice. ARRI and all affiliated companies disclaim liability for any injury,
damage, direct or indirect loss, consequential or economic loss or any other loss occasioned by the use of, inability to use or reli-
ance on the information contained in this document.
No part of this document may be used for distribution, reproduction, transmission, transcription, storage in a data retrieval system,
or translated into any language in any form by any means without the prior written permission of ARRI®. If you are downloading
files from our web pages for your personal use, make sure to check for updated versions. ARRI®cannot take any liability whatso-
ever for downloaded files, as technical data are subject to change without notice.
Art-NetTM Designed by and Copyright Artistic Licence Holdings Ltd.
ARRI, ARRI ARRI, the ARRI Logo, ARRIMAX, ARRISUN, EB, EBB, L-Series, MAX Technology, M-Series, POCKETPAR, True
Blue, SkyPanel, SKYPANEL, T 12 and T 24 are registered trademarks of Arnold & Richter Cine Technik GmbH & Co. Betriebs KG.

3
ContentContent
3
Content
Content ............................................................................................................................................................3
Introduction ....................................................................................................................................................5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Fixture Menu ...................................................................................................................................................7
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Features of the Fixture Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
POWER-LED (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
DATA-LED (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
STATUS-LED (3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
INTENSITY/SELECTOR (I/S, 4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Central Rotary Knob (5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Right Rotary Knob (6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
PRESET (7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
MODE (8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
DISPLAY (9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
MENU (10) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
BACK (11) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
To lock the fixture menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
To Set the Operation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
SkyPanel Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Fixture Modes ...............................................................................................................................................10
CCT and RGBW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
CCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
CCT & HSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
RGBW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
HSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
GEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
xy Coordinates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Source Matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Light Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Light Engine Control via DMX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Ultimate DMX Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Extended color control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Functions ......................................................................................................................................................12
To set the Lighting Parameters in CCT Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
To set the Color in HSI Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
To set the Lighting Parameters in GEL Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
To set the Light Source in Source Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
To set the Color in RGBW Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
To set the Color in X,Y Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Extended Color Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
To Use the Extended Color Control via DMX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
To Use the Extended Color Control via the Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
To Set the Brightness in all Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
To Set the Dimming Curve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
To Set a Special Control Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Content
4
Stage Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Low End Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Tungsten Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
High Speed Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Overview of the Special Control Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Master/Slave Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Calibrated RGBW Color Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Frequency Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
To set the Fan Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Lighting Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
To Activate and set Effect Parameters with the Fixture Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
To Set the Display Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
USB Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Preset Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
To Save and Load Fixture Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
To Save the Error and Service Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
To Read out Fixture Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
To Read out Fixture Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
To Perform a Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
DMX ...............................................................................................................................................................25
DMX Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
DMX Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
DMX-Signal-Loss Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Wireless DMX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Networking ....................................................................................................................................................27
Art-Net and sACN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Art-Net IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Art-Net Net . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Sub-Net . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Universe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Art-Net Merge Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Art-Net Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
ARRI Lighting Service Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
SkyPanel Web Portal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Overview of the Fixture Menu .....................................................................................................................30
RDM Commands ..........................................................................................................................................34
Error Codes ..................................................................................................................................................37
Overview of Typical CCT Values as DMX Values ......................................................................................38

5
IntroductionIntroduction
5
Introduction
Thank you for selecting a SkyPanel LED soft light from ARRI. The SkyPanel is a compact, ultra-bright and
high-quality LED soft light. It is much more efficient than a soft light with a conventional light source.
The different models of the SkyPanel emit white light with a fixed color temperature or colored light with
adjustable color temperature and adjustable green-magenta point. The light spectrum is optimized for ex-
cellent color rendition and fulfills perfect the demands of modern, digital cameras. All models of the Sky-
Panel can be controlled using the common DMX512-A protocol, Art-Net, sACN or the fixture menu.
Please observe the SkyPanel Installation and Safety Manual. The manual is available for free download on
the ARRI web site www.arri.com.
Features
Light Field
The SkyPanel offers the same functionality as a conventional softlight.
Even Light Field
The SkyPanel softlight produces a homogeneous, single-shadow light field, delivering natural results.
Vibrant Colors, Full Spectrum Lighting
True-to-life color rendition is an outstanding feature of the SkyPanel. The fully tunable white light of the
SkyPanel can be adjusted for different skin tones, camera sensors and mixed light environments. Full gam-
ut color mixing enables the rendition of all color shades. The extensive gel library (from firmware version
2.0) offers a wide range of familiar colors at the user’s fingertips.
Cool Light Beam
The SkyPanel does not emit any infrared or UV radiation and thus does not forward heat, making actors
feel comfortable in the light beam.
Properties
Accessory Holder
Diffuser plates or an intensifier is placed on the front of the fixture and secured by locking guiding rails or
held by four locking pins. Both the diffuser and intensifier of the S360-C are equipped with guiding rails at
the front to carry other accessories for shaping the light like a honey comb.
Yoke
Thealuminumorcarbon fiber yoke provides high strengthwithminimumweight.Theshort metal yoke (only
S360-C) is the perfect solution when the SkyPanel is mounted in a grid facing downwards.
This manual describes the C and RP models of the SkyPanel. Please note, that the RP model emits
only white light with a fixed color temperature. The color temperature is defined by the Phosphor
panel used.
NOTICE

Introduction
6
Tilt-Lock
The high strength tilt-locks on each side of the stirrup provide secure locking. It eliminates movement and
slippage and ensures that the SkyPanel will stay where you put it.
Control
All functions of the SkyPanel are controllable through DMX, Art-Net or sACN. The SkyPanel is also fully
RDM compatible (via DMX and Art-Net with suitable controllers) and is equipped with an RDM feedback
channel for reporting all set parameters including system status.
The SkyPanel S360-C is equipped with an integrated CRMX transceiver for wireless control and RDM com-
munication. All other models of the SkyPanel series can be controlled wireless when using the SkyLink
system, which is available as an accessory.
Fixture Menu
For location applications the SkyPanel is equipped with a fixture menu for manual adjustment of intensity,
color temperature, green-magenta point as well as hue and saturation and other parameters.
Control Options
You can set up or control the SkyPanel with the options listed in the table below
The model S360-C is equipped with an internal CRMX Transceiver, all other models need to be connected
to the SkyLink system (accessory) to gain wireless control.
Option Control Configuration Information
Fixture menu Yes Yes page 6
DMX Yes No
Please see „DMX
protocol specifica-
tion (free download
from www.arri.com)
CRMX (WDMX)* Yes No page 26
RDM No Yes page 35
Art-Net and sACN Yes No page 11
ALSM No Yes page 27
Web Portal No Yes page 29

7
Fixture MenuFixture Menu
7
Fixture Menu
This section describes the fixture menu of the SkyPanel and the SkyPanel remote control. Some options, especially
options for saving and loading data, are not available in the remote control fixture menu.
Overview
Features of the Fixture Menu
POWER-LED (1)
DATA-LED (2)
Color Indication
Green Fixture switched on. No error.
No color Fixture switched off.
Color Indication
Blue The fixture receives a valid DMX signal.
Blue / green The fixture receives a valid CRMX (WDMX) signal
(only S360-C).
Purple Master mode active
White Receiving valid Art-Net signal, Gateway active
Green Receiving valid Art-Net signal, Gateway not active
Orange Receiving valid sACN signal, Gateway active
Cyan Receiving valid sACN signal, Gateway not active
Red No communication between fixture menu and controller
board.
No light The fixture receives no valid control signal.
1
2
3
456
7
8
9
10
11

Fixture Menu
8
STATUS-LED (3)
INTENSITY/SELECTOR (I/S, 4)
The INTENSITY/SELECTOR encoder I/S has two functions:
• Fixture menu closed: Setting the intensity.
• Fixture menu open: Use I/S to scroll through the menu, open sub menus and set parameters. Pressing
the knob opens sub menus and confirms settings.
Central Rotary Knob (5)
Use the rotary knob to set the color temperature (CCT) or the color hue (HUE). The current function of the
rotary knob is shown in the display (9) above the knob.
Right Rotary Knob (6)
Use the rotary knob to set the green- magenta point or the color saturation (SAT) or, dependent on the ac-
tive color mode, categories or parameters. The current function of the rotary knob is shown in the display
(9) above the knob.
PRESET (7)
To call up a preset
A short press of the PRESET button brings up the list of all available presets. Turn I/S (4) to select one of
10 factory presets and 10 user definable presets. Press I/S (4) to activate the preset.
To store a preset
Use the fixture menu to adjust the settings. Hold PRESET, until the preset save dialog opens. Turn I/S (4)
to select a preset memory slot. Press I/S (4) to store the preset. Close the dialog with BACK.
MODE (8)
Press the MODE button short to swap between CCT, HSI, GEL, Source Matching, RGBW mode and X,Y
mode of the SkyPanel.
Press the MODE button long (> 3 sec.) to activate the extended color control. The extended color control
feature is not available in RGBW mode unless RGBW Calibrated Color Space is activated.
DISPLAY (9)
The display shows the current settings and other information during normal operation. Press the MENU
button (4) to open or close the fixture menu. Use I/S (4) and the BACK button (11) to navigate through the
fixture menu.
Color Indication
Green No error. Normal temperature.
Red flashing (0,5s rhythm)* Warning fixture over temperature (only
with fan modes LOW and High Speed).
Red*Fixture over temperature.
Change from red to green*Fixture normal temperature.
Red flashing (0,25s Rhythm)*Calibration data not loaded.
*Display lights up red when STATUS-LED is lit red

9
Fixture MenuFixture Menu
9
MENU (10)
The MENU button opens the fixture menu. Press MENU when the fixture menu is open to close the menu
and abort an action (Escape). Use I/S (4) to scroll through the menu, open sub menus and set parameters.
Press MENU long to display the menus which are used most.
BACK (11)
The BACK button closes a sub menu and aborts an action (Escape). Compared to the MENU button (10)
the BACK button only closes the sub menu, but not the fixture menu.
Press BACK long to display the last used menus.
To lock the fixture menu
• Press I/S in the home screen for 5 seconds to lock all buttons and knobs. Use the feature to prevent an
accidental change of settings.
• The word „LOCKED“ appears on the display when locked.
• Press I/S in the home screen for 5 seconds again to unlock all buttons and knobs.
• Please find a overview in chapter “Overview of the Fixture Menu” on page 30.
To Set the Operation Mode
Press the MODE button (8) short to switch from CCT to HSI to GEL to Source to RGBW to X,Y and back
to CCT mode.
In CCT mode the SkyPanel generates white light with optimized color rendition. In HSI mode the SkyPanel
generates colored light. If saturation is set very low, the SkyPanel generates white light, but not with opti-
mized color rendition. The GEL mode offers an extensive color gel library. In Source mode the SkyPanel
generates the light of traditional light sources. Use the RGBW mode to generate a RGBW color using the
control panel. The X,Y mode generates a color defined by its X,Y coordinates.
Press the MODE button long (> 3 sec.) to activate the extended color control. The extended color control
feature is not available in RGBW mode unless RGBW Calibrated Color Space is activated.
SkyPanel Remote
The SkyPanel Remote is connected with an USB cable to a SkyPanel softlight. It is powered by the
SkyPanel and does not use a battery. The SkyPanel Remote emulates the SkyPanel fixture menu. Each
SkyPanel Remote controls one SkyPanel.
Use multiple SkyPanel softlights in a master / slave configuation to control them with one SkyPanel
Remote.
The SkyPanel checks the firmware of the SkyPanel Remote every time it is connected. If the firmware ver-
sion of the SkyPanel Remote is different to the firmware version of the SkyPanel the SkyPanel Remote
firmware will be synchronized automatically, no matter if it is an up- or downgrade.

Fixture Modes
10
Fixture Modes
The SkyPanel offers, depending on the model, up to 31 control modes. Use the 8 bit modes with basic con-
trollers like dimmer consoles.
ARRI recommends the use of the 16 bit modes in combination with controllers supporting 16 bit resolution
to obtain best results. The high resolution provides smooth dimming and precise color adjustments.
The coarse / fine modes utilize two channels for most parameters and provide higher resolution compared
to the 8 bit modes in combination with controllers that do not support true 16 bit resolution. One channel
sets the coarse value between 0 and 255 of the function. Each step is divided in 256 increments using the
fine channel. This way it is possible to control the light very precise without using a true 16 bit resolution.
Below is a short overview of the different control modes. Please find a detailed overview of all DMX modes
in the document „SkyPanel DMX Protocol Specification“ which is available for free download on the ARRI
website www.arri.com.
CCT and RGBW
This mode provides control of intensity, color temperature, green-magenta point and individual channels
for controlling the red, green, blue and white color (only SkyPanel-C).
CCT
Simple white-only mode. It is used when the number of available channels of the controller is very limited.
It provides control of intensity, color temperature and green-magenta point.
CCT & HSI
Provides control of intensity, color temperature, green-magenta point, hue and saturation (HSI = hue, sat-
uration, intensity). In HSI mode (only SkyPanel-C) the color and intensity is very even over the fixtures as
it is controlled using color algorithms which take the tolerances of the light engines into account during cal-
culation.
RGBW
Simple mode for controlling the overall intensity and the red, green, blue and white intensity when only a
limited number of channels is available. Please find more information about the RGB color space on
page 16.
HSI
Simple mode for controlling hue, saturation and intensity when a limited number of channels is available.
GEL
The GEL mode offers an extensive color filter list. The color temperature has two settings, 3.200 K and
5.600 K. The intensity can be controlled as usual.
xy Coordinates
The xy mode determines the color displayed by its xy coordinates in the CIE 1931 diagram. Set the x and
y coordinate with 8 bit or 16 bit resolution. One channel determines the transition type when fading from
one color to another color.
Source Matching
Select from a list of light sources to match that color and spectrum. Source Matching saves a lot of time
when you need a specific illumination. Select from 50 different light sources the one which fits best to your
demands.

11
Fixture ModesFixture Modes
11
Light Effects
The SkyPanel contains a light effect engine with 13 different light effects. Activating a light effect is very
easy. Just activate a light effect via the fixture menu, DMX, Art-Net or sACN and set the parameters to get
exactly the effect you need.
Light Engine Control via DMX
The light engines of the SkyPanel can be controlled individually. The control modes CCT & RGBW, HSI
and X,Y coordinates apply to all light engines of a fixture, but you can set the corresponding parameters of
each light engine individually. The S30 has one light engine, the S60 has two, the S120 has four, and the
S360 has twelve light engines.
Ultimate DMX Mode
The ultimate DMX mode allows the combination of different control modes. You can select two modes and
fade between them. This allows you to quickly select, prepare and crossfade the most suitable control
modes for your application.
Extended color control
The extended color control allows to intuitively modify the current color. If extended color control is active,
eight parameters are added to each control mode (see “Extended Color Control” on page 12).
Depending on the selected mode the channels required for each SkyPanel should be allocated in
the controller to provide independent control of all SkyPanels connected to the controller.
NOTICE

Functions
12
Functions
To set the Lighting Parameters in CCT Mode
Set the color temperature continuously with the central rotary knob (5). Set the Green-Magenta point con-
tinuously with the right rotary knob (6). The current setting is displayed above the rotary knobs.
To set the Color in HSI Mode
Set the hue continuously with the central rotary knob (5). Set the saturation continuously with the right ro-
tary knob (6). The current setting is displayed above the rotary knobs.
To set the Lighting Parameters in GEL Mode
Use the central rotary knob (5) to set the color temperature 3.200 K or 5.600 K. The right rotary knob (6)
offers two options: „Best color“ displays the gel with optimized color quality, „Brightest“ displays the gel with
optimized brightness.
• Press I/S (4) to open the gel library. Choose the gel manufacturer (Rosco or LEE) with the central rotary
knob (5). Use the right rotary knob (6) to activate a gel category as shown in the table below.
• Turn I/S (4) to call up a gel from the gel set. Press I/S to select a gel or press BACK (11) to close the gel
set and set the intensity with I/S (4). Press I/S (4) again, to re-open the gel set.
To set the Light Source in Source Mode
Activate the source mode and press I/S to call up a list of the light sources available. Use the right rotary
knob (6) to select the category (please see „DMX protocol specification“, which is available for free down-
load for a detailed list). Turn I/S to select a light source. The SkyPanel calls up the selected light source in
real time. Press I/S to choose the selected light source.
To set the Color in RGBW Mode
The central rotary knob (5) has no function in RGBW mode. Use the right rotary knob (6) to select the func-
tionality of the encoder I/S (4). Dependent on the selection of the right rotary knob, I/S is used to set the
overall intensity of the red, green, blue and white color. Please note the setting „Direct Control“ or „RGBW
Color Space (see page 16). You can store the RGBW color as a preset.
To set the Color in X,Y Mode
The X,Y mode defines the color using its x,y coordinates. use the right rotary knob (6) to select the func-
tionality of the encoder I/S (4). Dependent on the selection of the right rotary knob, I/S is used to set the
intensity, the X or Y coordinate of the color. The range of both the X and Y coordinate is 0.0000 to 0.8000.
Extended Color Control
The extended color control allows the modification of the selected color in an intuitive way. It can be used
both via the control panel or DMX.
Rosco LEE
Color Correction Color Correction
CalColor Color Filters
Storaro Selection 600 Series
Cinelux Cosmetic
700 Series

13
FunctionsFunctions
13
To Use the Extended Color Control via DMX
The SkyPanel applies 8 additional channels to every DMX mode when the extended color control is acti-
vated vie the DMX settings menu. Please find more information in the „SkyPanel DMX Protocol Specifica-
tion V4.4“ which is available for free download on the ARRI web site www.arri.com.
To Use the Extended Color Control via the Control Panel
Press the MODE button for approximately 3 sec in the home screen to activate the extended color control.
If RGBW direct mode is active, the extended color control is not available. Please activate the calibrated
RGBW color mode ( see “Calibrated RGBW Color Space” on page 16) to be able to activate the extended
color control. If the extended color control is active, a short press of the MODE button switches between
the operation modes (see“To Set the Operation Mode” on page 9
If an effect is active, press the MODE button for at least 3 sec to switch between the color mode, the ex-
tended color control screen and the effect parameter screen.
The picture below shows the color control screen.
In the upper left and right corner of the display the active special and operation modes are displayed similar
to the home screen (in the picture above „HSI“ operation mode).
Each parameter available is shown as a slider. Neutral parameters are indicated with the solid horizontal
line at the middle of the bar. The horizontal bar of each slider indicates the value of each parameter. The
selected parameter is indicated by a small bar under its slider. The name of the parameter and its value is
shown under the sliders in the display.
From left to right, the bars in the extended color control screen stand for the following parameters:.
Select the parameter using the right rotary knob (6). Set the value of the parameter with the encoder I/S
(4). Please note:
• The resolution of the encoder adapts dynamically to the moving speed.
• Clockwise turn increments the value of the parameter.
• Counter-clockwise turn decrements the value of the parameter.
• Double press within 800 ms resets the selected parameter to neutral (0).
• Triple press within 1200 ms resets all parameters to neutral (0).
When changing the operation mode the current values of the parameters are stored and restored when
activating the operation mode the next time. After a power cycle, the SkyPanel extended color control pa-
rameters are restored for each operation mode.
Description Parameter Range
Color temperature Warmer / Cooler
-1.000 > 0.000 > +1.000
Saturation Saturate / Desaturate
Red portion of current color + Red / - Red
Green portion of current color + Green / - Green
Blue portion of current color + Blue / - Blue
Cyan portion of current color + Cyan / - Cyan
Magenta portion of current color + Magenta / - Magenta
Yellow portion of current color + Yellow / - Yellow
The extended color control is not available in LE DMX control modes.
NOTICE

Functions
14
With activated extended color control:
• A star next to the active operation mode indicates the activated extended color control,
• the parameters are stored with each preset. Presets which contain parameters of the extended color con-
trol are marked with a star,
• modifying an extended color control parameters leaves any active preset,
• the calibrated RGBW color space is activated by the SkyPanel when the extended color control is activat-
ed via DMX,
• the direct RGBW color space is not available,
• the parameters are applied both to the start and end point of a cross fading,
• the parameters are not applied to lighting effects.
To Set the Brightness in all Operating Modes
Set the brightness in both operating modes continuously with the encoder I/S (4). The setting is dynamic:
Turning the encoder fast changes the intensity in coarse steps, turning it slow changes the intensity in fine
steps.
To Set the Dimming Curve
The SkyPanel supports four dimming curves. The dimming curves are global: They affect both the intensity
control via the fixture menu or DMX, WDMX, Art-Net and sACN.
• Linear: The intensity changes proportional to the encoder I/S (4) or the channel value.
• Exponential: The resolution is high at lower intensity levels and low at higher intensity levels. Use this
dimming curve when you need a high resolution at low intensity levels. This is the default setting.
• Logarithmic: The resolution is low at lower intensity levels and high at higher intensity levels. Use this
dimming curve when you need a high resolution at high intensity levels.
• „S“ curve: The resolution is both high at lower and higher intensity levels and low at intensity levels in
between. Use this dimming curve, when you need a high resolution at low and high intensity levels.
To set the dimming curve
1.Press the MENU button (10) to open the fixture menu.
2.Turn I/S, until „Light Control“ is selected. Press I/S to open the menu.
3.Turn I/S, until „Dimming Curve“ is selected. Press I/S to open the menu.
4.Select the dimming curve by turning I/S. Press I/S to confirm the setting.
To Set a Special Control Mode
The SkyPanel supports four special control modes. The special control modes are global: They affect both
the intensity control via the fixture menu or DMX, WDMX, and Art-Net or sACN.
Stage Mode
Stage Mode is designed for live entertainment and theatrical performances which require completely
smooth dimming to zero without intensity drop offs. Some color changes may happen at very low dimming
levels.
Stage Mode is not designed for use with motion picture or broadcast cameras as flicker may occur.
Presets made in Firmware 4.0 or higher will not work on lower firmware versions.
NOTE
The dynamic of an effect using the intensity is very low, when you choose a basic intensity value in
a flat area of the dimming curve. Choose a different effect or select another dimming curve to create
a more dynamic effect.
NOTICE

15
FunctionsFunctions
15
Low End Mode
The Low End Mode optimizes the dimmer quality at low intensity levels and enables SkyPanel to generate
accurate CCTs with high color rendition and smooth dimming at very low light levels. The Low End Mode
can cause flickering when used with cameras shooting at high frame rates.
Tungsten Mode
Thetungsten Mode can mimic thedimmingcurve and strike on-and-offeffectof a traditional tungstenlamp.
The CCT warms as the light is dimmed and when the intensity drops to zero quickly there is a short after-
glow of warm light. This mode is perfect for mixing the SkyPanel with tungsten sources or for producing a
familiar effect.
High Speed Mode
The High Speed mode generates flicker-free light for High Speed shootings. High Speed Mode has been
tested up to 25.000 fps and down to 2° shutter angle with no flicker or roll bars. The intensity is fixed in High
Speed mode. The only settings are 0% (black out) or 100% (full intensity). In High Speed mode the settings
for low end mode, tungsten mode, effects and PWM frequencies are ignored.The operation modes CCT,
HSI and GEL are available in High Speed Mode. When modifying a parameter the SkyPanel performs a
short black-out when applying the new value. The operation modes SOURCE and RGBW are not available
in High Speed Mode.
To set a special control mode
1.Press the MENU button (10) to open the fixture menu.
2.Turn I/S, until „Light Control“ is selected. Press I/S to open the menu.
3.Turn I/S, until „Special Modes“ is selected. Press I/S to open the menu.
4.Select the special mode by turning I/S. Press I/S to confirm the setting.
5. Press MENU to close the menu.
Overview of the Special Control Modes
Control Mode Application Dimming behavior Flicker behavior
Stage Mode Live Audience Very good very low end
range Will most likely cause flicker
Low End Mode TV-Studio, Film Good in low end range Might cause flicker
Tungsten Mode Simulation of a tungsten
source Good through whole range Might cause flicker
Normal Mode (no special
control modes active) Normal dimming Good through whole range Unlikely to cause flicker
Highspeed Mode No dimming --- Flicker free
The stage mode can not be used with active low end mode and vice versa. The warning „Not Avail-
able: Low End Mode“ or „Not Available: Stage Mode“ will be displayed when you try to activate the
stage mode or low end mode if the other mode is active. You need to de-activate the other mode
before.
NOTICE
Effects are de-activated in High Speed mode. When you try to call up an effect in High Speed mode,
thewarning „Not Possible: HighSpeedActive“ is displayed.Whenyou try to activatethe High Speed
mode with an effect active, the warning „Not Possible: Effect Active“ is displayed. De-activate the
effect or the High Speed mode to change the control mode.
NOTICE

Functions
16
Master/Slave Mode
In Master/Slave mode the slave fixtures mimic the master fixture without delay. The master fixture gener-
ates a DMX signal on the 5-pin DMX Thru connector.
Connect a maximum of 32 SkyPanels and L-series fixtures to a DMX data link. Choose one SkyPanel to
be the master fixture.
To set the Master and Slave Fixtures
1.Press the MENU button (10) to open the fixture menu.
2.Turn I/S, until „Light Control“ is displayed. Press I/S to open the menu.
3.Turn I/S, until „Master/Slave Mode“ is displayed. Press I/S to open the menu.
4.Set all fixtures in the data link to „Off“ to de-activate master mode. Select „On“ on one fixture in the data
link to set the fixture as master fixture.
5.Press MENU to close the menu.
All fixtures in the data link will mimic the master fixture automatically and independent from their settings.
Please note when using the master/slave mode:
• Art-Net and sACN are de-activated on all fixtures in the data link.
• Changing the mode on the master fixture (CCT, HSI, GEL, Source Matching, RGBW) changes the mode
on all slave fixtures accordingly.
• Activating the extended color control on the master fixture activates the extended color control on slave
fixtures supporting extended color control.
• The settings DMX protocol version, DMX address, tungsten mode, low end mode, fans and signal loss
behavior are changed accordingly to the settings of the master fixture.
• Connect only C version fixtures of one type in a data link.
• L-series fixtures do not support the GEL mode.
• Presets are not available.
Calibrated RGBW Color Space
When using RGBW mode, the SkyPanel by default does not generate colors in a calibrated color space.
The color is generated with optimized brightness within the specified tolerances. You can activate the cal-
ibrated color space Kodak Pro Photo Color Gamut / ESTA standard E1.54 to force the SkyPanel to gener-
ate a calibrated color. The calibrated color space is a global setting and is active in both on-board controls
and DMX.
Use the right rotary knob (6) to adjust the portion of the red, green and blue color of the current color. Turn
the knob further to set the white point and green-magenta point of the current color.
To Activate and De-activate the Calibrated RGBW Color Space:
1.Press the MENU button (10) to open the fixture menu.
2.Turn I/S, until „Light Control“ is displayed. Press I/S to open the menu.
3.Turn I/S, until „RGBW Color Space“ is displayed. Press I/S to open the menu.
4.Select „Direct Control“ to generate colors with optimized intensity. Select „Calibrated Color“ to generate
a calibrated color.
5.Press MENU to close the menu.
Frequency Selection
Youcanchangethe frequency in the fixture menu. Change thefrequency,whenyourecognizeflickerwhen
in the camera picture or by your eyes. The default frequency is the highest frequency. You can change the
frequency in 10 steps. Frequency 1 is the highest frequency, while frequency 10 is the lowest frequency
setting.
There must not be more than one SkyPanel in the data link set to master.
Setting more than one fixture to master or connecting a DMX controller to the data link causes one
or all master fixtures to de-activate the master mode
NOTICE

17
FunctionsFunctions
17
To set the frequency
1.Press the MENU button (10) to open the fixture menu.
2.Turn I/S, until „Light Control“ is displayed. Press I/S to open the menu.
3.Turn I/S, until „Frequency Selection“ is displayed. Press I/S to open the menu.
4.Select a frequency. Press I/S to confirm the setting. The frequency is set immediately.
5. Press MENU to close the menu.
To set the Fan Mode
You can set the fan mode to adapt the cooling and noise level to the environment. The table below shows
the available options:
To set the fan Mode
1.Press the MENU button (10) to open the fixture menu.
2.Turn I/S, until „Fan Mode“ is displayed. Press I/S to open the menu.
3.Select the Fan mode by turning I/S. Press I/S to confirm the setting.
4.Press MENU to close the menu.
Lighting Effects
The SkyPanel offers an effect library with a wide variety of lighting effects used on set or in a TV studio.
The SkyPanel replaces many special effect devices with its unique effect library.
You can call up all effects using the fixture menu or via DMX, Art-Net or sACN. Every effect offers specific
parameters. A lighting effect can be stored in a preset slot for quick access at a later point.
To select and activate an effect
1.Press the MENU button (10) to open the fixture menu.
2.Turn I/S, until „Lighting Effects“ is displayed. Press I/S to open the menu.
3.Select the desired effect by turning I/S.
4.Press I/S to start the effect.
5.Set the parameters, as described below.
To stop an effect
1.Press the MENU button (10) to open the fixture menu.
2.Turn I/S, until „Lighting Effects“ is displayed. Press I/S to open the menu.
3.Select the option „Off“. Press I/S to confirm.
Start / Stop function of the effect
If an effect is running, press I/S to stop the effect execution. Press I/S again to restart the effect from the
beginning. While stopped, the SkyPanel performs a black out and a P:<Effect> shows the status in the dis-
play. The start / stop function is only available in the effects control screen.
The SkyPanel provides the following effects in DMX modes 22 (8 bit) and 23 (16 bit):
Party
The Party effect calls up the color spectrum or changes the color temperature from warm to cold and vice versa in an
endless loop.
Parameters:
• Saturation
• Speed
If you do not need the effect for shooting, you will need it for the party when the movie is done!
Fan Mode Max. power
(only S360-C) Description
Normal (only S360-C) 1500 W The fans operate temperature regulated.
Quiet Mode 1200 W The fans operate constantly at low speed
(silent).
Variable 1200 W The fans operate temperature regulated.
High Temp 1200 W The fans run at maximum speed.

Functions
18
Candle
Low flickering of a warm light, slower than fire and less energetic. The light gentle fades in CCT and bright-
ness with periods of static behavior in between. It consists of „flutters“ and static periods.
Parameters:
• CCT range
• Speed
Clouds Passing
Slow variations in intensity and CCT that can be offset. The effect is most useful when using many Sky-
Panels that are offset to prevent a simultaneous effect on different fixtures.
Parameters:
• Offset
• Passing speed
• Sync
Club Lights
Random colors that pulse, flash and fade.
Parameters:
• Color variety
• Speed
• Sync
Color Chase
Creates a color chasing effect over the surface of the SkyPanel using multiple LED light engines.
Parameters:
• Saturation
• Speed
• Offset
• Sync
Cop Car
Creates an on-board blue and red flashing effect to mimic a police car, an ambulance or a fire brigade. Do
not use the effect in public areas without permission.
Parameters
• Color combination
• Flash pattern
Explosion
A bright flash of light with a fast attack and a semi-slow decay.
Parameters:
• Trigger
• Decay
Fire
Creates a flickering fire effect.
Parameters:
• CCT range
• Flicker speed
Fireworks
Bright flashes of color and have a quick start and fade to zero intensity.
Parameters:
• Color combination
• Speed

19
FunctionsFunctions
19
Fluorescent Flicker
Fluorescent color with static periods and then periods of the light flickering on and off.
Parameters:
• Speed
• Frequency
Light Strobe
Generates a white or colored strobe effect with adjustable speed from 25 flashes / sec to 1 flash / sec.
Parameters:
• CCT
• Green-Magenta point
• Cross fade
• Saturation
• Flash speed
Lightning
Creates an on-board flashing lightning effect. Intensity, speed and frequency of flashing can be controlled.
Parameters:
• CCT
• Green-Magenta point
• Speed
• Frequency
• Sync
Paparazzi
Effect that mimics a flash bulb or modern camera flash.
Parameters:
• CCT
• Flash type
• Frequency
Process
Fading on and off of white light that moves from one light engine to the next.
Parameters:
• Speed
• Direction
DANGER
DANGER! Risk of injury or death through epileptic seizure.
Do not use the effect near stairways, in corridors or near public exits.
Provide advance notice that strobe lighting is in use. Display advisory notices on the set, at the point
of ticket sales, on tickets if possible, in the program, and at the entrance(s) to the venue or studio.
Avoid extended periods of continuous flashing, particularly at frequencies of 10 to 20 flashes per
second. At flash rates below 5 flashes per second, it is estimated that only 5% of flicker-sensitive
persons will be at risk of seizure
Make sure that personnel at the venue are trained in the care of a person who is having an epileptic
seizure and able to provide care if necessary.
If strobes are in use and a person has a seizure, switch the strobes off immediately.
Mount strobes as high above head height as practicable.

Functions
20
Pulsing
A pulsing or throbbing effect where the color and speed can be set.
Parameters:
• CCT
• Green-Magenta point
• Cross fade
• Color
• Saturation
• Frequency
• Span
Television
Creates an on-board TV effect. Cool CCT that changes intensity every few seconds.
Parameters:
• CCT range
• Speed
Welding
Quick bright flashes on different light engines with a fast decay.
Parameters:
• Speed
• Minimum brightness
To Activate and set Effect Parameters with the Fixture Menu
The rotary knobs adjust the effect parameters when an effect is active. For all effects applies:
• The selected effect is displayed in the left top corner of the display.
• Intensity / Selector adjusts the intensity.
• Press I/S to stop the effect (black out).
• Press I/S again to restart the effect.
• Press MODE long (> 1 sec) to activate the parameters described below (column „Mode“, not available for
all effects).
• Press MODE again to close the effect control and regain normal control.
