Assa Abloy DC3210 Series User manual

80-9330-3005-152 04/18
Installation Instructions
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Corbin Russwin, Inc. is prohibited.
DC3210 Series
Important
• An improperly installed or incorrectly adjusted door closer may cause property damage or personal injury; and will void
product warranty.
• To avoid personal injury, DO NOT DISASSEMBLE THIS DOOR CLOSER BODY.
• Door closers must be securely fastened to a properly reinforced door and frame with fasteners provided.
• Door closers with a HOLD OPEN ARM are not permitted to be installed in fire door assemblies.
• Door and frame must be specifically templated for 85°, 90°, 95°, 100°, 105° orb 110° door swing.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
A2 Hold Open without Backstop
A4 Non-Hold Open with Backstop
A5 Hold Open with Backstop
Heavy Duty Parallel Arm

2
80-9330-3005-152 04/18
DC3210 Series Closer
Installation Instructions
A2, A4 or A5 Heavy Duty Parallel Arm
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Corbin Russwin, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
**NOTE: These forces are for standard templating with bearing type
hinges and do not account for pressure differentials and draft.
Size of Door & Door Closer
Type of
Installation Interior Exterior In-swinging
Exterior
Out-swinging
Recommended
Closer Size
**Max. Opening
Force lbs/f
Parallel Arm
2' 4" - - 1 8
2' 6" - - 2 14
3' 0" - 2' 6" 3 16
3' 6" - 3' 0" 4 22
4' 0" - 3' 6" 5 24
4' 6" - 4' 0" 6 26
TO DETERMINE
HAND OF
YOUR DOOR:
LEFT
HAND
DOOR
RIGHT
HAND
DOOR
RHR LHR
1 Introduction
L
3/8
(10)
1/4-20 THREAD
Drill thru 9/32 (7.1) Enlarge to
3/8
(9.5) Dia. This Side Only
(4 Places)
DOOR
THICKNESS
SEX NUT
LENGTH “L”
1-3/8" (35mm)
1--3/4" (44mm)
&OVER
1-9/32" (33mm)
1-21/32" (42mm)
MOUNTINGSCREW SPECIFICATIONS
ARM AND CLOSER BRACKET
}
or{Option M54:
Sex nuts, furnished
when ordered
1/4-20 oval head machine
screw or 1/4-14 self-drilling
screw Type BSD. 3/16 (4.8)
diameter pilot hole required
forWood Applications.
L
3/8
(10)
1/4-20 THREAD
Drill thru 9/32 (7.1) Enlarge to
3/8 (9.5) Dia. This Side Only
(4 Places)
DOOR
THICKNESS
SEX NUT
LENGTH “L”
1-3/8" (35mm)
1--3/4" (44mm)
&OVER
1-9/32" (33mm)
1-21/32" (42mm)
MOUNTINGSCREW SPECIFICATIONS
ARM AND CLOSER BRACKET
}
or{Option M54:
Sex nuts,
furnished
when ordered
1/4-20 oval head machine
screw or 1/4-14 self-drilling
screw Type BSD. 3/16 (4.8)
diameter pilot hole required
forWood Applications.
Figure 1
A4 Arm
Non-Hold Open withBackstop
A5 Arm
A2 Arm
Hold Open with Backstop
*This application requires an
auxiliary door stop “byothers”
Hold Open Only
(NoStopFeature)

3
80-9330-3005-152 04/18
DC3210 Series Closer
A2, A4 or A5 Heavy Duty Parallel Arm
Installation Instructions
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Corbin Russwin, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
2 Installation
1. Template
Mark and prepare door and jamb (for closer
bracket and arm bracket). Use template and
dimensions charted. (Figure 2)
NOTES:
• Check hand of door. (Figure 1)
• Right Hand Application Shown,
Left Hand Opposite
• Dimensions given in inches (mm).
Do Not Scale Drawing.
• Closer must be installed in a true
horizontal plane to ensure proper closer
performance.
Figure 2
Opening
Maximum DIM. A DIM. B DIM. C Minimum
85° 13-3/4"
(349)
12-9/16"
(319)
28-3/4"
(730)
90° 12-13/16"
(325)
11-5/8"
(295)
27-7/8"
(708)
100° 11-1/4"
(286)
10-1/16
(256)
26-1/4"
(667)
110° 9-15/16"
(252)
8-3/4"
(222)
25"
(635)
5/8
(16)
2-5/8
(60)
FRAME STOP
TOPOF DOOR
C
L
HINGE
OR
PIVOT
DOOR
FRAME STOP
2-3/4
(70) 5/8
(16)
1-1/2
(38.1)
1/4
(6.35)
CLOSER
BRACKET
1
(25.4) 4-5/16
(109.5)
B
A
C
TYP.
15/16
(23.8)
3/4
(19) 1-3/8
(35)
Minimum Clearance
2
(50.8)
2
(50.8)
2
(50.8)
1
(25.4)
1-1/2
(38.1)
SEE MOUNTING SCREW
SPECIFICATIONS
NOTE: ANGLE SUPPORT MUST BE
DRILLED AND TAPPED IN THE FIELD
447F14 DOOR
FRAME
M85OPTION 447F14
ANGLE SUPPORT BRACKET
5/8
(16)
REF.
DOOR
FRAME
ARM
BRACKET
SPACER BLOCK
(When required)

4
80-9330-3005-152 04/18
DC3210 Series Closer
Installation Instructions
A2, A4 or A5 Heavy Duty Parallel Arm
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Corbin Russwin, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Pin Hole End
Countersunk Holes
Holding Pins
1/4-20 x 1/2 OHMS (2)
2 Installation
2. Install Closer Bracket. (Figure 3)
Figure 3
3. Mount Closer Body to Closer Bracket.
(Figure 4)
4. A4 & A5 Backstop Arms Only Arms
shipped for Left Hand Door. To change
handing: (Figure 5)
Remove Stop from Soffit with 5/32 Allen
Wrench. Remove Filler Plug. Switch Stop and
Filler Plug to opposite sides. Insert Stop and
tighten. Push Filler Plug into hole.
Figure 4
Figure 5
ST
OP
FILLER
PLUG
LH RH
SOFFIT

5
80-9330-3005-152 04/18
DC3210 Series Closer
A2, A4 or A5 Heavy Duty Parallel Arm
Installation Instructions
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Corbin Russwin, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Pin Hole End
Countersunk Holes
Holding Pins
1/4-20 x 1/2 OHMS (2)
Figure 6
2 Installation
5. Mount Arm to Door Frame.
(Figure 6)
6. Connect Arm To Closer. (Figure 7)
Using hex wrench provided, close (turn
clockwise) CLOSING SPEED VALVE (see
page 5 for location on closer). DO NOT
OVER TIGHTEN.
• Open door to approximately 60°.
• Using wrench on underside of spindle,
rotate spindle approximately 135° toward
hinge edge of door.
• Install arm on spindle at an approximate 90°
angle to door.
• Reopen CLOSING SPEED VALVE.
• Install and tighten arm washer and screw.
DOOR
SPINDLE
ARM
CENTERLINE
60°
DOOR
135°
WRENCH
90°
ARM
ALL ANGLES SHOWN ARE APPROXIMATE
DOOR
90°
SPINDLE
ROTATED 135°
Rotate 135°
SPINDLEAT REST
Figure 7

6
80-9330-3005-152 04/18
DC3210 Series Closer
Installation Instructions
A2, A4 or A5 Heavy Duty Parallel Arm
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Corbin Russwin, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
3 Adjustments
Adjustments (Figure 8)
(3/32 Allen Wrench Provided)
Closing Speed Valve (Figure 9)
To adjust speed of door closing from fully
open to a position 2 to 5" from closed, turn
Closing Speed Valve CLOCKWISE to SLOW
closing, COUNTER-CLOCKWISE to SPEED
closing.
Latching Speed Valve (Figure 10)
After closing speed has been obtained, turn
latching speed valve CLOCKWISE to SLOW
latching or COUNTER-CLOCKWISE to SPEED
latching for last 2" to 5" of door travel.
NOTE: Set combination of CLOSING and
LATCHING speeds to between 3 and 7
seconds. Use of door by handicapped,
elderly or small children, may require
even greater closing time.
Backcheck Intensity Valve (Figure 9)
Turn valve COUNTER- CLOCKWISE to reduce
backcheck or CLOCKWISE to increase
backcheck. (Backcheck should be set to give
a soft cushioning action, not a sudden stop).
Delayed Action Valve (Figure 9)
Turn valve CLOCKWISE to SLOW closing,
COUNTER-CLOCKWISE to SPEED closing.
Delayed action may be adjusted from 20
seconds to 90 seconds, depending on degree
of door swing. Delay occurs at the beginning
of the door closing cycle from fully open down
to 70°, where the closing speed valve then
begins its control.
Hold Open Operation (Figure 11)
(A2 and A5 Arms only)
A quarter turn of the tee handle in either
direction engages or disengages the hold
open feature.
Delayed Action
Option
M-71
Backcheck
Latch
Sweep
LATCHING
SPEED
VA LV E
Power
Size
Stamp
Date Stamp
BACKCHECK
INTENSITY VALVE
OPTION M71
DELAYED
ACTION VALVE
CLOSING
SPEED VALVE
SPRING POWER ADJUSTER
(5/16" WRENCH or SOCKET)
(FLAT TIP SCREWDRIVER)
Figure 8
Figure 9
Figure 10
Figure 11

7
80-9330-3005-152 04/18
DC3210 Series Closer
A2, A4 or A5 Heavy Duty Parallel Arm
Installation Instructions
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Corbin Russwin, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
3 Adjustments
Adjust Spring Power According to Chart
DC3200 Size 1-6 Adjustment (Figure 12)
• All DC3200 closers are factory set at an
approximate Size 3.
Full Cover(Standard)
Slim Cover (Option M76)
Figure 12
Figure 13
Size of Door No. of Full (360°)
Turns Clockwise of
Power Adjuster
Equivalent Closer
Size (Approx.)
Interior Exterior
In-Swinging
Exterior
Out-Swinging
2' 4"
(712)
2' 6"
(764) - 4 2
2' 6"
(764)
3' 0"
(915) - 8 3
3' 0"
(915)
3' 6"
(1067)
2' 6"
(764) 12 4
3' 6"
(1067)
4' 0"
(1219)
3' 0"
(915) 16 5
Figure 14
4 Cover Installation
Full Cover(Standard)
Slim Cover (Option M76)
Install Cover (Figure 13)
Slip cover over closer. Hold tightly against
closer mounting surface. Secure on each
side with 6-32 x 1/4 PBHMS screws.
Slim Cover Option M76 only (Figure 14)
Position spindle cap over unused spindle
and secure with truss head screw.
• Adjust closer as necessary for door size
using this chart.
• Readjustment may be required to suit
prevailing conditions.
