To Begin Programming:
The Lock Controller is preset at the factory with Master Code 1234.
Entering 1234 *will unlock the lock allowing the lever handle to retract the latchbolt.
Note: The Master Code must be changed (i.e., "Forced Change") prior to adding users.
Initial Set-Up Procedures
• The following are typical procedures to be used when setting up your Profile Series LK lock:
• If a mistake is made during any of the procedures, depress the “*” key several times until the yellow LED goes out
• If no keystroke is made in a 30 sec. timeframe, the programming up to that point will default and you will have
to start over
The LK Keypad Lock can support 100 users.
Each user is assigned a User Number in addition to the code used for entry.
Keypad Programming Instructions for t e Profile Series LK

Copyright © SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written per ission of SARGENT Manufacturing is prohibited.
2800-810-WIRE (9473) www.sargentlock.com A7857A
Keypad Programming Instructions for t e Profile Series LK Lock
LK Programming (100 Users)
To determine programming steps for your lock:
• If your controller has an LK label,, use the programming below.
• If your controller has a " 1.5" label and a keypad, refer to Section 3;
• If your controller has a " 1.5" label and no keypad refer to Section 4.
• If your label has a 1-LU, 1-PK, 1-PA, 1-TU, 1-TP or 1-TA; refer to
Keypad Programming Instructions A7716 at www.sargentlock.com
Change the Master Code
99# 1234* Yellow LED blinks
50# 1# Yellow LED blinks
New Master Code* Yellow LED blinks quickly
New Master Code* Yellow LED blinks slowly
* Yellow LED goes out (If solid, see note)
This example uses the Factory Default 1234*
It is recommended not to use the factory default master code.
To Enter the Emergency Code
99# Master Code* Yellow LED blinks
50# 02# Yellow LED blinks
Emergency (1-6 digits)* Yellow LED blinks quickly
Emergency (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Emergency Code defaults to a 10 second unlock time and will override a thrown deadbolt on a mortise lock.
To Enter or Change the Supervisor Code
99# Master Code* Yellow LED blinks
50# 1# 03# Yellow LED blinks
Supervisory (1-6 digits)* Yellow LED blinks quickly
Supervisory (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Enter A User Code
99# Master Code* or Supervisory Code* Yellow LED blinks
50# 1# (User Number 04-100)# Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Enter A Passage (Maintained) Code
99# Master Code* Yellow LED blinks
50# 0# (User Number 04-100)# Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Enter a Lock Out User Code
99# Master Code* Yellow LED blinks
50# 3# (User Number 04-100)# Yellow LED blinks
User Code* Yellow LED blinks quickly
User Code* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
The “Lock Out” user is location dependent— all users above the chosen user number location are locked out of the
keypad. To ensure that all users except Master, Supervisor and Emergency are locked out, program this user at
user number location “04”.
-
+
-
+
-
+
-
+
+
-
+
-LK
1

Copyright © SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written per ission of SARGENT Manufacturing is prohibited.
3
A7857A 800-810-WIRE (9473) www.sargentlock.com
Door Name 5666
Seq User Trans
0 001 —
1 003 —
2 003 —
3 020 —
4 003 —
Transaction
number
Transaction
type
User
number
Door
name
Varies
Keypad Programming Instructions for t e Profile Series LK Lock
Hold an infrared printer up to the infrared LED (as
shown). An HP82240B Infrared Printer can be used to
download information from the keypad to a printout.
For additional information, see “Transaction Log”.
To LED
location Infrared
printer
(52-2069)
Note: Seq. # 0 is the
programming request
to output the entries.
Sequence numbers
1-9 are the actual
entries.
Enter A One Time User Code
99# Master Code* or Supervisory Code* Yellow LED blinks
50# 5# (User Number 04-100)# Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly
(If solid, see note)
* Yellow LED goes out
To Deactivate/Reactivate “Beep” With Key Stroke
99# Supervisory or Master Code* Yellow LED blinks
30# 0# 0# (Off) (1# = On) Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Note: If turning beep off, not audible on last two steps.
Reset Master Code back to factory default (1234) and retains all other User codes
99# Master Code* Yellow LED blinks
40# 00000# 00000# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks very fast for 10 sec., then slow
* Yellow LED goes out
If the Master Code is not known, factory assistance will be required. Call 1-800-810-9473.
To Clear the Entire Memory
99# Master Code* Yellow LED blinks
46# 00000# 00000# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED goes solid and begins to blink
* Yellow LED goes out (If solid, see note)
This deletes ALL Codes, including Master, Emergency and Supervisory. The Master Code is set back to 1234*,
Sets Unlock Time to 5 seconds. If the Master Code is not known, factory assistance will be required to clear the
memory. Call 1-800-810-9473.
To Program Door Name into Keypad
99# Master Code* Yellow LED blinks
43# Door Name (up to 5 digits)# Yellow LED blinks
0# Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
To Interrogate Transaction Log
99# Supervisory or Master Code* Yellow LED blinks
70# 0# 0# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED goes out (If solid, see note)
When done printing, the green LED will turn off and the yellow LED will blink slowly.
* Yellow LED goes out

Copyright © SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written per ission of SARGENT Manufacturing is prohibited.
4800-810-WIRE (9473) www.sargentlock.com A7857A
Keypad Programming Instructions for t e Profile Series LK Lock
To Reset/Clear Transaction Log
99# Master Code* Yellow LED blinks
76# 00000# 00000# Yellow LED blinks
*Yellow LED blinks quickly
* Yellow LED blinks slowly
* Yellow LED goes out (If solid, see note)
To Delete A User
99# Master Code* Yellow LED blinks
50# 1# (User Number 04-100)# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
To Enable/Disable A User
99# Master Code* Yellow LED blinks
56# 0# (Enable) or 1# (Disable)
(User No. 04-100)# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
To Set Unlock Time
99# Master Code* Yellow LED blinks
11# (1-99 sec)# 0# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
The Unlock Time is adjustable for Momentary Operation. A 5 second unlock time is recommended to extend
battery life. Once the unlock time is entered, it is the same for ALL users except 02.
Status Indicators
No reen LED after code is entered once, but flashes after 3 consecutive entries- Invalid Code
4 Long beeps after code is entered - Low Battery.
4 long beeps after code is entered, 4 more long beeps - Voltage (batteries) too low to operate
Enter Emergency Code to gain 1 entry.
To output the last 15 transactions, enter 99# Supervisory or
Master Code *70 # 0 # 0 # **.
• Examples on this page are for
the 100 user, 15 transaction unit
Note: Seq. # 0 is the programming
request to output the entries.
Sequence numbers 1-9 are
the actual entries.
-
+
-
+
-
+
-
+
+
-
+
-LK
-
+
-
+
-
+
-
+
+
-
+
-LU PK
-
+
-
+
-
+
-
+
+
-
+
-
Transaction Log (LK Only)
2
Door Name 5666
Seq User Trans
0 001 —
1 003 —
2 003 —
3 020 —
4 003 —
Transaction
number
Transaction
type
User
number
Door
name
Varies

Copyright © SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written per ission of SARGENT Manufacturing is prohibited.
5
A7857A 800-810-WIRE (9473) www.sargentlock.com
G1-LU, G1-PK, G1-TU and G1-TP Programming (2000 Users)
Important
Profile Series v. 1.5 controllers replace v. 1 controllers. Product is still ordered as “ 1-” prefix. Controllers are
labeled “ 1.5”.
• The Keypad Lock can support 2000 users. Each user is assigned a User Number in addition to the code used
for entry.
• SofLink™ Plus applications software must be used with PA & TA (no keypad) controller for programming
• The Master Code is always User “01”. The Master Code assigns the Emergency and Supervisory Codes and is
also used for programming. Users are deleted through the Master Programming Code only.
• Emergency code is a 10 second unlock time and will override a thrown deadbolt on a mortise lock
• v. 1.5 locks allow multiple Supervisory users, the *default Supervisory Code is User “02”. Additional
Supervisory users can be entered starting with User Number "03". The Supervisory Code allows temporary
lock out of selected users, changes duration of unlock time, requests infrared interrogation output, and may
add additional User Codes
• The User Codes are entered at user number “03” or higher. User numbers do not have to be used or entered
sequentially.
Note: All User Codes must be followed by an asterisk ( * )
• The “Lock Out” user is location dependent - all users above the chosen user number location are locked out of
the keypad. To ensure that all users except Master, Supervisor, Emergency and Panic are locked out, program
this user at user number location "03".
• The “Passage” user has precedence over all users except the “Panic” user. The lock must be toggled back into
a locked state for other users to function.
To Begin Programming
The Lock Controller is preset at the factory with Master Code “1234”.
Entering 1234 * will unlock the lock allowing the lever handle to retract the latchbolt.
Note: The Master Code must be changed (i.e., "Forced Change") from the factory default “1234” prior to adding users.
Initial Set-Up Procedures
The following are typical procedures to be used when setting up your Profile Series v. 1.5 lock:
• If a mistake is made during any of the procedures, depress the “*” key several times until the yellow LED goes out
• If no keystroke is made in a 30 sec. timeframe, the programming up to that point will default and you will have
to start over
Keypad Programming Instructions for t e Profile Series LK/v.G1.5 Lock
Sequence Number
• Single digit - 0-9
• Latest transaction - 0
• Oldest transaction - 9
User Number
• Three digits - 001 through 099
• User numbers assigned at time of programming
Transaction Descriptions
• Will vary
Optional Equipment
• Printer Paper (6 Rolls) - 52-0034 used for infrared
printers
• Infrared Printer - 52-2069 - used to download the
user and transaction type.
• Remote Unlocking - 52-3010 - used for remote
unlocking of Profile mortise lock. When the deadbolt
is thrown and the remote unlocking feature is used,
both the latchbolt and deadbolt can be retracted by
turning the lever handle.
To LED
location Infrared
printer
(52-2069)
Hold an infrared printer up to the infrared
LED (as shown). An HP82240B Infrared
Printer can be used to download information
from the keypad to a printout.
3

Keypad Programming Instructions for t e Profile Series v.G1.5 Lock
To determine programming steps for your lock:
If your controller has a “ 1.5” label with keypad, use the programming below; if no keypad,
refer to Section 4. If your controller has an LK label, turn to LK programming in Section 1.
For RF Technology products ( 1-TU, 1-TP, 1-TA), please take note of the following advisories:
Advisory 1: There is a time delay period between initially depressing the RF FOB button and the actuation of the
lock. In some cases, the RF FOB will have to be depressed (and held for 3 seconds) multiple times to successfully
actuate the lock.
Advisory 2: In the event that there are co-located RF Technology locks using individual RF FOBs that are depressed
simultaneously, the locks may not actuate due to cross interference between the locks and the RF FOBs. The
“User” should repeatedly depress (and hold for 3 seconds) the RF FOB button until actuation of the lock occurs.
Change the Master Code
99# 1234* Yellow LED blinks
50# 1# 1# Yellow LED blinks
New Master Code* Yellow LED blinks quickly
New Master Code* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
This example uses the Factory Default 1234*
Note: The aster Code must be changed (i.e., "Forced Change") prior to adding any other users.
Change the Supervisor Code
99# Master Code* Yellow LED blinks
50# 1# 2# Yellow LED blinks
Supervisor Code (1-6 Digits)* Yellow LED blinks quickly
Supervisor Code (1-6 Digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Add a Supervisory Code
99# Master Code* Yellow LED blinks
50# 10 # User Number 03-2000)# Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Enter A User Code
99# Master Code* Yellow LED blinks
50# 1# (User Number 03-2000)# Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Enter A Panic User Code
99# Master Code* Yellow LED blinks
50# 9# (User Number 03-2000)# Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Enter A Passage (Maintained) Code
99# Master Code* Yellow LED blinks
50# 0# (User Number 03-2000) # Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Note: The “Passage” user has precedence over all users except the “Panic” user. The lock must toggle
back into a locked state for other users to function.
-
+
-
+
-
+
-
+
+
-
+
-LK
-
+
-
+
-
+
-
+
+
-
+
-
LUPK
-
+
-
+
-
+
-
+
+
-
+
-

Copyright © SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written per ission of SARGENT Manufacturing is prohibited.
7
A7857A 800-810-WIRE (9473) www.sargentlock.com
To Enter the Emergency Code
99# Master Code* Yellow LED blinks
50# 7# (User Number 03-2000)# Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Enter a Lock Out User Code
99# Master Code* Yellow LED blinks
50# 3# (User Number 03-2000)# Yellow LED blinks
User Code* Yellow LED blinks quickly
User Code* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Note: The "lock out" user is location dependent. To ensure that all users are locked out of the keypad,
program this user at "user location" #4.
Enter A One Time User Code
99# Master Code* Yellow LED blinks
50# 5# (User Number 03-2000)# Yellow LED blinks
User Code (1-6 Digits)* Yellow LED blinks quickly
User Code (1-6 Digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Enter An Extended Unlock User Code
99# Master Code* Yellow LED blinks
50# 4# (User Number 03-2000)# Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Enter a Card, Tag, Fob and RF Fob User
99# Master Code* Yellow LED blinks
50# Yellow LED blinks
(Select only one number below, end it with a #, ie 4#)
0= Passage Code; 1= Standard User; 3= Lockout Code; 4= Extended Unlock User; 5= One Time User; 7= Emergency
Code; 8= Communications Enable; 9= Panic User (Yellow LED blinks)
(User Number 03-2000)# Yellow LED blinks
* Yellow LED blinks Quickly
* Yellow LED blinks Slowly (if Solid See Note)
Present Card, Tag or RF Fob Beep / Yellow LED blinks
* Yellow LED blinks Slowly
* Yellow LED oes Out
Enter a User Code + Card, Tag, FOB and RF Fob
99# Master Code* Yellow LED blinks
50# 1# (User Number 03-2000)# Yellow LED blinks
User Code (1-6 digits)* Yellow LED blinks quickly
User Code (1-6 digits)* Yellow LED blinks slowly (If solid, see note)
Present Card, Tag, Fob or RF Fob BEEP / Yellow LED blinks
* Yellow LED blinks slowly
* Yellow LED goes out
To Activate The RF FOB Function
Note: Press the button on the RF FOB. If the controller beeps and LEDs flash, this procedure does not have
to be done. RF enabled will shorten the battery life of the unit.
Press the reset button located in the battery compartment and any front key at the same time for 1 second, then
release buttons.
Yellow LED blinks slowly
Enter code 1030# Yellow LED blinks slowly
1# Yellow LED blinks slowly
1# Or (0# to disable The RF Function) Yellow LED blinks slowly
* Yellow LED blinks faster
* Yellow LED blinks slowly
* Yellow LED out
Keypad Programming Instructions for t e Profile Series v.G1.5 Lock

Copyright © SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written per ission of SARGENT Manufacturing is prohibited.
8800-810-WIRE (9473) www.sargentlock.com A7857A
Keypad Programming Instructions for t e Profile Series v.G1.5 Lock
Reset Master Code back to factory default (1234) and retain all other User codes
99# Master Code* Yellow LED blinks
40# 00000# 00000# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks very fast for 10 sec., then slow
* Yellow LED goes out
Note: The factory default Master Code (1234) must be changed (i.e., “Forced Change”) prior to adding any other users.
To Clear the Entire Memory (Master Code defaults to 1234)
99# Master Code* Yellow LED blinks
46# 00000# 00000# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks very fast for 10 sec., then slow
* Yellow LED goes out
This deletes ALL Codes, including Master, Emergency and Supervisory. The Master Code is set back to 1234*
Sets Unlock Time to 5 seconds. If the Master Code is not known, factory assistance will be required to clear the
memory. Call 1-800-810-9473.
Note: The factory default Master Code (1234) must be changed (i.e., “Forced Change”) prior to adding any other users.
Turn OFF Audio Beep verification on every Key Depression
99# Master Code* Yellow LED blinks
30# 0# 0# (Off) (1# = On) Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Turn ON ellow LED verification on every Key Depression
99# Master Code* Yellow LED blinks
30# 1# 1# (On) (0# = Off) Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Set Time
99# Master Code* Yellow LED blinks
41# hh:mm# (24hr Format) 0# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
24Hr Format = 1PM = 13, 2PM = 14.......10PM = 22, Midnight = 00 Example 13:15 = 1:15P
Daylight Savings Time
99# Master Code* Yellow LED blinks
30# 13# 1# (On) (0# = Off) Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Set Date (Today’s Date)
99# Master Code* Yellow LED blinks
42# mmddyy# D.O.W.# (Sunday=1) Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
D.O.W. = Day of week
Set Unlock Time
99# Master Code* Yellow LED blinks
11# (1-99 sec.)# 0# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
The Unlock Time is adjustable for momentary operation. A 5 second unlock time is recommended to extend
battery life. Once the unlock time is entered, it is the same for ALL users except 02.

Copyright © SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written per ission of SARGENT Manufacturing is prohibited.
9
A7857A 800-810-WIRE (9473) www.sargentlock.com
G1-PA & G1-TA Programming
Important
Profile Series v. 1.5 controllers replace v. 1 controllers. Product is still ordered as “ 1-” prefix.
Controllers are labeled “ 1.5”.
To determine programming steps for your lock:
If your controller has a 1.5 label and no keypad (proximity only),
then use the programming below.
In a Prox Only (PA) or RF Technology & Prox (TA) configuration, all programming
must be completed using SofLink™ Plus Software. The Software includes a con-
venient Software User’s Manual (A7771), to be used as
a programming guide.
Reprogramming
Note 1: With a proximity card, fob, tag or RF Fob Card selected as a "CommEnable" User, presenting the "CommEnable"
card to the lock will initiate communications after performing Step 2 (above) without the need to press the
CommEnable button.
Note 2: After performing "first time programming" procedure,
create a CommEnable card to facilitate
communications from then on.
PDA Response: "Please enter your
communications code at the door"
The PDA will be in transferrin
(0-100%) of the door data to the lock.
-
+
-
+
-
+
-
+
+
-
+
-G1.5 - PA
Comm Enable
Push Button
4
To pro ram the lock for the first time (only), the followin steps are required.
1. Using SofLink Plus software, Hotsync door information to PDA.
2. On PDA - select “Imp/Exp”
“Do NOT click OK at this point”
3. Wake up the PA or TA lock by presenting an HID Credential (or by
depressing an RF Fob).
4. Within a couple of seconds, press and hold the PA or TA controller
CommEnable push button (below batteries) for 2 seconds, then release
the button.
5. On the PDA, click “OK”.
6. If there was an error, check connections and repeat process starting at Step 2.
Note: *The Card will NOT actuate the lock for 45 seconds from the start of the
downloading process. After this time expires, the card will function as defined by
its User Type.
Lock Response: Audible beep
Keypad Programming Instructions for t e Profile Series v.G1.5 Lock
To Enable/Disable A User
99# Master Code* Yellow LED blinks
56# 0# (Enable) or 1# (Disable)
(User Number 03-2000)# Yellow LED blinks
* Yellow LED blinks quickly
*Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
To Delete A User
99# Master Code* Yellow LED blinks
50# 1# (User Number 04-2000)# Yellow LED blinks
* Yellow LED blinks quickly
* Yellow LED blinks slowly (If solid, see note)
* Yellow LED goes out
Status Indicators
3 very rapid beeps after User Code entered - Invalid User Code
4 long beeps after User Code entered - Low Battery Indication
4 long beeps after User Code entered, 4 more long beeps - Voltage too low to operate. Enter aster or Emergency Code
to gain 1 entry
1 beep after User Code entered - Disabled user
4 beeps after User Code entered - Deadbolt thrown
3 beeps after User Code entered - User lockout
Alternating red/green LED — Awaiting second entry of Code/Card, Tag or Fob user

Copyright © SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written per ission of SARGENT Manufacturing is prohibited.
10 800-810-WIRE (9473) www.sargentlock.com A7857A
Keypad Programming Instructions for t e Profile Series LK/v.G1.5 Lock
Using Master Code 4732 and above information, the lock would be programmed as follows:
99# 4732* 50# 1# 05# 875* 875* 3# 12# 2226* 2226* 2# 08# 5444* 5444* 1# 50# 3367* 3367*
If all user codes are type 1, it is not necessary to enter the type number with each entry.
The format now simplifies to:
99# Master or Supervisor Code* User Number a# User code a* User Code a* UNb# UCb* UCb* UNc# UCc*
UCc*....... UN_# UC_* UC_**
An example with three user codes is shown below:
Using Master Code 45988 and above information, the lock would be programmed as follows:
99# 45988* 07# 77* 77* 15# 67832* 67832* 91# 7568* 7568**
To chain the User Number delete procedure:
99# Master Code* User Number a#** UNb#** UNc#**....... UN_#****
Using the information from the above example:
99# 45988* 07#** 15#** 91#****
Type User Number User Code
1 07 77
1 15 67832
1 91 7568
When programming multiple User Numbers and Codes into the LK or 1.5 with keypad, it is not necessary to leave
and re-enter the programming Mode (50) for each entry. Multiple entries may be chained together and the three
different types of user codes (Standard, Passage and One Time) may be mixed.
The format to be used is as follows:
“T” is the Type of user code with “1” Standard, “2” Passage and “3” One Time.
“UN_” is User Number (04-99)
“UC_” is User Code (2 to 6 digits) which correlates with the User Number
99# Master or Supervisor Code* 50# Type# User Number a# User Code a*
User Code a* T# UNb# UCb* UCb* T# UNc# UCc* UCc* ...... T# UN_# UC_* UC_**
An example with four user codes is shown below:
Type User Number User Code
1 05 875
3 12 2226
2 08 5444
1 50 3367
-
+
-
+
-
+
-
+
+
-
+
-G1.5 - PA
Comm Enable
Push Button
C ain Programming
5
Label indicates version
of electronics

Copyright © SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written per ission of SARGENT Manufacturing is prohibited.
11
A7857A 800-810-WIRE (9473) www.sargentlock.com
Table 1: Main Codes - User Programmed “Door” Log
Function User Number Default Code User Programmed Code
Master Code 01 1234*
Supervisory Code
Supplemental – Individual “Door” Log Sheet for keypad programming
Lock odel:
Door Name:
Location:
Table 2: User Programmed “Door” Log
User Name User Type User Number User Code Card/Fob#, Notes
Note: The factory default Master Code (1234) must be changed (i.e., “Forced Change”) prior to
adding any other users.
Keypad Programming Instructions for t e Profile Series LK/v.G1.5 Lock
6

Founded in the early 1800s, SARGENT®is a arket leader in locksets, cylinders, door closers, exit devices,
electro- echanical products and access control syste s for new construction, renovation, and replace ent applications.
The co pany’s custo er base includes co ercial construction, institutional, and industrial arkets.
Copyright ©SARGENT Manufacturing. All rights reserved.
Reproduction in whole or in part without the express written
per ission of SARGENT Manufacturing is prohibited.
ASSA ABLOY is the global leader in door opening solutions, dedicated to
satisfying end-user needs for security, safety and convenience. A7857A-1/08
