AT&T MERLIN LEGEND MLX-10 Non-Display Telephone User manual

AT&T
MERLIN LEGEND™
Communications System
MLX-10™ Non-Display
Telephone User's Guide

Copyright © 1991 AT&T
All Rights Reserved
Printed in U.S.A.
AT&T 555-610-123
Issue 1
August 1991
Notice
Every effort was made to ensure that the information in this book was
complete and accurate at the time of printing. However, information is
subject to change.
Federal Communications Commission (FCC)
Electromagnetic Interference Information
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be
required to correct the interference at his own expense.
Canadian Department of Communications (DOC)
Interference Information
This digital apparatus does not exceed the Class A limits for radio noise
emissions set out in the radio interference regulations of the Canadian
Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioéléctriques
dépassant Ies Iimites applicables aux appareils numériques de la classe
A prescrites dans Ie Réglement sur Ie brouillage radioélectrique édicté
par Ie ministére des Communications du Canada.
Trademarks
MLX-10 is a trademark of AT&T.
MERLIN LEGEND is a trademark of AT&T.

Rings
One long _______________________ Inside call
One long and one short ___________ Outside call
One long and two short ____________ Transfer or returning call
One long and three short ___________ Returning Callback call
Line Button Lights
Red
Automatic connection
Green
Line or feature in use
Red and green Line Request in use
Red and green You’re on line
Red and flash green Incoming call
Red and flash green Returning transfer
Fast flash green Held call (yours)
Slow flash green Held call (co-worker’s)
Conference Calls
1. Dial first extension or number
2. Press Conf
3. Press line button
4. Dial next extension or number
5. Announce call and press
7.
■
Conf
6. Repeat steps 2–5 for each
participant
Hang up to end conference
Press Drop and line button to
drop single participant
■ Press Hold to temporarily leave
conference
■ Press any participant’s line button
to rejoin conference
Transfer Calls
Unannounced Transfer
1. Press Transfer
2. Press line or SA button
3. Dial extension or number
4. Press Transfer or hang up
Announced Transfer
1. Press Transfer
2. Press line or SA button
3. Dial extension or number
4. Announce call
5. Press Transfer, hang up,
or return to call on hold
One-Touch Manual Transfer
1. Press Auto Dial button
2. Announce call
3. Press Transfer, hang up,
or return to call on hold
One-Touch Auto Transfer
1. Press Auto Dial
Camp-On
1. Press Camp-On or
press Feature and
dial 57

Feature Use
Programmed Button
1. Program a line button for each
Code
feature (Appendix C)
2. Press programmed button
Feature Code
1. Press Feature
2. Dial code (see below)
Account Code Entry
82+ code
Callback—Selective
55
Call Waiting—Pickup
87
Camp-On
57
Follow Me
34 + ext.
Forward 33 + ext.
Forward/Follow Me—Cancel
■ all ❋ 34 ❋
■ one
❋ 34 + ext.
■ from your phone —
33 + your ext.
Last Number Dial
84
Message—Cancel
❋ 53
Message—Leave
25
Personal Speed Dial code
Pickup-Group
88
Pickup-Inside
9 + ext.
Pickup—Outside
9 + line
Privacy—Off
❋ 31
Privacy—On
31
Recall
775
Reminder—Cancel
❋ 81
Reminder—Set —81 + time + A or P
System Speed Dial code
Account Codes
Name
Extension Numbers
Name
Ext

Contents
About This Book
■ Conventions Used
■ How to Comment on This Book
vii
viii
ix
1
■
■
■
■
■
■
Your MLX-10 Telephone
MLX-10 Model
Dedicated Feature Buttons
Line Buttons
Line Button Lights
Caring for Your Phone
Adjusting the Desk Stand
1-1
1-2
1-4
1-6
1-11
1-12
1-13
Contents i

Contents
2 Making and Answering Calls
■ Making Outside Calls on Phones
with SA Buttons
■ Making Outside Calls on Phones
with ICOM Buttons
■ Making Inside Calls
■ Answering Calls
■ Tones
2-1
2-2
2-3
2-4
2-6
2-9
3 Using and Programming Features
■ Using Features
■ Programming Features
3-1
3-4
3-5
4
Feature Finder
4-1
ii Contents

Contents
5
Features5-1
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
Account Code Entry
Auto Dial
Callback
Call Waiting
Conference
Coverage
Do Not Disturb
Forward and Follow Me
Headset/Handset Mute
Last Number Dial
Line Request
Messaging
Paging
Park
Personalized Ring
Personal Speed Dial
Pickup
Privacy
Recall
Reminder Service
5-2
5-4
5-6
5-9
5-11
5-13
5-19
5-20
5-24
5-25
5-26
5-27
5-32
5-34
5-37
5-38
5-39
5-42
5-43
5-44
Contents iii

Contents
5 Features—Continued
■ Ringing Options
■ Saved Number Dial
■ Signaling and Notify
■ System Speed Dial
■ Transfer
■ Voice Announce
5-45
5-48
5-49
5-52
5-53
5-61
ΑΑ Programming Special Characters
A-1
B
Feature Codes
B-1
C
Programming Codes
C-1
IG
Index/Glossary
iv Contents
IG-1

The exclamation point in an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
IMPORTANT SAFETY INSTRUCTIONS
Always follow these basic safety precautions when using your
telephone equipment. These precautions reduce the risk of fire,
electric shock, and injury to you and damage to the equipment.
■ Read and understand all instructions.
■ Follow all warnings and instructions marked on or packed with
the telephone.
■ Do not use the telephone near water, as in a wet basement.
The telephone can be hazardous if immersed in water. To
avoid the possibility of electrical shock, do not use it when you
are wet. If you accidentally drop it into water, do not retrieve it
until you have first unplugged the line cord from the modular
wall jack. Do not plug the telephone back in until it has dried
thoroughly.
■ Do not use the telephone (other than a cordless-type
telephone) during electrical storms in your immediate area.
There is a remote risk of electric shock from lightning.
■ Unplug the telephone from the wall outlet before cleaning.
Use a damp cloth for cleaning. Do not use liquid or aerosol
cleaners on the phone.
v

■
■
■
■
■
Never push objects of any kind into the telephone through
openings or slots. Never spill liquid of any kind on the
telephone.
Do not use the telephone near a gas leak. If you suspect a
gas leak, report it immediately, but use a telephone away from
the area in question. The telephone’s electrical contacts could
generate a tiny spark. While unlikely, it is possible that the
spark could ignite heavy concentrations of gas.
To reduce the risk of electric shock, do not disassemble the
telephone. There are no user-serviceable parts inside.
Opening or removing covers may expose you to hazardous
voltages, and incorrect reassembly can cause electric shock
when the telephone is used.
Call your AT&T representative or authorized dealer when
service or repair work is needed.
Accessories include answering machines, alerts, modems,
and fax machines. To connect an accessory, you must first
have a Multi-Function Module (MFM).
WARNING:
■ For your personal safety DO NOT install an MFM
yourself.
■ ONLY an authorized AT&T technician or dealer rep-
resentative shall install, set options, or repair an MFM.
■ To eliminate the risk of personal injury due to electric
shock, DO NOT attempt to install or remove an MFM
from your MLX telephone. Opening or removing the
module cover of your telephone may expose you to
dangerous voltages.
SAVE THESE INSTRUCTIONS
vi
