Atos Freevent XtraCare Mini Operating instructions

XtraCare
™
Freevent XtraCare Mini combines an HME with a
highly effective filtration of airborne particles,
such us viruses and bacteria, for daily protection.
Wash your hands.
1
Take the Freevent XtraCare Mini (HME)
out of the package.
2
Before removing, wash your hands.
1
To remove the HME, hold the tracheostomy
tube in place and gently remove the HME
using a twisting motion.
2
Dispose of the used HME.
3
How to use Freevent XtraCare Mini
Precautions
• Do not wash and re-use the HME. Washing the HME impairs the filtering and HME functions.
• Do not use a soiled or contaminated device as this may cause an infection.
• Do not administer a medicated nebulizer treatment over the device since the medication can be
deposited in the device.
• Do not use humidifiers or heated humidified oxygen over the device since the HME will become too
wet.
Attach: Remove:
Gently attach the HME to the tube using
a twisting motion.
3
Change the HME at least every 24 hours
or more often if needed, e.g. breathing
resistance increases due to mucus. Replace
the HME if unintentionally removed, e.g.
coughed or pulled off, and got dirty or
contaminated.
4

Freevent O2Adaptor Mini should be replaced
at least every 24 hours, or when it becomes
dirty, contaminated or shows any signs of
damage. If needed, it can be removed and
used again within 24 hours for the same
patient.
2
MC2611-TcEN 202010
© Atos Medical AB, 2020
Connect the Freevent O2Adaptor Mini to
Freevent XtraCare Mini (HME). An audible
click will confirm it’s securely in place.
1
Attach the oxygen tubing to the adaptor and
make sure the oxygen tube goes beyond the
conical edge of the connector.
2
Attach the HME to the tube as described in
section How to use Freevent XtraCare Mini.
3
Apply oxygen as prescribed by the physician.
4
To detach the Freevent O2Adaptor Mini from
the HME, unclip the adaptor and remove.
3
Remove the HME as described in section How
to use Freevent XtraCare Mini.
1
XtraCare
™
How to use Freevent O2 Adaptor Mini
If supplemental oxygen is needed, Freevent XtraCare
Mini can be combined with Freevent O2Adaptor
Mini. Oxygen tubing of 1/8 inch (3.2 mm) diameter is
connected to the oxygen port of the adaptor.
Attach: Remove:
5
Dispose of the used HME and Freevent O2
Adaptor Mini.
4
The oxygen tubing can be detached from the
adaptor after oxygen supply and attached if
oxygen supply is resumed.
