Auriol Z30300A User manual

3
53674_aur_Wanduhr_content_LB3.indd 3
08.07.10 09:55
WAVE
SET
Q U A R T Z
IEC LR6
RESET
DCF
NO(0) JEWELS UNADJUSTED
1
2
5
3
4

4 GB
Introduction
Proper Use..............................................................................Page 5
Description of Parts ................................................................Page 5
Technical details.....................................................................Page 6
Included items ........................................................................Page 6
Safety
General Safety Information...................................................Page 6
Safety Instructions for Batteries .............................................Page 7
Preparing the product for use..........................Page 8
Operation
Receiving the DCF radio time signal.....................................Page 9
Setting the time manually.......................................................Page 9
Reset the functions (RESET)....................................................Page 10
Cleaning and Maintenance.................................Page 10
Disposal...............................................................................Page 10
Information
Declaration of Conformity ....................................................Page 11
53674_aur_Wanduhr_content_LB4.indd 4
08.07.10 09:55

5GB
Radio-Controlled Wall Clock
Q
Introduction
Familiarise yourself with the product before using it for the
first time. In addition please refer carefully to the operating
instructions below and the safety advice. Use the product
only as described and for the indicated purpose. Keep these instruc-
tions in a safe place. If you pass the product on to anyone else, please
ensure that you also pass on all the documentation.
Q
Proper Use
The wall clock shows the time by using Radio time signal (DCF). The
device is intended for use indoors at normal room temperatures only.
Any other use or modification of the device constitute improper use and
may result in injury and /or damage to the device. The manufacturer is
not liable for damage caused by improper use. The device is not intended
for commercial use.
Q
Description of Parts
1RESET button
2!"#$ button
3Battery compartment
4Battery insulation strip
5SET button
53674_aur_Wanduhr_content_LB4.indd 5
08.07.10 09:55

6 GB
Q
Technical details
Radio time signal (DCF
%
Battery type: 1.5V , AA
Q
Included items
1 Wall clock
1 Battery 1.5V , AA
1 Operating instructions
Safety
WARNING! Please read all safety information and instructions.
Failure to comply with the safety information and instructions may result
in, fire and/or severe injuries.
KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN A SAFE
PLACE FOR FUTURE REFERENCE!
General Safety Information
J WARNING! DANGER TO LIFE AND ACCI-
DENT HAZARD FOR TODDLERS AND
SMALL
CHILDREN! Never allow children
to play unsupervised
with the packaging material. There is a danger of suffocation from
53674_aur_Wanduhr_content_LB4.indd 6
08.07.10 09:55

7GB
the packaging material. Children frequently underestimate the
dangers. Children should be kept away from the product at all
times. This is not a toy.
J Children or persons who lack the knowledge or experience to use
the device or whose physical, sensory or intellectual capacities are
limited must never be allowed to use the device without supervision
or instruction by a person responsible for their safety. Children must
never be allowed to play with the device.
WARNING! DANGER TO LIFE! Batteries can be swallowed,
which may represent a danger to life. If a battery has been swal-
lowed, medical help is required immediately.
J Do not use the device if it is damaged.
Safety Instructions for Batteries
J Remove the battery from the device if it is not going to be used for
a prolonged period.
J
CAUTION! DANGER OF EXPLOSION! The batter-
ies must never be recharged!
J When inserting the battery, ensure the correct polarity! This is shown
in the battery compartment.
J If necessary, clean the battery and device contacts before inserting
the battery.
J Remove a spent battery immediately from the device. There is an
increased danger of leaks!
J If the above instructions are not complied with, the battery may
discharge itself beyond its end voltage. There is then a danger of
leaking. If the battery has leaked inside your device, you should
remove it immediately in order to prevent damage to the device!
53674_aur_Wanduhr_content_LB4.indd 7
08.07.10 09:55

8 GB
J Batteries must not be disposed of in the normal domestic waste!
J Every consumer is legally obliged to dispose of batteries in the
proper manner!
J Keep batteries away from children; do not throw them in the fire,
short-circuit them or take them apart.
J Avoid contact with the skin, eyes and mucous membranes. Any
parts of the body coming into contact with battery acid should
be rinsed off with copious amounts of water and/or a doctor
contacted if necessary!
Q
Preparing the product for use
j Remove the battery insulation strip 4from between the battery
and the contact. The wall clock starts to operate and begins to
receive the radio time signal immediately after the battery isolation
strip has been removed.
Note: Reception may be considerably reduced by obstructions
(e.g. concrete walls) or sources of interference (e.g. other electrical
devices). In the event of reception problems, change the position
of the wall clock (e.g. to somewhere near a window).
Radio Signal (DCF):
The DCF signal (time signal transmitter) consists of time pulses emitted
by one of the most accurate clocks in the world close to Frankfurt/Main,
Germany – this varies by 1 second in a million years.
Your radio-controlled clock receives these signals under ideal conditions
up to a distance of approx. 1,500km around Frankfurt/Main. Reception
of the radio signal generally takes approx. 3-10 minutes.
53674_aur_Wanduhr_content_LB4.indd 8
08.07.10 09:55

9GB
Q
Operation
Q
Receiving the DCF radio time signal
The wall clock automatically starts to search for the DCF radio time signal.
This process takes about 3-10 minutes to complete.
The reception of the DCF radio time signal by the wall clock can also
be started manually.
j Press and keep pressed the !"#$ button
2at least 5 seconds. The
wall clock attempts to receive the DCF radio time signal. This process
takes a few minutes to complete.
Note: If the wall clock was not able to receive the DCF radio time
signal because of errors, e.g. due your location to being at too great a
distance from the transmitter or for other reasons, you can set the time
manually. The manually set value is overwritten as soon as reception
of the DCF radio time signal is successful.
Q
Setting the time manually
j Press and keep pressed the SET button 5at least &seconds.
The wall clock switches into manual mode.
j Press and keep pressed the SET button 5again until the hands
reach the correct position for you to set the time.
j Briefly pressing the SET button 5moves the hands forward in
one minute steps to enable you to set the current time manually.
Note: After 7 seconds without pressing the SET 5button, the
wall clock switches out of manual mode and keeps the time as
53674_aur_Wanduhr_content_LB4.indd 9
08.07.10 09:55
HINTS: Press the button by using a pointed object (e.g. pencil).

10 GB
normal. The manually set value is overwritten as soon as reception
of the DCF radio time signal is successful.
Q
Reset the functions (RESET)
j If the wall clock does not react, you can press the RESET button 1
to reset all the settings back to the default values. You can then
start again from the beginning.
Q
Cleaning and Maintenance
j The device should only be cleaned on the outside with a soft dry
cloth.
j Under no circumstances should you use liquids or detergents, as
these will damage the device.
j If the wall clock is not going to be used, remove the battery.
Q
Disposal
The packaging is made entirely of recyclable materials,
which you may dispose of at local recycling facilities.
Contact your local refuse disposal authority for more details of how to
dispose of your worn-out product.
To help protect the environment, please dispose of the product
properly when it has reached the end of its useful life and
not in the household waste. Information on collection points
53674_aur_Wanduhr_content_LB4.indd 10
08.07.10 09:55

11GB
and their opening hours can be obtained from your local
authority.
Faulty or used batteries must be recycled in accordance with Directive
2006/66/EC. Please return the batteries and/or the device to the
available collection points.
Environmental damage through incorrect
disposal of the batteries!
Batteries may not be disposed of with the usual domestic waste. They
may contain toxic heavy metals and are subject to hazardous waste
treatment rules and regulations. The chemical symbols for heavy metals
are as follows: Cd = cadmium, Hg= mercury, Pb = lead. That is why
you should dispose of used batteries at a local collection point.
Q
Information
Q
Declaration of Conformity
We, Milomex Ltd., c/o Milomex Services, Hilltop Cottage, Barton
Road, Pulloxhill, Bedfordshire, MK45 5HP, UK, hereby declare under
our sole responsibility that the product: Radio-Controlled Wall Clock,
Model No.: Z30300A, Z30300B, Version: 0'/201(, to which this
declaration refers, complies with the standards/normative documents
of 1999/5/EC.
53674_aur_Wanduhr_content_LB4.indd 11
08.07.10 09:55

12 GB
The full Declaration of Conformity is available on the Internet at
www.milomex.com.
EMC
Product description:
Radio-Controlled Wall Clock
Model No.: Z30300A, Z30300B
Version: 0'/201(
