Autel MaxiPRO MP808BT User manual

i
Trademarks
Autel®, MaxiSys®, MaxiPRO®, MaxiScan®, MaxiCheck®, MaxiRecorder®, and
MaxiPRO® are trademarks of Autel Intelligent Technology Corp., Ltd., registered
in China, the United States and other countries. All other marks are trademarks or
registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise without the prior written permission of Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on the
latest information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While
information of this manual has been carefully checked for accuracy, no guarantee
is given for the completeness and correctness of the contents, including but not
limited to the product specifications, functions, and illustrations.
Autel will not be liable for any direct, special, incidental, indirect damages or any
economic consequential damages (including the loss of profits).
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully, paying
extra attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
1-855-288-3587/1-855-AUTELUS (North America)
0086-755-86147779 (China)
[email protected]
For technical assistance in all other markets, please contact your local selling
agent.

ii
Safety Information
For your own safety and the safety of others, and to prevent damage to the device
and vehicles upon which it is used, it is important that the safety instructions
presented throughout this manual be read and understood byall persons operating
or coming into contact with the device.
There are various procedures, techniques, tools, and parts for servicing vehicles,
as well as in the skill of the person doing the work. Because of the vast number of
test applications and variations in the products that can be tested with this
equipment, we cannot possibly anticipate or provide advice or safety messages to
cover every circumstance. It is the automotive technician’s responsibility to be
knowledgeable of the system being tested. It is crucial to use proper service
methods and test procedures. It is essential to perform tests in an appropriate and
acceptable manner that does not endanger your safety, the safety of others in the
work area, the device being used, or the vehicle being tested.
Before using the device, always refer to and follow the safety messages and
applicable test procedures provided by the manufacturer of the vehicle or
equipment being tested. Use the device only as described in this manual. Read,
understand, and follow all safety messages and instructions in this manual.
Safety Messages
Safety messages are provided to help prevent personal injury and equipment
damage. All safety messages are introduced by a signal word indicating the hazard
level.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury to the operator or to bystanders.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury to the operator or to bystanders.
Safety Instructions
The safety messages herein cover situations Autel is aware of. Autel cannot know,
evaluate or advise you as to all of the possible hazards. You must be certain that
any condition or service procedure encountered does not jeopardize your personal
safety.

iii
DANGER
When an engine is operating, keep the service area WELL VENTILATED or attach
a building exhaust removal system to the engine exhaust system. Engines produce
carbon monoxide, an odorless, poisonous gas that causes slower reaction time and
can lead to serious personal injury or loss of life.
SAFETY WARNINGS
Always perform automotive testing in a safe environment.
Wear safety eye protection that meets ANSI standards.
Keep clothing, hair, hands, tools, test equipment, etc., away from all moving or
hot engine parts.
Operate the vehicle in a well-ventilated work area, for exhaust gases are
poisonous.
Put the transmission in PARK (for automatic transmission) or NEUTRAL (for
manual transmission) and make sure the parking brake is engaged.
Put blocks in front of the drive wheels and never leave the vehicle unattended
while testing.
Be extra cautious when working around the ignition coil, distributor cap, ignition
wires and spark plugs. These components create hazardous voltages when
the engine is running.
Keep a fire extinguisher suitable for gasoline, chemical, and electrical fires
nearby.
Do not connect or disconnect any test equipment while the ignition is on or the
engine is running.
Keep the test equipment dry, clean, free from oil, water or grease. Use a mild
detergent on a clean cloth to clean the outside of the equipment as necessary.
Do not drive the vehicle and operate the test equipment at the same time. Any
distraction may cause an accident.
Refer to the service manual for the vehicle being serviced and adhere to all
diagnostic procedures and precautions. Failure to do so may result in personal
injury or damage to the test equipment.
To avoid damaging the test equipment or generating false data, make sure the
vehicle battery is fully charged and the connection to the vehicle DLC is clean
and secure.
Do not place the test equipment on the distributor of the vehicle. Strong
electro-magnetic interference can damage the equipment.

iv
CONTENTS
Safety Information .........................................................................................................ii
Safety Messages..............................................................................................................ii
Safety Instructions..........................................................................................................ii
1 Using This Manual ..............................................................................................................1
Conventions ....................................................................................................................1
2 General Introduction............................................................................................................3
MaxiPRO MP808BT Display Tablet ............................................................................4
VCI –Vehicle Communication Interface .....................................................................8
Other Accessories.........................................................................................................10
3 Getting Started...................................................................................................................11
Powering Up .................................................................................................................11
Powering Down.............................................................................................................15
4 Diagnostics........................................................................................................................16
Establishing Vehicle Communication.........................................................................16
Getting Started .............................................................................................................18
Vehicle Identification...................................................................................................20
Navigation.....................................................................................................................25
Diagnostics Screen Layout...........................................................................................25
Diagnosis .......................................................................................................................28
Generic OBD II Operations.........................................................................................40
Exiting Diagnostics.......................................................................................................44
5 Service...............................................................................................................................46
Oil Reset Service...........................................................................................................46
Electronic Parking Brake (EPB) Service....................................................................50
Battery Management System (BMS) Service .............................................................53
Steering Angle Sensor (SAS) Service..........................................................................56
Diesel Particle Filter (DPF) Service ............................................................................64
6 Data Manager ....................................................................................................................72
Operations.....................................................................................................................72
7 Settings..............................................................................................................................77
Unit................................................................................................................................77

v
Language.......................................................................................................................78
Printing Setting.............................................................................................................79
Notification Center.......................................................................................................81
Auto Update..................................................................................................................82
System Settings.............................................................................................................83
About.............................................................................................................................84
8 Update ...............................................................................................................................85
Tablet Update ...............................................................................................................85
MaxiVCI Mini Update.................................................................................................87
9 VCI Manager.....................................................................................................................88
BT Pairing.....................................................................................................................88
Update ...........................................................................................................................89
Programmer Update ....................................................................................................89
10 Shop Manager..................................................................................................................90
Vehicle History .............................................................................................................91
Workshop Information................................................................................................93
Customer Manager.......................................................................................................94
11 Academy..........................................................................................................................97
12 Remote Desk ...................................................................................................................98
13 MaxiFix .........................................................................................................................100
Navigation...................................................................................................................100
Operations...................................................................................................................103
14 Support ..........................................................................................................................110
Product Registration..................................................................................................110
Support Screen Layout ..............................................................................................111
My Account.................................................................................................................111
User Complaint...........................................................................................................112
Data Logging...............................................................................................................114
Communities...............................................................................................................115
Training Channels......................................................................................................117
FAQ Database.............................................................................................................118
15 Quick Link.....................................................................................................................119
16 Function Viewer ............................................................................................................120

vi
17 Maintenance and Service...............................................................................................123
Maintenance Instructions ..........................................................................................123
Troubleshooting Checklist.........................................................................................124
About Battery Usage..................................................................................................124
Service Procedures .....................................................................................................126
18 Compliance Information................................................................................................129
19 Warranty........................................................................................................................132
Limited One Year Warranty.....................................................................................132

1
1 Using This Manual
This manual contains device usage instructions.
Some illustrations shown in this manual may contain modules and optional
equipment that are not included in your system. Contact your sales
representative for availability of other modules and optional tools or
accessories.
Conventions
The following conventions are used.
Bold Text
Bold text is used to highlight selectable items such as buttons and menu
options.
Example:
Tap OK.
Notes and Important Messages
Notes
A NOTE provides helpful information such as additional explanations, tips,
and comments.
Example:
NOTE
New Batteries reach full capacity after approximately 3 to 5 charging and
discharging cycles.

2
Important
IMPORTANT indicates a situation which, if not avoided, may result in
damage to the test equipment or vehicle.
Example:
IMPORTANT
Keep the cable away from heat, oil, sharp edges and moving parts. Replace
damaged cables immediately.
Hyperlink
Hyperlinks, or links, that take you to other related articles, procedures, and
illustrations are available in electronic documents. Blue italic text indicates a
selectable hyperlink and blue underlined text indicates a website link or an
email address link.
Illustrations
Illustrations used in this manual are samples, the actual testing screen may
vary for each vehicle being tested. Observe the menu titles and on-screen
instructions to make correct option selection.

3
2 General Introduction
Featuring the powerful Cortex-A9 processor, and a 7.0 inch LCD capacitive
touch screen, based on the Android multitasking operating system, and
combined with the ability to quickly read and clear DTCs for all available
modules of the majority of the makes and models on the market, the
MaxiPRO MP808BT is your ideal auto diagnostic and service tool. MP808BT
provides you with superior special functions, including Oil Reset, EPB
(Electronic Parking Brake), SAS (Steering Angle Sensor), BMS (Battery
Management System), and DPF (Diesel Particulate Filter).
There are two main components of the MP808BT system:
MP808BT Display Tablet –the central processor and monitor for the
system.
MaxiVCI Mini (Vehicle Communication Interface) –the device for
accessing vehicle data.
This manual describes the construction and operation of both devices and
how they work together to deliver diagnostic solutions.

4
MaxiPRO MP808BT Display Tablet
Functional Description
Figure 2-1 Display Tablet Front View
1. 7.0” LCD Capacitive Touchscreen.
2. Ambient Light Sensor –detects ambient brightness.
3. Power LED –indicates battery level & charging or system status.
4. Vehicle Communication LED –flashes green when the Display
Tablet is communicating/linking with the vehicle’s system.
The power LED displays green, yellow or green depending on power level
and operating state.
A. Green
Illuminates green when the Display Tablet is charging and the
battery level is above 90%.
Illuminates green when the Display Tablet is powered on and the
battery level is above 15%.
B. Yellow
Illuminates yellow when the Display Tablet is charging and the
battery level is below 90%.
C. Red
Illuminates red when the Display Tablet is powered on and the
battery level is below 15%.

5
Figure 2-2 Display Tablet Back View
5. Collapsible Stand –extends from the back to allow hands-free viewing
of the Display Tablet.
6. Heat Sink
7. MaxiVCI Mini Holder
8. Built-in Battery
Figure 2-3 Display Tablet Top View
9. Mini USB OTG Port
10. Micro SD Card Slot –holds the micro SD card.
11. HDMI (High-Definition Multimedia Interface) Port
12. USB Port
13. Lock/Power Button –turns the device on & off with long press, or locks
the screen with short press.
Power Sources
The tablet can receive power from any of the following sources:

6
Internal Battery Pack
External Power Supply
Internal Battery Pack
The tablet can be powered with the internal rechargeable battery, which if
fully charged can provide sufficient power for about 7 hours of continuous
operation.
External Power Supply
The tablet can be powered from a wall socket using the USB charging cable
and the USB external power adapter. The external power supply also
charges the internal battery pack.
Technical Specifications
Table 2-1 Specifications
Item
Description
Recommended Use
Indoor
Operating System
AndroidTM 4.4.2, KitKat
Processor
Cortex-A9 processor (1.5 GHz)
Memory
64GB
Display
7-inch LCD capacitive touchscreen with
1024 x 600 resolution
Connectivity
Mini USB 2.0
USB 2.0
Wi-Fi
HDMI Type A
Micro SD card (supports up to 32GB)
Sensors
Light sensor for brightness auto changing

7
Item
Description
Audio input/output
Input: N/A
Output: buzzer
Power and Battery
3.7 V/5000 mAh lithium-polymer
battery
Charges via 5 VDC power supply
Tested Battery Life
Around 7 hours of continuous use
Battery Charging
Input
5 V/1.5 A
Power Consumption
600 mA (LCD on with default brightness,
Wi-Fi on) @3.7 V
Operating Temp.
0 to 55°C(32 to 131°F)
Storage Temp.
-20 to 60°C (-4 to 140°F)
Operating Humidity
5% - 95% non-condensing
Dimensions (W x H x D)
237.8 mm (9.4”) x 148.6 mm (5.9”) x 35.5
mm (1.4”)
Net Weight
788 g (2.42 lb.)
Protocols
ISO9141-2, ISO14230-2, ISO15765, K/L-
Line, Flashing Code, SAE-J1850
VPW, SAE-J1850PWM, ISO11898
(Highspeed, Middlespeed, Lowspeed and
Singlewire CAN, fault-tolerant CAN), SAE
J2610,GM UART,UART Echo Byte
Protocol, Honda Diag-H Protocol, TP2.0,
TP1.6

8
VCI –Vehicle Communication Interface
The wireless diagnostic interface MaxiVCI Mini is a small vehicle
communication interface (VCI) used to connect to a vehicle’s data link
connector (DLC) and connect wirelessly with the tablet for vehicle data
transmission.
Functional Description
Figure 2-4 MaxiVCI Mini Views
1. Vehicle Data Connector (16-Pin) –connects the MaxiVCI Mini to the
vehicle’s 16-pin DLC directly.
2. Power LED –refer to Table 2- 2 Power LED on the Front Panel on page
8for details.
3. Connection LED –refer to Table 2- 3 Connection LED on the Front
Panel on page 9for details.
4. USB Port –provides the easiest connection between the device and the
tablet via a USB cable.
Table 2-2 Power LED on the Front Panel
LED
Color
Description
Power
Green
Lights solid green when powered on.
Red
Blinks red when system failure occurs. Note:
The power LED briefly lights red each time the
device powers on and then lights green when
the device is ready.

9
Table 2-3 Connection LED on the Front Panel
LED
Color
Description
Connection
Green
Lights solid green when the device is
successfully connected via theUSB cable
but is not communicating with the vehicle.
Blinks green when the device is
successfully connected via theUSB cable
and is communicating with the vehicle.
Blue
Lights solid blue when the device is
successfully connected via BT but is not
communicating with the vehicle.
Blinks blue when the device is
successfully connected via BT and is
communicating with the vehicle.
Technical Specifications
Table 2-4 Specifications
Item
Description
Communications
•BT V.2.1 + EDR
•USB 2.0
Wireless Frequency
2.4 GHz
Input Voltage Range
12 VDC to 24 VDC
Supply Current
150 mA @ 12 VDC
Operating
0°C to 50°C (ambient)
Storage
-20°C to 70°C (ambient)
Dimensions
(L x W x H)
47 mm (1.7”) x 23 mm (0.9”) x 51 mm
(2.0”)
Weight
33.1g (0.07 lb.)

10
Power Sources
The MaxiVCI Mini operates on 12-volt vehicle power, which is received
through the vehicle’s DLC. The unit powers on whenever it is connected to
the vehicle’s DLC.
Other Accessories
MaxiVCI Mini
Connects to the vehicle’s DLC and provides wireless
connection between the tablet and the vehicle.
USB Cable (for test)
2 m
USB Cable (for charging)
90 cm
USB External Power Adapter
Together with the mini USB cable, connects the tablet
to the external DC power port for power supply.

11
3 Getting Started
Ensure the tablet is sufficient charged or is connected to the external power
supply (see Power Sources on page 10).
NOTE
The images and illustrations depicted in this manual may differ slightly from
the actual ones.
Powering Up
Long press the Lock/Power button on the top right side of the tablet to power
on the unit. The power LED light will illuminate green. The system boots up
and displays the lock screen. Slide the Lock icon to the left to enter the
MaxiPRO Job Menu or slide to the right to unlock.
Figure 3-1 Sample MaxiPRO MP808BT Job Menu
1. Application Buttons
2. Locator and Navigation Buttons
3. Status Icons

12
NOTE
The tablet screen is locked by default when first powered on. It is
recommended to lock the screen to protect the information in the system and
reduce the power consumption.
The touch screen navigation is menu driven enabling quickly access to
functions and features by tapping on options headings and answering dialog
windows. Detailed descriptions of the menu structures are found in the
application chapters.
Application Buttons
Descriptions of the tool applications are displayed in the table below.
Table 3-1 Applications
Button
Name
Description
Diagnostics
Accesses diagnostic functions menu. See
Diagnostics on page 16.
Service
Accesses special functions menu. See Service
on page 46.
Shop
Manager
Allows you to edit and save workshop
information and customer data, as well as
reviewing test vehicle history records. See Shop
Manager on page 90.
Data
Manager
Accesses the organization system for saved data
files. See Data Manager on page 64.
Settings
Accesses MaxiPRO system settings menu and
general tablet menu. See Settings on page 77.
Update
Checks for the latest update available for the
MaxiPRO system, and performs updates. See
Update on page 85.
Support
Launches the Support platform which
synchronizes Autel’s on-line service base

13
Button
Name
Description
station with the MaxiPRO tablet. See Support
on page 110.
Academy
Accesses technical tutorials and training articles
about the device usage and vehicle diagnostic
techniques. See Academy on page 97 for
details.
Remote
Desk
Configures the unit to receive remote support
using the TeamViewer application program.
See Remote Desk on page 98.
MaxiFix
Launches the MaxiFix platform which provides
the most compatible and abundant repair
techniques and diagnostics database. See
MaxiFix on page 100.
Quick Link
Provides associated website bookmarks to
allow quick access to product update, service,
support and other information. See Quick Link
on page 119.
Function
Viewer
Provides quick search for the supported
functions and vehicles of Autel diagnostic tools.
See Function Viewer on page 120.
Locator and Navigation Buttons
Operations of the Navigation buttons at the bottom of the screen are
described in the table below:
Table 3-2 Locator and Navigation Buttons
Button
Name
Description
Locator
Indicates which screen you are on. Swipe the
screen left or right to view the previous or next
screen.
Back
Returns to the previous screen.

14
NOTE
The
Button
Name
Description
Android
Home
Returns to Android System’s Home screen.
Recent
Apps
Displays a list of applications that are currently
in use. Tap an app icon to launch. To remove
an app, swipe it to the top or bottom.
Chrome
Launches the Android built-in browser.
Screenshot
Takes a screenshot when you want to save the
displayed information.
MaxiPRO
Home
Returns to MaxiPRO Job Menu from other
operations.
VCI
Opens the VCI Manager application. The
check at the bottom right corner indicates the
tablet is communicating with the MaxiVCI Mini.
An X will display if the tablet is not connected
to VCI.
Diagnostics
Shortcut
Returns to the Diagnostics screen.
Service
Shortcut
Returns to the Service screen.
System Status Icons
As the tablet is working with the Android operating system, you may refer to
Android documents for more information.
By up sliding the bottom right corner, a Shortcuts Panel will be displayed, on
which you are allowed to set various system settings ofthe tablet. Operations
of each button on the panel are described in the table below:
shortcuts buttons will be highlighted when enabled, and dimmed when
disabled.
