Autonics BD Series User manual

User Manual
for communication
Displacement Sensor
BD Series
MSO-BDC1-V1.0-2001US
Thank you for purchasing an Autonics product.
This user manual contains information about the product and its proper use,
and should be kept in a place where it will be easy to access.
www.autonics.com

2

Preface
3
Preface
Thank you for purchasing Autonics product.
Please familiarize yourself with the information contained in the Safety Considerations
section before using this product.
This user manual contains information about the porduct and its proper use, and should be
kept in a place where it will be easy to access.

User Manual Guide
4
User Manual Guide
Please familiarize yourself with the information in this manual before using the product.
This manual provides detailed information on the product's features. It does not offer
any guarantee concerning matters beyond the scope of this manual.
This manual may not be edited or reproduced in either part or whole without
permission.
This manual is not provided as part of the product package. Please visit our website
(www.autonics.com) to download a copy.
The manual's content may vary depending on changes to the product's software and
other unforeseen developments within Autonics, and is subject to change without prior
notice. Upgrade notice is provided through our homepage.
We contrived to describe this manual more easily and correctly. However, if there are
any corrections or questions, please notify us these on our website.

User Manual Symbols
5
User Manual Symbols
Symbol
Description
Supplementary information for a particular feature.
Failure to follow instructions can result in serious injury or death.
Failure to follow instructions can lead to a minor injury or product
damage.
An example of the concerned feature's use.
※
Annotation mark.

Safety Considerations
6
Safety Considerations
Following these safety considerations will ensure the safe and proper use of the product
and help prevent accidents, as well as minimizing possible hazards.
Safety considerations are categorized as Warnings and Cautions, as defined below:
Warning
Failure to follow the instructions may lead to a serious
injury or accident.
Caution
Failure to follow the instructions may lead to a minor
injury or accident.
Fail-safe device must be installed when using the unit with machinery that may cause
serious injury or substantial economic loss. (e.g. nuclear power control, medical
equipment, ships, vehicles, railways, aircraft, combustion apparatus, safety equipment,
crime/disaster prevention devices, etc.)
Failure to follow this instruction may result in personal injury, economic loss or fire.
Do not use the unit in the place where flammable/explosive/corrosive gas, high
humidity, direct sunlight, radiant heat, vibration, impact, or salinity may be present.
Failure to follow this instruction may result in explosion or fire.
Do not disassemble or modify the unit.
Failure to follow this instruction may result in fire.
Do not connect, repair, or inspect the unit while connected to a power source.
Failure to follow this instruction may result in fire.
Check 'Connections' before wiring. [Amplifier unit]
Failure to follow this instruction may result in fire.
Do not stare at the laser emitter. [Sensor head]
Failure to follow this instruction may result in eye damage.
Use the unit within the rated specifications.
Failure to follow this instruction may result in fire or product damage.
Use dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in fire.
Mount the ferrite core to specified position before using. [Sensor head, Extension cable]
Failure to follow this instruction may result in output with noise.

Cautions during Use
7
Cautions during Use
Follow instructions in 'Cautions during Use'. Otherwise, it may cause unexpected
accidents.
The power supply should be insulated and limited voltage/current or Class 2, SELV
power supply device.
Do not install where strong magnetic or electric field exist. Otherwise, the resolution
may be adversely affected.
Mutual optical interference between laser sensors and photoelectric sensors may result
in malfunction.
Mutual optical interference between laser sensors may result in malfunction.
When connecting DC relay or other inductive load to the output, remove surge by using
diode or varistor.
Wire as short as possible and keep away from high voltage lines or power lines, to
prevent surge and inductive noise. [ Amplifier unit]
For the optimized performance, it is recommended to measure after 30 minute from
supplying power. [Amplifier unit]
Since external disturbance light (sunlight, fluorescent lighting, etc.) can cause product
malfunction, use the product with a light shield or slit. [Sensor head]
When detecting with the maximum sensitivity, an error may occur depending on each
characteristic deviation.
This unit may be used in the following environments.
① Indoors/Outdoors (in the environment condition rated in 'Specifications')
② Altitude max. 2,000m
③ Pollution degree 2
④ Installation category II
The specifications are subject to change and some models may be discontinued without
notice.
Be sure to follow cautions written in the instruction manual, user manual and the technical
descriptions (catalog, website).

Table of Contents
8
Table of Contents

1 Communication Overview
9
1Communication Overview
Modbus
The Modbus industrial protocol was developed in 1979 to make communication possible
between automation devices. T he protocol has expanded to include implementations over
serial, TCP/IP, and the user datagram protocol (UDP). Today, it is a common protocol used
by countless devices for simple, reliable, and efficient communica tion across a variety of
modern networks.
Refer to the reference document of developer for the details
Communication of BD-C series is based on Modbus RTU.
Frame Structure of Modbus RTU
Read Coil Status (Func 01 01H)
Read output (OX reference, Coil) ON/OFF status in the slave device.
Query (Master)
Slave
Address
Function
Starting Address
No. of Points
Error Check (CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Response (Slave)
Slave
Address
Function
Byte Count
Data
Data
Data
Error Check (CRC16)
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
CRC16
CRC16

1 Communication Overview
10
Read Input Status (Func 02 02H)
Read Input ON/OFF status (1X reference) in Slave device.
Query (Master)
Slave
Address
Function
Starting Address
No. of Points
Error Check (CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Response (Slave)
Slave
Address
Function
Byte Count
Data
Data
Data
Error Check (CRC16)
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Read Holding Register (Func 03 03H)
Read the Binary data of Holding Registers (4X reference) in Slave device.
Query (Master)
Slave
Address
Function
Starting Address
No. of Points
Error Check (CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Response (Slave)
Slave
Address
Function
Byte Count
Data
Data
Data
Error Check (CRC16)
High
Low
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
CRC16
CRC16
CRC16
CRC16

1 Communication Overview
11
Read Input Register (Func 04 04H)
Read the Binary data of Input Registers (3X reference) in Slave device.
Query (Master)
Slave
Address
Function
Starting Address
No. of Points
Error Check (CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Response (Slave)
Slave
Address
Function
Byte Count
Data
Data
Data
Error Check (CRC16)
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Force Single Coil (Func 05 05 H)
Turns ON (FF00 H) or OFF (0000 H) of single coil (0X reference) status within slave.
 Query (Master)
Slave
Address
Function
Coil Address
Preset Data
Error Check (CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Response (Slave)
Slave
Addres
Function
Coil Address
Preset Data
Error Check (CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
CRC16
CRC16
CRC16
CRC16

1 Communication Overview
12
Preset Single Register (Func 06 06H)
Read the Binary data of single Holding Registers (4X reference) in Slave device.
Query (Master)
Slave
Address
Function
Register Address
Preset Data
Error Check (CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Response (Slave)
Slave
Address
Function
Register Address
Preset Data
Error Check (CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Preset Multiple Register (Func 16 10H)
Write the Binary data of Holding Registers (4X reference) consecutively in Slave device.
Query (Master)
Slave
Address
Function
Starting
Address
No. of Register
Byte
Count
Data
Data
Error Check
(CRC16)
High
Low
High
Low
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Response (Slave)
Slave
Address
Function
Starting Address
No. of Register
Error Check (CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
Please use the Single Register Write function rather than Multi Register Write function if you
use the slave(device) connecting with external devices such as PLC, Graphic Panel, except in
the case of download that presets the minimum/maximum or basic value of parameter by
Input specifications in PC Loader Program.
CRC16
CRC16
CRC16
CRC16

1 Communication Overview
13
Exception Response-Error Code
If occurs an error, send a response command and transmit each Exception Code after set(1)
the highest level bit of received command(Function).
Slave Address
Function
+80 H
Exception Code
Error Check (CRC16)
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
ILLEGAL FUNCTION (Exception Code: 01 H): When a command is not supported
ILLEGAL DATA ADDRESS (Exception Code: 02 H): When Reserved area is r ead
ILLRGAL DATA VALUE (Exception Code: 03 H): When data write to out of setting range is
requested.
SLAVE DEVICE FAILURE (Exception Code: 04 H): When the parameter is locked or
communication write is disable.
SLAVE DEVICE BUSY (Exception Code: 06 H): When the device status cannot perform the
requested order.
When the exception response situation, the device do not respond data, but send
exception code only.
CRC16

1 Communication Overview
14
Autonics Modbus Address System
Parameter address structure
The parameter address is written in form Reference number - Decimal address
(Hexadecimal address).
For example, if the parameter address is 301001(03E8), it means that 3 is Reference
number, 01001 is Decimal address (DEC), 03E8 is Hexadecimal address (HEX).
Reference number per each FUNC
Reference
Function
0
FUNC 01[R], FUNC 05[W], FUNC 15[MW]
1
FUNC 02[R]
3
FUNC 04[R]
4
FUNC 03[R], FUNC 06[W], FUNC 16[MW]
Correlation between decimal address and hexadecimal address
The parameter address can be somewhat different for each manufacturer because the
regulation for a starting number is not defined.
Autonics Modbus address is started at 1 for decimal (DEC) address, and at 0 for
hexadecimal (HEX). So, decimal (DEC) address values are +1 for Hex (HEX)
address values.
03E8(HEX) →1001(DEC) (1000 + 1)
07D0(HEX) →2001(DEC) (2000 + 1)
157C(HEX) →5501(DEC) (5500 + 1)

2 Modbus Mapping Table
15
2Modbus Mapping Table
The meaning of HI/LO address
Some parameters of BD series divide the value into two addresses (HI/LO) because it
exceeds the maximum value (216, 16 bit) that can be sent from one address.
When inputting value greater than the maximum (216, 16 bit), convert it to hexadecimal
(HEX), enter up to 4 digits (low 16bit) into the LO address and over 5 digits (high 16 bit)
into the HI address.
For example, when inputting a value 99999 into Output hysteresis parameter, convert
'99999' into the hexadecimal value, 1869F. Input 1(0x0001) into HI address (OUT HYS
HI [Output hysteresis], 400065(0040)) and 869F(0x869F) into LO address (OUT HYS LO
[Output hysteresis], 400066(0041)), and send them.
If under the maximum (216, 16 bit) is needed to be set, input ‘0’(0x0000) into HI address
and the hexadecimal value (HEX) into LO address.
Force Single Coil (Function: 05)
Excute the function by communication input.
Amplifier unit - channel 1
NO
FUNC
R/W
Description
Setting range
00001(0000)
05
W
Excutes sensing
optimization
0: OFF
1: ON
00002(0001)
05
W
Sets zero adjustment
00003(0002)
05
W
Dismisses zero adjustment
00004(0003)
05
W
Auto sensitivity adjustment (Teaching)
00005(0004)
05
W
Initializes HIGH/LOW PEAK value
00006(0005)
05
W
Initializes current BANK
00007(0006)
05
W
Initializes all BANK
Address range of channel 1 to channel 8 (add 1000 per channel)
NO
Description
00001(0000) to 00007(0006)
Master
01001(03E8) to 01007(03EE)
Slave 1
02001(07D0) to 02007(07D6)
Slave 2
03001(0BB8) to 03007(0BBE)
Slave 3
04001(0FA0) to 04007(0FA6)
Slave 4
05001(1388) to 05007(138E)
Slave 5
06001(1770) to 06007(1776)
Slave 6
07001(1B58) to 07007(1B5E)
Slave 7

2 Modbus Mapping Table
16
Read Input Status (Function: 02)
These parameters are related to LED display and analog output of amplifier unit.
Amplifier unit - channel 1
NO
FUNC
R/W
Description
Setting range
10001(0000)
02
R
LED OUT HI
0: OFF
1: ON
10002(0001)
02
R
LED OUT GO
10003(0002)
02
R
LED OUT LOW
10004(0003)
02
R
LED OUT ALARM
10005(0004)
02
R
LED SV HI
10006(0005)
02
R
LED SV LOW
10007(0006)
02
R
LED SV RV
10008(0007)
02
R
LED SV ANALOG
10009(0008)
02
R
LED LASER
10010(0009)
02
R
LED RANGE
10011(000A)
02
R
LED CALC
10012(000B)
02
R
ANALOG OUT TYPE
0: CURRENT
1: VOLT
10013(000B)to
10020(0014)
02
R
Reserved
Amplifier unit - address range of channel 1 to channel 8 (add 1000 per channel)
NO
Description
10001(0000) to 10012(000B)
Master
11001(03E8) to 11012(03F3)
Slave 1
12001(07D0) to 12012(07DB)
Slave 2
13001(0BB8) to 13012(0BC3)
Slave 3
14001(0FA0) to 14012(0FAB)
Slave 4
15001(1388) to 15012(1393)
Slave 5
16001(1770) to 16012(177B)
Slave 6
17001(1B58) to 17012(1B43)
Slave 7

2 Modbus Mapping Table
17
Read Input Registers (Function: 04)
Amplifier unit
Amplifier unit model information - channel 1
NO
FUNC
R/W
Description
Setting range
30001(0000)
04
R
Product number H
-
30002(0001)
04
R
Product number L
-
30003(0002)
04
R
Hardware Version
-
30004(0003)
04
R
Software Version
-
30005(0004)
04
R
Model number 1
‘BD’
30006(0005)
04
R
Model number 2
‘A1’
30007(0006)
04
R
Model number 3
30008(0006)
04
R
Model number 4
30009(0008)
04
R
Model number 5
30010(0009)
04
R
Reserved
-
30011(000A)
04
R
Serial number1
30012(000B)
04
R
Serial number2
30013(000C)
04
R
Serial number3
30014(000D)
04
R
Serial number4
30015(000E)
04
R
Connected sensor head model
number
30, 65, 100
Reserved
Amplifier unit data - channel 1
NO
FUNC
R/W
Description
Setting range
30101(0064)
04
R
Present Value HI
-99999 to 99999
(Change display digit according to
‘Display digit’ parameter)
30102(0065)
04
R
Present Value LO
30103(0066)
04
R
Setting Value HI
-99999 to 99999
30104(0067)
04
R
Setting Value LO
30105(0068)
04
R
Display status
Bit
Parameter name
Setting range
0
LED OUT HI
0: OFF
1: ON
1
LED OUT GO
2
LED OUT LOW
3
LED OUT ALARM
4
LED SV HI
5
LED SV LOW
6
LED SV RV

2 Modbus Mapping Table
18
NO
FUNC
R/W
Description
Setting range
7
LED SV ANALOG
8
LED LASER
9
LED RANGE
10
LED CALC
11
ANALOG
OUT TYPE
0: CURRENT,
1: VOLT
12
SV BANK MODE
0: NONE
1: BANK
30106(0069)
04
R
HIGH Peak value HI
-99999 to 99999
30107(006A)
04
R
HIGH Peak value LO
30108(006B)
04
R
LOW Peak value HI
-99999 to 99999
30109(006C)
04
R
LOW Peak value LO
30110(006D)
04
R
ERROR
0: NONE
1: HEAD
2: LASER
4: MEMORY
8: AMP-C
16: VER
32: OUT
64: AIF
128: OUT CURR
256: DARK
512: BRIGHT
1024: FILTER DELAY
2048: RANGE
4096: LASER OFF
30111(006E)
04
R
Decimal point of PV
Value
0: 0.000
1: 0.00
2: 0.0
3: 0

2 Modbus Mapping Table
19
Amplifier unit - address range of channel 1 to channel 8 (add 1000 per channel)
NO
Description
30001(0000) to 30201(00C8)
Master
31001(03E8) to 31201(04B0)
Slave 1
32001(07D0) to 32201(0898)
Slave 2
33001(0BB8) to 33201(0C80)
Slave 3
34001(0FA0) to 34201(1068)
Slave 4
35001(1388) to 35201(1450)
Slave 5
36001(1770) to 36201(1838)
Slave 6
37001(1B58) to 37201(1C20)
Slave 7
Communication converter
Communication converter model information
NO
FUNC
R/W
Description
Setting range
38001(1F40)
04
R
Product number H
-
38002(1F41)
04
R
Product number L
-
38003(1F42)
04
R
Hardware Version
-
38004(1F43)
04
R
Software Version
-
38005(1F44)
04
R
Model number 1
“BD”
38006(1F45)
04
R
Model number 2
“CR“
38007(1F46)
04
R
Model number 3
“S”
38008(1F47)
04
R
Model number 4
-
38009(1F48)
04
R
Model number 5
-
38010(1F49)
04
R
Model number 6
-
38011(1F4A)
04
R
Model number 7
-
38012(1F4B)
04
R
Model number 8
-
38013(1F4C)
04
R
Model number 9
-
38014(1F4D)
04
R
Model number 10
-
38015(1F4E)
04
R
Serial number 1
-
38016(1F4F)
04
R
Serial number 2
-
38017(1F50)
04
R
Serial number 3
-
38018(1F51)
04
R
Serial number 4
-
38019(1F52)
04
R
Reserve
-
38020(1F53)
04
R
Reserve
-
38021(1F54)
04
R
Reserve
-
38022(1F55)
04
R
Reserve
-
38023(1F56)
04
R
Parameter change flag
-
38024(1F57)
04
R
The number of connected amplifier unit
1 to 8

2 Modbus Mapping Table
20
Read Holding Registers (Function: 03),
Preset Single Register (Function: 06),
Preset Multiple Registers (Function: 16, 10 Hex)
Sensitivity setting group - channel 1
NO
FUNC
R/W
Description
Setting range
40001(0000)
03/06/16
R/W
HIGH HI [Sensitivity high limit
setting value]
-99999 to 99999
40002(0001)
03/06/16
R/W
HIGH LO [Sensitivity high limit
setting value]
40003(0002)
03/06/16
R/W
LOW HI [Sensitivity low limit
setting value]
-99999 to 99999
40004(0003)
03/06/16
R/W
LOW LO [Sensitivity low limit
setting value]
Amplifier unit parameter group 1 [PARA1] - channel 1
NO
FUNC
R/W
Description
Setting range
40051(0032)
03/06/16
R/W
RSPD HI [Response time]
0: 330㎲
1: 500㎲
2: 1㎳
3: 2㎳
4: 5㎳
40052(0033)
03/06/16
R/W
RSPD LO [Response time]
40053(0034)
03/06/16
R/W
SENS HI [Teaching mode]
0: 1PNT
1: 2PNT
40054(0035)
03/06/16
R/W
SENS LO [Teaching mode]
40055(0036)
03/06/16
R/W
NO.NC HI [Output type]
0: NO
1: NC
40056(0037)
03/06/16
R/W
NO.NC LO [Output type]
40057(0038)
03/06/16
R/W
DISP HI [PV display]
0: STND: 0
1: SCALE: 1
40058(0039)
03/06/16
R/W
DISP LO [PV display]
40059(003A)
03/06/16
R/W
DOT HI [Display digit]
0: 0.000
1: 0.00
2: 0.0
3: 0
40060(003B)
03/06/16
R/W
DOT LO [Display digit]
40061(003C)
03/06/16
R/W
H-SC HI [High display scale]
-99999 to 99999
40062(003D)
03/06/16
R/W
H-SC LO [High display scale]
40063(003E)
03/06/16
R/W
L-SC HI [Low display scale]
-99999 to 99999
40064(003F)
03/06/16
R/W
L-SC LO [Low display scale]
40065(0040)
03/06/16
R/W
OUT HYS HI [Hysteresis]
-99999 to 99999
40066(0041)
03/06/16
R/W
OUT HYS LO [Hysteresis]
