AVer FC2020-P Instruction manual

FC2020-P
FC2020-PW
Cube IP Camera
Quick User Guide

Table of Contents
I. Camera Introduction........................................................................................1
1. Package Contents ...................................................................................1
2. Hardware Installation...............................................................................2
2.1 Factory Default...................................................................................5
3. SD card Compatibility List .......................................................................6
II. Monitor Setting................................................................................................7
III. IPAssignment .................................................................................................8
Finding IP Camera by using “NXU Lite recording software”..............................8
Finding IP Camera by using “AVer IPCam Utility”............................................ 11
Using NON-DHCP Server/Router Network......................................................13
IV. Connecting the IP Camera............................................................................15
COPYRIGHT.........................................................................................................16
NOTICE.................................................................................................................16
WARNING.............................................................................................................16
Limited Warranty.................................................................................................17
Governing Law and Your Rights........................................................................18

1
ENGLISH
Before Installation
Before installation, please be sure to read this quick installation guide and user’s manual carefully to
complete the installation.
I. Camera Introduction
The following section introduces package contents, hardware installation, factory default reset, and SD
card Compatibility List of each type camera.
1. Package Contents
Item Descriptions
1. FC2020-P or FC2020-PW
2. Bracket
3. Screw pack
4. Power Adaptor(DC 12V/0.5A) (Optional)
5. CD (User’s Manual and Quick Guide, NVR
software included)
6. Antenna (FC2020-PW model only)
**If any of the above items are missing, please contact your dealer immediately.

2
2. Hardware Installation
1. Install with bracket
Please refer to the picture for camera installation. Use the screws to lock the bracket to the wall or
ceiling, and then connect the camera to the bracket. There’s a knob on the back of the bracket.
Loosen the knob and you can adjust the angle of camera. Tighten it to fix the angle.
For FC2020-PW wireless model, please install antenna.

3
ENGLISH
2. Connector Instruction
The camera connectors are as below. Connect the power and the Ethernet cable with the camera,
and set it according to your network environment.
3. I/O Configuration
I/O Connection
a. Please connect the G & DO pin to the external relay (buzzer) device
When no event happens, DO output is 5V (DO and GND are disconnected). When the camera
detects event happening and triggers external alarm, DO output is 0V (DO and GND are
connected).

4
b. Please connect the G & DI pin to the external trigger device.
If you select "N.O" in "Input sensor setting", when external devise or circuit makes DI and GND
pin connected, the camera input alarm is triggered, and then camera will execute the action
user has set, for example, send snapshot to E-mail address.
If you select "N.C" in "Input sensor setting", when external devise or circuit makes DI and GND
pin disconnected, the camera input alarm is triggered, and then camera will execute the action
user has set, for example, send snapshot to E-mail address.

5
ENGLISH
2.1 Factory Default
1. To recover the default IP address and password, please follow the following steps.
2. Remove power and Ethernet cable.
3. Press and hold the button and connect power and Ethernet cable to the camera again and hold for
round 20 seconds for system booting.
4. Release the button when camera finishes proceed.
5. Re-login the camera using the default IP (http://192.168.1.168) or DHCP, and user name (admin),
password (admin).

6
3. SD card Compatibility List
FC2020-P and PC2020-PW are compliant with microSD/SDHC card and to ensure recording quality,
and please use memory cards over 2G and Class 4 above (Max. 32G)
MicroSD/SDHC card
Transcend SDHC class4 16GB
Transcend SD class4 16GB
Transcend SDHC class4 32GB
Transcend SD class4 32GB
Transcend SD class6 4GB
Transcend SDHC class6 4GB
Transcend SD class6 8GB
Transcend SDHC class6 8GB
Transcend SD class6 16GB
Transcend SDHC class6 16GB
Transcend SDHC class10 4GB
Transcend SDHC class10 8GB
Transcend SDHC class10 16GB
SanDisk SDHC class4 4GB
SanDisk SDHC class4 8GB
SanDisk SDHC class4 16GB
SanDisk SDHC class4 32GB

7
ENGLISH
II. Monitor Setting
1. Right-click on the desktop. Select “ Properties”
2. Change “Color quality” to “Highest (32-bit)”.

8
III. IP Assignment
There are two ways to find IP Camera:
−Finding IP Camera by using “NXU Lite recording software”
−Finding IP Camera by using “AVer IPCam Utility”
Finding IP Camera by using “NXU Lite recording software”
1. The NXU Lite software is in the attached software CD. Before launching it, please install the
software first. During the installing process, users will be required to input a User name and
Password for login NXU Lite system. Users can define the User name and Password as wishes.
Please refer to NXU Lite user manual for detailed installation instruction.
2. To run the application, double-click on your PC desktop or click Start > Programs > DVR >
NXU Lite. For security purpose, some of the features would require you to enter User name and
Password before it can be accessed. When the Authorization dialog box appears, key in your User
ID and Password. (If this is the first time, enter the one you have registered when installing the
software.
Click it to call out virtual
keyboard.
