1
Before Installation
Before installation, please be sure to read this quick installation guide and user’s manual carefully to
complete the installation.
I. Camera Introduction
The following section introduces packagecontents, hardware installation, factory default reset, and SD
card Compatibility List of each type camera.
1. Box Type IP Camera (SF2111H-R)
1.1 Package Contents
Item Descriptions
1. SF2111H-R
2. Accessory pack
3. Ethernet cable
4. Power Adapter (DC12V/1A)
(Optional)

2
Item Descriptions
5. CD (User’s Manual and Quick Guide
included)
**If any of the above items are missing, please contact your dealer immediately.
1.2 Hardware Installation
1. Connect power adapter or use PoE to eliminate the use of power cable.
2. Connect IP camera to PC or network with Ethernet cable.

3
1.3 Factory Default
1. To recover the default IP address and password, please follow the following steps.
2. Remove power, press and hold the button in the back of IP camera.
3. Power on the IP camera. Don’t release the button during the system booting.
4. It will take around 30 seconds to boot the camera.
5. Release the button when camera finishes proceed.
6. Re-login the camera using the default IP (http://192.168.1.200) or DHCP, and user name (admin),
password (admin).
Reset button

4
2. Bullet Type IP Camera (SF2111H-BR)
2.1 Package Contents
Item Descriptions
1. SF2111H-BR
2. Stand (The stand is well assembled while
shipped out)
3. Accessory pack
4. Ethernet cable
5. RJ45 socket
6. Power Adapter(DC 12V /1A)(Optional)

5
Item Descriptions
7. CD (User’s Manual and Quick Guide
included)
**If any of the above items are missing, please contact your dealer immediately.
2.2 Hardware Installation
1. Connect a power adapter and IP camera to PC or local network.
2. The SF2111H-BR is equipped with an external vari-focal lens controller. Please adjust
“ZOOM”and “FOCUS”as following picture until the image gets clear.

6
3. I/O Control Instruction
I/O terminal connector – used in application, for e.g., motion detection, event triggering, alarm
notifications. It provides the interface to:
Digital Input (GND+Alarm) : An alarm input for connecting devices that can toggle between
an open and closed circuit, for
1. GND (Ground) : Initial state is LOW
2. Alarm : Max. 50mA, DC 5V
Example: PIRs, door/window contacts, glass break detectors, etc. When a signal is
received the state changes and the input becomes active.
2.3 Factory Default
1. Remove the Ethernet cable and power adapter.
2. Take an electronic wire, plug one side of the wire into “Default” and the other side into “GND” on
the terminal block as the photo below.
3. Connect power again and connect Ethernet cable after the camera finishes rebooting..
4. Remove the wire. When camera starts again, please remove the pink default cable and plug
Ethernet cable for new setting.
5. Release the button when camera finishes proceed.
6. Re-login the camera using the default IP (http://192.168.1.200) or DHCP, and user name (admin),
password (admin).
.

7
3. Dome Type IP Camera
3.1 Package Contents
3.1.1 SF2111H-DR
Item Descriptions
1. SF2111H-DR
2. Accessory pack
3. RJ45 socket
4. Power Adaptor (DC 12V /1A) (Optional)
5. CD (User’s Manual and Quick Guide
included)
**If any of the above items are missing, please contact your dealer immediately.
3.1.2 SF2111H-DVR
Item Descriptions

8
1. SF2111H-DVR
2. Accessory pack
3. RJ45 socket
4. Power Adaptor(DC 12V/1A)
(Optional)
5. CD (User’
s Manual and Quick Guide
included)
**If any of the above items are missing, please contact your dealer immediately.

9
3.2 Hardware Installation
3.2.1 SF2111H-DR
1. Connect a power adapter and IP camera to PC or local network.
2. 3-Axis Gimbals Adjustments
Once the users open the case, the gimbals adjustment offers the convenience method to install on
the wall. The pan, tilt, and rotation are provided in this model. The users can adjust the
gimbals with Pan 172 degrees, tilt 30~90 degrees, and rotation 180 degrees respectively.
 Pan: 172°

Rotation: 180°
 Tilt: 30°~90°

10
3. Installation steps
I/O Control Instruction
I/O terminal connector – used in application, for e.g., motion detection, event triggering, alarm
notifications. It provides the interface to:
Digital Input (GND+Alarm) : An alarm input for connecting devices that can toggle between an
open and closed circuit, for
1. GND (Ground) : Initial state is LOW
2. Alarm : Max. 50mA, DC 5V
Example: PIRs, door/window contacts, glass break detectors, etc. When a signal is
received the state changes and the input becomes active.
(1) Use screws to lock the
bottom of camera to the
ceiling or the wall.
(2) Use 3-Axis to adjust the lens
angle.
(3) Close the dome cover.
(4) Tighten the screw on the
cover to fix it.

11
3.2.2 SF2111H-DVR
1. Remove the dome cover, and you will see the structure as below.
2. Connect power adaptor, then connect the IP camera to PC or network. Set up the network
configurations according to the network environment. The following picture shows a DC 12V
connector for adapter jack plug.
microSD
G
DO
DI
G
Line out
MIC In
G
Video

12
3. Installation Tips
In order to ensure IP66 waterproof level, please install the vandal dome according to the
instruction.
a. The Unused cable outlet hole must be closed, and the waterproof connector on the used hole
must be locked closely
b. We recommend the bottom of housing be set on the smooth flat and closely seal with the
surface.
c. When you mount the camera housing on the ceiling or wall, please use the screws with the
black rubber o-rings. Without the o-ring, the water may seep into the machine.
d. Turn and loose the control stick, shift right and left to adjust the vari-focal lens until the image
becomes clear, then turn and tighten the stick to fix it.

13
e. Use the 3-Axis bracket to adjust the camera to appropriate angle.
f. f. Before you close the dome cover, make sure that the black rubber band sticks to the inside
of the cover completely. Crook or uneven rubber band may cause the waterproof defective.
g. Lock tightly the screws on the dome cover to ensure there's no gap between the lid and base.

14
4. I/O Interface
I/O Connection
a. Please connect the GND & DO pin to the external relay (buzzer) device.
b. Please connect the GND & DI pin to the external trigger device
c. I/O PIN definition
 GND (Ground): Initial state is LOW
 DO (Digital Output): DC 5V
 DI (Digital Input): Max. 50mA, DC 5V

15
3.3 Factory Default
3.3.1 SF2111H-DR
1. To recover the default IP address and password, please follow the following steps.
2. Remove power, and press and hold the button. Please refer to the picture below.
3. Power on the camera. Don’t release the button during the system booting.
4. It will take around 30 seconds to boot the camera.
5. Release the button when camera finishes proceed.
6. Re-login the camera using the default IP (http://192.168.1.200) or DHCP, and user name (admin),
password (admin).
Reset button

16
3.3.2 SF2111H-DVR
1. To recover the default IP address and password, please follow the following steps.
2. Remove power and Ethernet cable, press and hold the button for 10 sec. Please refer to the
picture below.
3. Connect power and Ethernet cable to the camera again. Power on the camera. Don’t release the
button during the system booting.
4. It will take around 30 seconds to boot the camera.
5. Release the button when camera finishes proceed.
6. Re-login the camera using the default IP (http://192.168.1.200) or DHCP, and user name (admin),
password (admin).
