AVer FV2026 User manual

AVer FV2026
User Manual

Table of Contents
PRODUCT SPECIFICATIONS.............................................................................................1
PACKAGE CONTENTS.......................................................................................................5
PRODUCT INSTALLATION.................................................................................................7
MONITOR SETTING .............................................................................................................7
HARDWARE INSTALLATION....................................................................................................8
POWER OVER ETHERNET (POE)..........................................................................................9
IPASSIGNMENT................................................................................................................10
FINDING IPCAMERA BY USING “NXU LITE RECORDING SOFTWARE”........................................10
FINDING IPCAMERA BY USING “AVER IPCAM UTILITY”.........................................................13
USING NON-DHCPSERVER/ROUTER NETWORK................................................................15
INSTALL ACTIVEXCONTROL...............................................................................................17
USING THE IP CAMERA BROWSER INTERFACE..........................................................19
PREVIEW .........................................................................................................................19
SYSTEM >GENERAL .........................................................................................................22
SYSTEM >GENERAL >MAINTENANCE.................................................................................22
TO UPGRADE THE IP CAMERA FIRMWARE.......................................................................23
SYSTEM >GENERAL >DATE &TIME...................................................................................24
SYSTEM >USER MANAGEMENT .........................................................................................25
SYSTEM >USER MANAGEMENT .........................................................................................25
SYSTEM >NETWORK SETTING >SETTING...........................................................................27
SYSTEM >NETWORK SETTING >SEVER .............................................................................28

SYSTEM >NETWORK SETTING >DDNS.............................................................................29
SYSTEM >NETWORK SETTING >OTHER 1..........................................................................31
SYSTEM >NETWORK SETTING >OTHER 2..........................................................................33
SYSTEM >NETWORK SETTING >IPV6................................................................................37
SYSTEM >ADVANCE >HTTPS..........................................................................................38
SYSTEM >ADVANCE >SNMP ...........................................................................................40
SYSTEM >ADVANCE >ACCESS LIST ...................................................................................42
SYSTEM >ADVANCE >QOS/DSCP ...................................................................................43
SYSTEM >IMAGE..............................................................................................................44
SYSTEM >IMAGE>OSD ...................................................................................................44
SYSTEM >IMAGE >PREFERENCE.......................................................................................45
SYSTEM >IMAGE>ADVANCED ...........................................................................................46
SYSTEM >IMAGE>PRIVACY MASK .....................................................................................48
SYSTEM >VIDEO STREAM >GENERAL ...............................................................................49
SYSTEM >VIDEO STREAM >STREAM1...............................................................................52
SYSTEM >VIDEO STREAM >STREAM2...............................................................................54
SYSTEM >VIDEO STREAM >STREAM3...............................................................................56
SYSTEM >AUDIO..............................................................................................................57
SYSTEM >SD CARD.........................................................................................................58
EVENT >ARRANGEMENT >MOTION....................................................................................59
EVENT >ARRANGEMENT >PREFERENCE ............................................................................60
EVENT >SCHEDULE .........................................................................................................63
STATUS INFORMATION .......................................................................................................65
NETWORK CONFIGURATION..........................................................................................66

FACTORY DEFAULT .........................................................................................................68
TROUBLESHOOTING.......................................................................................................69
APPENDIX.........................................................................................................................70
FCC NOTICE (CLASS A)...................................................................................................71
COPYRIGHT......................................................................................................................71
NOTICE..............................................................................................................................71
WARNING..........................................................................................................................71
LIMITED WARRANTY .......................................................................................................72
LIMITATIONS OF WARRANTY .........................................................................................72
DISCLAIMER OF WARRANTY .........................................................................................72
LIMITATION OF LIABILITY ...............................................................................................73
GOVERNING LAW AND YOUR RIGHTS ..........................................................................73

1
Product Specifications
Full HD 1080P Real Time
IK10/ IP66
3D+2D Digital Noise Reduction
Power over Ethernet (PoE)
H.264/MJPEG Compression
SD card backup (SD card is not included)
2-way audio
Digital Wide Dynamic Range
Power over EthernetAvailable
SDK for software integration
IR LED Built-in 15MAvailable
Free bundled 32-CH AVer NXU Lite recording software

2
Specifications
Hardware
CPU
Multimedia SoC
DDR2
256MB
Flash
16M
Image sensor
1/2.7” CMOS (2 Megapixel)
Mini. illumination
Color : 0.14 Lux @ F1.4
B / W: 0 Lux @ F1.4(IR LED on)
Lens Type
Vari-focal 2.8~12 mm Megapixel Lens
ViewAngle
98.8°(W)~32.3°(T) Horizontal
53.2°(W)~18.1°(T) Vertical
ICR
Mechanism IR Cut Filter
LED
Built-in 18 IR LED
IR Distance-15M
I/O
1 DI /1 DO
Audio
G.711(64K) and G.726(32K,24K) audio compression
Input : External Audio in
Output: External Line out
Support 2-way audio
Power Over Ethernet
Yes
Power Consumption
DC 12V Max: 3.84W(IR ON), 2.52W(IR OFF)
PoE Max: 4.8W(IR ON), 3.36W(IR OFF)
Operation Temperature
-10°C ~ 50°C
Dimensions
140mm x 130mm
Weight
1300g
Network
Ethernet
10/100 Base-T
Network Protocol
IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP, Access
list, RTSP, TCP/ IP, UDP, SMTP, FTP, PPPoE, DHCP,
DDNS, NTP, UPnP, 3GPP, SAMBA, Bonjour

3
System
Video Resolution
1920x1080@30fps,1280x960@30fps,1280x720@30fps,
800x600@30fps,640x480@30fps, 320x240@30fps,
176x144@30fps
Video Adjust
Brightness, Contrast, Hue, Saturation, Sharpness,AGC,
Shutter Time, Sense-Up, D-WDR, Lens Distortion
Correction, Flip, Mirror, Red Gain and Blue Gain,
De-noise, Anti-fog
Triple Streaming
Yes
Image snapshot
Yes
Full screen monitoring
Yes
Privacy Mask
Yes, 5 different areas
Compression format
H.264/ JPEG
Video bitrate adjust
CBR, VBR
Motion Detection
Yes, 3 different areas
Triggered action
Mail, FTP, Save to SD card, Samba
Security
Password protection, IP address filtering, HTTPS
encrypted data transmission, QoS/DSCP
Firmware upgrade
HTTP mode, can be upgraded remotely
Simultaneous connection
Up to 10
MicroSD/SDHC card management
Recording trigger
Motion Detection, IP Check, Network Status (wire
Connection only), Schedule, Alarm
Video format
AVI, JPEG
Video playback
Yes
Delete files
Yes

4
Web browsing requirement
OS
Windows®XP (32-bit), 7 (32/64-bit)
Microsoft®IE 6.0 or above (32-bit only)
Hardware Suggested
Intel®Dual Core 2.53GHz, RAM: 1024MB, Graphics
Card: 128MB
Mobil support
iOS 4.3 or above,Android 1.6 or above.
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.

5
Package contents
Item
Descriptions
1. FV2026
2. Power adapter(Option)
3. Hex wrench
4. Star Wrench
5. Screws
6. O-ring
7. Wall plug

6
8. CD (User’s Manual and Quick Guide, NVR
software included)
**If any of the above items are missing, please contact your dealer immediately.

7
Product Installation
Monitor Setting
1. Right-click on the desktop. Select “ Properties”
2. Change “Color quality” to “Highest (32-bit)”.

8
Hardware Installation
1. Connector Instruction
Remove the dome cover, and you will see the structure as below.
[Note] TV’s resistance is 75ohm(±10%)
Connect power adaptor, then connect the IP camera to PC or network. Set up the network
configurations according to the network environment.
The following picture shows a DC 12V connector for adapter jack plug.

9
Power Over Ethernet (PoE)
Set up the IP camera through Power over Ethernet (PoE). PoE is a technology that integrates power
into a standard LAN infrastructure. It enables power to be provided to the network device, such as an
IP camera, using the same cable as that used for network connections. It eliminates the need for
power outlets at the camera locations.
[Note] 802.3af, 15.4W PoE Switch is recommended.
Ethernet
PoE Switch
PoE IP Camera
PoE IP Camera
Ethernet Cable
Ethernet Cable

10
IP Assignment
There are two ways to find IP Cameras:
Finding IP Camera by using the “NXU Lite recording software”
Finding IP Camera by using the “AVer IPCam Utility”
Finding IP Camera by using “NXU Lite recording software”
1. The NXU Lite software is in the attached software CD. Before launching it, please install the
software first. During the installation process, users will be required to input a User name and
Password for login NXU Lite system. Users can define the User name and Password as desired.
Please refer to the NXU Lite user manual for detailed installation instructions.
2. To run the application, double-click on your PC desktop or click Start > Programs > DVR >
NXU Lite. For security purposes, some of the features require you to enter the User name and
Password before it can be accessed. When the Authorization dialog box appears, key in your User
ID and Password. (If this is the first time, enter the one you have registered when installing the
software.
Click it to call out the
virtual keyboard.

11
3. Click the “Setup”button.
4. Click the “Add IPCam”button.
5. Select the “IP Camera”item.

12
6. Enter IP Camera’s ID and Password (default is admin/admin) and click “Auto Search”to find
camera.
7. In the Search Result window, click the IP camera model that the user has purchased (Please
ignore ONVIF connection item); the camera is in red text that is configurable. Users can click on
the camera in the red text and configure the IP camera’s settings; even if the IP camera is not in
the same IP segment. Press “OK”to go back to the previous screen and press ”Connect”to start
live view.
Click the IP camera model
that user has purchased (ex:
FV2026).
Please ignore ONVIF
protocol selection; NXU Lite
doesn’t support ONVIF
connection.

13
Finding IP Camera by using “AVer IPCam Utility”
1. Use the software, “AVer IPCam Utility” to assign the IP address of the IP camera. The software is
in the attached software CD.
2. Run the IPCam Utility
3. Select the proper network adapter and click [Search] to begin searching.
4. Select and double click the IP camera you want to access. If you want to change the settings of the
selected IP camera, enter the user ID, correct password, and change the settings and then click
Apply button. This will change the setting and rescan the network again.

14
5. The IE browser will open and direct you to the IP camera login page. This requires IPViewer.ocx to
run. If the IE ActiveX warning message appears, click to allow running the add-on.
[Note]
The default IP address is: 192.168.1.168
The default ID and Password are both ”admin”.
You can’t enter a device name in Chinese or any other special characters (' " \ & ^).
Gateway number can’t be “0”.
IP camera device name should be less than 30 digits
Default ID: admin
Default Password: admin
