Avery Dennison SNAP 700 User manual

1
2
Reference Guide 3
4
5
FEATURE SUMMARY..................................................................................................................................2 6
DETAILED PRINTER FEATURE REVIEW - PRINTER...............................................................................3 7
PRINTER ITEM #DECISION MATRIX...............................................................................................................5 8
CONNECTIVITY ............................................................................................................................................6 9
SENSORS....................................................................................................................................................7 10
REMOTE PANEL...........................................................................................................................................8 11
VERIFIER.....................................................................................................................................................9 12
STAND-ALONE EQUIPMENT -UNWIND .........................................................................................................10 13
STAND-ALONE EQUIPMENT –SONIC KNIFE .................................................................................................11 14
OTHER PRINTER OPTIONS .........................................................................................................................12 15
OTHER EQUIPMENT ...................................................................................................................................13 16
DOCUMENTATION ......................................................................................................................................14 17
REPLACEMENT ITEMS ................................................................................................................................15 18
CHECK OUT...............................................................................................................................................16 19
SPECIAL CONFIGURATIONS........................................................................................................................17 20
APPENDIX A –ON-LINE CONFIGURATION AND QUOTING.................................................................18 21
ON-LINE CONFIGURATION..........................................................................................................................18 22
RFQ –REQUEST FOR QUOTE....................................................................................................................19 23
APPENDIX B - SELECTING THE PRINTING SYSTEM............................................................................20 24
APPENDIX C –PRINTER SPECIFICATIONS...........................................................................................22 25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
March 25, 2011 40
SNAPTM 700 Thermal Transfer Printer
Machine Guide

SNAP 700 Reference Guide
Avery Dennison Page 2
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
41
Feature Summary 42
43
See the explanations and item numbers for the features below by locating the corresponding 44
paragraph numbers. For example, if you want more information on ―Ink Ribbons‖, find 45
paragraph 6.: 46
47
48
49
50
51
Print Width –
5‖ (127mm)
means wider
tickets and more
productivity.
Connectivity –A
variety of options
available including serial,
Ethernet, and USB
(option).
Stock Unwind –
creates variable
back tension for
better stock tracking
and decurling. Self
centering.
Decurling –Back
tension plus back
bending removes curl
from paper stock (not
PS or fabric) for better
quality output.
Self
Centering –
Using an
easy knob,
align the
stock for
better output
and printhead
wear.
Ink Ribbons –Easy
loading, easy centering,
positive control over
unwind and rewind.
Means fewer wrinkles
and higher quality
output.
Registration
Sensors –Senses
pre-printed marks or
holes in the stock for
accurate print
placement. Adjustable
across web.
Easily Accessible
Printheads –Easier access
means printheads can be
cleaned more often leading to
better print quality and longer
life. Easy change means better
productivity.
Near Edge
Printheads –High
speed and excellent
print quality from near
edge inks. However,
still runs less
expensive flat head ink
at slower speeds.
Integrated
Cutter –Cutter
included with printer
purchase means no
post processing.
Down Stacker
–Simple, easy to
use stacker.
Barcode Verifier –
Option, provides peace
of mind by stopping the
printer for bad
barcodes.
Control Panel –
Easy buttons and
lights. Voice prompts.
More information
through PCMate.
Software –
PCMate Platinum is
bundled with the
printer and provides
control and
adjustments.
Stand-alone
Equipment
10 - Installation
11 - Packaging
12 - Decision Matrix
21 - 20‖ Unwind
22 - Sonic Knife
28 - Rewinder
29 - Manual
33 - Spare Parts
17,18, 19 –
Remote Panel
13 - USB
14 - Ethernet
15,16
2,3
1
20
24,27
8 - Short feed
6
25
4 - Voltage
5 - Power cord
7 - Chinese
9 - RFID
23 –Green Platen
26 - Slitter
30
31
32

SNAP 700 Reference Guide
Avery Dennison Page 3
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Detailed Printer Feature Review - Printer 52
53
54
1. SNAP 700 –5‖ (127mm) print width, multimedia printer (SNAP 500 is 2‖/51mm fabric only). 55
The standard printer includes a cutter and down-stacker. 56
57
 Decision
See matrix below for item numbers
Select this option if….
Printing more than fabrics, wider than 2‖
Reason not to select . . .
SNAP 500 is less expensive and less complex
Upgrade in field?...
No
58
59
2. Number of heads –1/1 or 1/0. 1/0 is a single head machine, 1/1 is a two-headed machine 60
with a head for each side. 61
62
 Decision
1/1 –2 sided printing
Select this option if….
Printing on 2 sides
Reason not to select . . .
Expensive, not necessary for a vast majority of tag and
sticker applications
Upgrade in field?...
No
63
64
3. 305 dpi –305 dots for every inch of printhead. This is the only option available. 65
66
67
4. Voltage –115/230V –The printer can handle either voltage. You have to tell the factory 68
which one to install. Voltage also determines power cord, see below. 69
70
71
5. Power cord –is determined by the voltage selected. 115V models will get a US power cord. 72
230V models get no power cord. Chinese models get a Chinese power cord. 73
74
75
6. Ink Arbors –The SNAP 700 uses a different ink arbor system than the SNAP 500. 76
Therefore, there is no need to specify whether the ink widths are in inches or mms as 77
you have to specify with the SNAP 500. 78
79
Note: Contact your local customer service to ensure you are using the correct thermal transfer 80
ink ribbon and care label and paper or pressure sensitive stocks. 81
82
83
7. Chinese model –any item number with ―CHN‖ will have a Chinese power cord and 84
documentation in Chinese. Order these models for shipment to factories in mainland 85
China. Hong Kong is not considered mainland China. 86
87
 Decision
Chinese Model
Select this option if….
Installing machine in China
Reason not to select . . .
Not installing in China
Upgrade in field?...
No
88
89

SNAP 700 Reference Guide
Avery Dennison Page 4
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
90
8. Short feed option –a special part that allows the printer to cut shorter labels. 91
92
Standard machine –Minimum is 1-1/6‖ or 27mm 93
Short feed option –Minimum is 5/8‖ or 16mm. 94
95
 Decision
Short feed option
Select this option if….
Need to print tags or labels less than 1-1/6‖ or 27mm
Reason not to select . . .
Expensive, unnecessary if not doing short labels
Upgrade in field?...
Yes, adds expense –Item # 05620057
96
97
9. RFID –the SNAP 700 can be configured with an RFID writer/reader. This comes in three 98
configurations: 99
US/Canada configuration: FCC 902-928 MHz 100
EU configuration: ETSI 865-868MHz 101
China configuration: 920.5 - 924.5MHz. 102
103
 Decision
RFID Option
Select this option if….
Need RFID
Reason not to select . . .
Expensive, unnecessary if not doing RFID
Upgrade in field?...
Yes, adds expense
05620009-x US/Canada
05620021-x Europe
05620038-x China
104
105
10. Installation –Installation charges and policies vary globally. In the US, installation is quoted 106
by field service. Contact your local office to determine the installation charges and 107
policies. 108
109
110
11. Special Packing –If your customer requires special packing requirements, you must specify 111
those at the time of your order. There may be an expense to this special packaging 112
request. Use the item number 05SPECIALPACK for getting those requests quoted. 113
114
115
116
117

SNAP 700 Reference Guide
Avery Dennison Page 5
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Printer Item # Decision Matrix 118
119
12. Decision Matrix –Select the item number for the appropriate requirements. 120
121
Note: The ―-x‖ at the end of any item number is the release number. As features are added to 122
the standard printer model, a new item number is required. Sayre handles this 123
requirement by using the same item number and appending ―-1‖, or ―-2‖ etc. Always 124
check the on-line configuration tool for the latest item number before placing your order. 125
126
All these models come with a knife and down-stacker. 127
128
129
Item #
SNAP 700
305 dpi
Heads -1/0
Heads -1/1
Chinese
Short feed
RFID-US
RFID-EUR
RFID-CN
05620002-x
05620004-x
05620019CHN-x
05620018CHN-x
05620070-x
05620071-x
05620073CHN-x
05620072CHN-x
05620025-x
05620026-x
05620027-x
05620028-x
05620042CHN-x
05620043CHN-x
130

SNAP 700 Reference Guide
Avery Dennison Page 6
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Connectivity 131
132
The SNAP 700 comes with a serial port for connecting to the PC. Other options are available for 133
connecting to the PC. 134
135
13. USB –Most PCs do not have serial ports but do have USB ports. Although the printer has a 136
USB port, it is not available for downloading data. The PC must be within 5 meters from 137
the printer. 138
139
 Decision
USB Option
Select this option if….
Need to download data to the printer using USB, no serial
port available on the PC.
Reason not to select . . .
Using some other method, either serial or Ethernet. USB
adds expense if selected and not used.
Upgrade in field?...
Yes
140
141
USB Board –This is a PC board which plugs into the motherboard of the printer and accepts 142
the USB cable from the PC. 143
144
 Decision
05580033 –USB Board Option
Select this option if….
Faster download speeds.
Reason not to select . . .
The USB to serial converter is much less expensive. It
operates at 115kByes which is fast enough for most tag
and care label applications.
Do not need USB communications.
Upgrade in field?...
Yes –requires service to install.
145
USB to serial adapter –Item # 05581173 This plugs into the PC and converts the cable to a 146
serial plug which can then connect to the printer. This adapter comes with software to 147
redirect a COM port to USB so PCMate can find it. 148
149
 Decision
05581173 –USB to Serial Adapter
Select this option if….
Want a less expensive USB option.
Reason not to select . . .
Do not need USB communications.
Require faster download speeds.
Upgrade in field?...
Yes –same item number. Requires a driver to be installed
on the PC.
150
151
152
14. Ethernet –This option allows the printer to connect the factory networks. The Ethernet port 153
on the motherboard of the printer is not available. 154
155
 Decision
05591105 –Ethernet Board Option
Select this option if….
Want Ethernet connectivity
Reason not to select . . .
Using serial or USB
Upgrade in field?...
Yes
156
157

SNAP 700 Reference Guide
Avery Dennison Page 7
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Sensors 158
159
The SNAP 700 comes with the following sensors standard: 160
Top reflective –detects a high-contrast (black on white) mark or logo on the top of 161
the stock 162
Bottom reflective –detects a high-contrast (black on white) mark or log on the bottom 163
of the stock 164
Hole/slot –detects a hole anywhere on the web or a slot on either edge of the web. 165
The sensors are adjustable across the entire web. 166
167
Specification: The pre-printed sensemark needs to have a minimum size of 0.33‖ (8.4mm) x 168
0.125‖ (3.2mm) with a minimum of 0.4‖ (10mm) white space prior to the mark. 169
170
171
172
Other sensor options are available: 173
174
15. Top Contrast –This allows for the printer to sense marks with less contrast that black on 175
white. It may also work with color marks. Testing is required for qualification. 176
177
 Decision
05620006-x –Top Contrast Sensor
Select this option if….
Need sensing on lighter sense marks
Reason not to select . . .
Using a hole, slot, or black on white sensemark. This adds
expense.
Upgrade in field?...
Yes - 05620006-x
178
179
180
181
16. Top Color –This allows for the printer to sense marks with colors, usually for care label 182
applications with less contrast that black on white. Testing is required for 183
qualification. 184
185
 Decision
056200076-x –Top Color Sensor
Select this option if….
Need sensing on colors
Reason not to select . . .
Using a hole, slot, or black on white sensemark. This adds
expense.
Upgrade in field?...
Yes - 05620007-x
186
187
188

SNAP 700 Reference Guide
Avery Dennison Page 8
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Remote Panel 189
190
The SNAP 700 has a very simple printer control panel on the machine. It consists of 2 buttons 191
and 4 indicator lights. More complicated adjustments and information about the printer 192
are available on the ―Virtual Control Panel.‖ This panel appears when the printer is 193
connected to PCMate. 194
195
Other adjustments will be available through the Ethernet port when the printer web server is 196
introduced. This feature is not available as of November 16, 2010. 197
198
If your customer is not using PCMate but wants to make adjustments to the printer, then 199
recommend the ―Remote Control Module.‖ This module consists of a panel that plugs 200
into the printer and internal cabling to attach the plug to the motherboard. This cable is 201
not standard because it adds unnecessary cost. 202
203
Your customer should only require 1 panel for a print room and one cable for each printer. 204
205
17. Remote Panel –Factory installed panel and harness 206
207
208
 Decision
05580026 –Remote Panel and Harness
Select this option if….
Need both the panel and the option for a single printer in a
print room.
Reason not to select . . .
Using PCMate and the Virtual Control Panel
Upgrade in field?...
Yes –same item number
209
210
211
18. Remote Panel –Panel only –Item # 05580022 212
213
214
 Decision
05580022 –Remote Panel only
Select this option if….
Already have the internal cable but only want the panel
Reason not to select . . .
Using PCMate and the Virtual Control Panel
Upgrade in field?...
Yes –same item number
215
216
217
19. Remote Panel –Internal cable, factory install 218
219
220
 Decision
05580019F –Remote Panel Harness only
Select this option if….
Already have a panel and only want the harness.
Reason not to select . . .
Using PCMate and the Virtual Control Panel
Upgrade in field?...
Yes –05580019K, same as 05580019F but includes
documentation. Requires service to install harness.
221
222

SNAP 700 Reference Guide
Avery Dennison Page 9
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Verifier 223
224
The SNAP 700 produces barcodes. Usually there is not problem with producing a barcode 225
because the printer will not print a barcode unless it is correct. Problems can occur if: 226
Dot out on a printhead –the printer is not able to create the correct width bars. The 227
printer does not have a way to detect this condition. 228
Ink or ribbon wrinkle –if the ribbon is wrinkling such that large gaps appear in the 229
barcode, then the barcode will not scan properly. 230
Bad stock or ink –If the stock is dirty or dusty or the ribbon has a transfer problem, the 231
barcode may not print correctly 232
Contrast adjustment –if the contrast on the printer is too low or too high, then the 233
barcode may not print correctly 234
235
Proper maintenance and cleaning of the printer and printhead can avoid most of the issues 236
listed above. 237
238
Bad barcodes can lead to chargebacks. Many print room supervisors want the peace of mind of 239
knowing that every barcode has been scanned. 240
241
242
20. Barcode Verifier –The barcode verifier option includes a verifier device, mounting bracket 243
and internal connector cable. These items are not on the standard printer because of 244
cost. 245
246
 Decision
05620008F-x –Barcode Verifier
Select this option if….
Wanting the peace of mind of scanning every barcode.
Reason not to select . . .
Not printing barcodes
Using some other method of assuring barcode quality.
Extra expense
Upgrade in field?...
Yes –Item # 05620008-x
247
248

SNAP 700 Reference Guide
Avery Dennison Page 10
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Stand-alone Equipment - Unwind 249
250
The SNAP 700 can handle an 11.8‖ (290mm) supply stock roll. Some print rooms want more, 251
particularly if they are printing and commissioning RFID. A stand-alone unwind device 252
will handle 20‖ (508mm) rolls. This option includes a switch for the stock arbor to rotate 253
backwards. 254
255
256
21. 20‖ Unwind –includes a 1.5‖ (38mm) turn roller 257
258
 Decision
05620011 –20” Unwind – non RFID
Select this option if….
Want to handle large supply rolls
Reason not to select . . .
Do not need large rolls
RFID (use next item)
Upgrade in field?...
Yes –same item since this is a stand alone item
259
For Service bureaus only: 260
261
There is a clean roller kit available to Service Bureaus only. This part removes dust and 262
dirt from the base stock. Item # 05620015. 263
264
265
266
20‖ RFID Unwind –includes a 3‖ (76mm) turn roller which protects the RFID inlay that may 267
be damaged by sharp corner turns. 268
269
 Decision
05620044 –20” Unwind - RFID
Select this option if….
Want to handle large RFID supply rolls
Reason not to select . . .
Do not need large rolls
RFID (use next item)
Upgrade in field?...
Yes –to convert a 20‖ unwind in the field with a 1.5‖
(38mm) turn roller to a 3‖ (76mm) turn roller, use Item #
05620053
270
For Service bureaus only: 271
272
20‖ RFID Unwind with 3‖ (76mm) turn and clean rollers – Item # 05620045 273
Clean rollers upgrade to a 20‖ unwind with the 3‖ (76mm) turn – Item # 05620046 274
Clean roller and 3‖ upgrade for a 20‖ unwind with only 1.5mm turn – Item # 05620054 275
276
277

SNAP 700 Reference Guide
Avery Dennison Page 11
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
278
Stand-alone Equipment –Sonic Knife 279
280
The SNAP 700 prints woven edge tape. This tape will fray if cut with the standard knife on the 281
printer and the ends are not sewn in. To prevent this fraying, the printer must cut with a 282
sonic knife option. 283
284
If your customer is only printing woven edge tape, select the SNAP 500 with the Sonic Knife 285
option instead. This printer is less expensive and less complicated than the SNAP 700. 286
287
22. Sonic Knife Option –includes a 1.5‖ (38mm) turn roller 288
289
 Decision
05700070 (115V) 05700075 (230V) –Sonic Knife
Select this option if….
Want to print woven edge tape that will not have both ends
sewn in along with hang tags and stickers.
Want to print other material >2‖ (51mm)
Reason not to select . . .
Only printing woven edge tape, select the SNAP 500
instead.
Upgrade in field...
Yes –same item. Service required to install the harness
and set up the sonic knife.
290
Note: If you are installing a sonic knife on the SNAP 700, you must order a SNAP 500 down 291
stacker. The down stacker on the SNAP 700 will not fit. 292
293
05580005 - SNAP 600/600 down stacker 294
295
296

SNAP 700 Reference Guide
Avery Dennison Page 12
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Other Printer Options 297
298
23. Green Platen Roller –The SNAP 700 comes with red platen rollers. Green platen rollers 299
help print on uncoated, rougher stocks. 300
301
 Decision
05625045 –Green Platen Roller
Select this option if….
Need to improve print quality on uncoated or rougher
stocks.
Reason not to select . . .
Extra expense. May not need to print uncoated stocks or
are satisfied with print quality.
Upgrade in field?...
Yes –this can be changed by the operator so no
installation is required.
302
303
24. 8‖ (203mm) Label Stacker Platform –The SNAP 700 comes with a 6‖ (152mm) label stacker 304
platform. This option allows the stacker to handle longer tags, stickers, or care labels. 305
306
 Decision
05628007 –8” Label Stacker Platform
Select this option if….
Need to stack longer tags, stickers, or care labels
Reason not to select . . .
Extra expense. Not printing longer than 6‖
Upgrade in field?...
Yes –same item number.
307
308
25. 3‖ or 4‖ (76 or102mm) Stock Arbor Modification –The SNAP 700 can handle 3‖ (76mm) 309
stock cores. Some stock is on 4‖ (102mm) cores. This modification allows the printer to 310
handle these cores. This option is standard on SNAP 700 RFID models. 311
312
 Decision
05620017 –3” or 4” Stock Arbor Modification
Select this option if….
Need to handle 3‖ or 4‖ stock cores
Reason not to select . . .
Extra expense. Only handling 3‖ stock cores
Upgrade in field?...
Yes –same item number. Requires service to install.
313
26. In-Line Slitter Option –To improve productivity, the SNAP 700 can print 2 or 3 tags or 314
stickers at one time. This is known as ―number up‖ or ―number across‖. The tags are 315
usually held together with a small tab. Some customers do not like this tab. So the 316
printer comes with an option to slit the tags apart. 317
318
This option is only available on a one headed or SNAP 700 1/0 machine. 319
320
 Decision
05627191 –In-Line Slitter option
Select this option if….
Need to print multiple tag or stickers at a time and the
customer does not like the small tab that held the tickets
together.
Reason not to select . . .
Extra expense.
Does not work for care labels
Need to print on 2 sides.
Upgrade in field?...
Yes –same item number. Requires service to install.
321
322

SNAP 700 Reference Guide
Avery Dennison Page 13
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Other Equipment 323
324
27. Quick Change Stacker Trays –The SNAP 700 must stop to remove tags from the stacker. 325
While this is requires a short time, some print room operators want better productivity. 326
Using removable stacker trays will allow the operator to remove a stack of tags or label 327
quickly and work on them off-line. 328
329
 Decision
05628091 –Quick change, removable stacker tray
Select this option if….
Improve productivity by removing tags or labels from the
stacker quickly and minimizing down time on the printer
Reason not to select . . .
Extra expense. May not need extra productivity.
Upgrade in field?...
Yes –this can be changed by the operator so no
installation is required.
330
Note: The item number is for 1 tray. Consider ordering 2 or 3 trays for best usage. 331
332
333
28. Rewinder 334
335
 Decision
05110042 –CAT-2 Rewinder
Select this option if….
Want to rewind stickers or care label stock and not cut into
single, finished output.
Reason not to select . . .
Extra expense.
Upgrade in field?...
Yes –this can be changed by the operator so no
installation is required. The operator either disables the
knife in the format or the Virtual Control Panel.
336
337

SNAP 700 Reference Guide
Avery Dennison Page 14
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Documentation 338
339
29. Manual - The printer comes with PCMate software on a CD. Documentation is available on- 340
line for download at no charge. This is because: 341
342
Adding a paper manual to each printer wastes paper for customer ordering multiple 343
printers and only want 1 manual. 344
Shipping expense is saved with less weight. 345
The latest, most up-to-date manual is always available on line. 346
347
348
349
The manuals are available online 350
351
352
353
Go to the InfoXchange In-Plant Printing wiki, 354
355
Click on ―Engineering Manuals‖ 356
357
Then click on ―Manuals‖ 358
359
Next, click on ―700 SNAP‖ 360
361
Place your cursor over the file you want, right click and select ―Copy to…‖ or ―Save as…‖ 362
363
Enter the location on your PC. 364
365
Note: If you want a CD with the manual on it, the order Item # 05621389 366
367
30. PCMate –the tag and label printing software is also available on-line 368
369
370
371

SNAP 700 Reference Guide
Avery Dennison Page 15
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Replacement Items 372
373
31. Printhead Assembly and Cleaning Kits 374
375
05625094-x Printhead assembly for 700 376
05921341 Printhead Cleaning Kit: 1 bottle alcohol, 3 alcohol pads, 5 cotton swabs, 1 377
Velcro pad 378
05921341K Starter Printhead Cleaning Kit: Static Wrist Strap, 2 Anti-Static Gloves, 1 379
bottle alcohol, 3 alcohol pads, 5 cotton swabs, 1 Velcro pad 380
381
32. Replacement Knife 382
383
05627092 Replacement rotary knife kit, for 700 (blades and springs, not a module 384
385
33. Spare Parts Kit 386
387
05620010 Spare parts kit: 2 Printhead, 2 knife sets, 4 rollers, 10 springs, 10 bearings, 1 388
bracket, 1 sensor, 27 clip/ring, 3 gloves, 11 fuse/brushes 389
390
391

SNAP 700 Reference Guide
Avery Dennison Page 16
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Check out 392
393
To ensure that the printer will work when installed in the customer’s factory, the SNAP 700 394
should be checked out using the same conditions as the factory. 395
396
Ensure that you inform the factory how to check out the printer system you have ordered using 397
the correct check boxes on the order form. 398
399
400
CHECK OUT INFORMATION - for SNAP 700 selected above:
See order notes for other check out instruction and or supplies
Synchronize this shipment with supplies order
Check out with RFID
Check out with Verifier
Check out with Remote Panel
Check out with 20 inch Unwind
Check out with Sonic Knife
Check Out with SS Finisher
401
402
403

SNAP 700 Reference Guide
Avery Dennison Page 17
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Special Configurations 404
405
Some locations want special SNAP 700 configurations for various reasons. 406
407
These are generally not readily available. Please contact customer service or program support if 408
you want to order one of these models. 409
410
411
Item Number
SNAP 700
305 dpi
Heads -1/0
Heads -1/1
Knife
Down
stacker
RFID
Heat
transfer
Additional Notes
05620001-x
No
05620003-x
No
05620016-x
No
No
No internal support components
05620029-x
No
No
05620030-x
No
No
US
05620031-x
No
No
EU
05620032-x
No
No
05620033-x
No
No
US
05620034-x
No
No
EU
05620035-x
Not released, beta model only
05620036-x
No
Not released, beta model only
412

SNAP 700 Reference Guide
Avery Dennison Page 18
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
413
Appendix A –On-Line Configuration and Quoting 414
415
On-Line Configuration 416
417
Before placing an order for a machine, you have to determine the correct configuration and item 418
numbers. This manual has gone through all the options and has supplied item numbers. In 419
order to ensure you have the latest item numbers, use the on-line configuration tool. 420
421
Go to InfoXchange, In-Plant printing Solutions Information wiki. 422
423
Click on the ―Machine Configurator‖ under ―Hot Links‖ 424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
Enter username ―machines‖ and then 443
―machines‖ for the password. 444
445
446
447
448
449
450
451
452
453
454
Finally, click on ―700 SNAP‖ 455
456
457
458
459
460
461
462

SNAP 700 Reference Guide
Avery Dennison Page 19
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
463
RFQ –Request for Quote 464
465
To ensure that you are getting the machine and options you want, we request you fill out a 466
Request for Quote. This quote form is similar to the configuration page discussed above. 467
468
This requires a username and password. Contact Eric Kinsman –469
[e-mail] , copy Jeff Deery [e-mail] and Joel 470
Alexander [e-mail] for your log-in information. 471
472
For more information on how to use the RFQ tool, 473
please go to the InfoXchange In-Plant Printing Solutions wiki 474
Under ―Collateral Links‖, click on ―How To‖ 475
Click on ―How to Quote a Machine OnLine ―476
477
478
479

SNAP 700 Reference Guide
Avery Dennison Page 20
Retail Branding and Information Solutions March 25, 2011
For Official Use Only
Appendix B - Selecting the Printing System 480
481
Selecting the correct printer configuration: 482
483
1. Are you only printing care labels, less than or equal to 2‖? 484
YES: Select SNAP 500 485
NO: You required tags, RFID, pressure sensitive up to 5‖ wide -> Continue 486
487
2. How many sides do you need to print? 488
One-side only: Select SNAP 700 1/0 489
Two-sides: Select SNAP 700 1/1 490
491
3. Will the SNAP 700 be installed in China? 492
YES: Select CHN model 493
NO: Select standard model. 494
495
4. What label lengths will you required to print? 496
Greater than 1-1/16‖: Select SNAP 700 standard model 497
Minimum length 5/8‖: Select SNAP 700 short feed option 498
499
5. Will the printer have to commission RFID tags? 500
YES: Select SNAP 700 RFID for the region you require (US, Europe, or China) 501
NO: Select SNAP 700 standard 502
503
6. How do you plan to connect the data source to the printer? 504
Serial: SNAP 700 standard 505
USB: Select USB board option or USB to serial adapter 506
Ethernet: Select Ethernet board option 507
508
7. Will you be printing materials with low contrast or color sensemarks? 509
YES: Select Top Contrast or Top Color sensor 510
NO: Use sensors already on the machine 511
512
8. Will you be using PCMate to drive the printer? 513
YES: Printer can be adjusted using the virtual control panel in PCMate. 514
NO: Select a Remote Control Panel option. Install a harness in each SNAP 700 and order 515
one panel for your print room. 516
517
9. Will you be printing barcodes? 518
YES: Order a barcode verifier option. 519
NO: Do nothing 520
521
10. Will you have stock supply rolls > 11.8‖? 522
YES: Order a 20‖ Unwind Unit. 523
NO: Do nothing 524
525
11. Will you be printing woven edge satin polyester tape that will fray if cut with the printer’s 526
knife? 527
YES: Order the Sonic Knife option or consider the SNAP 500. 528
NO: Do nothing. 529
