AVLink VGA-LDW User manual

VGA EXTENDER
VGA-LDW VGA-LDW-PRO
VGA-LDW
+
VGA-LDW
+
-PRO
VGA-ED2W/VGA-ED4W/VGA-ED8W
(Local)
VGA-RDW VGA-RDW-PRO
(Remote)
USER MANUAL V1.0

Package Contents for VGA-EDW
VGA-LDWLocalUnit
VGA-RDWRemoteUnit
1usermanual
2poweradapterDC12V
8footpads
4screws
 1 VGA 1.2M cable (HD-15 Male to Male)
Package Contents for VGA-EDW-PRO
VGA-LDW-PROLocalUnit
VGA-RDW-PRORemoteUnit
1usermanual
2poweradapterDC12V
8footpads
4screws
 1 VGA 1.2M cable (HD-15 Male to Male)
Package Contents for VGA-EDW+
VGA-LDW
+Local Unit
VGA-RDWRemoteUnit
1usermanual
2poweradapterDC12V
8footpads
4screws
1VGA1.2Mcable(HD-15MaletoMale)
Package Contents for VGA-EDW+-PRO
VGA-LDW
+-PRO Local Unit
VGA-RDW-PRORemoteUnit
1usermanual
2poweradapterDC12V
8footpads
4screws
 1 VGA 1.2M cable (HD-15 Male to Male)
Package Contents for VGA-ED2W
VGA-ED2WLocalUnit
1usermanual
1poweradapterDC12V
4footpads
2screws
 1 VGA 1.2M cable (HD-15 Male to Male)

Package Contents for VGA-ED4W
VGA-ED4WLocalUnit
1usermanual
1poweradapterDC12V
4footpads
2screws
 1 VGA 1.2M cable (HD-15 Male to Male)
Package Contents for VGA-ED8W
VGA-ED8WLocalUnit
1usermanual
1poweradapterDC12V
4footpads
2screws
 1 VGA 1.2M cable (HD-15 Male to Male)
Package Contents for VGA-RDW
VGA-RDWRemoteUnit
1usermanual
1poweradapterDC12V
4footpads
2screws
Package Contents for VGA-RDW-PRO
VGA-RDW-PRORemoteUnit
1usermanual
1poweradapterDC12V
4footpads
2screws
Any thing missed, please contact with your vendor.

Features
ThroughtheVGAExtender,youcanuseonePCtodisplayidenticalimageandextensionofVGA
signal up to 180/300 meter on monitors.
 Equalization length is adjustable.
 VGA signal gain is adjustable.
EDIDcopyfromRemotetoLocal.
**note:VGA-ED2W/VGA-ED4W/ VGA-ED8W only allow EDID copy from CAT.5 output port1.
Specifications
Function VGA-LDW VGA-RDW VGA-LDW-PRO VGA-RDW-PRO
VGA In/Out Connector HD-15 Female x 1
RJ-45 Connector 1
Max. Resolution Depends on
remote unit
1600x1200
60Hz
Depends on
remote unit 1920x1440 60Hz
Cable Distance 180 m (Max.) 300 m (Max.)
Power Adapter (Min.) DC 12V
Housing Metal
Weight 153g 155g 153g 155g
Dimensions (LxWxH) 104*59*25mm 104*59*25mm
Function VGA-LW+VGA-LW
+ -PRO VGA-ED2W VGA-ED4W VGA-ED8W
VGA In Connector HD-15 Female x 1
VGA Out Connector HD-15 Female x 1
RJ-45 Connector 1 1 2 4 8
Max. Resolution Depends on remote unit
Cable Distance 180 m
(Max.) 300 m (Max.)
Power Adapter (Min.) DC 12V
Housing Metal
Weight 288g 288g 469g 481g 653g
Dimensions (LxWxH) 129x105x25 mm 171x119x25 mm 245x119x25
mm

LOCAL FRONT VIEW
VGA-LDW/VGA-LDW-PRO
VGA-LDW+/VGA-LDW+-PRO
VGA-ED2W/VGA-ED4W
VGA-ED8W
1. CAT.5 (RJ-45 Connector)
2. Power LED
3. Power jack
LOCAL REAR VIEW
VGA-LDW/VGA-LDW-PRO
VGA-LDW+/VGA-LDW+-PRO
VGA-E2DW/VGA-E4DW
VGA-ED8W
1. VGA Input (HD-15 Female Connector)
2. VGA Output (HD-15 Female Connector)
3. Power LED
4. Power jack
REMOTE FRONT VIEW
VGA-RDW/VGA-RDW-PRO
1. Power jack
2. Power LED
3. CAT.5 (RJ-45 Connector)

REMOTE REAR VIEW
VGA-RDW/VGA-RDW-PRO
1. VGA Output (HD-15 Female Connector)
REMOTE TOP VIEW
VGA-RDW/VGA-RDW-PRO
1. EQ – Equalization length adjust (Adjust it and weak characters be sharp)
2. GAIN – Adjust brightness
Installation
1. Turn off the PC.
2. Connect VGA-Extender Local Unit HD-15 female input connector with HD-15 male to male cable
from PC.
3. Connect VGA-Extender Local Unit HD-15 female output connector with HD-15 male to male cable
from monitor.
4. Connect VGA-Extender Local and Remote Unit with CAT.5 cable.
5. Connect VGA-Extender Remote Unit HD-15 female connector with HD-15 male to male cable from
monitor.
6. Connect the power cord on each side.
7. Turn on the monitor and PC.
Auto EDID Copy Operation
When the user reconnects the CAT.5 cable between the local and remote unit, the VGA-Extender will
start to copy EDID from remote Monitor to local unit.
And local unit will save the EDID content from the remote monitor even when the VGA-Extender
re-power.
The VGA-Extender will update the EDID content, when the remote monitor’s EDID is different with the
EDID in the memory of the VGA-Extender.
**note: When remote unit connects a new monitor, it needs re-connect the VGA cable between the local
unit and PC, so that some windows system (like Windows 7…etc) start to require the EDID content
from local unit. After that, the windows update the monitor information.
*note: When there is no connection between the local and remote unit, the local unit will use the EDID
content of the local monitor to the PC.

Additional Options
Select any additional options you may require.
1. It provides perfect skew delay correction, we suggest when distances over 150M it is needed.
(ItemNo:SK-101)
Distances and Resolutions for CAT.5/5E and CAT.6 cables
50M 2048x1536
100M 1280x1024
180M 1024x768
200M 800x600
CAT.5/5E
300M 640x480
30M 1920x1440
50M 1280x1024
CAT.6
100M 800x600
PS. We suggest to use CAT.5 cable because the performance is better than others.
Wiring Information & Coding
Conductor Identification RJ45 Pin Assignment Color Code for Conductor
5 White-Blue
Pair 1 4 Blue
1 White-Orange
Pair 2 2 Orange
3 White-Green
Pair 3 6 Green
7 White-Brown
Pair 4 8 Brown
