AXE MMR-N Series User manual

Rev.10
AL1
AL2
B1
B2
B3
DIO
AXE MICROPROCESS RPM&LINE-SPEED CONTROLLER METER MMR-N Series
■Features
◎Acceptmoretypesensors(switch,encoder,proximity
switch,…etc)finishRPM/LINESPEEDcontrol
◎16BITDACanalogoutputcanbemodified
◎Accuracy0.03%F.S. ◎Twoalarmfunction
◎Inputrange(0~50KHz),Readoutrange(0~99999) ◎Man-machineinterface,easytooperate
◎Decimalpointcanbemodified ◎0.56"highlightdisplay
◎LINE-SPEEDunitcanbemodified ◎BAUDRATE:19200/9600/4800/2400
◎Inputpulseofrevolutioncanbemodified(1~99999) ◎RS485Communicationinterface,ProtocolMODBUSRTUMODE
◎Diameter(LINE-SPEED)/scale(RPM)canbemodified
(0.0001~9.9999)
◎EEPROMSaving,datasafekeepingabout10years
◎Displayavragetimescanbemodified(1~99) ◎Modifiedinsideparameter,musthavepasscode
■NameofParts
■ConnectDiagram
◎Contactinput(PNP) ◎CMOSinput(12V or 15V) ◎Sensorinput(PNP 12V)
◎Contactinput(NPN) ◎TTLinput(5V) ◎Sensorinput(NPN 12V)
■Inputfunctionjumpertable
Position 4 ON: TTL OFF:CMOS
Position 3 ON: 0~50Hz OFF:0~50KHz
Position 2 ON: PNP
Position 1 ON: NPN
Alarm Indicate

Display
BANK 1 Indicate
Parameter Enter(Function call out)
Set-value up(Scale adjustment call out)
Set-value down(Analog output adjustment call out
整
)
Cursor shift(Alarm adjustment call out)
ENT
FUNC

E
ALARM

SCALE

A-ADJ
BANK 2 Indicate
BANK 3 Indicate
Communication Indicate
RST
COM
IN
12V Inside jumper
4 3 2 1
OFF
ON
ON
OFF
COM
IN
12V
Inside jumper
4 3 2 1
OFF
OFF
ON
OFF
COM
IN
12V Inside jumper
4 3 2 1
OFF
OFF
ON
OFF
COM
IN
12V Inside jumper
4 3 2 1
OFF
OFF
OFF
ON
COM
IN
12V Inside jumper
4 3 2 1
ON
OFF
ON
OFF
COM
IN
12V Inside jumper
4 3 2 1
OFF
ON
OFF
ON
GND
GND
Sensor
Sensor
4
3
2
1

Rev.10
Key Introduce Operation Manual
 Key Function 1.In normal display,The key function is call out setting group
2.In parameter setting page,The key function is data Enter , and goto next page
 Key Function 1.In normal display,The key function is call out alarm value setting page
2.Into parameter setting page,the parameter mark&data is alternate display,If need modi
fy data can
press shift key into setting procedure,The display is lock parameter data,this time must let off key
about 0.2 sec,press again,the cursor(twinkle express)is cycle moving left.
(Key Response about 0.2
sec)
 Key Function 1.In normal display,The key function is call out adjustment display scale page
2.Into parameter setting page,the parameter mark&data is alternate display,If need modify data can
press up key into setting procedure,The display is lock parameter data,this time must let off key
about 0.2 sec,press again,the parameter data will increment. (Key Response about 0.2 sec)
 Key Function 1.In normal display,The key function is call out adjustment analog output ZERO&SPAN page
2.Into parameter setting page,the parameter mark&data is alternate display,If need modify data can
press down key into setting procedure,The display is lock parameter data,this time must let off key
about 0.2 sec,press again the parameter data will decrement. (Key Response about 0.2 sec)
 &  Key Function In setting group or setting page press  &  key return normal display,but if in setting page the
modify data will be lost
No Key in anything In setting group or setting page no key in anything about 2 minutes,return normal display,but if in
Setting page the modify data will be lost
Step Parameter Mark Description Parameter Mark Operation Manual
1
Normal display

Press  /FUNC key into P.COD setting page

2
P.COD(Pass code input page)

1.Key in 5 digit pass code with  or  or  key
2.Press  key,the pass code is right into setting group , otherwise
return normal display
3
SYS(System setting group)

ROP(Alarm setting group)

AOP (Analog output setting group)

DOP (Communication setting group)

1.Select setting group with  key
2.Press  key into setting page of selection setting group
4
SYS(System setting group)

Press  key decide SYS setting group , press  key into Dp setting page

4-1
DP(Decimal Point setting
page)Default=0

1.Decide decimal point position with  or  key (0 to 4)
2.Press  key enter data and into TYPE setting page

4-2
TYPE(Display Type)
Default=RPM

1.Decide display type with  or  key(RPM/LINE)
2.Press  key enter data,If select LINE into UNIT setting page,
otherwise into PPR setting page

4-3
UNIT(Line Speed Unit)
Default=METER

1.Decide line speed unit with  or  key(METER/FOOT/YARD)
2.Press  key enter data and into PPR setting page

4-4
PPR(Pulse Per Revolution)
Default=1

1.Decide pulse per revolution with  &  &  key(1~99999)
2.Press  key enter data and into TBASE setting page

4-5
TBASE (Sampling Time
Base)
Default=0.1

1.Decide sampling time base with  &  &  key(0.1~99.9 sec)
2.Press  key enter data and into AVG setting page

4-6
AVG (Display Average
times)
Default=1

1.Decide display average times with  &  &  key(1~99)
2.Press  key enter data and into CODE setting page

4-7
CODE(Pass Code)
Default=0

1.Decide pass code with  &  &  key(0~99999)
2.Press  key enter data and into LOCK setting page

4-8
LOCK(Panel Lock)
Default=NO

1.Decide panel lock with  &  key(NO or YES)
2.Press  key enter data and return SYS setting group

Rev.10
5 ROP(Alarm setting group)

Press  key decide ROP setting group,press 
key into ACT1 setting
page

5-1
ACT1(Alarm Active 1 setting
page )
Default =HI

1.Decide active 1 with  or  key(HI or LO)
2.Press  key enter data and into ACT2 setting page

5-2
ACT2(Alarm Active 2 setting
page )
Default =HI

1.Decide active 2 with  or  key(HI or LO)
2.Press  key enter data and into HYS1 setting page

5-3
HYS1(Alarm Hysteresis 1
setting page)
Default =0

1.Decide Hysteresis 1 with  or  or  key(0~999)
2.Press  key enter data and into HYS2 setting page

5-4
HYS2(Alarm Hysteresis 2
setting page)
Default =0

1.Decide Hysteresis 2 with  or  or  key(0~999)
2.Press  key enter data and into DEL1 setting page

5-5
DEL1(Alarm Delay 1 setting
page)
Default =0

1.Decide delay 1with  or  or  key(0~99.9 sec)
2.Press  key enter data and into DEL2 setting page

5-6
DEL2(Alarm Delay 2 setting
page)
Default = 0

1.Decide delay 2 with  or  or  key(0~99.9sec)
2.Press  key enter data and return ROP setting group
 5-7
SB(Start band)
Default = 0

1.Decide Start band with  or  or  key (0~999)
2. Press  key enter data and into SDT setting page
Note: If the input is less than this setting range, the alarm will not be
compared & act
 5-8
SDT(Start Delay Time)
Default = 0

1.Decide Start Delay Time with  or  or  key (0~99.9)
2. Press  key enter data and return ROP setting group
Note: If the input exceeds the start delay range and the delay time is
reached, the alarm resumes comparison & action
6
AOP(Analog output setting
group)

Press  key decide AOP setting group , press  key into ANLO
setting page

6-1
ANLO(A/O Zero According
to Display setting page)Value
on EEPROM reset=0

1.Decide ANLO with  or  or  key(0~99999)
2.Press  key enter data and into ANHI setting page

6-2
ANHI(A/ O Span According
to Display setting page)Value
on EEPROM reset=99999

1.Decide ANHI with  or  or  key(0~99999)
2.Press  key enter data and return AOP setting group
7
DOP(Communication setting
group)

press  key decide DOP setting group,press  key into ADDR
setting page

7-1
ADDR(Communication –Add
ress setting page )
Value on EEPROM reset=0

1.Decide address with  or  or  key(0~255)
2.Press  key enter data and into BAUD setting page

7-2
BAUD(Communication Baud
Rate setting page)Value on
EEPROM reset=19200

1.Decide baud rate with  or  key(19200,9600,4800,2400)
2.Press  key enter data and into PARI setting page

7-3
PARI(Commun
ication Parity
Check setting page)Value on
EEPROM reset=n82

1.Decide parity check with  or  key(n82,n81,even,odd)
2.Press  key enter data and return DOP setting group
Step Parameter mark description Parameter mark Operation manual
8
Normal display

Press  /ALARM key about 3 sec,into AL1 1setting page

8-1
AL1 (Alarm value 1 setting
page)
Value on EEPROM reset=0

1.Decide alarm value 1 with  or  or  key(0~99999)
2.Press  key enter data and into AL2 setting page

8-2
AL2 (Alarm value 2 setting
page)
Value on EEPROM reset=0

1.Decide alarm value 2 with  or  or  key(0~99999)
2.Press  key enter data and return normal display

Rev.10
Step Parameter mark description Parameter mark Operation manual
9 Normal display

Press  /SCALE key about 3 sec,into SCALE setting page

9-1
SCALE (Display Scale
setting page)
Value on EEPROM reset=1

1.Decide scale with  or  or  key(0.0001~9.9999)
2.Press  key enter data and return normal display
RPM(scale = 0.0001~9.9999), LINE-SPEED(rotation diameter =
0.0001~9.9999M)
Step Parameter mark description Parameter mark Operation manual
10
Normal display

Press  /A-ADJkey about 3 sec,into AZERO adjustment page

10-1
AZERO(Analog Output
Zero Adjustment page)
Value on EEPROM reset=0

1.Adjustment analog output zero with  or  or  key(±6000)
2.Press  key enter data and into ASPAN adjustment page

10-2
ASPAN(Analog Output
Span Adjustment page)
Value on EEPROM reset=0

1.Adjustment analog output span with  or  or  key(±6000)
2.Press  key enter data and return normal display
Appendix Error Mark description Error Mark Analyze & Description
1
Input over range error
detect

Input signal over range(0~50KHz)
2
Display over range error
detect

Input signal over display range(99999)


3
EEPROM error detect

1.External interference when EEPROM read/write
2.EEPROM write over 1 million times(guarantee 10 years)
Please power reset,if still display E-00,doing following step:
1.E-00 & No alternate display for inquire reset EEPROM
2.Decide Yes with or key,press key return normal display  
3.EEPROM was reset,Please follow step 1~10 set again

Rev.10
MMR-N Modbus RTU Mode Protocol Address Map
Data format 16Bit/32Bit,sign bit
8000~7FFF( –32768~32767 )/80000000~7FFFFFFF(-2147483648~2147483647)
Address Name Description Accept
0000 DP DP,inputrange0000~0004(0~4)0:10
0
,1:10
-1
,2:10
-2
,3:10
-3
,4:10
-4 R/W
0002 TYPE TYPE,inputrange0000~0001(0~1)0:RPM,1:LINE R/W
0004 UNIT UNIT,inputrange0000~0002(0~2)0:METER,1:FOOT,2:YARD
R/W
0006 TBASE TBASE,inputrange0001~03E7(1~999) R/W
0008 AVG AVG,inputrange0001~0063(0~99) R/W
000A ACT1 ACT1,inputrange0000~0001(0~1)0:HI,1:LO R/W
000C ACT2 ACT2,inputrange0000~0001(0~1)0:HI,1:LO R/W
000E HYS1 HYS1,inputrange0000~03E7(0~999) R/W
0010 HYS2 HYS2,inputrange0000~03E7(0~999) R/W
0012 DEL1 DEL1,inputrange0000~03E7(0~999) R/W
0014 DEL2 DEL2,inputrange0000~03E7(0~999) R/W
0016 ADDR ADDR,inputrange0000~00FF(0~255) R/W
0018 BAUD BAUD,inputrange0000~0003(0~3)0:19200,1:9600,2:4800,3:2400 R/W
001A PARI PARI,inputrange0000~0003(0~3)0:N82,1:N81,2:EVEN,3:ODD R/W
001C AZERO AZERO,inputrangeE890~1770(-6000~6000) R/W
001E ASPAN ASPAN,inputrangeE890~1770(-6000~6000) R/W
0020 BANK BANK,inputrange0000~0002(0~2)0:BANK0,1:BANK1,2:BANK3 R/W
0022 LOCK LOCK,inputrange0000~0001(0~1)0:NO,1:YES R/W
0024 PPR PPR,inputrange00000001~0001869F(1~99999) R/W
0028 CODE CODE,inputrange00000000~0001869F(0~99999) R/W
002C SCALE SCALE,inputrange00000001~0001869F(1~99999) R/W
0030 AL1 AL1,inputrange00000000~0001869F(0~99999) R/W
0034 AL2 AL2,inputrange00000000~0001869F(0~99999) R/W
0038 ANLO ANLO,inputrange00000000~0001869F(0~99999) R/W
003C ANHI ANHI,inputrange00000000~0001869F(0~99999) R/W
0040 DISPLAY Displayvaluerange00000000~0001869F(0~99999) R
0044 SB Startband,inputrange0000~03E7(0~999) R/W
0046 SDT StartDelayTime,inputrange0000~03E7(0~999) R/W
