AIE100-ONX Series
Edge AI Embedded System
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, or any liability arising from such uses.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update any information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted in any
forms or by any means, electronic, mechanical, photocopying, recording, among others, without
prior written permissions of Axiomtek Co., Ltd.
©Copyright 2023 Axiomtek Co., Ltd.
All Rights Reserved
May 2023, Version A1
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. The AIE100-ONX does not come with an operating system which must be loaded first
before installation of any software into the computer.
2. Be sure to ground yourself to prevent static charge when installing any internal
components. Use a wrist grounding strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
3. Disconnect the power cord from the AIE100-ONX prior to making any installation. Be sure
both the system and all external devices are turned OFF. Sudden surge of power could
ruin sensitive components. Make sure the AIE100-ONX is properly grounded.
4. Make sure the voltage of the power source is correct before connecting it to any power
outlet.
5. Turn Off system power before cleaning. Clean the system using a cloth only. Do not spray
any liquid cleaner directly onto the screen.
6. Do not leave equipment in an uncontrolled environment where the storage temperature is
below -40℃or above 80℃as it may damage the equipment.
7. Do not open the system’s back cover. If opening the cover for maintenance is a must, only
a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
⚫Before handling a board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. This will help discharge any static electricity on human
body.
⚫When handling boards and components, wear a wrist grounding strap available from
most electronic component stores.
8. Note!! Caution with touch! AIE100-ONX will be hot when it's on.

iv
Classification
1. Degree of production against electric shock: not classified
2. Degree of protection against ingress of water: IP40 (IP42 rating by optional cover kit)
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture with air,
oxygen or nitrous oxide.
4. Mode of operation: Continuous
Note: All of I/O connectors should be connected with corresponding cables when the
system is operating with IP40 & IP42 rated definition. If some of I/O ports are not be
used or connected during operation, users must to connect optional I/O covers to
meet IP40 & IP42 standard.

v
General Cleaning Tips
Please keep the following precautions in mind while understanding the details fully before and
during any cleaning of the computer and any components within.
A piece of dry cloth is ideal to clean the device.
1. Be cautious of any tiny removable components when using a vacuum cleaner to absorb
dirt on the floor.
2. Turn the system off before clean up the computer or any components within.
3. Avoid dropping any components inside the computer or getting circuit board damp or wet.
4. For cleaning, be cautious of all kinds of cleaning solvents or chemicals which may cause
allergy to certain individuals.
5. Keep foods, drinks or cigarettes away from the computer.
Cleaning Tools:
Although many companies have created products to help improve the process of cleaning
computer and peripherals, users can also use house hold items accordingly for cleaning. Listed
below are items available for cleaning computer or computer peripherals.
Pay special attention to components requiring designated products for cleaning as
mentioned below.
⚫Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although
paper towels or tissues can be used on most hardware as well, it is recommended to use
a piece of cloth.
⚫Water or rubbing alcohol: A piece of cloth may be somewhat moistened with water or
rubbing alcohol before being rubbed on the computer. Unknown solvents may be harmful
to plastic parts.
⚫Absorb dust, dirt, hair, cigarette and other particles outside of a computer can be one of
the best methods of cleaning a computer. Over time these items may restrict the airflow
in a computer and cause circuitry to corrode.
⚫Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are applicable to
reach areas in keyboard, mouse and other areas.
⚫Foam swabs: If possible, it is better to use lint free swabs such as foam swabs.
Note: It is strongly recommended that customer should shut down the system before
start to clean any single components.
Please follow the steps below:
1.Close all application programs;
2.Close operating software;
3.Turn off power switch;
4.Remove all devices;
5.Pull out power cable.

vi
Scrap Computer Recycling
If the computer equipment’s needs the maintenance or are beyond repair, we strongly
recommended that you should inform your Axiomtek distributor as soon as possible for the
suitable solution. For the computers that are no longer useful or no longer working well, please
contact your Axiomtek distributor for recycling and we will make the proper arrangement.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®and Pentium®are registered trademarks of Intel Corporation.
NVIDIA®and Jetsonare registered trademarks of NVIDIA Corporation.
MS-DOS, Microsoft C and QuickBasic are trademarks of Microsoft Corporation.
Windows 10, Linux and other brand names and trademarks are the properties and
registered brands of their respective owners.

vii
Table of Contents
Disclaimers............................................................................................................. ii
Safety Precautions................................................................................................ iii
Classification......................................................................................................... iv
General Cleaning Tips ...........................................................................................v
Scrap Computer Recycling................................................................................... vi
SECTION 1 INTRODUCTION.........................................................................1
1.1 General Description........................................................................... 1
1.2 System Specifications.......................................................................2
1.2.1 Product Specification......................................................................................2
1.2.2 I/O System ........................................................................................................3
1.2.3 System Specification.......................................................................................4
1.3 Dimensions ........................................................................................5
1.3.1 System Dimension...........................................................................................5
1.3.2 Wall mount Bracket Dimension (Screw: M3 *4L 4pcs) ................................6
1.3.3Din-rail mount Bracket Dimension (Screw: M3 *4L 8pcs) ...........................7
1.3.4VESA arm mount Bracket Dimension (Screw: M3 *4L 4pcs) ......................8
1.4 I/O Outlets...........................................................................................9
1.5 Packing List...................................................................................... 10
1.6Model List......................................................................................... 10
SECTION 2 HARDWARE INSTALLATION .................................................11
2.1Installing the PCI Express Mini Card.............................................. 12
2.2Installing LTE or Wi-Fi Antenna Cable............................................ 14
2.3Installing the M.2 2280 Key M SSD Drive........................................ 17
SECTION 3 JUMPER SETTING & CONNECTOR.......................................21
3.1 Jumper & Connector Location........................................................21
3.2Connectors.......................................................................................23
3.2.1 Digital I/O Connector (CN2) (Optional) ........................................................24
3.2.2 HDMI Connector (CN4)..................................................................................24
3.2.3 USB2.0 & USB3.2 Gen2 Connector (CN5) ...................................................25
3.2.4 DC Power Jack w/ Screw (CN6)....................................................................25
3.2.5 PCI-Express Mini Card Connector (SCN1)..................................................26
3.2.6 M.2 2280 Key M PCIe x4 SSD slot (SCN2) ...................................................27
3.2.7 SIM Card Slot (SCN3) ...................................................................................28
3.2.8 Micro USB 2.0 Connector (Micro USB) (SCN4)...........................................28
3.2.9 Ethernet Ports (LAN1, LAN2).......................................................................29
3.2.10 Power Button & Reset Button (SW1)...........................................................30
3.2.11 AT/ATX Switch (SSW1) .................................................................................30
3.2.12 Recovery Mode Switch (SSW2)....................................................................30
3.2.13 Debug Port Connector (JP1) ........................................................................31
3.2.14 CMOS Battery Interface (BAT1) ...................................................................31
3.2.15 Power and Storage LED Indicator (LED1)...................................................31
SECTION 4 JETPACK BSP FLASH METHOD............................................33
4.1 Jetpack Flash Method......................................................................33
4.2 Image Information Inquiry Command.............................................36
4.3 JTOP-Third-party Jetson Platform Monitor Tool............................37

viii
This page is intentionally left blank.

AIE100-ONX Series User’s Manual
Introduction 1
SECTION 1
INTRODUCTION
This chapter contains general information and detailed specifications of the AIE100-ONX. The
Chapter 1 includes the following sections:
◼General Description
◼System Specifications
◼Dimensions
◼I/O Outlets
◼Packing List
◼Model List
1.1 General Description
The AIE100-ONX is an embedded system with NVIDIA®Jetson Orin™NX Series
supercomputer on a module to support Linux Ubuntu 20.04, suitable for the most endurable
operation.
It features fanless design with full feature I/O, one 8 or 16 GB 128-bit LPDDR4x memory, and
enhanced system dependability by built-in Watchdog Timer.
⚫Features
1. NVIDIA®Jetson Orin™NX with Ampere™, 1024 CUDA cores GPU
2. High AI computing performance for GPU-accelerated processing
3. Ideal for various edge AI applications at smart city and smart retail
4. Optional IP42 rating cover kit for semi-outdoor applications
5. Supports 1 USB 2.0, 1 USB 3.2 Gen2, 1 GbE LAN and 1 GbE PoE
6. JetPack supported

AIE100-ONX Series User’s Manual
2Introduction
⚫Reliable and Stable Design
The AIE100-ONX adopts the advanced fanless system and supporting the PCIex4 NVMe
through M.2 interface, which makes it especially suitable for AI computing environments,
best for smart city, GPU-accelerated processing, edge computing and smart retail
applications.
⚫JetPack Supported
The AIE100-ONX supports JetPack 5.1.1 or later. NVIDIA JetPack SDK is the most
comprehensive solution for building AI applications.
JetPack supports Jetson AGX Orin™, Orin™NX, AGX Orin™, Jetson Orin™NX,
Jetson™TX2 NX, Jetson™Nano and Jetson TX2 series. It bundles all the Jetson
platform software, including TensorRT, cuDNN, CUDA Toolkit, VisionWorks, GStreamer,
and OpenCV, all built on top of L4T with LTS Linux kernel.
⚫OS Supported
The AIE100-ONX supports Linux Ubuntu 20.04.
⚫High-performance NVMe SSD Storage Supported
The AIE100-ONX supports one M.2 2280 Key M with PCI-Express 2.0 x4 interface.
1.2 System Specifications
1.2.1 Product Specification
⚫NVIDIA Jetson SKU
◼NVIDIA®Jetson Orin™NX
⚫CPU
◼8GB: 6-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU 1.5MB L2 + 4MB L3
◼16GB: 8-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3
⚫GPU
◼1024-core NVIDIA Ampere GPU with 32 Tensor Cores
⚫Storage
◼One M.2 2280 M Key with PCI-Express 2.0 x4 NVMe SSD slot
⚫System Memory
◼8GB: 8GB 128-bit LPDDR5 102.4 GB/s
◼16GB: 16GB 128-bit LPDDR5 102.4 GB/s
⚫WLAN & WWAN
◼One PCI Express Mini Card modules slot to support Wi-Fi or 3G/4G/LTE modules

AIE100-ONX Series User’s Manual
Introduction 3
1.2.2 I/O System
⚫One HDMI 2.0 for display (HDMI 2.0 Resolution: up to 4096 x 2160@60Hz)
⚫One RJ-45 connector for 10/100/1000 Base-T Ethernet port
⚫One RJ-45 connector for 10/100/1000 Base-T PoE (IEEE 802.3af; PSE), max. up to
15.4 Watts
Note: AIE100 is a power supply device. Two PSE devices should not be
connected together, which may cause the risk of power conflict. Correctly
connect PD Device or switch without PoE. If you need PoE switch, please find
the switch with uplink port.
⚫One USB 2.0 and one USB 3.2 Gen2 connectors
⚫Front-access design for ease of updating NVIDIA Jetpack
◼One Micro USB connector for image flash only
◼One Recovery switch
⚫One M.2 2280 Key M with PCI-Express 2.0 x4 SSD slot for extra storage
⚫One full-size PCI Express Mini Card slot (USB + PCI Express signal)
⚫One Power button and one Reset button
⚫Two Indicators LEDs (System Power, M.2 Storage)
⚫Two SMA type connector openings for Antenna
⚫One 12VDC Power Jack connector

AIE100-ONX Series User’s Manual
4Introduction
1.2.3 System Specification
⚫Watchdog Timer
◼Built-in NVIDIA®Jetson Orin™NX
⚫Power Supply
◼Input : 12VDC
⚫Operation Temperature
◼-20°C to +50°C (-4°F to +122°F)
⚫Humidity
◼10% ~ 95% (non-condensation)
⚫Vibration Endurance
◼3Grm w/ M.2 SSD Storage (5-500Hz, X, Y, Z directions)
⚫Weight
◼1 kg(2.20lb) without package
◼1.6 kg(3.52lb) with package
⚫Dimensions
◼148.6 mm (5.85") (W) x 129.8 mm (5.11") (D) x 34.6 mm (1.36") (H)
Note: All specifications and images are subject to change without notice.

AIE100-ONX Series User’s Manual
Introduction 5
1.3 Dimensions
The following diagrams show you dimensions and outlines of the AIE100-ONX.
1.3.1 System Dimension

AIE100-ONX Series User’s Manual
6Introduction
1.3.2 Wall mount Bracket Dimension (Screw: M3 *4L 4pcs)

AIE100-ONX Series User’s Manual
Introduction 7
1.3.3 Din-rail mount Bracket Dimension (Screw: M3 *4L 8pcs)

AIE100-ONX Series User’s Manual
8Introduction
1.3.4 VESA arm mount Bracket Dimension (Screw: M3 *4L 4pcs)

AIE100-ONX Series User’s Manual
Introduction 9
1.4 I/O Outlets
The following figures show you I/O outlets on front view of the AIE100-ONX.
⚫Front View drawing
⚫Rear View drawing

AIE100-ONX Series User’s Manual
10 Introduction
1.5 Packing List
The package bundled with your AIE100-ONX should contain the following items:
⚫AIE100-ONX System Unit x 1
⚫Foot pad x 4
⚫Screws Pack x 1
⚫Thermal pad x 3 (for M.2 M-Key SSD)
※Regarding the latest product manual, please download them from Axiomtek official website.
1.6 Model List
AIE100-ONX-16GB
Fanless Edge AI System with NVIDIA® Jetson Orin™NX 16GB
SoM, 1 HDMI, 1 GbE LAN, 1 GbE PoE and 2 USB
AIE100-ONX-8GB
Fanless Edge AI System with NVIDIA® Jetson Orin™NX 8GB
SoM, 1 HDMI, 1 GbE LAN, 1 GbE PoE and 2 USB
If you cannot find this package or any items are missing, please contact Axiomtek distributors
immediately.

AIE100-ONX Series User’s Manual
Hardware Installation 11
SECTION 2
HARDWARE INSTALLATION
The AIE100-ONX is convenient for your various hardware configurations, such as SSD (Solid
State Drive), and PCI Express Mini Card modules. The chapter 2 will show you how to install
the hardware.
Note: Waterproof capability of the IPX2 rating may be affected if a system is
dissembled or improperly assembled; under such circumstances Axiomtek
shall not be liable for any quality deterioration.
Besides assembling the optional IP42 rating cover kit, please refer to
tightening torque below for all system screws and waterproof antenna
connectors to ensure the waterproof capability:
Philips screws at bottom side: 6Kgf-cm
Waterproof antennas connector of SMA cables: 6Kgf-cm
Note: To support the IP42 rating, AIE100-ONX must be installed with
waterproof SMA cables.

AIE100-ONX Series User’s Manual
12 Hardware Installation
2.1 Installing the PCI Express Mini Card
Step 1 Turn off the system, and unplug the power adaptor.
Step 2 Turn the system upside down to locate screws at the bottom side as red
marked and loosen four screws.
Step 3 Remove the bottom cover, and locate PCI Express mini card slot on the board.
