AXIOMTEK eBOX710-521-FL Series User manual

eBOX710-521-FL Series
Embedded System
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, or any liability arising from such uses.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update any information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted in
any forms or by any means, electronic, mechanical, photocopying, recording, among others,
without prior written permissions of Axiomtek Co., Ltd.
Copyright 2020 Axiomtek Co., Ltd.
All Rights Reserved
JAN 2020, Version A1
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. The eBOX710-521-FL does not come with an operating system which must be loaded
first before installation of any software into the computer.
2. Be sure to ground yourself to prevent static charge when installing any internal
components. Use a wrist grounding strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
3. Disconnect the power cord from the eBOX710-521-FL prior to making any installation.
Be sure both the system and all external devices are turned OFF. Sudden surge of
power could ruin sensitive components. Make sure the eBOX710-521-FL is properly
grounded.
4. Make sure the voltage of the power source is correct before connecting it to any power
outlet.
5. Turn Off system power before cleaning. Clean the system using a cloth only. Do not
spray any liquid cleaner directly onto the screen.
6. Do not leave equipment in an uncontrolled environment where the storage temperature
is below -40℃or above 80℃as it may damage the equipment.
7. Do not open the system’s back cover. If opening the cover for maintenance is a must,
only a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help discharge any static electricity on
human body.
When handling boards and components, wear a wrist grounding strap available from
most electronic component stores.
8. Caution:
Risk of explosion if battery is replaced by an incorrect type Dispose of used batteries
according to the instructions.
IL Y A RISQUE D’EXPLOSION SI LA BATTERIE EST
REMPLACEE
PER UNE BATTERIE DE TYPE INCORRECT.
METTRE AU REBUT LES BATTERIES USAGEES
CONFORMEMENT AUX INSTRUCTIONS
9. Waring:
Hot Surface Do Not Touch.
Restricted access locations: The equipment should only be installed in a Restricted
Access Area.

iv
Classifications
1. Degree of production against electric shock: not classified
2. Degree of protection against ingress of water: IP40
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture with air,
oxygen or nitrous oxide.
4. Mode of operation: Continuous

v
General Cleaning Tips
Please keep the following precautions in mind while understanding the details fully before and
during any cleaning of the computer and any components within.
A piece of dry cloth is ideal to clean the device.
1. Be cautious of any tiny removable components when using a vacuum cleaner to absorb
dirt on the floor.
2. Turn the system off before cleaning up the computer or any components within.
3. Avoid dropping any components inside the computer or getting circuit board damp or wet.
4. For cleaning, be cautious of all kinds of cleaning solvents or chemicals which may cause
allergy to certain individuals.
5. Keep foods, drinks or cigarettes away from the computer.
Cleaning Tools:
Although many companies have created products to help improve the process of cleaning
computer and peripherals, users can also use house hold items accordingly for cleaning.
Listed below are items available for cleaning computer or computer peripherals.
Pay special attention to components requiring designated products for cleaning as
mentioned below.
Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although
paper towels or tissues can be used on most hardware as well, it is recommended to use
a piece of cloth.
Water or rubbing alcohol: A piece of cloth may be somewhat moistened with water or
rubbing alcohol before being rubbed on the computer. Unknown solvents may be harmful
to plastic parts.
Absorb dust, dirt, hair, cigarette and other particles outside of a computer can be one of
the best methods of cleaning a computer. Over time these items may restrict the airflow
in a computer and cause circuitry to corrode.
Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are applicable to
reach areas in keyboard, mouse and other areas.
Foam swabs: If possible, it is better to use lint free swabs such as foam swabs.
.
【Note】: It is strongly recommended that customer should shut down the system before
starting to clean any single components.
Please follow the steps below:
1. Close all application programs;
2. Close operating software;
3. Turn off power switch;
4. Remove all devices;
5. Pull out power cable.

vi
Scrap Computer Recycling
Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in
case computers require maintenance or repair; or for recycling in case computers are out of
order.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines
Corporation. Intel®and Pentium®are registered trademarks of Intel Corporation.
MS-DOS, Microsoft C and QuickBasic, Windows 10, Windows 8.1, Windows 8,
Windows 7, Windows XPE, Windows XP, Windows CE embedded, Linux are
trademarks of Microsoft Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

vii
Table of Contents
Disclaimers.............................................................................................................ii
Safety Precautions................................................................................................iii
Classifications.......................................................................................................iv
General Cleaning Tips ........................................................................................... v
Scrap Computer Recycling................................................................................... vi
SECTION 1 INTRODUCTION ........................................................................1
1.1 General Descriptions.........................................................................1
1.2 System Specifications.......................................................................3
1.2.1 CPU ...................................................................................................................3
1.2.2 I/O System ........................................................................................................3
1.2.3 System Specifications.....................................................................................4
1.2.4 Driver Contents................................................................................................5
1.3 Dimensions ........................................................................................6
1.3.1 System Dimensions.........................................................................................6
1.3.2 Wall-mount Bracket Dimensions....................................................................7
1.3.3 Din-Rail Bracket Dimensions..........................................................................8
1.4 I/O Outlets ..........................................................................................9
1.5Packing List...................................................................................... 11
1.6Model List......................................................................................... 11
SECTION 2 HARDWARE INSTALLATION..................................................13
2.1Installation of CPU.......................................................................... 13
2.2Installation of 2.5" SATA Device.................................................... 16
2.3 Installation of SO-DIMM................................................................... 17
2.4Installation of Mini PCIe Module (Full-size) ................................... 18
2.5Installation of Flexible I/O Modules................................................19
2.6Installation of PCIe card..................................................................21
SECTION 3 JUMPER & CONNECTOR SETTINGS ....................................23
3.1 Locations of Jumpers & Connectors............................................. 23
3.2 Summary of Jumper Settings ........................................................ 25
3.2.1Restore BIOS Optimal Defaults (JP1) ..........................................................25
3.3 Connectors ..................................................................................... 26
3.3.1 DC-in Phoenix Power Connector (CN29).....................................................27
3.3.2 HDMI Connector (CN2)..................................................................................27
3.3.3 DisplayPort Connector (CN1) .......................................................................28
3.3.4 Serial Port Connector (CN27,CN27).............................................................28
3.3.5USB 3.2 Connector ........................................................................................29
3.3.6Ethernet Connector (LAN1~LAN6) ...............................................................30
3.3.7 DVI-I Connector (CN30).................................................................................31
3.3.8 ATX Power on/off (SW3)................................................................................31
3.3.9Reset Button (SW2) .......................................................................................31
3.3.10Remote Power Switch Connector (PWRBT1).............................................32
3.3.11AT/ATX Switch ...............................................................................................32

viii
3.3.12 SATA Connector (SATA 1 & 2) ......................................................................32
3.3.13 SATA Power Connector (CN16,CN17)..........................................................33
3.3.14SIM Card Slots (CN13,CN14) ........................................................................33
3.3.15 Full-Size PCI Express Mini Card Slot (CN12,CN15)....................................34
3.3.16 Intel®HD Audio Digital Header (HDA1)(Optional).......................................36
3.3.17 Digital I/O (CN11) (optional)..........................................................................36
SECTION 4 BIOS SETUP UTILITY..............................................................37
4.1 Starting............................................................................................. 37
4.2 Navigation Keys............................................................................... 37
4.3 Main Menu........................................................................................ 38
4.4 Advanced Menu................................................................................39
4.5 Chipset Menu ...................................................................................51
4.6 Boot Menu........................................................................................ 56
4.7Save & Exit Menu............................................................................. 57
APPENDIX A WATCHDOG TIMER..............................................................59
About Watchdog Timer .................................................................................. 59
Sample Program.............................................................................................. 60
APPENDIX B PROGRAMMABLE LED........................................................61
APPENDIX C CONFIGURING SATA FOR RAID.........................................63
C.1 Configuring SATA Hard Drive(s) for RAID...................................... 63

eBOX710-521-FL Series user’s Manual
Introduction
1
SECTION 1
INTRODUCTION
This section contains general information and detailed specifications of the eBOX710-521-
FL.Section 1 consist of the following sub-sections:
General Descriptions
System Specifications
Dimensions
I/O Outlets
Packing List
Model List
1.1 General Descriptions
The eBOX710-521-FL is a high performance Fanless Expandable System that features the
9th/8th generation Intel®Xeon®& Core™ i7/i5/i3 & Celeron®processors (35W). It comes with
an IP40-rated heavy-duty aluminum extrusion design, offers 24V DC power input with power
protection and supports -40°C to +70°C extended temperature range, thus enabling reliable
operation in harsh environments.
To minimize deployment time, eBOX710-521-FL supports one flexible I/O window for
customers to easily install additional I/O output. It also supports multiple I/O connections
including 6 USB 3.2 ports, 2 COM ports, 6 GbE ports, plus 2 SIM sockets are provided for
remarkable mobile availability. It is making perfectly suitable for intelligent factory, machine
vision, and edge computing applications.

eBOX710-521-FL Series user’s Manual
Introduction
2
Features
9th/8th generation Intel®Xeon & Core™ i7/i5/i3 & Celeron®processors 35 watt with Intel®
C246 PCH
Dual swappable 2.5" SATA HDD drive bay with RAID 0/1 supported
ECC SO-DIMM memory supported , up to 64GB
DVI-I, HDMI, and DisplayPort with triple-view supported
One PCIe x4 expansion slot supported
TPM 2.0 onboard
AXView 3.0 intelligent embedded monitoring software ready
Reliable and Stable Design
The embedded system supports 9th/8th generation Intel®Xeon®& Core™ i7/i5/i3 and
Celeron®35 watt processors, along with high flexibility and multi-functional design that make it
the best solution for smart factory applications.
Flexible Connectivity
The eBOX710-521-FL-DC-6GbE comes with rich I/O interfaces including two RS-232/422/485
ports, six USB 3.2 ports, six GbE ports, triple display and flexible I/O window supported.
Embedded O.S. Supported
The eBOX710-521-FL with 9ht/8th generation platform supports Windows®10, Windows®10
IoT and various Linux versions.
Various Storage Supported
In terms of storage, the eBOX710-521-FL supports two swappable 2.5" SATA storage drive
bay and one mSATA device.

eBOX710-521-FL Series user’s Manual
Introduction
3
1.2 System Specifications
1.2.1 CPU
CPU(Xeon®)
Intel®Xeon®E-2278GEL Processor (35W)
CPU (9th gen)
LGA1151 9th gen Intel®Core™ i7/i5/i3 & Celeron®processors (35W)
Intel®Core™ i7-9700TE Processor
Intel®Core™ i5-9500TE Processor
Intel®Core™ i3-9100TE Processor
Intel®Celeron®G4930T
CPU (8th gen)
LGA1151 8th gen Intel®Core™ i7/i5/i3 & Celeron®processors (35W)
Intel®Core™ I7-8700T, 35W processor
Intel®Core™ I5-8500T, 35W processor
Intel®Core™ I3-8100T, 35W processor
Intel®Pentium®G5400T, 35W processor
Intel®Celeron®G4900T, 35W processor
Chipset
Intel®C246
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
System Memory
2 x 260-pin DDR4-2666 SO-DIMM, up to 64GB
ECC Memory supported
1.2.2 I/O System
Display
1 x HDMI 1.4 (3840 x 2160@30 Hz)
1 x DisplayPort 1.2 (Resolution:4K/2K@60 Hz)
1 x DVI-I (VGA: 1920 x1080@60 Hz; DVI-D: 1920 x1200@60 Hz)
Ethernet
6 x 10/100/1000 Ethernet ports (5 x i210IT, 1 x i219LM)
USB Ports
4 x USB 3.2 Gen 2
2 x USB 3.2 Gen 1
Serial Ports
2 x RS-232/422/485 (COM1/2)
Expansion Interface
2 x Full-size PCI Express Mini Card Slots (USB + PCI Express signal)
1 x PCIe x4 slot

eBOX710-521-FL Series user’s Manual
Introduction
4
Storage
2 x 2.5" swappable SATA HDD/SSD drive bay, up to 9.5mm height
RAID 0/1 supported via 2 x 2.5" SATA HDD/SSD
1 x mSATA (enabled in BIOS setting)
Flexible I/O Window
Default : 2 x DB9 half cut bracket
Optional I/O kits via mPCIE interface
Indicator
1 x Green LED as indicator for PWR status
1 x Green LED as indicator for HDD active
4 x Green LED as indicator for programmable
Switch
1 x ATX PWR switch
1 x Remote PWR switch
1 x AT/ATX Quick switch
1 x Reset switch
Antenna & SIM
4 x SMA type connector openings for antenna
2 x Internal SIM slot
TPM 2.0
1 x ST33HTPH2E32AHB4
1.2.3 System Specifications
Watchdog Timer
1~255 seconds or minutes; up to 255 levels.
Power Supply
24V DC input
Operation Temperature
-40°C to 70°C (-40°F to +140°F) (with W.T. DRAM & SSD,CPU TDP 35W)
Storage Temperature
-40℃~+80℃(-40 ºF ~ 158ºF)
Humidity
10% ~ 95% (non-condensation)
Shock
IEC 60068-2-27 (w/SSD: 50G@wall mount, half sine,11 ms duration)
Vibration Endurance
IEC 60068-2-64 (w/SSD: 3Grms STD, random, 5 - 500 Hz,1 hr/axis)
Weight
4.8 kg (10.58 lb) without package
5.6 kg (12.34 lb) with package
Dimension
280mm (11.02") (W) x 210mm (8.26") (D) x 80.5mm (3.16") (H)

eBOX710-521-FL Series user’s Manual
Introduction
5
1.2.4 Driver Contents
Please download the following eBOX710-521-FL drivers from Axiomtek official website.
Ethernet
Chipset
Graphic
Serial Port
USB 3.1
Intel® ME
User Manual
【Note】: All specifications and images are subject to change without notice.

eBOX710-521-FL Series user’s Manual
Introduction
6
1.3 Dimensions
The following diagrams show dimensions and outlines of the eBOX710-521-FL.
1.3.1 System Dimensions

eBOX710-521-FL Series user’s Manual
Introduction
7
1.3.2 Wall-mount Bracket Dimensions
Users can get 6pcs truss head M3*6L screws for fixing the wall mount kit from the
accessories box.
Note: When users install wall mount kit, please turn the LAN ports side outlet
towards the floor.

eBOX710-521-FL Series user’s Manual
Introduction
8
1.3.3 Din-Rail Bracket Dimensions
Users can get 6pcs truss head M3*6L screws for fixing the wall mount kit from the
accessory box.

eBOX710-521-FL Series user’s Manual
Introduction
9
1.4I/O Outlets
The following figures show I/O outlets on the eBOX710-521-FL.
Front View
1
1 x Reset button
7
System LEDs
2
1 x Power button
8
1 x Remote power switch
3
2 x Swappable HDD tray
9
1 x HDMI 1.4
4
4 x Antenna opening
10
1 x DisplayPort 1.2
5
2 x USB 3.2 (Gen1)
11
6 x GbE
6
1 x AT/ATX quick switch

eBOX710-521-FL Series user’s Manual
Introduction
10
Rear View
12
1 x PCIe x4 slot
15
1 x DVI-I
13
Flexible I/O window
16
2 x RS232/422/485 (COM 1)
14
4 x USB 3.2 (Gen2)
17
24VDC power input

eBOX710-521-FL Series user’s Manual
Introduction
11
1.5 Packing List
The eBOX710-521-FL comes with the following bundle package:
eBOX710-521-FL System Unit x 1
Thermal Grease x 1
Terminal Block x 1
Remote Switch Cable x 1
Foot Pad x 4
Screw Pack x 1
1.6 Model List
eBOX710-521-FL-DC-6GbE
Fanless Expandable System with LGA1151 9th/8th gen
Intel® Intel® Xeon /Core™ i7/i5/i3 & Celeron®
processor, Intel® C246, ECC memory and 1 PCIe x 4
expansion slot
Please contact Axiomtek’s distributors immediately in case any abovementioned items are
missing.

eBOX710-521-FL Series user’s Manual
Introduction
12
This page is intentionally left blank.
