AXIOMTEK GOT-5152T-830 User manual

GOT-5152T-830
All-in-One
15”XGA TFT Fanless Touch Panel
Computer with Intel®AtomTM N270
Processor Onboard
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to
contain accurate information. Axiomtek Co., Ltd. assumes no
responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or
responsibility for the accuracy, completeness or usefulness of
any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document
and/or product at any time without notice.
No part of this document may be reproduced, stored in a
retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
Copyright 2011 Axiomtek Co., Ltd.
All Rights Reserved
December 2011, Version A2
Printed in Taiwan

iii
Safety Approvals
CE Marking
FCC Class A
FCC Compliance
This equipment has been tested in compliance with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are meant to provide reasonable protection against harmful
interference in a residential installation. If not installed and used in
accordance with proper instructions, this equipment might generate or
radiate radio frequency energy and cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following methods:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment to another outlet of a circuit that doesn’t
connect with the receiver.
4. Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with the
emission limits.
CAUTION：RISK OF EXPLOSION IF BATTERY IS EPLACED BY AN
INCORRECT TYPE DISPOSES OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.

iv
Safety Precautions
Before getting started, please read the following important
safety precautions.
1. The GOT-5152T-830 does not come equipped with an
operating system. An operating system must be loaded first
before installing any software into the computer.
2. Be sure to ground yourself to prevent static charge when
installing the internal components. Use a grounding wrist strap
and place all electronic components in any static-shielded
devices. Most electronic components are sensitive to static
electrical charge.
3. Disconnect the power cord from the GOT-5152T-830 before
any installation. Be sure both the system and external devices
are turned OFF. A sudden surge of power could ruin sensitive
components that the GOT-5152T-830 must be properly
grounded.
4. The brightness of the flat panel display will be getting weaker as
a result of frequent usage. However, the operating period varies
depending on the application environment.
5. Turn OFF the system power before cleaning. Clean the system
using a cloth only. Do not spray any liquid cleaner directly onto
the screen. The GOT-5152T-830 may come with or w/o a
touchscreen. Although the touchscreen is chemical resistant, it
is recommended that you spray the liquid cleaner on a cloth first
before wiping the screen. In case your system comes without
the touchscreen, you must follow the same procedure and not
spray any cleaner on the flat panel directly.
6. Avoid using sharp objects to operate the touchscreen.
Scratches on the touchscreen may cause malfunction or
internal failure to the touchscreen.
7. The flat panel display is not susceptible to shock or vibration.
When assembling the GOT-5152T-830, make sure it is
securely installed.
8. Do not open the system’s back cover. If opening the cover for
maintenance is a must, only a trained technician is allowed to
do so. Integrated circuits on computer boards are sensitive to
static electricity. To avoid damaging chips from electrostatic
discharge, observe the following precautions:

v
9 Before handling a board or integrated circuit, touch an
unpainted portion of the system unit chassis for a few
seconds. This will help to discharge any static electricity
on your body.
When handling boards and components, wear a wrist-
grounding strap, available from most electronic component
stores.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd. IBM, PC/AT,
PS/2, VGA are trademarks of International
Business Machines Corporation.
Intel®and Atom™are registered trademarks of Intel
Corporation.
MS-DOS, Microsoft C and Quick BASIC are trademarks of
Microsoft Corporation.
VIA is a trademark of VIA Technologies, Inc.
SST is a trademark of Silicon Storage Technology, Inc.
UMC is a trademark of United Microelectronics Corporation.
Other brand names and trademarks are the properties and
registered brands of their respective owners.

vi
Table of Contents
Disclaimers....................................................................................ii
Safety Approvals...........................................................................iii
Safety Precautions........................................................................iv
CHAPTER 1 INTRODUCTION................................................................ 1
1.1 General Description .................................................... 1
1.2 Specifications.............................................................. 3
1.2.1 Main CPU Board......................................................... 3
1.2.2 I/O System .................................................................. 3
1.2.3 System Specification................................................... 4
1.3 Dimensions ................................................................. 6
1.4 I/O Outlets................................................................. 10
1.5 Packing List............................................................... 11
CHAPTER 2 HARDWARE INSTALLATION ................................... 13
2.1 CF card Installation................................................... 13
2.2 Serial Ports Interface ................................................ 15
2.3 Ethernet..................................................................... 17
2.4 Mountings –Panel/Wall/Desktop/VESA ................... 18
2.4.1 Panel Mounting......................................................... 18
2.4.2 Wall-Mounting........................................................... 19
2.4.3 Desktop-Mounting..................................................... 20
2.4.4 VESA-ARM Mounting................................................ 22
2.5 HDD Installation........................................................ 24
2.6 DRAM Installation ..................................................... 27
2.7 Wireless LAN Card Installation................................. 29
CHAPTER 3 AMI BIOS SETUP UTILITY.......................................... 33
3.1 Starting...................................................................... 33
3.2 Navigation Keys ........................................................ 33
3.3 Main Menu ................................................................ 35
3.4 Advanced Menu........................................................ 36
3.5 PCI PnP Menu .......................................................... 50
3.6 Boot Menu................................................................. 53
3.7 Security Menu........................................................... 58
3.8 Chipset Menu............................................................ 60
3.9 Exit Menu.................................................................. 65
CHAPTER 4 DRIVERS INSTALLATION ......................................... 67

vii
4.1 System ...................................................................... 67
4.2 Touch Screen............................................................ 68
4.2.1 Specification.............................................................. 68
4.2.2 Driver Installation- Windows XP................................ 68
4.3 Embedded O.S. ........................................................ 71
4.3.1 Windows XP Embedded........................................... 71
4.3.2 Windows CE.NET 6.0............................................... 72

viii
MEMO:

GOT-5152T5152T User’s Manual
Introduction
1
CHAPTER 1
INTRODUCTION
This chapter contains general information and detailed
specifications of the GOT-5152T-830. Chapter 1 includes the
following sections:
General Description
Specification
Dimensions
I/O Outlets
Package List
1.1 General Description
The GOT-5152T-830 is a fan-less and compact-size touch
panel computer, equipped with a 15”TFT LCD display and low
power consumption Intel○RAtomTM N270 1.6GHz processor with
FSB 533MHz. The GOT-5152T-830 supports Windows®XP,
Windows®CE.NET and Windows®XP embedded. The panel
computer is able to install a CompactFlash™card and provide
a Mini card slot for wireless module. Its excellent ID and
friendly user interface make it a professional yet easy-to-use
panel computer. The GOT-5152T-830 is an ideal for space-
limited applications in factory automation, machine maker
operating systems, building automation, and more.

GOT-5152T5152T User’s Manual
Introduction
2
GOT-5152T-830: 15”TFT XGA Fanless Touch Panel Computer
Reliable and Stable Design
The GOT-5152T-830 adopts a fanless cooling system
and a CompactFlash™card, which makes it suitable
for vibration environments.
Embedded O.S. Supported
The GOT-5152T-830 not only supports Windows®XP,
but also supports embedded OS, such as Windows®
CE.NET, and Windows®XP embedded. For storage
device, the GOT-5152T-830 supports CompactFlash™
card and 2.5”SATA device.
Industrial-grade Product Design
The GOT-5152T-830 has an incredible design to be
used in different industrial environments.
The front bezel meets the IP65/NEMA4 standard.
For connecting other devices, the GOT-5152T-830 also features
several interfaces: USB, Ethernet, and RS-232/422/485.

GOT-5152T5152T User’s Manual
Introduction
3
1.2 Specifications
1.2.1 Main CPU Board
CPU
Intel○RAtomTM N270 1.6GHz processor with FSB 533MHz
onboard
System Chipset
945GSE + ICH7M
BIOS
America Megatrends BIOS
System Memory
One 200-pin DDR2 SO-DIMM socket
Maximum memory up to 2GB
1.2.2 I/O System
Standard I/O
Three RS-232 and one RS-232/422/485
Four USB 2.0
One Audio Line-out
One RJ-45
One VGA
Ethernet
1x10/100/1000Mbps
Audio
Built-in speakers 2W*2 (optional)
One microphone on front bezel (optional)
Expansion
One Mini card

GOT-5152T5152T User’s Manual
Introduction
4
Storage
One slot for CF card
One SATA
Power connector
GOT-5152T-830: 10VDC to 30VDC with phoenix power
connector
GOT-5152T-830-J: External 60W AC Adapter with screw type
connector
1.2.3 System Specification
15”TFT LCD
Heat Dispensing Design
Disk drive housing:
One 2.5”SATA drive
Net Weight
3.2 Kgs (7.05 lb)
Dimension (Main Body Size)
387.9 x 307.7 x 54.6mm
Operation Temperature
0℃to 50℃
Relative Humidity
10% to 90% @ 40℃, Non-Condensing
Vibration
2.0G, 5 to 500 Hz, 2.0 G random for CF card
Power input
10~30VDC with phoenix power connector
External 60W AC Adapter
—Power Input: 90VAC to 264VAC
—Power Output: 12VDC, Max. 5A

GOT-5152T5152T User’s Manual
Introduction
5
NOTE All specifications and images are subject to change
without notice.
NOTE If the operation temperature is higher than 35℃,
the wide temperature DRAM and HDD are
recommended to be used on the device.

GOT-5152T5152T User’s Manual
Introduction
6
1.3 Dimensions
This diagram shows you dimensions and outlines of the GOT-
5152T-830.

GOT-5152T5152T User’s Manual
Introduction
7

GOT-5152T5152T User’s Manual
Introduction
8

GOT-5152T5152T User’s Manual
Introduction
9

GOT-5152T5152T User’s Manual
Introduction
10
1.4 I/O Outlets
Please refer to the following illustration for I/O locations of the
GOT-5152T-830.
No
Function
1
POWER SWITCH (ATX)
2
Power Input connector (phoenix type)
2.1
Power Input connector (screw type)
3
2 X USB 2.0
4
COM 4 (RS-232)
5
COM 3 (RS-232)
6
COM 1(RS-232/422/485)
7
COM 2(RS-232)
8
VGA
9
1X ETHERNET (RJ-45)
10
2 X USB 2.0
11
AUDIO (LINE-OUT)

GOT-5152T5152T User’s Manual
Introduction
11
1.5 Packing List
When you receive the GOT-5152T-830, the bundled package
should contain the following items:
GOT-5152T-830 x 1
Panel Mount Kit x 10
Driver CD x1
Wall-Mount Kit x1
Power Adapter & power cord (for GOT-5152T-830-J)
If you can not find the package or any items are missing,
please contact Axiomtek distributors immediately.

GOT-5152T5152T User’s Manual
Introduction
12
MEMO:
