Bandai Namco JUMBO JUMPIN' User manual

JUMBO
JUMPIN'

OPERATORS MANUAL
Important
Read PRECAUTIONS and INSTALLATION
Sections before operating game
FCC Notice
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operating in a
commercial environment. This equipment uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.

Jumbo Jumpin’Operators Manual
TABLE OF CONTENTS
1.0 SPECIFICATIONS 1
2.0 INTRODUCTION 2
3.0 PRECAUTIONS 2
3.1 Installation 2
3.2 Handling 2
4.0 INSTALLATION 3
5.0 OPTION MENU
6.0 ERROR MESSAGES
7.0 DIAGNOSTICS
8.0 GAME PLAY
9.0 TROUBLESHOOTING
5-6
7
7
8
8
APPENDIX A: PARTS LIST 9
APPENDIX B: WIRING DIAGRAM 10

Jumbo Jumpin’Operators Manual
1.0 SPECIFICATIONS
Logic Power Supply:
Input Power:
Overall Height:
Crated Dimensions:
Installed Dimensions:
Shipping Weight:
Convenience Kit: (1)
(located in coin box) (1)
350 Watt
120/220 VAC,50/60 Hz, 5 Amps max
106.5”
77”H x 111”W x 30”D
106.5”H x 73”W x 92”D
600 lbs
Operators Manual
Power cord
Linking cable (1)
Note: Specifications subject to change without prior notice. Modifications and/or
alterations of the Jumbo Jumpin’  game with kits or parts not supplied by
BANDAI NAMCO Amusement may void the warranty.
WARNING
REMOVAL OF SERIAL NUMBERS AND/OR BAR-CODES FROM PRODUCT OR
COMPONENTS WILL VOID THE WARRANTY
1

Jumbo Jumpin’Operators Manual
2.0 INTRODUCTION
BANDAI NAMCO'sJumbo Jumpin’  is a redemption game featuring an interactive virtual
jump rope. Players select between classic and double dutch experiences.
Those that successfully jump until the progress bar fills up win the bonus!
3.0 PRECAUTIONS
3.1 Installation
This game is designed for indoor use only. It must not be installed outdoors. The
following conditions must be avoided:
1. Direct exposure to sunlight, extreme high humidity, direct water contact,
dust, high heat or extreme cold.
2. Vibration. The game must be installed on a level surface.
Do not install in an area such that the game would present an obstacle in case of
an emergency (i.e., close to fire equipment or emergency exists).
3.2 Handling
1. Before operating the game, make sure that the main AC power hookup
includes a safety ground. This will ensure safe operation as well as
compliance with the applicable FCC and UL regulations. Measure the AC
power line voltage. Verify that the voltage selection switch on the power
supply is set to the correct setting.
2. Before replacing any parts, turn the AC power OFF and unplug the game.
3. Do not attempt to repair the Printed Circuit Board (PCB) on-site. It contains
sensitive integrated circuit chips that could be easily damaged, even by the
small internal voltage of a multi-meter. Always return the PCB to your
distributor for any repairs.
2

Jumpin' JackpotOperators Manual
INSTALLATION
Note: Shipping damage may void the warranty. In case of shipping damage, contact your
distributor and the transportation carrier immediately.
1. Unpack the game.
2. Position the game close to its final location.
3. Carefully raise the main game back panel to a vertical position and attach the left
and right side supports using the supplied 16-bolts and 4 mounting brackets. See
Figure 1.
4. Place the floor mat into position and attach it to the lower backpanel frame using
the supplied 2 bolts. See Figure 1.
5. Connect the floor mat cable to the mating cable located at the bottom center of the
light ring.
6. If a single stand alone game is being installed, skip to step 7. If two games are to be
linked together: Remove all but the top two screws on the back panels. Loosen the
top two screws on both games a couple of turns. Then feed one supplied linking
cable (Cat 5 RJ45 patch cord) through the back panel holes and attach one end to
each main logic port labeled “LINK”. See Figure 2. Once connected, reinstall allback
panel screws being careful not to over tighten.
7. Attach the power cord to the game and wall outlet, and turn on the power. Wait a
couple of minutes while the game completes its power on diagnostics. Ifthis isthe
first time the game is turned on, you may be presented with a screen reporting
“MASTER UNIT NOT DETECTED”. This isnormal operation. and you should press
the “MENU” button to enter the game options mode. Iftwo games are linked, only
press the menu button on one of the games (it doesn’t matter which game you
choose)
8. Follow the on screen prompts. Review and change any of the options as required. If
necessary, refer to the Option Menu section of this manual for detailed explanations
for each option. When complete, exit the options mode by pressing the menu
button.
The game is ready to play!
3

Figure 2
Figure 1

Jumbo Jumpin’Operators Manual
OPTION MENU
Enter the options menu by pressing the “MENU” button located on the service panel inside
the coin door. Advance through all options by pressing the “TEST” BUTTON. Increase
displayed values with your foot by stepping on the right side of the mat. Reduce values
using your foot by stepping on the left side of the mat..
The Game options include the following choices:
1- GAME VOLUME This sets the volume for when a game is being played. Setting
it to “1" isthe softest and “10" isthe loudest. (Default setting is“8")
2- ATTRACT VOLUME This sets the volume of the music that plays during the
attract mode. The range is “OFF”, “1” isthe softest and “10" is the loudest. (Default
setting is“5")
3- COINS TO START PLAY This option determines how many coins (pulses on the
COIN #1 input) will start a game. The range is “FREE PLAY”, 1 – 8. The default
value is “1” and is typical for card reader systems. The Free play setting is for
demonstration and trade shows. Free play games start when a player stands in the
jump zone. Any tickets awarded during free play display as normal, but will not be
dispensed.
4- COIN #2 VALUE The second coin input can be set to a higher value in multiples of
coin #1. For example: Let;s say you want to accept quarters ($0.25) as coin #1
and dollars ($1.00) as coin #2. Setting the COIN #2 VALUE to 4 tells the game that
each pulse on the coin #2 input = 4 pulses on the coin #1 input. This helps make
the coin counter work properly using different coin values. The range is “OFF”, 1 –
8. The default setting is “1” (coin 2 = coin 1 value). The OFF setting can be
selected if the coin #2 input is not used.
5
5- MONEY PROMPT This option tells the player the type of money accepted. The
options are: COINS, TOKENS, SWIPE CARD, INSERT CARD. The default setting
is SWIPE CARD.
6- WARM UP JUMP COUNT This sets the number of warm up jumps a player gets
before the game can end. The range is 1 – 9 (Default setting is “7”)
7- STATION ID This option is used to identify more than one game. The range is 0 – 1
(default setting = 1). Zero identifies the master (or standalone) unit and one
identifies the slave unit. Up to two games can be connected together.
IMPORTANT NOTE: no two games should be set to the same STATION ID.

6
JUMPIN’ JACKPOTOperators Manual
8- MINIMUM TICKETS This sets the minimum number of tickets a player will receive
regardless of their performance. The range is 0 – 25 tickets (Default setting is“10")
9- AVERAGE TICKETS PER PLAY This sets the average number of tickets a player
will receive per game played. The range is 0-100 (Default setting is“35") NOTE:
The player will receive a proportional amount of tickets between the “MINIMUM
TICKETS” and the “AVERAGE TICKETS PER PLAY” settings, based upon the
percentage of completion.
10- BONUS VALUE This sets the bonus value for winning the game. Possible bonus
values are common numbers between 0-2000 (Default setting is“1000")
11- TICKET MULTIPLIER This sets the multiple value of you ticket. Use this setting
when your ticket value is 2x.(Default setting is“1" = standard 1x tickets)
12- DIFFICULTY This option sets how skilled a player needs to be to win the game.
The rangeis“AUTO”, 1 – 8 (default = AUTO). The auto setting isrecommended,
and attempts to accommodate a wide range of skill levels. Manual settings between
“1” (easy) to “8” (hard) are the fixed difficulty choices.
13- AUDIO ATTRACT INTERVAL This sets how often music will play when the game
sits idle. The value set equals the number of minutes. The range is 0-15 (Default
setting is“5")
14- RES DEF (RESET DEFAULTS) When this isset to “1" and you exit the menu
screen, allof the game settings will be restored to their default value. (Default
setting is“0")
15- LAMP/SWITCH TEST This option doesn’t affect game operation, but provides an
operator the a way to test allLEDand switch inputs. When the jump zone, isclear,
the game will repeat the sequence red, green and blue on the light ring. Ifany of the
floor mat switches are pressed, the corresponding 15 the lower center tubes will
light red. In this mode, the coin inputs can also be tested (sound will be played, but
ignored by normal game functions.
16- BONUS WIN COUNTS This option doesn’t affect game operation, and only
displays the win counters. The format is: XXXXXXXXXXXXXXXX. The first (left
most) pairof digits represent difficulty 1 wins. The second pair are difficulty 2 wins
and continue to the last pair, difficulty 8 wins. For each pair of digits, the left digit are
the single rope wins and the right digit are the double dutch wins. Each digit has a
range of 0-9.Much like coin counters, these counters can’t be reset and operators
will need to subtract starting from ending values to determine the wins during a
period of time. These win counts have little value when operating the game using
auto difficulty, but can be used to help guide manual difficulty settings.

7
6.0 ERROR MESSAGES
MASTER UNIT NOTDETECTED This error message will be displayed on all slave
games (STATION ID= 1) when no master game is connected and running. Ifthis
message is displayed and all games are powered up and connected, Enter the options
mode on each game, and make sure only one game is setto STATION ID= 0.
CONNECT MAT. This error will be displayed when the main logic PCB can not
communicate with the floor mat. Inspect the floor mat wiring for any disconnection or
breakage. Reconnect or repair any broken cables. If all checks out, the floor mat may
need to be serviced.
ONE PLAYER AT A TIME! Please clear all objects from the JUMP ZONE! This error will
be displayed when an object stays in the Jump zone for over 1 minute. Clear the object
and the game will automatically return to normal operation. If nothing is on the Jump zone,
make sure there is nothing under the mat and the floor is smooth and flat. If everything
checks out, and the error message persists, the floor mat may need to be serviced.
7.0 DIAGNOSTICS
On every power up, the game will perform internal tests. If everything checks out, the
video and main logic software versions will be displayed. Refer to section 6.0 Error
messages if any problem is displayed.
8.0 GAME PLAY
A player inserts the required money, then selects either classic or double dutch play.
When the game starts the player must jump the virtual jump rope as it spins around. The
longer the player successfully jumps the more the progress bar fills up . When the
progress bar is full, the player wins the bonus!

8
Jumpin' JackpotOperators Manual
TROUBLESHOOTING
Problem Probable Cause Solution
No lights. 1) No AC power. 1) Check AC input plug and wire harness.
Verify PS switch is ON and the fuse in
the power entry module is working.
Disconnect the 15 pin connector on the
main logic. If the AC power inputs are
present at the power supply and the
green power supply indicator LED is
off, the power supply will need to be
replaced.
2) No DC power. 2) Check AC input plug on switching
power supply. Verify PS switch is ON.
Check DC output voltage for 12-
13VDC. If this voltage is very low,
check for output shorts by removing
load connectors one at a time (ref.
overall wiring diagram in Appendix). If
loads are OK, If the voltage is close, try
to trim the voltage using the adjustment
on the power supply.
3) Main PCB problem. 3) If main PCB rack is suspected bad,
verify by swapping with known good
unit. If service is req’d, contact your
Distributor.
No audio. 1) Cables bad, or incorrectly
connected. 1) Check connectors on MAIN PCB.
2) Sound output set too low. 2) Adjust audio volume in OPTIONS. Ref.
GAME VOLUME or ATTRACT
VOLUME.
Distorted audio. 1) Volume set too high. 1) Adjust in OPTIONS under MAIN MENU.
Ref. GAME VOLUME or ATTRACT
VOLUME.
2) Main PCB problem. 2) Main PCB rack requires service.
3) Incorrect speaker impedance. 3) Verify 4 ohm speakers.

9
Jumpin' JackpotOperators Manual
APPENDIX A: PARTS LIST
Part Number Description
PLASTIC TUBE WITH LED ASSEMBLY
PLASTIC RING LINK
JJ215-19301-00 PCB, MAIN LOGIC
JJ215-19302-00 PCB, RGB CONTROLLER
FLOOR MAT ASSEMBLY
FLOOR MAT DECAL
POWER SUPPLY, 12VDC 350W
MANUAL, JUMPIN’ JACKPOT
TICKET DISPENSER, ENTROPY 2000
TICKET BIN W/LOW TICKET SWITCH
JJ205-19305-00
JJ290-19306-00
JJ205-19396-00
JJ240-19355-00
VG88-19340-00
JJ245-19385-00
VG82-00138-00
VG83-19327-00

10
Jumpin' JackpotOperators Manual
APPENDIX B: WIRING DIAGRAM

11
WARRANTY
Seller warrants that its printed circuit boards and parts thereon are free from defects in materials
and workmanship under normal use and service for a period of ninety (90) days from the date of
shipment. Seller warrants that its video displays (in games supplied with video displays) are free
from defects in material and workmanship under normal use and service for a period of thirty (30)
days from the date of shipment. None of the Seller’s other products or parts thereof are warranted.
Seller’s sole liability shall be, at its option, to repair, replace, or credit Buyer’s account for such
products which are returned to Seller during said warranty period, provided:
a) Seller is promptly notified in writing upon discovery by Buyer that said products are defective.
b) Such products are returned prepaid to Seller's plant; and
c) Seller's examination of said products discloses to Seller's satisfaction that such alleged defects
existed and were not caused by accident, misuse, neglect, alteration, improper repair, improper
installation, or improper testing.
In no event shall Seller be liable for loss of profits. loss of use, incidental or consequential damages.
Except for any express warranty set forth in a written contract between Seller and Buyer which
contract supersedes the terms herein, this warranty is in lieu of all other warranties expressed or
implied, including the implied warranties of merchantability and fitness for a particular purpose, and
all other obligations or liabilities on the Seller's part, and it neither assumes nor authorizes any other
person to assume for the Seller any other liabilities in connection with the sale of products by Seller.
BANDAI NAMCO Amusement America Inc. distributors are independent, being privately
owned and operated. In their judgment they may sell parts or accessories other than BANDAI
NAMCO Amusement America Inc. parts or accessories. BANDAI NAMCO Amusement America
Inc. cannot be responsible for the quality, suitability or safety of any non-BANDAI NAMCO
Amusement America Inc. part or any modification including labor that is performed by such
distributor.
SERVICE
If you have questions regarding any BANDAI NAMCO Amusement America Inc. product or require technical
support:
Contact BANDAI NAMCO Amusement America Inc. Customer Service at:
Tech: [phone] or Parts: [phone]
Parts & Service: [email protected]
FAX [phone]
Hours: 9:00 am - 5:00 pm CST
Parts and repair services for BANDAI NAMCO Amusement America Inc. products are
available through your distributor.

BANDAI NAMCO Amusement
America Inc.
712 N Central Ave Suite B
Wood Dale, IL 60191
FAX: [phone]Technical
Assistance (USA)
Main: [phone] Fax: [phone]
Reorder Number JJ245-19385-00
NOVEMBER 2019
The specifications of this machine and the instructions in this Operation Manual are
subject to change without notice for enhancement.
13
