Banner LTF User manual

LTF Time of Flight Laser Distance Sensor
Instruction Manual
Original Instructions
p/n: 194135 Rev. J
June 22, 2023
© Banner Engineering Corp. All rights reserved.




2
Contents
Contents.................................................................................................................................. 2
Chapter 1 Product Description
Models .......................................................................................................................................................................................................... 5
Overview..................................................................................................................................................................................................... 5
Features and Indicators ......................................................................................................................................................................... 6
Display ................................................................................................................................................................................................... 6
Buttons and Icons .................................................................................................................................................................................. 6
Laser Description and Safety Information .................................................................................................................................................... 7
Class 2 Laser Models ............................................................................................................................................................................ 7
Chapter 2 Sensor Installation
Mount the Device.......................................................................................................................................................................................... 9
WiringDiagrams .......................................................................................................................................................................................... 9
ConnectingtoRSD1.................................................................................................................................................................................. 10
Chapter 3 Sensor Programming
QuickMenu ............................................................................................................................................................................................... 13
LTFSensorMenu(MENU) ......................................................................................................................................................................... 14
RemoteInput ............................................................................................................................................................................................ 14
LockingandUnlockingtheSensor ........................................................................................................................................................... 16
Analog Output Menu (A_OUT) ................................................................................................................................................................... 17
TEACH 4 mA (0 V) and TEACH 20 mA (10 V) .................................................................................................................................... 17
MidpointTEACH ................................................................................................................................................................................. 19
Adjust4mA(0V) ................................................................................................................................................................................ 21
Adjust20mA(10V) ............................................................................................................................................................................ 22
Slope................................................................................................................................................................................................... 22
LossofSignal .................................................................................................................................................................................... 23
DiscreteOutputMenu(D_OUT) ................................................................................................................................................................. 24
Two-Point TEACH................................................................................................................................................................................ 24
MidpointTEACH ................................................................................................................................................................................. 26
AdjustSwitchPointOne .................................................................................................................................................................... 28
AdjustSwitchPointTwo..................................................................................................................................................................... 29
TEACHSwitchPoint........................................................................................................................................................................... 29
AdjustSwitchPoint ............................................................................................................................................................................ 30
Mode .................................................................................................................................................................................................... 30
SwitchPointReference(SPtRef)........................................................................................................................................................ 32
SwitchPointTEACHOffset ............................................................................................................................................................... 32
SwitchPointHysteresis ...................................................................................................................................................................... 32
Timer.................................................................................................................................................................................................... 34
Polarity ................................................................................................................................................................................................. 34
Input Menu (INPUT) ................................................................................................................................................................................... 34
InputType .......................................................................................................................................................................................... 35
InputActive ........................................................................................................................................................................................ 35
Measure Menu (MEASURE) ...................................................................................................................................................................... 35
Speed.................................................................................................................................................................................................. 36
Trigger................................................................................................................................................................................................. 36
Display Menu (DISPLAY)............................................................................................................................................................................ 38
Units................................................................................................................................................................................................... 39
ZeroandShift ..................................................................................................................................................................................... 39
View .................................................................................................................................................................................................... 40
Sleep.................................................................................................................................................................................................. 41
Information Menu (INFO)............................................................................................................................................................................ 41
Reset Menu (RESET)................................................................................................................................................................................. 41
Factory Default Settings ............................................................................................................................................................................. 42
Chapter 4 Sync Master/Slave ............................................................................................ 43
Chapter 5 Additional Remote TEACH Procedures
TEACHAnalogOutputandDiscreteOutputSwitchPointsTogether...................................................................................................... 45
TEACHAnalogOutputandDiscreteOutputMidpointsTogether ............................................................................................................. 46




3
Chapter 6 Specifications
Repeatability Performance ......................................................................................................................................................................... 48
Dimensions................................................................................................................................................................................................ 50
Chapter 7 Troubleshooting ................................................................................................ 51
Chapter 8 Sensor Menu Full Map........................................................................................ 53
Chapter 9 Accessories
Cordsets ..................................................................................................................................................................................................... 55
Brackets..................................................................................................................................................................................................... 56
RSD1 Remote Display................................................................................................................................................................................ 57
Chapter 10 Banner Engineering Corp Limited Warranty
..................................................................................................................................................................................................................... 59

Blank page




4

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


5
•
•
•
•
•
•
•
Chapter Contents
Models................................................................................................................................................................................................................. 5
Overview ........................................................................................................................................................................................................... 5
Laser Description and Safety Information ........................................................................................................................................................... 7

Laserdistancesensorwithbothanaloganddiscrete(switched)outputs

High-performancetimeofflightmeasurement
Extendedrangesupto24m
Reliablydetectschallengingtargets
Fastsetupwithanintuitiveinterface
WARNING:
Do not use this device for personnel protection
Using this device for personnel protection could result in serious injury or death.
This device does not include the self-checking redundant circuitry necessary to allow its use in
personnel safety applications. A device failure or malfunction can cause either an energized (on)
or de-energized (off) output condition.
Models
Family Connector
Blank = 2 m Integral Cable
Q = Rotatable M12/Euro QD
QP = PVC M12/Euro Pigtail QD
W/30 = 9 m Integral Cable
QD models require mating cordset
Q
Range
12
LTF
Laser
Class
C2
C2 = Class 2I = 4 to 20 mA analog
and (1) NPN/PNP discrete
U= 0 to 10 V analog
and (1) NPN/PNP discrete
LD = Laser diffuse
ILD
Output
Sensing
Mode
NOTE: Somemodelcombinationsmaynotbeavailable.
Overview
TheLTF Time of Flight Laser Distance Sensorisdesignedforprecise,long-distancemeasurements.A2-lineLCDshowsthe
real-time distance measurement, in either millimeters or inches,andtheanalogoutputmeasurement,inmilliampsor
volts,whenthesensorisinRunmode.
ProductDescription
Chapter 1
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


6
•
•
•
•
See Factory Defaults foralistofsensordefaultsettings.
Modelswithcurrentorvoltageanalogoutputsareavailable.This manual provides the display information and the navigation
paths for the current models with the voltage model text in parentheses if it is different.
Features and Indicators
Features
Analog Output
LED Indicator
Power
LED Indicator
Discrete Output
LED Indicator
Up and Down
Buttons
Enter Button
Escape Button
Display
ThreeLEDindicatorsprovideanongoingindicationofthe
sensing status.
AnalogOutputLEDIndicator
Solid Amber = Displayed distance is within the taught
analogoutputwindow
Off=Displayeddistanceisoutsidethetaughtanalog
outputwindow
PowerLEDIndicator
SolidGreen=Normaloperation,powerOnandlaserOn
FlashingGreen(1Hz)=PowerOnandlaserOff(laser
enablemode)
DiscreteOutputLEDIndicator
SolidAmber=DiscreteOutputisOn
Off=DiscreteOutputisOff
Display
showninRunMode
The display is a 2-line, 8-character LCD. The main screen is
the Run mode screen, which shows the real-time distance
measurementandtheanalogoutputmeasurement.
Buttons and Icons
UsethesensorbuttonsDown,Up,Enter,andEscapetoprogramthesensorandtoaccesssensorinformation.



Down and Up Buttons
PressDownandUpto:
AccesstheQuickMenufromRunmode
Navigatethemenusystems
Changeprogrammingsettings
Changeindividualdigitvaluesindistancebasedsettings
Whennavigatingthemenusystems,themenuitemsloop.
Continued on page 7
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


7
•
•
•
•
•
•
•
•
•
•
•
•
Continued from page 6


Enter Button
PressEnterto:
AccesstheSensorMenufromRunmode
Accessthesubmenus
Moverightonedigitindistancebasedsettings
Savechanges
IntheSensorMenu,acheckmark inthelowerrightcornerofthedisplayindicatesthatpressingEn-
teraccessesasubmenu.
PressEntertosavechanges.Newvaluesflashrapidlyandthesensorreturnstotheparentmenu.


Escape Button
PressEscapeto:
Leavethecurrentmenuandreturntotheparentmenu
ReturntoRunmodefromtheQuickMenu
IMPORTANT: PressingEscapediscardsanyunsavedprogrammingchanges.
IntheSensorMenu,areturnarrowintheupperleftcornerofthedisplayindicatesthatpressingEscapere-
turnstotheparentmenu.
PressandholdEscapefor2secondstoreturntoRunmodefromanymenuorremoteteach.
Alocksymboldisplaysintheupperleftcornerofthedisplaytoindicatewhenthesensorislocked.
Laser Description and Safety Information
CAUTION:
Return defective units to the manufacturer.
Use of controls or adjustments or performance of procedures other than those specified herein
mayresultinhazardousradiationexposure.
Donotattempttodisassemblethissensorforrepair.Adefectiveunitmustbereturnedtotheman-
ufacturer.
Class 2 Laser Models
CAUTION:
Never stare directly into the sensor lens.
Laserlightcandamageyoureyes.
Avoid placing any mirror-like object in the beam. Never use a mirror as a retroreflective target.
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


8
•
•
•
•
 
For Safe Laser Use - Class 2 Lasers
Donotstareatthelaser.
Donotpointthelaserataperson’seye.
Mountopenlaserbeampathseitheraboveorbeloweyelevel,where
practical.
Terminate the beam emitted by the laser product at the end of its useful
path.
Reference IEC 60825-1:2007, Section 8.2.
Class 2 Lasers
Class 2 lasers are lasers that emit visible radiation in the wavelength range from
400nmto700nm,whereeyeprotectionisnormallyaffordedbyaversionre
sponses,includingtheblinkreflex.Thisreactionmaybeexpectedtoprovideade
quate protection under reasonably foreseeable conditions of operation, including
theuseofopticalinstrumentsforintrabeamviewing.
FDA (CDRH) warning label (Class 2)
Class 2 Laser Safety Notes
Lowpowerlasersare,bydefinition,incapableofcausingeyeinjurywithinthedu
ration of a blink (aversion response) of 0.25 seconds. They also must emit only
visible wavelengths (400 to 700 nm). Therefore, an ocular hazard may exist only
if individuals overcome their natural aversion to bright light and stare directly into
thelaserbeam.
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


9
Chapter Contents
Mount the Device ................................................................................................................................................................................................ 9
WiringDiagrams................................................................................................................................................................................................. 9
ConnectingtoRSD1......................................................................................................................................................................................... 10

NOTE: Handlethesensorwithcareduringinstallationandoperation.Sensorwindowssoiledbyfinger-
prints, dust, water, oil, etc. may create stray light that may degrade the peak performance of the sensor.
Blowthewindowclearusingfiltered,compressedair,thencleanasnecessaryusing70%isopropylalco-
hol and cotton swabs or water and a soft cloth.
Mount the Device
WiringDiagrams
Analog Current Model
shield
+
12-30 V DC
D_Out
A_Out
Input
–
Load
* User-configurable PNP/NPN setting
bu (3)
bn (1)
wh (2)
bk (4)
gy (5)
Analog Voltage Model
shield
+
12-30 V DC
D_Out
A_Out
Input
–
Load
* User-configurable PNP/NPN setting
bu (3)
bn (1)
wh (2)
bk (4)
gy (5)
0-10V
Key
2
3
4
1
5
1=Brown
2=White
3=Blue
4=Black
5=Gray
SensorInstallation
Chapter 2
Ifabracketisneeded,mountthedeviceontothebracket.
1.
Mount the device (or the device and the bracket) to the machine or equipment at the desired location. Do not tighten
themountingscrewsatthistime.
2.
Checkthedevicealignment.
3.
Tightenthemountingscrewstosecurethedevice(orthedeviceandthebracket)inthealignedposition.
4.
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


10
ConnectingtoRSD1
ThefollowingdiagramdepictstheconnectionoftheLTFtotheoptionalRSD1accessory.
LTF to RSD1
MQDEC3-503SS
Double Ended Shielded
MQDEC3-506SS
MQDEC3-515SS
MQDEC3-530SS
MQDEC2-506
Flying Lead Shielded
MQDEC2-515
MQDEC2-530
RSD1
LTF
MQDEC3-503SS
Double Ended Shielded
MQDEC3-506SS
MQDEC3-515SS
MQDEC3-530SS
UsethesecordsetstoconnecttheRSD1totheLTFsensorortootherdevices,suchasPLCinputs,IO-Linkmasters,orcon-
trol systems.
5-PinMaleThreadedand5-PinFemaleQuickDisconnectM12CordsetwithShield—DoubleEnded
Model Length"L1" Style Pinout(Male) Pinout(Female)
MQDEC3-503SS 0.91m(2.99ft)
FemaleStraight/MaleStraight

1
4
5
3
2

2
3
4
1
5

MQDEC3-506SS 1.83m(6ft)
MQDEC3-515SS 4.58m(15ft)
MQDEC3-530SS 9.2m(30.2ft)
M12 x 1
14.5
ø 5.9
14.5
“L1”
47.4 47.4
M12 x 1

1=Brown
2=White
3=Blue
4=Black
5=Gray
5-PinThreadedM12CordsetswithShield—SingleEnded
Model Length Style Dimensions Pinout(Female)
MQDEC2-506 2m(6.56ft)
Straight

44 Typ.
ø 14.5
M12 x 1


2
3
4
1
5
1=Brown
2=White
3=Blue
4=Black
5=Gray
MQDEC2-515 5m(16.4ft)
MQDEC2-530 9m(29.5ft)
MQDEC2-550 15m(49.2ft)
MQDEC2-575 23m(75.44ft)
MQDEC2-5100 30.5m(100ft)
Continued on page 11
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


11
Continued from page 10
5-PinThreadedM12CordsetswithShield—SingleEnded
Model Length Style Dimensions Pinout(Female)
MQDEC2-506RA 2m(6.56ft)
Right-Angle

32 Typ.
[1.26"]
30 Typ.
[1.18"]
ø 14.5 [0.57"]
M12 x 1

MQDEC2-515RA 5m(16.4ft)
MQDEC2-530RA 9m(29.5ft)
MQDEC2-550RA 15m(49.2ft)
MQDEC2-575RA 23m(75.44ft)
MQDEC2-5100RA 31m(101.68ft)
© Banner Engineering Corp.

Blank page




12

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


13
Chapter Contents
QuickMenu ...................................................................................................................................................................................................... 13
LTFSensorMenu(MENU)................................................................................................................................................................................ 14
RemoteInput................................................................................................................................................................................................... 14
LockingandUnlockingtheSensor.................................................................................................................................................................. 16
Analog Output Menu (A_OUT) .......................................................................................................................................................................... 17
DiscreteOutputMenu(D_OUT)........................................................................................................................................................................ 24
Input Menu (INPUT) .......................................................................................................................................................................................... 34
Measure Menu (MEASURE) ............................................................................................................................................................................. 35
Display Menu (DISPLAY) .................................................................................................................................................................................. 38
Information Menu (INFO) .................................................................................................................................................................................. 41
Reset Menu (RESET)........................................................................................................................................................................................ 41
Factory Default Settings .................................................................................................................................................................................... 42

Programthesensorusingthebuttonsonthesensorortheremoteinput(limitedprogrammingoptions).
FromRunmode,usethebuttonstoaccesstheQuickMenuandtheSensorMenu.See"QuickMenu" on page
13and"LTFSensorMenu(MENU)" on page 14formoreinformationontheoptionsavailablefromeachmenu.ForTEACH
options,followtheTEACHinstructions.
In addition to programming the sensor, use the remote input to disable the buttons for security, preventing unauthorized or
accidentalprogrammingchanges.See"RemoteInput" on page 14formoreinformation.
Accessing the menus
from Run Mode
Access
Quick Menu
Access
Sensor Menu
See"QuickMenu" on page 13  See"LTFSensorMenu(MENU)" on page 14
QuickMenu
ThesensorincludesaQuickMenuwitheasyaccesstoviewandchangetheanaloganddiscreteoutputswitchpoints.Ac-
cesstheQuickMenubypressingDownorUpfromRunmode.WhenintheQuickMenu,thecurrentdistancemeasurement
displaysonthefirstlineandthemenunameandtheanalogvaluealternateonthesecondlineofthedisplay.PressEnterto
accesstheswitchpoints.PressDownandUptochangeeachdigit.PressEntertomoverightonedigit.Afterreviewingeach
digit,pressEnteragaintosavethenewvalueandreturntotheQuickMenu.PressCanceltoignoreanychangesmadeifon-
lysomedigitshavebeenchanged.
SensorProgramming
Chapter 3
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


14
Quick Menu Map (Window Mode)
Quick Menu
4mA Pt (value)
MENU
20mA Pt (value)
SPt1 Pt (value)
SPt2 Pt (value)
access Sensor
Menu (Top Menu)
Run
Mode set value with
or
Save setting
and return to
Quick Menu
Cancel and
return to
Quick Menu
LTFSensorMenu(MENU)
AccesstheSensorMenubypressingEnterfromRunmode.TheSensorMenuisalsoaccessiblefromtheQuickMenu:navi-
gatetoMENUandpressEnter.TheSensorMenuincludesseveralsubmenusthatprovideaccesstoviewandchangesen-
sorsettingsandtoviewsensorinformation.
Sensor Menu Basic Map
MENU A_OUT Access analog output settings
MENU D_OUT Access discrete output settings
MENU INPUT Select input line settings (remote TEACH, trigger mode, etc.)
MENU MEASURE Select response speed and trigger measurement
MENU DISPLAY Select display units, zero reference, shift, and orientation
MENU INFO View sensor information
MENU RESET Reset to factory defaults
Sensor Menu
Run
Mode
(See Sensor Menu Full Map for the complete map)
or
or
Go Back to Parent Menu
Select Menu Item
Press to Save Setting
Press and Hold to Go Back
to Run Mode
See"Sensor Menu Full Map" on page 53andtheMenusectionsofthismanualformoreinformation.
RemoteInput
Use the remote input to program the sensor remotely. The remove input is disabled by default. Activate remote input using
thebuttonstonavigatetotheInputTypemenuoption.
The remote input provides limited programming options and is Active Low by default. For Active Low, connect the gray input
wiretoground(0VDC),witharemoteswitchconnectedbetweenthewireandground.TousetheActiveHighfunction,con-
figure the sensor for Active High using the buttons on the sensor, then connect the gray input wire to V+ (12 to 30 V DC).
Pulsetheremoteinputaccordingtothediagramandtheinstructionsprovidedinthismanual.
ThelengthoftheindividualprogrammingpulsesisequaltothevalueT:0.04seconds≤T≤0.8seconds.
Exit remote programming modes by holding the remote input low for > 2 seconds, or waiting for the automatic 60-second
timeout,orbypressingandholdingEscapefor2seconds.ThesensorreturnstoRunmodewithoutsavinganynewsettings.
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


15
Remote Input Map
5x
6x
4x
3x
2x
1x Set Window Size to X1 , then back to Run mode
Set Window Size to X2 , then back to Run mode
Set Window Size to X3 , then back to Run mode
Set Window Size to X4 , then back to Run mode
Set Window Size to X5 , then back to Run mode
Set Window Size to X6 , then back to Run mode
1x
2x
1x
1x
2x
1x Select Slope Positive, then back to Run mode
Select Slope Negative, then back to Run mode
8x
Enter Remote TEACH RMT TCH with measurement value
Enter Remote Setup REMOTE SETUP
Teaching..(4mA) Tch4mA with measurement value, then to Tch20mA
Teaching..(20mA) Tch20mA with measurement value, then back to Run mode
1x
REMOTE TEACHREMOTE SETUP
Slope Slope value (positive or negative)
Window Size WndSize with value
Sensor Lock / Unlock Locks or Unlocks Sensor
Lock Sensor
Unlock Sensor
Reset to Default Settings Resets Sensor to Factory Default Settings
0.04 seconds < T < 0.8 seconds
Timing between Pulse groups > 1 second
Pulse Timing (T)
NOTE: Follow procedure for the TEACH/SET method
(highlighted in black box) chosen in the TEACH Selection menu.
Timeout is 60 seconds.
3x
2x Teaching.. (SPt1) TchSPt1 with measurement value, then to TchSPt2
Teaching..(SPt2) TchSPt2 with measurement value, then back to Run mode
1x
3x Teaching.. (TchA&D1) Tch4mA and TchSPt1 with measurement value, then to TchA&D2
Teaching..(TchA&D2) Tch20mA and TchSPt2 with measurement value, then
1x
4x Teaching.. (Tch12mA) Tch12mA with measurement value, then back to Run mode
5x Teaching.. (TchMdPt) TchMdPt (teaches SPt in Switch Mode) with measurement value, then
6x Teaching.. (TchA&D) Tch12mA and TchMdPt (teaches SPt in Switch Mode) with measurement
value, then back to Run mode
5x
6x
4x
3x
2x
1x Set Mode to Alarm, then back to Run mode
Set Mode to Health, then back to Run mode
Set Mode to Switch , then back to Run mode
Set Mode to Switch , then back to Run mode
Set Mode to Window , then back to Run mode
Set Mode to Window , then back to Run mode
Sensor Mode Mode with current value
2x
Run
Mode
2x
1x
4x
back to Run mode
back to Run mode
Refer to the Window size table for the acceptable values.
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


16
Remote TEACH window sizes
Variable
RemoteTEACHWindowSize(mm)
LTF12 LTF24
X1 10 10
X2 20 20
X3 100 100
X4 500 500
X5 2000 2000
X6 11950 23950
LockingandUnlockingtheSensor
Usethelockandunlockfeaturetopreventunauthorizedoraccidentalprogrammingchanges.Alocksymboldisplaysinthe
upper left corner of the display to indicate when the sensor is locked. When locked, the menus are available to view settings,
butthevaluescannotbechanged.Theremoteinputisalsodisabled,exceptfortheunlockfunction.
Button Instructions--Tolockorunlockthesensorusingthebuttons,pressandholdDownandEscapesimultaneouslyfor3
seconds.
Remote Input Instructions
Access the setup mode.
Action Result
Double-pulsetheremoteinput.

T T
T

"REMOTE SETUP"displays.
1.
Access the lock/unlock function.
Action Result
Four-pulsetheremoteinput.

T T
TTT
T T

"LOCK" and the current status (unlocked or
locked)display.
2.
Lock or unlock the sensor.
Action Result
Unlock :Single-pulsetheremoteline.

T

"Unlocked" flashes and the sensor returns to
Runmode.Thesensorisunlocked.
Lock:Double-pulsetheremoteinput.

T T
T

"Locked" flashes and the sensor returns to
Run mode. The sensor is locked and the
locksymboldisplaysintheupperleftcor-
ner.
3.
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


17
•
•
•
•
•
Analog Output Menu (A_OUT)
UsetheAnalogOutputmenutovieworchange:
4mA(0V)setpoint
20mA(10V)setpoint
12mA(5V)window
Slope
Lossofsignalbehavior
Analog Output Menu Map
MENU A_OUT
or
or
Go Back to Parent Menu
Select Menu Item
Press to Save Setting
Press and Hold to Go Back
to Run Mode
Adj20mA +12000mm
Adj4mA +00050mm
Tch4mA 50mm
Tch20mA 12000mm
Tch2Pt Tch20mA
Tch2Pt Tch4mA
WndSize +02000mm
Tch12mA 6000mm
TchMid Tch12mA
TchMid WndSize
Slope Negative
Slope Positive
LossSig 20.5 mA
LossSig Hold
LossSig 3.5 mA
A_OUT Adj4mA
A_OUT Adj20mA
A_OUT Tch2Pt
A_OUT TchMid
A_OUT Slope
A_OUT LossSig
Offset 0mm
TchMid Offset
TEACH 4 mA (0 V) and TEACH 20 mA (10 V)
TheTch4mA(Tch0V)andTch20mA(Tch10V)optionsusetargetstosetthe4mA(0V)and20mA(10V)tothedesiredset-
points. When using the buttons, only one value needs to be set if the second value is valid. When using the remote input,
bothvaluesmustbeset.
Navigate:MENU›A_OUT›Tch2Pt›Tch4mA (Tch0V)ornavigate:MENU›A_OUT›Tch2Pt›Tch20mA (Tch10V)
Remoteinput:Available
ButtonInstructions
Present the target.
Action Result
Presentthetarget.Thetargetmustbewithinthesensor'smeasurementrange. The target's analog output measurement
anddistancemeasurementvaluesdisplay.
1.
Access the TEACH mode and TEACH the sensor.
2.
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


18
Remote Input Instructions
Teaches both the 4 mA (0 V) and 20 mA (10 V) setpoints.
Action Result
Navigate:MENU›A_OUT›Tch2Pt›Tch4mA (Tch0V)
OR
Navigate:MENU›A_OUT›Tch2Pt›Tch20mA (Tch10V)
The selected TEACH mode and "Teaching"
display while the sensor is being taught.
TEACH Accepted
The new value is shown on the second line
of the display and flashes before it is saved
andthesensorreturnstotheparentmenu.
TEACH Not Accepted
"FAIL" and a warning message display, and
thesensorreturnstotheparentmenu.
Repeatsteps1to2fortheothersetpoint,ifdesired.
3.
Access the TEACH mode.
Action Result
Single-pulsetheremoteinput.

T

"RMT TCH" and the current measurement
valuedisplay.
1.
Present the target.
Action Result
Presentthe4mA(0V)target. "RMT TCH" and the target's measurement
valuedisplay.
2.
TEACHthesensor.
Action Result
Single-pulsetheremoteinput.

T

"Tch4mA (Tch0V) Teaching" displays while
the sensor is being taught.
TEACH Accepted
The new value displays on the second line
of the display, flashes, and then "Tch20mA
(Tch10V)"andthecurrentmeasurementval-
uedisplay.
TEACH Not Accepted
"FAIL" flashes, the sensor returns to step 2,
and "RMT TCH"displays.
3.
Present the target.
Action Result
Presentthe20mA(10V)target. "Tch20mA (Tch10V)"andthetarget'smea-
surementvaluedisplay.
4.
TEACHthesensor.
5.
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


19
MidpointTEACH
Window and Midpoint Example
4 mA
20 mA
12 mA
(500 mm) (700 mm)
(600 mm)
Midpoint
The Midpoint TEACH uses both the window size and the 12 mA
(5 V) setpoint to determine the actual measurement window. For
example, a window of 200 mm with a 12 mA (5 V) setpoint of 600
mm places the measurement window from 500 mm to 700 mm.
To use the Midpoint TEACH:
The Analog Output Midpoint TEACH and the Discrete Output
MidpointTEACHareindependentsettings(see"Midpoint
TEACH" on page 26).
WindowSize
TheA_OUT›TchMid›WndSizeoptionsetsthewindowsizethattheMidpointTEACHusestosetthe4mA(0V)and20mA
(10V)setpoints.
Thetaughtsurfacemustbeinsidethedefinedsensingrange,andatleastonesetpoint(withoffsetapplied,ifany)mustbelo-
catedwithinthesensingrange.
TheAnalogOutputwindowsizeisadifferentsettingthantheDiscreteOutputwindowsizewhendefinedusingthepushbut-
tons.
Parameters LTF12 LTF24
WindowSizeMinimum 10mm 10mm
WindowSizeMaximum 11950mm 23950mm
Range 50mmto12000mm 50mmto24000mm
DefaultWindowSize 2000mm 2000mm
Navigate:MENU›A_OUT›TchMid›WndSize
Remote Input:Available
Action Result
Single-pulsetheremoteinput.

T

"Tch20mA (Tch10V) Teaching" displays
while the sensor is being taught.
TEACH Accepted
The new value displays on the second line
ofthedisplay,flashes,andthesensorre-
turnstoRunmode.
TEACH Not Accepted
"FAIL" flashes, the sensor returns to step 2,
and "RMT TCH"displays.
Setthewindowsize.
1.
Setthemeasurementwindowusing"TEACH12mA(5
V)" on page 20.
2.
Access the Window Size mode.
Method Action Result
Push Button Navigate:MENU›A_OUT›TchMid›WndSize"WndSize" and the current window
sizevaluedisplay.
Continued on page 20
1.
© Banner Engineering Corp.

June 22, 2023
LTF Time Of Flight Laser Distance Sensor Instruction Manual


20
TEACH12mA(5V)
TheTch12mA(Tch5V)optionsetsthemidpointthatdeterminestheactualmeasurementwindow.
Navigate:MENU›A_OUT›TchMid›Tch12mA (Tch5V)
Remote Input:Available

Button Instructions
Continued from page 19
Method Action Result
Remote Input
a.Double-pulsetheremoteinputtoenterset-
up mode.

b.Three-pulsetheremoteinputtoenterwin-
dowsizemode.

T T
T
T T
T
T
T

a. "REMOTE SETUP" displays.

b. "WndSize" and the current window
sizevaluedisplay.
Set the window size.
Method Action Result
Push Button
a.UsetheUpandDownbuttonstosetthedesiredwindowsize—thevalue
changes in increments of 2.
b.PressEntertosavethenewvalue.
a. "WndSize" and the new value
display.

b. The new value flashes and the
sensor returns to "TchMidWnd-
Size".
Remote Input
(Sets A_OUT
and D_OUT
windowSize)
Pulse the remote input 1 to 6 times to select the desired window size.
1 pulse: 10 mm
2 pulses: 20 mm
3 pulses: 100 mm
4 pulses: 500 mm
5 pulses: 2000 mm
6 pulses: 11950 mm for the LTF12; 23950 mm for the LTF24
The new value flashes and the
sensorreturnstoRunmode.
2.
Present the target.
Ac-
tion Result
Present
the
tar-
get.
Thetarget'sanalogoutputmeasurementanddistancemeasurementvaluesdisplay.
1.
Access the TEACH 12 mA (5 V) mode and TEACH the sensor.
2.
© Banner Engineering Corp.
