Bartscher 850006 User guide

ILZF10
850006

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Service hotline: [phone]
www.bartscher.com
Version: 2.0
Date of preparation: 2023-07-28
Original instruction manual
EN

850006 3 / 6
EN
Technical Specifications
Name:
Paper towel dispenser ILZF10
Article number:
850006
Material:
chrome nickel steel, brushed
Dimensions (W x D x H), in mm:
285 x 100 x 370
Weight in kg:
1,9
We reserve the right to implement technical modifications!
Version / Characteristics
•Version: wall-mounting
•Refillable
•Filling level check: viewing slot
•Loaded via the front flap
•Suitable for standard folded paper towels
•Paper towels folded the following way:
–Interfold folding
–Layer folding
–Zig-zag folding
•Lockable
•The set includes: attachment material (four-point attachment)
•The set does not include: filling

4 / 6 850006
EN
B
List of Components of the Appliance
1. Lock
2. Front flap
3. Filling check viewing slot
4. Dispensing opening
Assembly
1. Unpack the paper towel dispenser and remove the entire packaging material.
2. Open the front flap of the paper towel dispenser
with the key included.
3. Use the fixing plate as a pattern and mark on the
wall and at the required height 4 spots for holes.
4. Bore 4 holes in the wall and put the supplied
pegs inside.
5. Use the included bolts to screw the paper towel
dispenser to the wall.

850006 5 / 6
EN
Suitable paper towels
NOTE!
When filling, pat attention to the direction of folding towels. Place them
in a way shown below.
Layer folding
Zig-zag folding
Interfold folding

6 / 6 850006
EN
Filling/dispensing paper towels
1. Open the front flap.
2. Fill the dispenser with suitable paper towels.
3. Close the front flap.
4. Use the key open the paper towel dispenser.
5. Take paper towels from the bottom dispensing
opening according to your needs.
The viewing slot in the front flap makes it possible
to check filling level.
Cleaning
ATTENTION!
Never use aggressive nor coarse cleaning agents which may scratch
the surface.
1. Use a soft, damp cloth to wipe the inside and the outside surface of the paper
towel dispenser.
2. Finally, dry the cleaned surfaces with a soft cloth.
