Batavia 7064220 User manual

Page 1
Model: BT-CRW001
Item-No.: 7064220
www.bataviapower.com
Cordless ratchet wrench
Akku-Ratschenschlüssel
clé à cliquet sans l
Accu ratelsleutel
cricchetto senza li
llave de carraca de batería
chave de roquete sem o
grzechotka akumulatorowa
Operating instructions
PACK 12 V
7064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 17064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 1 25-03-2022 10:3625-03-2022 10:36

2
.
Page 2
34
1
2
65
7064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 27064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 2 25-03-2022 10:3625-03-2022 10:36

3
.
Overview
1. Forward/ reverse rotation lever
2. Battery charge indicator
3. LED work light
4. On-off trigger
5. Battery (not included)
6. Battery Release Button
Contents
Safety Instructions . . . . . . . . . 4
Before first use . . . . . . . . . . 5
Intended use . . . . . . . . . . . 5
Operation . . . . . . . . . . . . 5
Accessories . . . . . . . . . . . 5
Maintenance and Cleaning . . . . . . 5
Technical data. . . . . . . . . . . 6
Disposal . . . . . . . . . . . . . 6
EC-Declaration of conformity . . . . . 7
Prefer a digital instead of a paper manual
or another language than English?
EN: Go to bataviapower.com or scan the QR-code. Less paper, more digital.
DE: Gehen Sie zu Bataviapower.com oder scannen Sie den QR-Code
FR: Allez sur Bataviapower.com ou scannez le code QR
NL: Ga naar Bataviapower.com of scan de QR-code
IT: Vai a Bataviapower.com o scansiona il codice QR
ES: Ir a Bataviapower.com o escanear el código QR
PT: Ir a Bataviapower.com ou digitalizar o código QR
PL: Wejdź na stronę Bataviapower.com lub zeskanuj kod QR
PL
7064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 37064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 3 25-03-2022 10:3625-03-2022 10:36

English
4
Dear customer
Please familiarize yourself with the proper
usage of the device by reading and follow-
ing each chapter of this manual, in the order
presented. Keep these operating instruc-
tions for further reference.
Please read all safety instructions!
This manual contains important informa-
tion on operating and handling the device.
Keep these operating instructions for fur-
ther reference. Please pass it on along with
the unit if it is handed over to a third party.
Battery and charger not included!
The battery is available separately under
-


These items are available online and in
participating stores.
1. Explanation of the symbols
The following symbols are used in the user

Warning! To reduce the risk of
injury, the user must read the
instruction manual.
Denotes risk of personal injury, loss
of life or damage to the tool in case
of non-observance of the
instructions in this manual.
Always wear hearing protection.
The effects of noise can cause
hearing loss.
Wear safety glasses. When working
with electric power tools, sparks,
splinters, chips and dust particles
may be generated and these can
cause loss of sight.
Wear safety gloves!.
Variable speed control.
CE stands for “Conformité
Européenne”, which means “In
accordance with EU Regulations”.
With the CE marking, the
manufacturer conrms that this
Electric tool complies with the
applicable European directives.
Do not dispose of electric power
tools with domestic refuse.
2. Machine specic safety warn-
ings for cordless ratchet wrench
• Wear hearing protection when impact
screwing. Exposure to loud noise can
lead to hearing loss.
• Secure the workpiece! A workpiece
securely held by a clamping device or
vice is much safer than one held in your
hand.
• 
can occur for brief periods while tight-
ening and loosening screws.
• Wait until the power tool has come to a
stand-till before putting it down. The
tool can jam his leading to loss of con-
trol of the power tool.
• Hold the power tool by insulated grip-
ping surfaces, when performing an
operation where the fastener may con-
tact hidden wiring. Fasteners contact-
ing a “live” wire may make exposed
metal parts of the power tool “live” and
could give the operator an electric
shock.
• 
Be sure no one is below when using the
tool in high locations.
• Wear ear protectors. Exposure to noise
can cause hearing loss.
• Check the impact socket carefully for
wear, cracks or damage before
installation.
• Keep hands away from rotating parts.
• Do not touch the ratchet head, impact
socket, bolt, nut or the workpiece imme-
diately after long time operation. They
may be extremely hot and could burn
your skin.
• 
safety glasses when working with the
machine. The use of protective clothing
is recommended, such as dust mask,
protective gloves, sturdy non-slip foot-
wear, helmet and ear defenders.
7064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 47064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 4 25-03-2022 10:3625-03-2022 10:36

5
English
• The dust produced when using this tool
may be harmful to health. Do not inhale
the dust. Wear a suitable dust protec-
tion mask.
• Do not work with any materials that


• Switch the device off immediately if the
insertion tool stalls! Do not switch the
device on again while the insertion tool
is stalled, as doing so could trigger a
sudden recoil with a high reactive force.
Determine why the insertion tool stalled
and rectify this, paying heed to the
safety instructions. The possible

it is tilted in the workpiece to be
machined
it has pierced through the material
to be machined
the power tool is overloaded
• Do not reach into the machine while it is
running.
• 
take care to avoid electric cables and
gas or waterpipes.
• Clamp your workpiece with a clamping
device. Unclamped workpieces can
cause severe injury and damage.
3. Before rst use
Remove any packing material and loose
parts from unit. Check the accessories

and your purpose. If the machine is new, the

Attention!
After long time storage, the battery capacity
will be reduce. Battery is housed in the han-
dle, press the battery retention clips, and
remove battery from handle. A substantial
drop in operating period per charge indi-
cates that the battery is worn out and must
be replaced.
4. Intended use
The ratchet wrench is intended to be used
only by adults who have read and under-
stood the instructions and warnings in this
manual, and can be considered responsible
for their actions. The product is intended for
fastening and removing screws and bolts
using an impact socket. The product is
intended for consumer use only. Do not use
the product for any other purpose. Use of
the product for operations different from
intended could result in a hazardous
situation.
5. Operation
5.1 On/Off Trigger
• Use the On/Off trigger (4) to start the
machine and keep holding it for contin-
uous operation.
• The rotation speed can be varied by
depressing the On/Off trigger. The more
the trigger is pressed, the faster the
rotation speed.
• To switch the machine off, release the
On/Off trigger
5.2 Reverse-rotation Lever
Important! The machine has to come to a
complete stop before the reverse rotation
lever can be used; otherwise the machine
may be damaged.
Use the reverse-rotation lever (1) to switch
-
wise rotation or vice-versa. With the
reverse-rotation lever in the central position
the trigger switch is locked and cannot be
depressed. Put the reverse-rotation lever in
the central position before you put the
machine down, to avoid unintentional
starting.
5.3 LED work light
The LED work light (3) will be lit automati-

trigger (4).
6. Accessories
Use only accessories with an allowable
speed matching at least the highest no-load
speed of the tool.
7. Maintenance and Cleaning
WARNING: Always disconnect from the
mains power supply, before carrying out any
maintenance/ cleaning of the charger.
Remove the battery before carrying out any
maintenance/cleaning of the tool.
7064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 57064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 5 25-03-2022 10:3625-03-2022 10:36

English
6
7.1 Maintenance
There are no inner parts of the tool which
need maintenance.
7.2 Cleaning
• Keep safety devices, ventilation open-
ings and the motor housing as free as
possible from dirt and dust. Rub the
electric power tool with a clean cloth or
blow over it with low pressure com-
pressed air.
• We recommend that you clean your
electric power tool immediately after
each use.
• Clean the electric power tool regularly
with a damp cloth and somewhat soft
soap.
Do not use any cleaning or solvent materi-
als; these can attack the device’s plastic
components. Make sure that no water can
get inside the electric power tool.
8. Technical data
Speed . . . . . . . . . . . . . . . . . -1
Chuck size . . . . . . . . . . . . 
. . . . . . . . . . . . . . . .
Weight. . . . . . . . . . . . . . . . . . 
Sound Pressure Level LpA . . . . . 
Uncertainty KpA. . . . . . . . . . . . . . .3 dB
Sound Power Level LWA . . . . . . . 
Uncertainty KWA . . . . . . . . . . . . . . 3 dB
Hand Arm Vibration . . . . . . . . 11.64 m/s2
Uncertainty K. . . . . . . . . . . . . .1.5 m/s2
8.1 Noise/Vibration information
Measured sound values determined accord-

Wear hearing protection!


The vibration emission level given in this
information sheet has been measured in
accordance with a standardized test given

one tool with another.
It may be used for a preliminary assess-
ment of exposure.
The declared vibration emission level repre-
sents the main applications of the tool.
However if the tool is used for different
applications, with different accessories or
poorly maintained, the vibration emission

the exposure level over the total working
period.
An estimation of the level of exposure to
vibration should also take into account the
times when the tool is switched off or when
it is running but not actually doing the job.

level over the total working period.
Identify additional safety measures to pro-
tect the operator from the effects of vibra-

accessories, keep the hands warm, organi-
sation of work patterns.

 
 
time.
9. Disposal
Do not dispose of electric power
tools with domestic refuse.
The electric power tool is shipped in
packaging to reduce transport damage.
This packaging is a raw material and as
such can either be reused or can be fed
back into the raw material cycle. The elec-
tric power tool and its accessories are
made from various materials such as met-
als and plastics. Take defective compo-
nents to a special refuse collection point.
Ask about these at your specialist shop or
local council. The product and the user
manual may be subject to changes. Techni-
cal data may be changed without prior
notice.
9.1 Batteries
Think of the environment when disposing of
batteries. Contact your local authorities to

Do not dispose of batteries with domestic
refuse.
Do not dispose of by burning, risk of
explosion.
7064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 67064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 6 25-03-2022 10:3625-03-2022 10:36

7
English
10. EC-Declaration of conformity
We, the Batavia B.V., Weth. Wassebali-
estraat 6d, NL-7951 SN Staphorst, declare
by our own responsibility that the product
Cordless Ratchet Wrench, Model
BT-CRW001, Item-No 7064220 is accord-

-
magnetic Compatibility 2014/30/EU
2006/42/EC2011/65/EU

evaluation of conformity, the following har-

EN62841-1:2015
EN62841-2-2:2014
AfPS GS 2019:01 PAK
EK9-BE-91(V4):2020
EN55014-1:2017
EN55014-2:2015

Meino Seinen, QA Representative Batavia


The product and the user manual may be
subject to changes. Technical data may be
changed without prior notice.
7064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 77064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 7 25-03-2022 10:3625-03-2022 10:36

Model: BT-CRW001
Item-No.: 7064220
www.bataviapower.com
[email protected]
2YEARWARRANTY
This product has got a 2 year warranty
Dear Client, if for any reason this product is not working, please ensure you contact our Client Service Centre. Ensure you have your original
receipt of purchase. This warranty covers all defects in workmanship or materials in this Batavia product for a two year period from the date
of purchase. The warranty does not cover any malfunction, or defect resulting from misuse, neglect, alteration, or repair.
Dieses Produkt hat 2 Jahre Garantie
Sehr geehrter Kunde, unsere Produkte unterliegen einer strengen Qualitätskontrolle. Sollte dieses Gerät nicht einwandfrei sein, so
wenden Sie sich bitte immer zuerst an unseren Kunden-Service. Bitte bewahren Sie unbedingt den Kaufbeleg auf. Die Garantieleistung
             
unsachgemäßer Behandlung oder Gewalteinwirkung verursacht worden sind.
Ce produit a 2 ans de garantie
  Centre de service après-vente.
Conservez le bon d’achat original. Cette garantie couvre tous les défauts de matériau et de main d’oeuvre constatés sur ce produit
Batavia pendant une période de deux ans à compter de la date d’achat. Les défauts de fonctionnement et autres résultant d’abus ou
de mauvais emploi, de négligence, de modifications ou réparations non autorisées sont exclus de la garantie.
Dit product heeft 2 jaar garantie
Geachte klant, onze producten ondergaan een streng kwaliteitscontrole proces. Wanneer dit product niet correct functioneert, wend u zich
alstublieft altijd eerst tot onze klantenservice. Bewaar altijd uw aankoopbewijs. De garantieservice is alleen van toepassing op materiaal- of
productiefouten. Uitgesloten zijn gebreken veroorzaakt door intensief gebruik, misbruik en incorrecte behandeling of extern geweld.
Questo prodotto è garantito per 2 anni
                   
Centro Assistenza Clienti


Este producto tiene dos años de garantía
                      .
Asegúrese de tener a mano la factura de compra original. Esta garantía cubre todos los defectos de mano de obra o materiales
de este producto de Batavia por un período de dos años a partir de la fecha de compra. La garantía no cubre ningún mal

Este produto tem uma garantia de 2 anos
               
Centro de Apoio ao Cliente


Produkt posiada 2-letnią gwarancję.
             
naszym           



Deutschland – Kundenservice
01805 937 832*
Other European countries – Customer Services /
Autres pays d’Europe – Service clientèle /
Overige landen Europa – Klantenservice
 /
 / 
00800 664 774 00
BATAVIA B.V. | Weth. Wassebaliestraat 6d | 7951SN Staphorst | Netherlands
7064220/2 EN ONLY


WARRANTY
2 YEARS
7064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 87064220-Cordless_Ratchet-wrench-Ma-EN-2203-11.indb 8 25-03-2022 10:3625-03-2022 10:36
